Data and Instrumentation YOUR ENERGY, OUR SYSTEMS, ANYWHERE… 2008

DATA ANDINSTRUMENTATION PRYSMIAN – TECHNICAL MANUALS COMMUNICATION CONSTRUCTION DATA & INSTRUMENTATION FIBRE TO THE PREMISES FIRE PERFORMANCE FLEXIBLE CABLES MEDIUM VOLTAGE MINING & INDUSTRIAL OVERHEAD CONDUCTORS

01 CONTENTS Page No. INTRODUCTION 02 CABLE USAGE CHARACTERISTICS 03 INFORM@X ® CABLES P20 and P21 Data 04 P31 Flexible 08 P50 – P56 Information 10 General Information 14

02 INTRODUCTION Prysmian Cables & Systems is well placed to meet the future demands of information transfer being one of the world’s leadingmanufacturers of data and instrumentation cables. The INFORM@X ® range of data and instrumentation cables include multicore and multipair configurations to suit specific applications and environments. P20 TYPE DATA CABLES A range of 24 AWG cables having pairs with flexible conductors, colour coded insulation and overall screening, used in datatransmission, where interconnecting cables of small size and low capacitance are required with minimum signal distortion andgood crosstalk attenuation. P20 cables are suitable for use with both analogue and digital systems operating at highmodulation rates over long distances.P20 cables are recommended for use as balanced interface cables connecting Data Terminal Equipment and DataCommunication Equipment in systems complying with EIA Standard RS485, RS422 and RS449 data transmission. P21 TYPE DATA CABLES An alternative range of 24 AWG cables comprising a number of single wires of flexible conductors, colour coded insulation andoverall screening. Typical use for these inter-connecting cables is in data systems which require cables of small size and lowcost, operating over short distances at low modulation rates, in an unbalanced mode. They are recommended for use asinterface cables connecting Data Terminal Equipment and Data Communication Equipment in systems complying with EIAStandard RS423, RS232C and 4-20 mA loop circuits. P31 TYPE DATA CABLES A range of 20 AWG cables comprising a number of finely stranded single wires, with colour coded insulation and a flexibleoverall braid screen. These cables are designed for connecting equipment in environments of frequent movement or vibration. P50-P56 TYPE INSTRUMENTATION CABLES The P50-P56 range is a particular group of pair or triple (0.5 mm ² or 1.5 mm²) cables with numbered cores for the interconnection of electrical instruments and control equipment in industry and processing plants.Typical uses are for interconnecting: • Electrical measuring devices to instrument panel• Instrument to instrument• Field bus RS485 and RS422 data links• Electrical sensing devices• Control cabinets to supervisory consoles and panels• Remote auxiliary contacts to supervisory indicators• Telemeters to recorders and annunciators and for general transmission of electrical signals in any systems of remote control, indication, telemetering, monitoring and analysis where a rugged communication type cable is required • Resistance Temperature Detectors (RTD) Typical wiring systems will use multipair cables to connect control room equipment to junction panels in field junction boxes.Single pair cables are used to connect junction panels to field devices. P50-P55 cables are suitable for use in those areas whereit is necessary to provide protection from: • Interference to the transmission signal by other electrical circuits• Physical damage to the cable by including in the designs various screens and armours• Intrinsically safe designed cables are coloured blue for easy identification ALTERNATE SUPPLY The tables on the following pages list the most commonly required data and instrumentation cables. Cable configurations notlisted can also be supplied. These include: • Alternative core or element combinations• Cables finished with a nylon jacket as a protective barrier against termite or ant attack• Steel wire armoured versions OTHER CABLES IN THE PRYSMIAN CABLES & SYSTEMS RANGE Prysmian Cables & Systems can supply a total cable solution for the industrial environment, from our extensive range of energycables to indoor and outdoor LAN cables, plus a full range of optical fibre cables for both indoor and outdoor use. INFORM@X ® INFORM@X ® is a registered trademark ® of Prysmian Cables & Systems.

03 AMBIENT TEMPERATURE MINIMUM BENDING RADIUS MECHANICAL IMPACT RESISTANCE RESISTANCE TO SOLAR RADIATION AND WEATHER RESISTANCE TO WATER CHEMICAL RESISTANCE BEHAVIOUR IN FLAME AND FIRE  LOW SMOKE EMISSION FLEXIBILITY HALOGEN FREE CABLE USAGE CHARACTERISTICS LAYING CONDITIONS Maximum operating temperatureMinimum operating temperature Minimum bending radius of installed cables 1 Light impact2 Moderate impact3 Heavy impact4 Very heavy impact Excellent Permanent Very good Frequent Good Occasional Acceptable Accidental Poor None Negligible No humidity Water drops Occasional condensation Spray Water run off Splashes Exposed to water splashes Heavy sea Exposed to waves Immersion Temporarily covered by water Submersion Permanently covered by water Excellent Permanent Very good Frequent Good Occasional Acceptable Accidental Poor None Reaction To Fire Resistant To Fire C1 Fire retardant Level 1 – Ultimate fire survival C2 Flame retardant Level 2 – Two hours fire survival C3 No fire performance Level 3 – Restrained spread  & self extinguishing AS/NZS 4507 Rigid Flexible Semi-rigid Very flexible AS/NZS 4507 In accordance with research, new material developments and changes inrelevant standards, published details may change without notice. MINIMUM INSTALLATION TEMPERATURE IN  GROUND IN  DUCT DOMESTIC APPLIANCES MACHINES MOBILE  EQUIPEMENT SUBMERGED OVERHEAD AERIAL IN  CONDUIT OUTDOOR APPLIANCES FESTOON INTERNAL WIRING INDUSTRIAL EQUIPEMENT EXTERNAL  BUILDING IN  FREE AIR IN TRENCH IN GROUND WITH PROTECTION MINIMUM BENDING RADIUS DURING INSTALLATION

04 Flexible Fixed 8D Level 1 Spray Good C2 +70°C Good OD≤25 6D OD 25 9D LIGHT  EQUIPMENT INDUSTRIALEQUIPMENT IN FREE AIR MACHINES MOBILE EQUIPMENT FESTOON DATA CABLE P20 CABLES ARE UL RECOGNISED TOSTYLE 2493, P21 CABLES ARE ULRECOGNISED TO STYLE 2464 INFORM@X ® P20 & P21  CONDUCTOR:Tinned copper wire (7/0.2 mm - 24 AWG)  INSULATION:P20 - Polyolefin UL Style 1589 or P21 - Polyolefin UL Style 1729 SCREEN:Aluminium/Polyester tape with a 7/0.2 mm tinned copper drain wire SHEATH:PVCColours: Grey APPROVALS:AS/ACIF S008 (previously known as ACA TS-008) UL recognised toStyle 2493 (P20) or 2464 (P21) CABLE DESIGN INFORM@X ® P20 cables are low capacitance cables for extended distance balanced pair operation (RS422/RS485). They are usedextensively in PLC environments and also for connecting computerperipheral equipment such as printers and modems. Due to the greaternoise immunity of twisted pairs, P20s are able to carry higher dataspeeds than multi-conductor cables. They are available with collective(CS) or element and collective (ESCS) screening.INFORM@X ® P21 cables are overall screened (CS) multicores for use in limited distance unbalanced mode. They are used in serial datatransmission such as RS232 and 4-20 mA loop circuits. Other cable configurations not shown in the table are available.These cables are not to be regarded as power cables for the directconnection of equipment to mains power supplies INSTALLATION CONDITIONS CABLE CHARACTERISTICS

Product Code Pairs CS Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km ESCS CS ESCS CS ESCS CS ESCS P2001 (CS or ESCS) 1 5.0 - 40 - 34 - 32 - P2002 (CS or ESCS) 2 6.1 6.7 49 54 68 68 45 57 P2003 (CS or ESCS) 3 6.9 7.6 56 61 102 102 53 70 P2004 (CS or ESCS) 4 7.5 8.3 60 67 135 135 63 80 P2006 (CS or ESCS) 6 9.5 10.6 76 85 203 203 92 125 P2008 (CS or ESCS) 8 10.0 10.6 80 85 271 271 108 140 P2012 (CS or ESCS) 12 10.9 12.3 88 99 406 406 135 182 P2018 (CS or ESCS) 18 12.7 - 102 - 609 - 187 - P2025 (CS or ESCS) 25 15.3 - 123 - 846 - 266 - P2036 (CS or ESCS) 36 17.6 - 141 - 1219 - 356 - P2050 (CS or ESCS) 50 20.2 - 162 - 1692 - 450 - P20 DATA – OVERALL (CS) OR ELEMENT & OVERALL SCREEN (ESCS) P20 DATA – COLOUR CHART INFORM@X ®  – DATA CABLES P20 CABLES ARE UL RECOGNISED TO STYLE 2493  P20-P21 P21 CABLES ARE UL RECOGNISED TO STYLE 2464 Core 1 Core 2 Pair  No. Colour Core 1 Core 2 Pair  No. Colour Core 1 Core 2 Pair  No. Colour Core 1 Core 2 Pair  No. Colour Core 1 Core 2 Pair  No. Colour 1 White Blue 6 Red Blue 11 Black Blue 16 Yellow Blue 21 Violet Blue 2 White Orange 7 Red Orange 12 Black Orange 17 Yellow Orange 22 Violet Orange 3 White Green 8 Red Green 13 Black Green 18 Yellow Green 23 Violet Green 4 White Brown 9 Red Brown 14 Black Brown 19 Yellow Brown 24 Violet Brown 5 White Grey 10 Red Grey 15 Black Grey 20 Yellow Grey 25 Violet Grey 05

Product Code Cores Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km P2104CS 4 4.5 36 68 28 P2106CS 6 5.2 42 102 40 P2108CS 8 6.1 49 135 50 P2112CS 12 6.6 53 203 65 P2118CS 18 7.5 60 305 87 P2124CS 24 8.8 71 406 110 P2136CS 36 9.9 80 609 148 P2150CS 50 11.7 94 846 212 P21 DATA – OVERALL SCREEN (CS) P21 DATA – COLOUR CHART INFORM@X ®  – DATA CABLES P20 CABLES ARE UL RECOGNISED TO STYLE 2493  P20-P21 P21 CABLES ARE UL RECOGNISED TO STYLE 2464 Core No. Colour Core No. Colour Core No. Colour Core No. Colour Core No. Colour 1 Red 11 Turquoise 21 Blue/Black 31 White/Brown 41 Yellow/Black 2 Blue 12 Grey 22 Orange/Blue 32 Brown/Black 42 Grey/Orange 3 Green 13 Red/Blue 23 Green/Blue 33 Grey/Brown 43 Grey/Red 4 Yellow 14 Red/Green 24 Grey/Blue 34 Yellow/Violet 44 Grey/Black 5 White 15 Yellow/Red 25 Yellow/Green 35 Violet/Black 45 Orange/Brown 6 Black 16 White/Red 26 White/Green 36 White/Violet 46 Orange/Black 7 Brown 17 Red/Black 27 Green/Black 37 White/Orange 47 Green/Brown 8 Violet 18 Red/Brown 28 Orange/Green 38 White/Grey 48 Blue/Brown 9 Orange 19 Yellow/Blue 29 Grey/Green 39 White/Black 49 Pink/Blue 10 Pink 20 White/Blue 30 Yellow/Brown 40 Yellow/Grey 50 Pink/Orange 06

P20 CS, P20 ESCS, P21 CS DATA – ELECTRICAL CHARACTERISTICS INFORM@X ®  – DATA CABLES P20 CABLES ARE UL RECOGNISED TO STYLE 2493  P20-P21 P21 CABLES ARE UL RECOGNISED TO STYLE 2464 Cable Type P20 CS P20 ESCS P21 CS Conductor Size mm 7/0.2 7/0.2 7/0.2 Conductor Resistance ohms/100m at 20°C 8.9 8.9 8.9 Maximum Working Voltage V rms 300 300 300 Capacitance Between Wire Pairs pF/m 50 65 - Capacitance Between Adjacent Wires pF/m - - 90 Capacitance Between Each Wire to All Others Bunched Together pF/m 95 110 145 Cross-talk Between Pairs:  at 1 kHz dB/100m 90 100 - at 100 kHz dB/100m 50 80 - Characteristic Impedance at 100 kHz ohms 135 115 - Attenuation of a Pair: at 1 kHz dB/100m 0.15 0.20 - at 10 kHz dB/100m 0.42 0.50 - at 100 kHz dB/100m 0.80 1.0 - at 150 kHz dB/100m 0.90 1.3 - at 1 MHz dB/100m 1.9 3.6 - at 1.5 MHz dB/100m 2.4 4.6 - 07

08 FLEXIBLE DATA CABLE P31 CABLES ARE UL RECOGNISED TO STYLE 2464 INFORM@X ® P31 CONDUCTOR:Tinned copper wire (16/0.2 mm - 20 AWG)  INSULATION:PVC-UL Style 1729 SCREEN:Tinned copper wire braid, with greater than 87% coverage SHEATH:PVCColour: Black APPROVALS:AS/ACIF S008 (previously known as ACA TS-008) and UL Style 2464 CABLE DESIGN INFORM@X ® P31 cables are designed to be used for the connection of electronic equipment and instruments whereflexibility is important. This could be in areas of direct movementsuch as limit sensors, or in areas subject to vibration. INSTALLATION CONDITIONS CABLE CHARACTERISTICS Flexible Fixed 8D Medium Industrial Spray Good Flame  Retardant +75°C Good OD≤25 6D OD 25 9D LIGHT  EQUIPMENT INDUSTRIALEQUIPMENT IN FREE AIR MACHINES MOBILE EQUIPMENT FESTOON Other cable configurations not shown in the table are available.These cables are not to be regarded as power cables for the directconnection of equipment to mains power supplies

P31 FLEXIBLE DATA – OVERALL SCREEN (CS) INFORM@X ®  – DATA CABLES P31 CABLES ARE UL RECOGNISED TO STYLE 2464 P31 09 Product Code Cores Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km P3102CS 2 5.6 45 77 45 P3103CS 3 5.8 47 116 53 P3104CS 4 6.2 50 155 63 P3106CS 6 7.3 59 232 86 P3110CS 10 9.1 73 387 123 P3112CS 12 9.3 75 464 128 P3118CS 18 10.7 86 696 194 P3125CS 25 12.6 101 967 273 P3136CS 36 14.0 112 1393 384 P31 DATA – COLOUR CHART Core No. Colour Core No. Colour Core No. Colour Core No. Colour 1 Red 10 Pink 19 Yellow/Blue 28 Orange/Green 2 Blue 11 Turquoise 20 White/Blue 29 Grey/Green 3 Green 12 Grey 21 Blue/Black 30 Yellow/Brown 4 Yellow 13 Red/Blue 22 Orange/Blue 31 White/Brown 5 White 14 Red/Green 23 Green/Blue 32 Brown/Black 6 Black 15 Yellow/Red 24 Grey/Blue 33 Grey/Brown 7 Brown 16 White/Red 25 Yellow/Green 34 Yellow/Violet 8 Violet 17 Red/Black 26 White/Green 35 Violet/Black 9 Orange 18 Red/Brown 27 Green/Black 36 White/Violet P31 DATA – ELECTRICAL CHARACTERISTICS Cable Type P31 Conductor Size mm 16/0.2 Conductor Resistance ohms/100m at 20°C 3.7 Maximum Working Voltage V rms 300

10 INSTRUMENTATIONCABLE P50-P56 CABLES ARE INTRINSICALLY SAFEELECTRICALLY TO AS 2380.7 & AS 2381.7 INFORM@X ® P50 - P56 CONDUCTOR:Plain copper wireP50 / P53 - 0.5 mm ² 20 AWG (7/0.3 mm) P51 / P55 / P56 - 1.5 mm ² 16 AWG (7/0.5 mm) INSULATION:V90-HT PVCColours: Triples - Black, White, Red numbered cores Pairs - Black and White numbered cores SCREEN:Aluminium/Polyester tape with a 7/0.2 mm tinned copper drain wire SHEATH:V90-HT PVCColours: Black. Blue on request ARMOUR (Optional):Galvanised mild steel wire. (Add SWA to the product code) COMMUNICATION WIRE (Optional):A 7/0.25mm central communication wire APPROVALS:AS/ACIF S008 (previously known as ACA TS-008)These cables are not to be regarded as power cables, for the directconnection of equipment to mains power supplies CABLE DESIGN The INFORM@X ® P50 range of instrumentation cables are a balanced pair design for the interconnecting of monitoring andcontrol systems. Typical uses includeelectrical sensing devices, fieldbus RS 485 and RS 422 data links, control cabinets to supervisoryconsoles, electrical measuring devices and many other supervisoryapplications. Flexible 6D Level 1 Spray Good C2 +75°C Good IN FREE AIR FESTOON INDUSTRIALEQUIPMENT MACHINES LIGHT  EQUIPMENT MOBILE EQUIPMENT INSTALLATION CONDITIONS CABLE CHARACTERISTICS

P50 INSTRUMENTATION – OVERALL SCREEN (CS) INFORM@X ®  – INSTRUMENTATION CABLES  P50 CABLES ARE INTRINSICALLY SAFE P50-P56 ELECTRICALLY TO AS 2380.7 AND AS 2381.7 11 Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5001CS 1 5.8 - 35 - 70 - 41 P5002CS 2 7.0 12.4 42 149 140 1390 60 320 P5004CS 4 9.9 15.1 60 182 280 2060 120 455 P5006CS 6 11.5 16.7 69 201 420 2520 160 545 P5008CS 8 12.9 18.1 78 218 560 2950 200 625 P5010CS 10 14.1 19.3 85 232 700 3360 240 700 P5012CS 12 15.8 21.1 95 254 840 4010 300 800 P5016CS 16 17.7 23.7 107 285 1120 5060 380 1075 P5020CS 20 20.2 26.2 122 315 1400 6180 460 1235 P5024CS 24 21.8 27.8 131 334 1680 6960 535 1370 P5036CS 36 26.5 32.4 159 389 2520 9450 790 1765 P5050CS 50 30.5 37.6 183 452 3500 12730 1045 2450 P50 INSTRUMENTATION – ELEMENT AND OVERALL SCREEN (ESCS) Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5002ESCS 2 7.7 13.1 47 158 140 1550 80 360 P5004ESCS 4 10.8 16.0 65 192 280 2310 150 510 P5006ESCS 6 12.7 17.9 77 215 420 2890 205 620 P5008ESCS 8 14.2 19.4 86 233 560 3390 260 720 P5010ESCS 10 16.2 21.5 98 258 700 4170 330 850 P5012ESCS 12 17.5 23.5 105 282 840 4980 385 1065 P5016ESCS 16 19.6 25.6 118 308 1120 5900 490 1250 P5020ESCS 20 21.6 27.6 130 332 1400 6860 590 1430 P5024ESCS 24 23.9 29.8 144 358 1680 8000 720 1620 P5036ESCS 36 28.4 35.2 171 423 2520 11160 1030 2310 P5050ESCS 50 32.9 40.0 198 480 3500 14400 1375 2900 P51 INSTRUMENTATION – OVERALL SCREEN (ES) Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5102ES 1 Pair 7.0 12.4 42 149 210 1390 65 325 P5103ES 1 Triple 7.4 12.8 45 154 315 1480 85 355

12 Product Code Triples Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5304CS 4 11.5 16.7 69 201 420 2520 160 545 P5306CS 6 13.5 18.7 81 225 630 3150 220 660 P5312CS 12 18.6 24.6 112 296 1260 5450 415 1140 P5316CS 16 21.0 27.0 126 324 1680 6570 530 1330 P5336CS 36 31.6 38.7 190 465 3780 13480 1120 2585 P53 INSTRUMENTATION – OVERALL SCREEN (CS) Product Code Triples Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5304ESCS 4 12.7 18.0 77 216 420 2920 200 620 P5306ESCS 6 15.6 20.9 94 251 630 3940 295 790 P5308ESCS 8 17.5 23.5 105 282 840 4980 370 1050 P5312ESCS 12 20.8 26.8 125 322 1260 6470 520 1320 P5316ESCS 16 24.0 29.9 144 359 1680 8050 695 1590 P5336ESCS 36 34.2 41.3 206 496 3780 15360 1410 2970 P53 INSTRUMENTATION – ELEMENT AND OVERALL SCREEN (ESCS) INFORM@X ®  – INSTRUMENTATION CABLES   P50 CABLES ARE INTRINSICALLY SAFE P50-P56  ELECTRICALLY TO AS 2380.7 AND AS 2381.7 Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5502CS 2 9.3 14.5 56 174 420 1900 120 440 P5504CS 4 12.1 17.3 73 208 840 2700 210 610 P5506CS 6 14.3 19.5 86 234 1260 3430 290 750 P5508CS 8 16.7 22.0 101 264 1680 4360 390 920 P5510CS 10 18.3 24.3 110 292 2100 5320 470 1190 P5512CS 12 19.7 25.7 119 309 2520 5950 550 1310 P55 INSTRUMENTATION – OVERALL SCREEN (CS)

13 INFORM@X ®  – INSTRUMENTATION CABLES   P50 CABLES ARE INTRINSICALLY SAFE P50-P56 ELECTRICALLY TO AS 2380.7 AND AS 2381.7 Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5502ESCS 2 10.2 15.4 62 185 420 2140 140 490 P5504ESCS 4 13.3 18.5 80 222 840 3090 245 680 P5506ESCS 6 16.3 21.6 98 260 1260 4200 360 890 P5508ESCS 8 18.4 24.4 111 293 1680 5360 460 1180 P5510ESCS 10 20.2 26.2 122 315 2100 6180 560 1340 P5512ESCS 12 21.8 27.8 131 334 2520 6960 655 1495 P55 INSTRUMENTATION – ELEMENT AND OVERALL SCREEN (ESCS) Product Code Pairs Plain Nominal O.D. mm Min. Bending Radius mm Max. Pulling Tension N Approx. Mass kg/km SWA Plain SWA Plain SWA Plain SWA P5604 (CS or ESCS) 4 14.3 16.3 86 98 1260 1260 290 350 P5606 (CS or ESCS) 6 17.5 19.3 105 116 1890 1890 430 490 P5612 (CS or ESCS) 12 23.9 26.4 144 159 3780 3780 815 930 P56 INSTRUMENTATION – OVERALL (CS) OR ELEMENT AND OVERALL SCREEN (ESCS) P31 DATA – ELECTRICAL CHARACTERISTICS Cable Type Units P50 CS P50 ESCS P51 ES P53 CS P53 ESCS P55 CS P55 ESCS P56 CS Conductor Size mm ² 0.5 0.5 1.5 0.5 0.5 1.5 1.5 1.5 Conductor Resistance at 20ºC ohms/100m 3.8 3.8 1.3 3.8 3.8 1.3 1.3 1.3 Insulation Resistance at 20ºC mohms/km 140 140 150 140 140 150 150 150 Max Continuous Current Rating A 3.2 3.2 12 3.2 3.2 12 12 12 Max D.C. Voltage Withstand kV 3 3 3 3 3 3 3 3 Capacitance of pairs pF/m 80 145 200 - - 110 200 - Capacitance Unbalanced between pairs pF/100m 300 30 - - - 300 30 - Conductor to Screen Capacitance pF/m - 240 - - - - 300 - Attenuation Between pairs at 1kHz dB/100m 90 120 - - - 90 - - Character Impedance at 1kHz ohms 380 300 200 - - 200 150 - Inductance at 1kHz mH/km 0.9 0.9 0.8 - - 0.8 0.8 - L/R Ratio ohms 13 13 31 - - 31 31 - Loop Resistance at 20ºC ohms 67.5 67.5 26.5 67.5 67.5 26.5 26.5 26.5

14 GENERAL INFORMATION ElementAn element consists of a pair (or triple) formed by twisting the wires together. Elements are twisted with different twist lengths toreduce interference between them. Cable coreThe cable core is formed by assembling the required number of wires or elements together. Screened element (ES)The twisted element is wrapped with aluminium/polyester laminate as a tape with the bare tinned copper wire laid in contact withthe aluminium side of the tape. A further layer of polyester tape is applied over the core. Screened core (CS)The aluminium/polyester laminate is applied as a screen over the core in lieu of plain tape with the bare tinned copper drain wirelaid in contact with the aluminium side of the tape. Armour (SWA)A further protective covering can be provided by the application of galvanised steel wires and a PVC oversheath. SheathThe wrapped core is sheathed with PVC.

Loose Tube Optical Cable for Direct Burial Horizontal Distribution/Riser Rated Optical Cable Internal Telephone Cable Customer Premises Lead-in Cable Distribution Network Jelly Filled Telephone Cable Aerial Self-Supporting Unfilled  Telephone Cable Underground Telephone Cable with  Moisture Barrier Screen  Multi-Core Data/Supervisory Cable Multi-Pair Data/Supervisory Cable Instrumentation Cable with Collective Screen Instrumentation Cable with Individual and Collective Screens Instrumentation Cable with Collective Screens and Steel Wire Armour Single Pair Instrumentation Cable Single Triple Instrumentation Cable UTP LAN Cable Datacom Cables w e ’ v e   g o t   t h e   r a n g e   c o v e r e d

16 NOTES

17 Whilst every care has been taken in the preparation of this publication, Prysmian Cables & Systems takesno responsibility for any errors and/or omissions. This technical manual is intended as a guide only andreference must be made by any person using this information to the appropriate Australian Standardand/or to local Electricity Supply Authority rulings. Copyright © Prysmian Cables & Systems (ABN 36 096 594 080) 2008. All rights reserved. Subject to change without notice. ABN 36 096 594 080 1 Heathcote Road Liverpool NSW 2170 Tel 1300 300 304 Fax 1300 300 307 [email protected] www.prysmian.com.au ISO 9001 Lic QEC 20164 SAI Global ™
