Crompton Lighting LED Downlights Catalogue

Crompton Lighting's range of LED downlights from their latest catalogue.

Downlights XL-LED Performance Downlight Kits 9XL-LED MAX Performance Downlight Kits 12XL-LED MAX 'Sunset Dim' Kit 14XL-LED ECO Performance Centre Tilt Kits 16XL-LED ECO II Performance Downlight Kits 19XL-LED Performance Diffused Downlight Kits 20XL-LED Recessed Fixed Downlight 24XL-LED Performance Surface Mounted Downlight Kit 25XL-LED Performance GU10 Downlight Kits 26XL-LED PROFESSIONAL Downlights 27XL-LED Performance Downlights 32XL-LED Performance Mini Cabinet Light Kit 35XL-LED Performance Barlight Kits 36

D o w nli g hts 9 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 The Crompton XL-LED Performance lamp and driver combination was designed in Australia specifically to meet Australian conditions. The latest generation of the Crompton XL-LED, XL-LED ECO and XL-LED MAX utilize ‘Binless’ LED chip technology, which means that designers and installers no longer have to worry about colour instability, colour matching is now standard across the three premium levels of Crompton LED downlights. The LED Technology XL-LED Downlights

D o w nli g hts 10 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 XL-LED Performance Downlight Kits Features & Benefits Custom Designed Inner Locking Ring Allows the PERFORMANCE LED lamp housing to be secured on a tilt ensuring a safe installation. The ring also prevents the fitting from being retrofitted with a standard MR16 halogen lamp. This is a significant advantage for use in buildings seeking a full Energy Star Rating. Thermal Wind Back The XL-LED specially designed driver incorporates a Thermal Wind Back System. The driver monitors the LED case temperature and automatically reduces the power to protect the lifetime of the LED. Should the maximum surface temperature reach 90°C, the fitting will start to “wind back” the LED, resulting in automatic dimming in small increments rather than completely shutting down the LED light source. Solid State Lighting Luminaire Lighting Council of Australia launched their SSL (Solid State Lighting) quality scheme in 2010 to assist the market with identifying LED products which meet guaranteed performance criteria, accredited to strict test parameters. The Crompton XL-LED was one of the first fittings registered under the SSL Quality Scheme. Fully Dimmable The LED Controller can be used on a dimmer switch or dimming circuit of either leading or trailing edge. Light Output The light output is similar to most wide beam FNV MR16 halogen lamp with a 55° beam spread, and has energy saving of up to 70% when compared to a standard MR16 50W halogen lamp. Australian Design Designed in Australia for Australian conditions - patent pending and registered design. C-Bus Crompton XL-LED Downlights are C-Bus compatible. Warranty Register Customers can have confidence in the XL-LED Warranty by registering the details for each installation with Crompton.

D o w nli g hts 11 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 REFERENCE COLOUR DOWNLIGHT CODE 3000K KLED12FW White Fixed 26274 KLED12FSC Satin Chrome Fixed 26275 KLED12AW White Gimbal 26272 KLED12ASC Satin Chrome Gimbal 26273 4000K KLED12FW4K White Fixed 26497 KLED12FSC4K Satin Chrome Fixed 26498 KLED12AW4K White Gimbal 26495 KLED12ASC4K Satin Chrome Gimbal 26496 100 40 Cut-out: 90mm 86 45 o GIMBAL DOWNLIGHT FIXED DOWNLIGHT ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 100mA Power Factor 0.95 undimmed Total Input Power 16W maximum Secondary Output Voltage 12V - 24V DC Secondary Output Current 650mA regulated Lamp Power 12W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Aluminium Attachment Clip Steel Lens Retaining Clip Steel, chrome plated Lens Polycarbonate Controller Base & Cover Polycarbonate Terminal Clamp Moulding Polycarbonate Electronic Components & PCB’s RoHS compliant with Pb-free solder THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Colour Temperature 3000K 4000K Luminous Flux 700 lumens 800 lumens CRI 85 85 Beam Angle 55 o 55 o DIMENSIONS / WEIGHT / LIFE Downlight 150g Controller 165(W)x44(D)x37(H) mm, 185g LED Lamp Life 50,000HR Controller Life 50,000HR Cut-out: 70mm 82 35 86 XL-LED Performance Kit contents: ▪ 1 x 12W LED lamp (3000K or 4000K) ▪ 1 x 12V-24V, 650mA (16W) LED driver with 1.5m flex & plug and secondary leads ▪ 1 x DL23LED (gimbal) or DL21LED (fixed downlight) with twist-lock face ▪ C-Bus compatible ▪ Fully dimmable with leading or trailing edge dimmers PRODUCT SPECIFICATIONS PRODUCT FEATURES ENERGY SAVING 70% 0% 100% 50,000 3000K - WARM 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L Compared to a standard MR16 50W lamp XL-LED Performance Downlight Kits 12W 700/800 LUMENS

D o w nli g hts 12 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 The Crompton XL-LED MAX has been designed for maximum performance and light output. XL-LED MAX is class leading, with significantly higher lumen output, exceeding that of a 50W halogen MR16 Lamp, whilst using significantly less power. Crompton XL-LED MAX is suitable for a wide range of applications. These include both residential and commercial applications including shops, offices and general lighting areas. They are also most beneficial in installations that have high ceilings, enabling maximum light output, whilst resulting in additional cost savings from lower maintanance costs due to less frequent lamp changes. XL-LED MAX is registered to carry the prestigious SSL Label, which guarantees performance, colour rendition and maintanance and energy efficiency. Luminous Flux 1000 lm Luminous Efficacy 55 lm/W INPUT POWER 18 W TEST VOLTAGE 240V AC Colour Correlated Colour Temperature (CCT) 2700 K Colour Rendering Index (CRI, Ra) 85 LED Performance Solid State Lighting Luminaire LIGHT COLOUR Correlated Colour Temperature (CCT) WARM WHITE COOL WHITE DAYLIGHT 2700 (WARM WHITE) VISIT www.lightingcouncil.com.au for the Label Reference Guide The specifications above are contained in certified or accredited reports provided to Lighting Council Australia Ltd by the manufacturer/supplier of this product. Lighting Council Australia makes no representation as to the product’s specification or suitability. 2600K 3200K 4500K 6500K Supplier/Product ID: 018/132-1 Brand Name: CROMPTON The LED Technology XL-LED MAX Performance

D o w nli g hts 13 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED14F DIMENSIONS / WEIGHT / LIFE Downlight & lamp 375g Controller 165(W)x44(D)x37(H) mm, 185g LED Lamp Life 50,000HR Controller Life 50,000HR XL-LED MAX Performance Kit contents: ▪ 1 x 14W 2700K LED lamp pre-fitted into white aluminium 45 o centre tilt downlight with steel mouse-trap clips ▪ 1 x 12V-24V, 650mA thermoplastic casing LED driver with click tooth cover prewired to 600mm lamp lead and 1.5m flex & plug ▪ 1 x spare lamp locking ring for optional installation into a fixed or gimbal type LED downlight fixture ▪ C-Bus compatible ▪ Fully dimmable with leading, trailing edge and universal dimmers PRODUCT SPECIFICATIONS PRODUCT FEATURES ENERGY AVE 0% 100% 50,000 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 100mA Power Factor 0.95 undimmed Total Input Power 18W Secondary Output Voltage 12V - 24V DC Secondary Output Current 650mA regulated Lamp Power 14W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Aluminium Attachment Clip Steel Lens Retainer Aluminium Lens / Diffuser PMMA Controller Base & Cover Polycarbonate Terminal Clamp Moulding Polycarbonate Electronic Components & PCB’s RoHS compliant with Pb-free solder THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 1000 lumens CRI 85 Colour Temperature 2700K Beam Angle 54 o FNV REFERENCE COLOUR CODE KLED14FS Silver 26950 KLED14FW White 26949 Cut-out: Ø70 85 (mm) 96 45 o 1000 1000 LUMEN OUTPUT XL-LED MAX Performance Downlight Kits 14W 1000 LUMENS

D o w nli g hts 14 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 2900K 1750K SUNSET DIM Standard LED downlights reduce the luminous intensity while maintaining a constant colour temperature, when dimmed. Crompton XL-LED MAX Sunset Dim combines class leading engineering technology, with an enhanced feature of visual stimulation through the transition of "colour experience" similar to that of actual sunset. To achieve this effect, the Crompton XL-LED MAX SUNSET DIM simultaneously reduces both the luminous intensity and colour temperature when dimmed. This effect is similar to traditional incandescent and halogen lighting which become warmer (orange glow) when dimmed. With a smart combination of an amber LED into the circuit, the Crompton XL-LED Sunset Dim produces a colour controlled dimming curve that uniquely matches that of a standard halogen MR16 lamp, when using most of the common phase control dimmers on the market. XL-LED MAX 'Sunset Dim' The LED Technology

D o w nli g hts 15 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED15AWSD DIMENSIONS / WEIGHT / LIFE Downlight & lamp 375g Controller 165(W)x44(D)x37(H) mm, 185g LED Lamp Life 50,000HR Controller Life 50,000HR XL-LED MAX Sunset Dim Kit contents: ▪ 1 x 14W LED lamp complete with 7 LEDs ▪ Pre-fitted into white aluminium 45 o centre tilt downlight with steel mouse-trap clips ▪ 1 x 12V-24V, 650mA thermoplastic casing LED driver with click tooth cover prewired to 600mm lamp lead and 1.5m flex & plug ▪ 1 x spare lamp locking ring for optional installation into a fixed or gimbal type LED downlight fixture ▪ C-Bus compatible ▪ Fully dimmable with leading, trailing edge and universal dimmers PRODUCT SPECIFICATIONS PRODUCT FEATURES ENERGY AVE 0% 100% 50,000 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2900K - WARM ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 100mA Power Factor 0.9 Total Input Power 22W Secondary Output Voltage 12V - 24V DC Secondary Output Current 650mA regulated Lamp Power 14W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Aluminium Attachment Clip Steel Lens Retaining Clip Steel, chrome plated Len / Diffuser Polycarbonate Controller Base & Cover Polycarbonate Terminal Clamp Moulding Polycarbonate Electronic Components & PCB’s RoHS compliant with Pb-free solder THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 1000 lumens CRI 85 Colour Temperature 2900K Beam Angle 54 o FNV REFERENCE COLOUR CODE KLED15AWSD White 27009 XL-LED MAX ‘Sunset Dim’ Downlight Kit Cut-out: Ø70 85 (mm) 96 45 o 14W 1000 LUMENS

D o w nli g hts 16 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Crompton's XL-LED ECO downlights incorporate the latest technology to provide users with an LED option to achieve significantly improved energy efficiency, colour rendering quality and light output, when compared to older technology, such as compact fluorescent and incandescent. The XL-LED ECO offers a cost effective engergy saving buildings lighting solution for small to medium sized commercial or as a direct replacement for halogen lighting in all residential applications. Ø70mm cut-out / Ø92mm cut-out XL-LED ECO Performance Kits

D o w nli g hts 17 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 40,000 KLED15A WEIGHT / LIFE Downlight 250g Controller 140(W)x44(D)x28(H) mm, 240g LED Lamp Life 40,000HR Controller Life 40,000HR Cut-out: Ø70 85 (mm) 87 45 o REFERENCE COLOUR CODE 2700K KLED15AW27K White 26869 KLED15AS27K Silver 26870 4000K KLED15AW4K White 26871 KLED15AS4K Silver 26872 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.07A Power Factor 0.98 Total Input Power 17W Secondary Output Voltage 15V - 17V DC Secondary Output Current 700mA Lamp Power 15W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Finned aluminium Attachment Clip Chrome Body Die-cast Aluminium Lens Reverse concave polycarbonate Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic Electronic Components & PCB’s RoHS compliant THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC 2700K 4000K Luminous Flux 490 lumens 660 lumens CRI 85 67 Beam Angle 60 o 60 o PRODUCT FEATURES PRODUCT SPECIFICATIONS ▪ 15W 2700K / 4000K LED centre tilt kit ▪ Die-cast aluminium downlight ring & fascia ▪ Centre tilt (45°) lamp retaining ring ▪ Chrome mouse-trap type clips ▪ 15V-17V, 650mA-700mA LED driver with 1.5m flex & plug and 600 mm secondary leads ▪ 10% - 100% dimmable with most trailing edge dimmers ▪ Includes 15W LED module 10% 100% ENERGY SAVING 70% 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM Compared to a standard MR16 50W lamp Ø70mm cut-out XL-LED ECO Performance Centre Tilt Kits 15W 490/660 LUMENS

D o w nli g hts 18 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Cut-out: Ø92 102 (mm) 87 45 o ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.07A Power Factor 0.98 Total Input Power 17W Secondary Output Voltage 15V - 17V DC Secondary Output Current 700mA Lamp Power 15W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Finned aluminium Attachment Clip Chrome Body Die-cast Aluminium Lens Reverse concave polycarbonate Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic Electronic Components & PCB’s RoHS compliant THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 490 lumens CRI 85 Colour Temperature 2700K Beam Angle 60 o REFERENCE COLOUR CODE K15AW27K White 27032 K15AS27K Silver 27033 40,000 K15AW27K WEIGHT / LIFE Downlight & lamp 300g Controller 140(W)x44(D)x28(H) mm, 240g LED Lamp Life 40,000HR Controller Life 40,000HR PRODUCT FEATURES PRODUCT SPECIFICATIONS ▪ 15W 2700K LED adjustable downlight kit ▪ Die-cast aluminium downlight ring & fascia ▪ Adjustable lamp retaining ring ▪ Chrome mouse-trap type clips ▪ 15V-17V, 700mA LED driver with 1.5m flex plug and 600 mm secondary leads ▪ 10% - 100% dimmable with most trailing edge dimmers ▪ Includes 15W LED module 10% 100% ENERGY SAVING 70% 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM Compared to a standard MR16 50W lamp Ø92mm CUT-OUT XL-LED ECO Performance Adjustable Downlight Kits 15W 490 LUMENS

D o w nli g hts 19 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED9F3K KLED9A3K DIMENSIONS / WEIGHT / LIFE Downlight DL21LED - 40g DL23LED - 80g Controller 165(W)x44(D)x37(H) mm, 185g LED Lamp Life 50,000HR Controller Life 50,000HR XL-LED ECO II Performance Kit contents: ▪ 1 x 8W 3000K LED lamp ▪ 1 x 12V, 650mA thermoplastic casing LED driver with click tooth cover prewired to 800mm lamp lead and 1.2m flex & plug ▪ 1 x white / satin chrome fixed or gimbal downlight with twist-lock face PRODUCT SPECIFICATIONS PRODUCT FEATURES 0% 100% 50,000 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 50mA Power Factor 0.95 Total Input Power 11W Secondary Output Voltage 12V DC Secondary Output Current 650mA Lamp Power 8W Input Capacitance of Driver 47nF = 0.047µF MATERIALS Heatsink Finned aluminium Lens Retainer Polycarbonate Lens / Diffuser PMMA Controller Base & Cover Polycarbonate Terminal Clamp Moulding Polycarbonate Electronic Components & PCB’s RoHS compliant with Pb-free solder THERMAL Protection Overload, short-circuit Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 553 lumens CRI 85 Colour Temperature 3000K Beam Angle 45 o FNV XL-LED ECO II Performance Downlight Kits Cut-out: 70 82 35 87 (mm) ENERGY AVE 100 40 Cut-out: 90 87 45 o (mm) REFERENCE COLOUR DOWNLIGHT CODE KLED9FW3K White Fixed 26989 KLED9FSC3K Satin Chrome Fixed 26990 KLED9AW3K White Gimbal 27058 KLED9ASC3K Satin Chrome Gimbal 27059 8W 553 LUMENS

D o w nli g hts 20 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 The Crompton XL-LED Diffused range has been designed for maximum performance and light output. Unlike some diffusers that significantly reduce the LED efficiency beyond acceptable levels, the Crompton diffusers have been specifically designed to reduce overall glare, whilst still maintaining high lumen intensity. Crompton XL-LED Diffused range are suitable for a wide range of applications. These include both residential and commercial applications including shops, offices and general lighting areas. They are also most beneficial in installations that require lower glare, but maximum light output. The Crompton XL-LED Diffused range of LED Downlights are aesthetically pleasing to suit most interior applications, giving advanced performance in efficiency and visual comfort. XL-LED Performance Diffused Downlight Kits The LED Technology

D o w nli g hts 21 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED25W4K KLED32W4K PRODUCT SPECIFICATIONS PRODUCT FEATURES 40,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L ENERGY AVE Ø175mm cut-out / Ø220mm cut-out ▪ XL-LED Performance diffused downlight kit ▪ White powder coated die-cast aluminium body and base ▪ PMMA thermoplastic diffuser ▪ 25W downlight with 30V DC, 700mA LED driver ▪ 32W downlight with 41V DC, 700mA LED driver ▪ Polycarbonate body LED driver prewired to 600mm lamp lead and flex & plug ▪ Includes 25W or 32W LED module XL-LED Performance Diffused Downlight Kits Ø190 47 Cut-out: Ø175 (mm) Ø240 85 Cut-out: Ø210 (mm) 32W 1600 LUMENS 25W 1030 LUMENS REFERENCE COLOUR DOWNLIGHT CODE KLED25W4K White 25W 27067 KLED32W4K White 32W 27068 ELECTRICAL 25W 32W Supply Voltage 220-240V AC 230-240V AC Supply Frequency 50-60Hz 50-60Hz Supply Current 0.15A 0.15A Power Factor 0.9 0.9 Total Input Power 25W 32W Secondary Output Voltage 30V DC 41V DC Secondary Output Current 0.7A regulated 0.7A regulated Lamp Power 25W 32W MATERIALS Heatsink Aluminium Attachment Clip Steel Body Aluminium Diffuser PMMA Controller Base & Cover Polycarbonate THERMAL Thermal Protection Fully protected Fully protected Ambient Temperature Rating 50°C 50°C Maximum Surface Temp 75°C 75°C Ingress Protection Rating IP20 IP20 OPTICAL / PHOTOMETRIC Luminous Flux 1030 lumens 1600 lumens CRI 65 85 Colour Temperature 4000K 4000K Beam Angle 150° 150° WEIGHT / LIFE Downlight 1.02Kg 1.56Kg LED Lamp Life 40,000HR 40,000HR Controller Life 40,000HR 40,000HR

D o w nli g hts 22 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED17ADW REFERENCE COLOUR CODE 2700K KLED17ADW27K White 26963 4000K KLED17ADW4K White 26960 ▪ 15W 2700K / 4000K LED diffused downlight kit ▪ Die-cast aluminium white downlight with steel mouse-trap clips and aluminium heat sink ▪ Opal polycarbonate diffuser ▪ 15V-17V DC, 700mA thermoplastic body LED driver prewired to 600mm lamp lead and 1.4m flex & plug PRODUCT FEATURES PRODUCT SPECIFICATIONS 40,000 10% 100% 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 700mA Power Factor 0.9 Total Input Power 17W Secondary Output Voltage 15V - 17V DC Secondary Output Current 700mA Lamp Power 15W Input Capacitance of Driver 0.033µF MATERIALS Heatsink Aluminium Attachment Clip Steel Body Die-cast Aluminium Fascia Die-cast Aluminium Lens Polycarbonate Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC 2700K 4000K Luminous Flux 330 lumens 470 lumens CRI 75 75 Beam Angle 120 o 120 o Cut-out: 70 94 65 (mm) DIMENSIONS / WEIGHT / LIFE Downlight 190g Controller 140(W)x44(D)x28(H) mm, 240g LED Lamp Life 40,000HR Controller Life 40,000HR ENERGY AVE XL-LED ECO D Performace Diffused Downlight Kits Ø70mm cut-out 15W 330/470 LUMENS

D o w nli g hts 23 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED21ADW REFERENCE COLOUR CODE 2700K KLED21ADW27K White 26962 4000K KLED21ADW4K White 26961 ▪ 21W 2700K / 4000K LED diffused downlight kit ▪ Die-cast aluminium white downlight with steel mouse-trap clips and aluminium heat sink ▪ Opal polycarbonate diffuser ▪ 25V DC, 700mA thermoplastic body LED driver prewired to 600mm lamp lead and 1.4m flex & plug PRODUCT FEATURES PRODUCT SPECIFICATIONS 40,000 10% 100% 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.15A Power Factor 0.9 Total Input Power 24W Secondary Output Voltage 25V DC Secondary Output Current 700mA Lamp Power 21W Input Capacitance of Driver 0.033µF MATERIALS Heatsink Aluminium Attachment Clip Steel Body Die-cast Aluminium Fascia Die-cast Aluminium Lens Polycarbonate Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic THERMAL Thermal Protection Fully protected Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC 2700K 4000K Luminous Flux 480 lumens 680 lumens CRI 75 75 Beam Angle 120 o 120 o Cut-out: 90 110 75 (mm) DIMENSIONS / WEIGHT / LIFE Downlight 230g Controller 140(W)x44(D)x28(H) mm, 240g LED Lamp Life 40,000HR Controller Life 40,000HR ENERGY AVE XL-LED ECO D Performace Diffused Downlight Kits Ø90mm cut-out 21W 480/680 LUMENS

D o w nli g hts 24 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 PRO-DL13W27 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.21A Power Factor 0.6 Total Input Power 13W Secondary Output Voltage 21V DC Secondary Output Current 1050mA Lamp Power 13W MATERIALS Heatsink Finned aluminium Attachment Clip Chrome spring clips Body Powder coated matt finish Fascia Powder coated matt finish Lens / Diffuser Glass Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic Electronic Components & PCB’s RoHS compliant THERMAL Thermal Protection Fully protected Ambient Temperature Rating -20 o C to 45 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 700 lumens CRI 90 Colour Temperature 2700K Beam Angle 120 o WEIGHT / LIFE Downlight 230g Controller 175g LED Lamp Life 50,000HR Controller Life 50,000HR ▪ Powder coated matt finish body and fascia ▪ Specular aluminium polished reflector ▪ Clear front glass cover ▪ Finned aluminium heat sink ▪ Prewired to electronic driver which is attached to primary wires in an enclosed quick-connect terminal block ▪ Includes 1 x 13W LED module PRODUCT SPECIFICATIONS REFERENCE COLOUR CODE PRO-DL13W27 White 26853 PRODUCT FEATURES 115 (mm) Cutout - Ø 84 50,000 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM XL-LED Recessed Fixed Downlight ENERGY AVE 13W 700 LUMENS

D o w nli g hts 25 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 DL3880 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.15A maximum Power Factor 0.53 Total Input Power 15W Secondary Output Voltage 44V DC maximum Secondary Output Current 0.35A Lamp Power 14W MATERIALS Heatsink Aluminium Body Aluminium THERMAL Protection Thermal, short-circuit Ambient Temperature Rating 45° Maximum Surface Temp 75° Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 1200 lumens CRI 80 Colour Temperature 3000K Beam Angle 50° DIMENSIONS / WEIGHT / LIFE Downlight 750g Controller 115(W)x34(D)x19(H) mm, 150g LED Lamp Life 50,000 HR Controller Life 50,000 HR ENERGY AVE 50,000 REFERENCE COLOUR CODE DL3880 White 27035 190 91 40 (mm) XL-LED Performance Surface Mounted Downlight ▪ 14W LED surface mounted downlight kit ▪ Matt white powder coated die-cast aluminium body ▪ White painted base ▪ Inbuilt LED driver ▪ Includes 1 x 14W LED module 14W 1200 LUMENS

D o w nli g hts 26 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 KLED21GU1027K KLED23GU1027K XL-LED Performance GU10 Kit: ▪ 1 x 10W LED GU10 lamp ▪ 1 x DLM23 (gimbal) or DLM21 (fixed downlight) in white / satin chrome with twist-lock face ▪ Die-cast aluminium body and twist lock ring with lamp retaining spring ▪ Chrome spring clips ▪ Terminal block casing and cable anchoring mounted on stand off bracket with GU10 lampholder and 120mm lead PRODUCT SPECIFICATIONS PRODUCT FEATURES 1 0 0 0 K 7 0 0 0 K W A RM C O O L 2700K - WARM ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.9 Lamp Power 5 x 2W MATERIALS Lamp Heatsink Aluminium Attachment Clip Steel Lens Retaining Clip Steel, chrome plated Lens / Diffuser Polycarbonate Terminal Clamp Moulding Thermoplastic THERMAL Ambient Temperature Rating -20°C to 50°C Maximum Surface Temp 55°C OPTICAL / PHOTOMETRIC Luminous Flux 340 lumens CRI 80 Colour Temperature 2700K Beam Angle 40 o DIMENSIONS / WEIGHT / LIFE Downlight Fixed-100g, Gimbal-150g LED Lamp Life 35,000HR REFERENCE COLOUR DOWNLIGHT CODE KLED21GU10W27K White Fixed 26966 KLED21GU10SC27K Satin Chrome Fixed 26967 KLED23GU10W27K White Gimbal 26968 KLED23GU10SC27K Satin Chrome Gimbal 26969 ENERGY AVE 10% 100% 35,000 134 82 Cut-out: 70 (mm) 134 102 Cut-out: 90 (mm) 45° XL-LED Performance GU10 Downlight Kits 10W 340 LUMENS

D o w nli g hts 27 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Crompton's XL-PRO LED Professional Downlights incorporate the latest technology to provide users with an LED option to achieve significantly improved energy efficiency, colour rendering quality and light output, when compared to older technology, such as compact fluorescent and incandescent. The Crompton XL-PRO LED Professional Downlights are manufactured to strict performance criteria, resulting in lower levels of radiant heat through integrated thermal management and no emission of Ultra Violet (UV) or Infra Red (IR). XL-PROFESSIONAL LED Downlights Professional Downlights with LED Module

D o w nli g hts 28 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Features & Benefits Fortimo LED Module l The Fortimo LED Module used in the Crompton XL-PRO series is manufactured to the highest standards, ensuring compatibility to suitable environments, which guarantees long term reliability and return for the investment. l The Fortimo Module provides immediate light, without frequency limits over time, ensuring consistent lighting levels are maintained. l Due to the improved thermal management, significant reductions in energy costs are achievable due to the lower loads possible, for example, on commercial air conditioning. Extraction Cooling (19W) l The 19W Crompton XL-PRO LED Downlight comes with noiseless heat extraction design which removes excess heat from the core of the module to prevent over heating. This is extremely important in protecting the life of the LED chip Note: The unique extraction feature is not required on other XL-PRO models due to much lower operating temperatures. Quality Design & Construction l Crompton XL-PRO is made in Italy with a high resistant polycarbonate vacuum metalized faceted reflector. l High performance LED module and fully compatible driver. Light Filtering System l No ultraviolet and infrared rays which are potentially harmful to fresh goods, art & crafts and interior finishing. l No mercury ensures the Crompton XL-PRO Downlights are RoHS compliant. XL-PRO LED RA18B 10W XL-PRO LED RA18B 19W COMPARABLE COMPACT FLUORESCENT FITTINGS 1100 lm 2000 lm 1x26W 2x18W 2x26W Efficiency (%) 93 93 45 53 47 Efficacy (lm) 1023 1860 810 1272 1692 Lamp power (W) 10 19 26 36 52 Ratio flux power (lm/W) 110 105 31 31 32 No. of fittings used 5 4 10 9 8 Lamp replacement 0 0 6/7 6/7 6/7 MADE IN ITALY XL-PROFESSIONAL LED Downlights Professional Downlights with LED Module

D o w nli g hts 29 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 XL-PRO LED RA23 19W XL-PRO LED RA23 35W COMPARABLE COMPACT FLUORESCENT FITTINGS 2000 lm 3000 lm 1x26W 2x18W 2x26W Efficiency (%) 93 93 45 53 47 Efficacy (lm) 1860 2790 810 1272 1692 Lamp power (W) 19 35 26 36 52 Ratio flux power (lm/W) 105 86 31 31 32 No. of fittings used 4 3 10 9 8 Lamp replacement 0 0 6/7 6/7 6/7 RA18 LED Fortimo 10W 1100 lm 10 RA18 LED Fortimo 19W 2000 lm 19 RA23 LED Fortimo 35W 3000 lm 35 RA23 LED Fortimo 19W 2000 lm 19 XL-PRO LED RA18B 10W - PHOTOMETRIC XL-PRO LED RA18B 19W - PHOTOMETRIC XL-PRO LED RA23 19W - PHOTOMETRIC XL-PRO LED RA23 35W - PHOTOMETRIC

D o w nli g hts 30 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Installation Cut-out: Ø172mm XL-PRO LED RA18 REFERENCE COLOUR CODE 10W XL-PRO LED RA18B 17W White 26531 XL-PRO LED RA18B 17W Silver 26532 19W XL-PRO LED RA18B 37W White 26533 XL-PRO LED RA18B 37W Silver 26534 ELECTRICAL 10W 19W Supply Voltage 220-240V AC 220-240V AC Supply Frequency 50-60Hz 50-60Hz Supply Current 0.15A 0.08A to 0.24A Power Factor 0.9 - 0.98 0.9 - 0.98 Total Input Power 10W 19W Secondary Output Voltage 24V DC 70V DC Max. Secondary Output Current 0.7A 0.2A to 0.7A Lamp Power 10W 19W MATERIALS Heatsink Aluminium Attachment Clip Steel Body Epoxy polyester painted die-cast aluminium Fascia Epoxy polyester painted die-cast aluminium ring Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic Electronic Components & PCB’s RoHS compliant THERMAL Thermal Protection Fully protected Fully protected Ambient Temperature Rating -20 o C to 60 o C -20 o C to 50 o C Maximum Surface Temp 90 o C 65 o C Ingress Protection Rating IP43 IP43 OPTICAL / PHOTOMETRIC Luminous Flux 1100 lumens 2000 lumens CRI 80 80 Colour Temperature 4000K 4000K Beam Angle 54 o 54 o PRODUCT FEATURES PRODUCT SPECIFICATIONS ▪ XL-PRO LED fixed downlight ▪ Made in Italy ▪ Ring in epoxy-polyester painted die-cast aluminium ▪ High resistant polycarbonate high vacuum metalized faceted reflector ▪ Black painted aluminium heat sink ▪ Patented spring system enables the fixture to be installed and removed without causing ceiling damage ▪ Easy to install into ceilings with thicknesses from 1-30mm ▪ Includes 1 x (10W / 19W) LED module 50,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L WEIGHT / LIFE Downlight 1.96Kg LED Lamp Life 50,000HR Controller Life 50,000HR XL-PRO LED RA18 PROFESSIONAL Downlights ENERGY AVE 10W 1100 LUMENS 19W 2000 LUMENS

D o w nli g hts 31 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 ELECTRICAL 19W 35W Supply Voltage 220-240V AC 230-240V AC Supply Frequency 50-60Hz 50-60Hz Supply Current 0.15A 0.24A Power Factor 0.9 - 0.98 0.9 - 0.98 Total Input Power 19W 35W Secondary Output Voltage 24V DC 70V DC Max. Secondary Output Current 0.7A 0.2A to 0.7A Lamp Power 19W 35W MATERIALS Heatsink Aluminium Attachment Clip Steel Body Epoxy polyester painted die-cast aluminium Fascia Epoxy polyester painted die-cast aluminium ring Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic Electronic Components & PCB’s RoHS compliant THERMAL Thermal Protection Fully protected Fully protected Ambient Temperature Rating -20 o C to 60 o C -20 o C to 50 o C Maximum Surface Temp 90 o C 65 o C Ingress Protection Rating IP43 IP43 OPTICAL / PHOTOMETRIC Luminous Flux 2000 lumens 3000 lumens CRI 80 80 Colour Temperature 4000K 4000K Beam Angle 54 o 54 o Installation Cut-out: Ø220 200 143 138 138 Ø230 (mm) XL-PRO LED RA23 REFERENCE COLOUR CODE 19W XL-PRO LED RA23 22W White 26863 35W XL-PRO LED RA23 45W White 26862 ▪ XL-PRO LED fixed downlight ▪ Made in Italy ▪ Epoxy-polyester painted die-cast aluminium ring ▪ High resistant polycarbonate high vacuum metalized faceted reflector ▪ Black painted aluminium heat sink ▪ Patented spring system enables the fixture to be installed and removed without causing ceiling damage ▪ Easy to install into ceilings with thicknesses from 1-30mm ▪ Includes 1 x (19W / 35W) LED module PRODUCT FEATURES PRODUCT SPECIFICATIONS 50,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L WEIGHT / LIFE Downlight 2Kg LED Lamp Life 50,000HR Controller Life 50,000HR XL-PRO LED RA23 PROFESSIONAL Downlights ENERGY AVE 19W 2000 LUMENS 35W 3000 LUMENS

D o w nli g hts 32 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 Cut-out: 70mm 82 35 ▪ LED fixed / gimbal downlight with twist-lock face ▪ Die cast aluminium body and fascia ▪ Chrome spring clips Suitable for XL-LED lamp 100 40 Cut-out: 90mm 45 0 DL21-LED DL23-LED MATERIALS Attachment Clip Chrome spring clips Body Die-cast aluminium Fascia Die-cast aluminium WEIGHT DL21-LED DL23-LED Downlight 40g 80g REFERENCE COLOUR DOWNLIGHT CODE DL21W-LED White Fixed 26300 DL21SC-LED Satin Chrome Fixed 26301 DL23W-LED White Gimbal 26298 DL23SC-LED Satin Chrome Gimbal 26299 PRODUCT FEATURES PRODUCT SPECIFICATIONS XL-LED Performance Downlight Heads

D o w nli g hts 33 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 ▪ LED square fixed / gimbal downlight with twist-lock face ▪ Die cast aluminium body and fascia ▪ Chrome spring clips Suitable for XL-LED lamp DL41-LED DL44-LED Cut-out: 68mm (round) 82 35 Cut-out: 85mm (round) 97 35 30 0 MATERIALS Attachment Clip Chrome spring clips Body Die-cast aluminium Fascia Die-cast aluminium WEIGHT DL41-LED DL44-LED Downlight 60g 80g REFERENCE COLOUR DOWNLIGHT CODE DL41W-LED White Fixed 26726 DL41SC-LED Satin Chrome Fixed 26727 DL44W-LED White Gimbal 26728 DL44SC-LED Satin Chrome Gimbal 26729 PRODUCT FEATURES PRODUCT SPECIFICATIONS XL-LED Performance Square Downlight Heads

D o w nli g hts 34 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 MATERIALS Attachment Clip Chrome spring clips Body Die-cast aluminium Fascia Powder coated white / silver WEIGHT DL45-LED DL46-LED Downlight 220g 180g ▪ LED square / round tilt baffle downlight ▪ Powder coated fascia ▪ Recessed lamp retaining ring with adjustable tilt ▪ Chrome spring clips Suitable for XL-LED lamp DL45-LED DL46-LED REFERENCE COLOUR DOWNLIGHT CODE DL45W-LED White Square 26730 DL45S-LED Silver Square 26731 DL46W-LED White Round 26732 DL46S-LED Silver Round 26733 PRODUCT FEATURES PRODUCT SPECIFICATIONS 100 45 Cut-out: 90mm (round) 100 45 Cut-out: 90mm (round) XL-LED Performance Downlight Heads

D o w nli g hts 35 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 XL-888SC ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.02A Power Factor 0.9 Total Input Power 5W Secondary Output Voltage 12V DC Secondary Output Current 0.42A Lamp Power 3 x 1.4W MATERIALS Body Metal Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic THERMAL Ambient Temperature Rating 45 o C Maximum Surface Temp 80 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 70 lumens each CRI 75 Colour Temperature 4000K LED mini cabinet light kit contents: ▪ 3 x 1.4W satin chrome lights with metal body and inserts fitted with 21 surface mounted LEDs prewired to 1.5m quick connect cable ▪ 1 x 15W DC LED driver attached to 1.5m flex & plug and parallel quick connector KL3P PRODUCT SPECIFICATIONS REFERENCE COLOUR CODE XL-888SC Satin Chrome 26809 PRODUCT FEATURES 25 70 70 (mm) 30,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L WEIGHT / LIFE Downlight 100g each LED Lamp Life 30,000HR Controller Life 30,000HR XL-LED Performance 3 Circular Mini Cabinet Light Kit ENERGY AVE 4.2W 210 LUMENS

D o w nli g hts 36 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 SENSOR T O U C H XL-3SLS PRODUCT SPECIFICATIONS REFERENCE COLOUR CODE XL-3SLS Silver Grey 26808 PRODUCT FEATURES LED 3 bar lights kit contents: ▪ 3 x 2.64W silver grey aluminium body with frosted PMMA diffuser fitted with surface mounted LEDs prewired to 1.5m quick connect cable ▪ Each bar light has touch sensor with blue pilot light on one end ▪ 1 x 15W DC LED driver attached to 1.5m flex & plug and parallel quick connector KL3P 600 10 (mm) 10 30,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.9 Total Input Power 15W Secondary Output Voltage 12V DC Secondary Output Current 1.25A Lamp Power 3 x 2.6W MATERIALS Body Aluminium Lens / Diffuser Frosted PMMA Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic THERMAL Ambient Temperature Rating 45 o C Maximum Surface Temp 80 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 130 lumens each CRI 75 Colour Temperature 4000K WEIGHT / LIFE Bar 100g each LED Lamp Life 30,000HR Controller Life 30,000HR XL-LED Performance 3 Light Barlight Kit ENERGY AVE 7.8W 390 LUMENS

D o w nli g hts 37 Fittings do not include lamps unless specifically stated. E.&.O.E. LED 07/12 SENSOR T O U C H XL-3BLS 3 bar lights kit contents: ▪ 3 x 2.28W silver grey aluminium body with 3 polycarbonate clear diffuser windows with touch sensor ▪ Each touch sensor with blue pilot light covered with frosted polycarbonate diffuser ▪ 1 x 15W DC LED driver attached to 1.5m flex & plug and parallel quick connector KL3P ▪ 3 x 1.5m quick connect cables ▪ 2 x 0.5m link cables ▪ 2 x butt connectors PRODUCT SPECIFICATIONS REFERENCE COLOUR CODE XL-3BLS Silver Grey 26807 PRODUCT FEATURES 600 35 (mm) 8 30,000 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.9 Total Input Power 15W Secondary Output Voltage 12V DC Secondary Output Current 1.25A Lamp Power 3 x 2.28W MATERIALS Body Silver grey aluminium Lens / Diffuser Frosted polycarbonate Controller Base & Cover Thermoplastic Terminal Clamp Moulding Thermoplastic THERMAL Ambient Temperature Rating 45 o C Maximum Surface Temp 80 o C Ingress Protection Rating IP20 OPTICAL / PHOTOMETRIC Luminous Flux 140 lumens each CRI 75 Colour Temperature 4000K WEIGHT / LIFE Bar 220g each LED Lamp Life 30,000HR Controller Life 30,000HR XL-LED Performance 3 Light Barlight Kit ENERGY AVE 6.8W 420 LUMENS
