ESSAILEC ® range Test blocks Main catalogue

ES0012 Applications: • Measurement, current or voltage injection, repair, device replacement. • Current testing without cutting the energy supply.• Voltage testing with the possibility of cutting or not the energy supply to the device according to the voltage sockets implemented. • Simultaneous testing of 1 to 4 independent circuits on the same socket. • The test plug can also be connected continuously to the socket in order to supply current or voltage to secondary circuits sub assemblies. Characteristics and benefits: • Fast and easy testing procedure.• No cursor or switch element to operate manually: the current transformers short circuiting is automatically performed in the correct sequence with the current socket with "make before break contacts". Security for the operator:• IP20 protection degree.• Coding protection.• Locking system.• Sealed cover.• Range and versions product identification with marking and colour coding. Flexibility:• Panel and switchboard mounting: base mounting, flush mounting, rack mounting, din rail… • Several wiring technologies, wire connection up to 10 mm². Essailec ® , Test blocks ESSAILEC ® has been especially designed to fit the electricity Utilities requirements for safe and reliable testing.ESSAILEC ® allows the testing, without any circuit break, of meters and protective relays installed in the current transformers and voltage transformers secondary circuits.ESSAILEC ® has been approved by major Utilities and has been successfully implemented for years in worldwide electricity production, transport and distribution networks.

ES0022 Contents Generalities .............................................................................................................................2 Examples .................................................................................................................................7 Current range ........................................................................................................................10 Voltage range ........................................................................................................................12 Polarity range ........................................................................................................................14 Trip range ...............................................................................................................................16 Multicircuits range ...............................................................................................................18 Coding ....................................................................................................................................19 Outer dimensions, mounting instructions ......................................................................20 Index .......................................................................................................................................21 ESSAILEC ® Test blocks ABB | 1

ES0001 CC-E-VA-6.6 Compatibility between the socket and plug designs: Circuit type Contacts socket 2.x.4.poles plug 4.poles plug Current. Make.before.break Measurement Calibration Distribution Voltage. Make.before.break Measurement Calibration Distribution Opened Measurement Calibration Measurement Calibration Closed Measurement Distribution Socket The.ESSAILEC ® .socket.is.installed.in.the.circuit.and.wired.to.the.device.to.be.tested.during.its. installation.or.its.servicing..The.use.of.the.cover.is.strongly.recommended.in.order.to.prevent. unauthorized.access. The.sockets.are.available.in.the.following.designs: . -.Socket.with."make.before.break".contact.design,.available.in.the.Current.and.Voltage.ranges. . -.Socket.with."opened".("break.before.make").contact.design,.available.in.Voltage.range. . -.Socket.with."closed".contact.design,.available.in.Voltage.range. Plug The.plug.is.connected.on.its.other.extremity.to.the.test.equipment..For.testing,.the.cover.is. removed.and.replaced.by.the.test.plug. The.test.plugs.are.available.in.the.following.designs: . -.2x4.poles.plug:.allows.the.testing.of.4.current.or.voltage.circuits. . -.4.poles.plug:.allows.the.testing.of.4.voltage.circuits. . -.2.poles.plug:.allows.the.testing.of.1.current.or.voltage.circuit. Socket Bayonet.security.test.plug Plug.4.poles Plug.2.poles Ø.4.mm.double.test.plug Test accessories and prewired plug The.ESSAILEC ® .range.offers.a.wide.range.of.test.accessories.as.well.as.prewired.plugs.with. the.following.test.accessories.wired.on.its.test.equipment.extremity: . -. Security. bayonet. test. plug. (bayonet. locking. mechanism. in. the. test. equipment. for. . . maximized.security.during.the.testing). . -. Ø.4mm.IP20.test.plug. The.security.test.plugs.can.be.connected.together.with.the.use.of.two.accessories:.straight. and.H.adapters..The.purpose.of.these.two.accessories.is.to.offer.extra.test.configurations.with. the.prewired.plug. CIRCUIT TYPE: C:. Current. T:. Voltage. P:. Polarity. DE:. Trip. CONTACTS: C:. Make.before.break O:. Opened F:. Closed CODING: 6.6:. Current2.2:. Voltage8.8:. Polarity CONNECTION: VA:. Ring-tongueVL:. Screw.clampC5A:. Quick-connect MOUNTING: TH35.:.Symetrical.rail.TH35DS:. Half-base./.BaseE:. Flush D:. Half-base R:. Rack I:. Reverse Socket identification: Prewired.plug ESSAILEC ® Generalities Plug.2x4.poles.with.crimping.pins.or.DIA.4.mm.direct.outputs 2 | ABB

ES0011 Protection:IP20.operator.protection Ring-tongue Screw clamp Quick-connect Protection.against.reverse.plug.insertion Locking mechanism:No.risk.of.unplugging.during.task. Coding:Up.to.6.combinations.possible Premarked block with color coding:. -.Green. .:.Current . -.Grey. .:.Voltage . -.Blue. .:.Polarity . -.Orange. .:.Trip Connection technologies Premarked block:1,.2,.3,.4:.Transformers.side01,.02,.03,.04:.Equipment.side Protection . Provide.dust.protection.and.prevent.unauthorised.access. . (lead.seal). Cover Lid Lid with electrical continuity Cover with electrical continuity Compatible.with.flush,.rack,.half-base.and.reverse.mounting.Benefits:.Wire.pulling.safe. Compatible.with.flush,.rack.and.half-base.mounting.Benefits:.Quick.and.vibration.safe. Compatible.with.base.and.half-base.mounting.and.G32.&.TH35.rails.Benefits:.Universal.connecting.technology. . Lid.and.cover.with.electrical.continuity,.to.be.mounted.on.opened. . contacts.socket. . Provide.the.electrical.continuity.thanks.to.the.inner.pins.and.linking. . bar.that.close.the.circuit. Socket features ESSAILEC ® Generalities ABB | 3

ES0002 1 2 3 Applications: .-.Measurement.-.Injection.-.Distribution Servicing During.normal.servicing,.the.socket.with.make.before.break.contact.design.supplies.energy.to.the.device...The.lid.is.installed.and.sealed.. Test The.lid.is.removed..When.the.plug.is.inserted.(1),.the.plug.pins.make.contact.with.the.socket.test.pins..The.test.circuit.is.established.but.still.remains.closed.(2).When.the.plug.is.completely.inserted.in.the.socket,.the.inner.mobile.contact.is.opened:.the.current.completely.deviates.in.the.test.circuit.(3).. Re servicing Thanks.to.the.inner.mobile.contact.the.circuit.will.close.automatically.when.the.plug.is.removed. lid socket plug socket plug.pin test.pin mobile.contact ESSAILEC ® Test principle: Make before break 4 | ABB

ES0003 1 2 Applications: .-.Measurement.-.Injection Servicing During.normal.functioning,.electrical.continuity.is.ensured.by.the.lid.with.electrical.continuity.mounted.on.the.socket. Test The.removing.of.the.lid.opens.the.circuit.(1).The.device.to.be.tested.is.then.isolated.from.the.power.supply.(transformer).and.is.no.longer.energised.(2). Re servicing When.the.test.is.finished,.the.circuit.is.closed.when.the.lid.is.reinstalled. lid socket plug socket ESSAILEC ® Test principle: Break before make (opened) ABB | 5

ES0004 Closed contacts: The.electrical.connection.is.continuous..This.socket.is.particularly.suitable.for.power.distribution. Applications: .-.Measurement.-.Distribution Servicing The.electrical.connection.is.continuous:.removing.or.fitting.the.lid.does.not.have.any.impact.on.the.circuits. Test The.measurement.is.performed.by.the.insertion.of.the.4.poles.test.plug. Re servicing No.particular.procedure. plug socket socket ESSAILEC ® Test principle: Closed contacts 6 | ABB

ABB | 7 ES0005 1 2 3 4 01 02 03 04 1 2 3 4 01 02 03 04 COR-C-2 COR-C-5 COR-C-1 COR-C-4 1, 2, 3, 4 01, 02, 03, 04 A B S1 S2 C S1 S2 S1 S2 A 1 4 3 2 04 03 02 01 03 04 010203 3 4 2 1 04 01 02 B S1 S2 C S1 S2 S1 S2 A 1 4 3 2 04 03 02 01 é quipement é quipement . de .test FCB.bayonet.security.test.plug IR1.straight.adaptor,.ensure.the.electrical.continuity.on.the.neutral.phase.(not.tested) Ammeter 2x4.poles.plugFIC-2/4 CC.socket Simultaneous.current.measurement.on.3.phases.without.cutting.the.circuit. Current.injection.on.the.equipment,.without.disturbing.the.current.transformer,.with.the.special.use.of.the.H.adapter.(current.transformers.side.shunted). Measurement Calibration Curr ent transformers Equipment (meters, .relays...) Solution 1 :.FIC-2/4.plug.with.the.special.use. of.the.H.adapter.(current.transformers.side.shunted). Solution 2 :.specific.prewired.plug.COR-C-2. or.COR-C-5.(prewired.plug.with.short.circuited.inner.contact.pins:.1-2-3-4.side). IR2.H.adaptor(short.circuit.the.transformer.side) Curr ent .injection .equipment Equipment (meters, .relays...) Curr ent transformers FCB.bayonet.security.test.plug 2x4.poles.plugFIC-2/4 CC.socket ESSAILEC ® Current range: examples of applications Equipment Test . equipment Equipment

ES0023 01020304 1 2 3 4 01020304 1 1 2 3 4 01020304 2 1 2 3 4 1 2 3 4 01020304 FCB.bayonet.security.test.plug CA.Isolating.cap.for.FCB.plugs 2x4.poles.plugFIT-2/4 TC.socket Voltage.measurement.with.TC.type.voltage.socket.(make.before.break).and.2x4.poles.plug: Voltmeters FCB.bayonet.security.test.plug or FC4.test.plug Voltage.measurement.with.TO.type.voltage.socket.(opened).and.4.poles.plug: meters,.relays... Equipment (meters, .relays...) Voltage transformers Measurement TO.socket Lid.with.electrical.continuity Equipment (meters, .relays...) During servicing Voltage transformers Voltage.measurement.with.TF.type.voltage.socket.(closed).and.4.poles.plug: Voltmeters Voltmeters During testing 4.poles.voltage.plugFIT-1/4-G TO.socket 4.poles.voltage.plug FIT-1/4-D or FIT-1/4-D TF socket FCB.bayonet.security.test.plug or FC4.test.plug FCB.bayonet.security.test.plug or. FC4.test.plug ESSAILEC ® Voltage range: examples of applications 8 | ABB

ES0009 01020304 01020304 01020304 1 2 1 2 3 4 1 2 3 4 1 2 3 4 CA.isolating.cap 2x4.poles.plugFIT-2/4 TC.socket Voltage.injection.with.TC.type.voltage.socket.(make.before.break).and.2x4.poles.plug. Voltage .injection .equipment FCB.bayonet.security.test.plug Voltage.injection.with.TO.type.socket.(opened).and.4.poles.plug. TO.socket Lid.with.electrical.continuity Voltage .injection .equipment TO.socket Voltage.plugFIT1/4-D meters,.relays... Equipment (meters, .relays...) Equipment (meters, .relays...) Voltage transformers Voltage transformers Equipment (meters, .relays...) Voltage transformers During servicing During testing Calibration Calibration FCB.bayonet.security.test.plug or FC4.Ø.4.mm.test.plug FCB.bayonet.security.test.plug or FC4.Ø.4.mm.test.plug ESSAILEC ® Voltage range: examples of applications ABB | 9

ES0007 CC-E-VA CC-E-VA-6.6 COR-C-3 COR-C-2 COR-C-1 FIC-2/1-1 FIC-2/4-2. FIC-2/4-1. COR-C-4 COR-C-5 CC-DS-VL CC-TH35-VL-6.6 FIC-2/4-DIA4 Technical data I EC 947-1 Socket Plug Screw.clamp.(VL) Ring-tongue.(VA) Pin.BRE Connecting capacity Rigid.conductor 0.2.-.6.mm² Flexible.conductor 0.22.-.4.mm² 0.34.-.10.mm² Wire.stripping.length 9.5.mm./..370" See.Datasheet Recommended.screwdriver 4.mm./..157" 1SNC 169 040 D1701 Recommended.torque 0.5-0.8.Nm./.4.4-7.1 lb.in Ø Ø.3.mm Width 7.5.mm Rated.voltage 400.V Impulse.withstand.voltage 4.KV Pollution.degree 3 Rated.current 15.A Short-circuit.current 100.A/5.s.-.200.A/1.s Storage.temperature.range -25.°C.~.+70.°C Working.temperature.range -10.°C.~.+55.°C Front.panel.protection with.cover IP40 without.cover IP20 Make.before.break..Current.range.color.code:.Green.Body:.Polycarbonate..Conductive.parts:.Gold-plated Sockets Plugs Prewired plugs Ordering details Description Type Order code Packaging Weight kg Sockets .(a) TH35.rail.mounting Screw CC-TH35-VL-6.6 1SNA 166 963 R0000 1 0.11 Half-base.mounting./.base.mounting Screw CC-DS-VL 1SNA 166 500 R0000 1 0.1 Flush.mounting R.tongue CC-E-VA 1SNA 166 737 R2000 1 0.15 Half-base.mounting R.tongue CC-D-VA 1SNA 166 738 R0100 1 0.09 Rack.mounting R.tongue CC-R-VA 1SNA 166 523 R1200 1 Reverse.mounting R.tongue CC-I-VA-2 1SNA 166 941 R2500 1 Flush.mounting R.tongue with.lid.and.coding.6.6 CC-E-VA-6.6 1SNA 166 625 R2000 Other.preequipped.sockets:.consult.us Plugs Plug.2.poles.with.2.5.mm².pins FIC-2/1-1 1SNA 166 819 R2300 1 Plug.2x4.poles.(b) FIC-2/4-2 1SNA 166 936 R1000 1 0.11 Plug.2x4.poles.(b) FIC-2/4-1 1SNA 166 525 R1400 1 0.09 Plug.2x4.poles,.rack.mounting.R.(b) FIC-2/4-R 1SNA 166 529 R2000 1 Plug.2x4.poles,.reverse.mounting.I.(b) FIC-2/4-I 1SNA 166 589 R2500 1 Plug.2x4.poles,.with.direct.insertion.Dia..4.mm FIC-2/4-DIA4 1SNA 167 937 R0000 1 0.064 Please.refer.to.selection.guide.for.socket.compatibility Prewired plugs .(c) 2.poles.prewired.plug.made.of: COR-C-3 1SNA 166 643 R0200 1 1.plug.2.poles Red.. FIC-2/1-1 2.bayonet.security.test.plugs Yellow.. FCB.. 2x4.poles.prewired.plug.made.of: COR-C-1 1SNA 166 638 R0500 1 0.87 1.plug.2x4.poles Green.. FIC-2/4-1 4.bayonet.security.test.plugs Green.. FCB.. 4.bayonet.security.test.plugs Red.. FCB.. 2x4.poles.prewired.plug.made.of: COR-C-4 1SNA 167 932 R1500 1 0.87 1.plug.2x4.poles Green.. FIC-2/4-2 4.x.Ø.4.mm.test.plugs Black.. FC4-5 4.x.Ø.4.mm.test.plugs Red.. FC4-4 2x4.poles.prewired.plug.for.injection.made.of: COR-C-2 1SNA 166 778 R1100 1 0.47 1.plug.2x4.poles Green.. FIC-2/4-1 with.4.short.circuited.pins.(1-2-3-4)1.bayonet.security.test.plug Green.. FCB.. 1.bayonet.security.test.plug Grey.. FCB.. 1.bayonet.security.test.plug Brown.. FCB.. 1.bayonet.security.test.plug Yellow.. FCB.. 2x4.poles.prewired.plug.for.injection.made.of: COR-C-5 1SNA 167 934 R1700 1 0.47 1.plug.2x4.poles Green.. FIC-2/4-2 with.4.short.circuited.pins.(1-2-3-4)4.x.Ø.4.mm.test.plugs Black.. FC4-5 (a)..The.various.accessories.necessary.for.each.mounting.option.are.supplied.with.the.socket.as.well.as.the.2.coding.pins.COP-E-1.(see.coding. section)..For.rack.and.reverse.mounting.sockets.drawing,.refer.to."Outer.dimensions,.mounting.instructions".section. (b).Plugs.supplied.with.8.locking.pins.and.2.coding.pins.COP-F-1,.the.BRE.contacts.pins.are.to.be.ordered.separately.(c).Cable.length:.2m/.6.6".-.Conductors.section:.2.5.mm²,.all..conductors.marked.(marking.begins.with.0.on.the.equipment.side).-.Precoded:.6.6.. Caution:.The.prewired.test.leads.must.be.connected.to.the.equipment.prior.to.the.insertion.of.the.ESSAILEC ® .prewired.plug.on.the.socket. ..The.BRE.contacts.pins.are.to.be.ordered. separately ESSAILEC ® Current range 10 | ABB

ES0007 1 2 4 3 17 18 15 11 8 20 10 14 6 7 9 13 16 12 19 21 5 Lids Covers Plugs CPC-1 CPC-7 FIC-2/4-DIA4 . Universal .plug FIC-2/1-1 FIC-2/4-2 FIC-2/4-1 FIC-2/4-R . rack .mounting .R FIC-2/4-I . reverse .mounting .I Mounting Sockets TH35.Rail. CC-TH35-VL-6.6 • • • • • • Base..Half-base. CC-DS-VL • • • • • • Flush CC-E-VA • • • • • Half-base CC-D-VA • • • • • Rack CC-R-VA • • • Reverse CC-I-VA-2 • • Flush.with.lid CC-E-VA-6.6 • • • • (a).Compatible.with.base.mounting.only.(b).Compatible.with.ring-tongue.connection.type.socket.only.(VA).(c).Compatible.with.screw.connection.type.socket.only.(VL). Selection guide Accessories Rep. Description Type Order code Packaging Weight kg For sockets 1 Lid CPC-1 1SNA 166 578 R0100 1 2 Cover.(a) CPC-7 1SNA 166 734 R2500 1 0.07 3 Ring-tongue.lug.for.10.mm².wire CS-10 1SNA 167 700 R1100 10 4 Socket.interlocking.peg CVABM 1SNA 183 436 R0500 10 5 TH35.rail.mounting.kit KEM-3 1SNA 166 962 R0000 10 0.02 6 Mounting.kit.for.DIN.1.rail.(a) FX 1SNA 167 682 R2300 10 7 Replacement.kit.for.flush.mounting.(b) KEM-1 1SNA 166 928 R2000 50 0.02 8 Comb-type.jumper.bar.(b) PCVA 1SNA 167 496 R1100 10 9 Comb-type.jumper.bar.IP20.(c) PCVL 1SNA 167 681 R2200 10 10 Jumper.bar.for.2.sockets.(c) BJ-VL 1SNA 167 680 R0500 10 For plugs 11 Pin.1.mm² BRE-C-1 1SNA 167 264 R0700 10 Pin.1.5.mm² BRE-C-1.5 1SNA 167 265 R0000 10 Pin.2.5.mm² BRE-C-2.5 1SNA 167 260 R1700 10 Pin.4.mm² BRE-C-4 1SNA 205 876 R0400 10 Pin.6.mm² BRE-C-6 1SNA 168 146 R0200 10 12 Pin.extraction.tool EXBR1 1SNA 167 008 R0300 1 13 Crimping.tool.for.BRE.pins 1.to.2.5mm² PSC 1SNA 173 181 R1300 1 For test Ø.4.mm.test.plugs 14 IP20.with.mobile.protection Red. FC4-1 1SNA 167 927 R1000 10 0.01 15 IP20.with.permanent.protection Black. FC4-5 1SNA 167 931 R1400 10 0.01 Red. FC4-4 1SNA 167 930 R2700 10 0.01 16 Bayonet.security.test.plug Black. FCB-1 1SNA 167 690 R0700 10 0.01 Red. FCB-2 1SNA 167 692 R2500 10 0.01 17 Isolating.cap.for.FCB.plug CA 1SNA 167 697 R2200 10 18 Straight.adaptor IR1 1SNA 167 622 R2600 5 19 H.adaptor IR2 1SNA 167 623 R2700 5 20 Isolating.cap.for.IR1.&.IR2.adaptors DI 1SNA 167 981 R1700 10 0.01 21 Adaptor.between.FCB.plug.and. ring-tongue.test.interface IR3 1SNA 167 624 R2000 10 Nota:.CPC-7.compatible.with.CC-DS-VL.socket.only.in."base".mounting.option. ESSAILEC ® Current range ABB | 11

ES0010 TC-E-VA TC-E-VA-2.2 FIT-1/4-G. FIT-2/1-1 FIT-2/4-2. FIT-2/4-1. COR-T-4-1 COR-T-1 COR-T-4-4 COR-T-5 TC-DS-VL TC-TH35-VL-6.6 FI-2/4-DIA4 Ordering details Description Type Order code Packaging Weight kg Sockets .(a) TH35.rail.mounting.short.circuited.contacts Screw TC-TH35-VL 1SNA 166 964 R0000 1 0.11 Half-base.mounting./.base.mounting Screw opened.contacts TO-DS-VL 1SNA 166 741 R0400 1 0.1 short-circuited.contacts TC-DS-VL 1SNA 166 742 R0500 1 0.1 closed.contacts TF-DS-VL 1SNA 166 503 R2700 1 Flush.mounting R.tongue opened.contacts TO-E-VA 1SNA 166 743 R0600 1 short-circuited.contacts TC-E-VA 1SNA 166 747 R0200 1 0.14 closed.contacts TF-E-VA 1SNA 166 745 R0000 1 Half-base.mounting R.tongue opened.contacts TO-D-VA 1SNA 166 744 R0700 1 short-circuited.contacts TC-D-VA 1SNA 166 748 R1300 1 closed.contacts TF-D-VA 1SNA 166 746 R0100 1 0.12 Reverse.mounting R.tongue opened.contacts TO-I-VA-2 1SNA 166 945 R2100 1 Flush.mounting.with.lid R.tongue short-circuited.contacts.and precoded.2.2 TC-E-VA-2.2 1SNA 166 627 R2200 1 0.15 Other.preequipped.sockets:.consult.us Plugs . Plug.2.poles.with.2.5.mm².pins FIT-2/1-1 1SNA 166 821 R1500 1 Plug.2x4.poles.(b) FIT-2/4-2 1SNA 166 937 R1100 1 0.11 Plug.2x4.poles.(b) FIT-2/4-1 1SNA 166 550 R0100 1 0.09 Plug.2x4.poles,.reverse.mounting.I.(b) FIT-2/4-I 1SNA 166 672 R0700 1 Plug.4.poles.-.insertion.1-2-3-4.(c) FIT-1/4-G 1SNA 166 547 R2200 1 Plug.4.poles.-.insertion.01-02-03-04.(c) FIT-1/4-D 1SNA 166 546 R2100 1 Plug.2x4.poles,.with.direct.insertion.Dia..4.mm FI-2/4-DIA4 1SNA 167 936 R1100 1 0.064 Other.2.poles.plugs:.consult.us Please.refer.to.selection.guide.for.socket.compatibility Prewired plugs .(d) 4.poles.prewired.plug.made.of: COR-T-4-1 1SNA 166 640 R1300 1 1.plug.4.poles Grey.. FIT-1/4-D 4.bayonet.security.test.plugs Grey.. FCB.. 4.poles.prewired.plug.made.of: COR-T-4-4 1SNA 167 935 R1000 1 1.plug.4.poles Grey.. FIT-1/4-D 4.x.Ø.4.mm.test.plugs Black.. FC4-5 2x4.poles.prewired.plug.made.of: COR-T-1 1SNA 166 639 R0600 1 0.87 1.plug.2x4.poles. (precoded:.2.2) Grey.. FIT-2/4-1 4.bayonet.security.test.plugs Red.. FCB.. 4.bayonet.security.test.plugs Grey.. FCB.. 2x4.poles.prewired.plug.made.of: COR-T-5 1SNA 167 933 R1600 1 0.87 1.plug.2x4.poles. (precoded:.2.2) Grey.. FIT-2/4-2 4.x.Ø.4.mm.test.plugs Black.. FC4-5 4.x.Ø.4.mm.test.plugs Red.. FC4-4 Technical data IEC 947-1 Socket Plug Screw.clamp.(VL) Ring-tongue.(VA) Pin.BRE Connecting capacity Rigid.conductor 0.2.-.6.mm² Flexible.conductor 0.22.-.4.mm² 0.34.-.10.mm² Wire.stripping.length 9.5.mm./..370" See.Datasheet . wire.0.22.-.0.34.mm² 1SNC 169 040 D1701 . wire.0.75.-.6.mm² Recommended.screwdriver 4.mm./..157" Recommended.torque 0.5-0.8.Nm./.4.4-7.1 lb.in Ø Ø.3.mm Width 7.5.mm Rated.voltage 400.V Impulse.withstand.voltage 4.KV Pollution.degree 3 Rated.current 8.A Short-circuit.current 25.A/5.s.-.800.A/25.ms Storage.temperature.range -25.°C.~.+70.°C Working.temperature.range -10.°C.~.+55.°C Front.panel.protection with.cover IP40 without.cover IP20 Contacts:. -.Make.before.break.. . -.Opened. . . -.Closed. Voltage.range.color.code:.Grey.Body:.Polycarbonate.Conductive.parts:.Silver-plated. (a).The.various.accessories.necessary.for.each.mounting.option.are.supplied.with.the.socket.as.well.as.the.2.coding.pins.COP-E-1.(see.coding.section)..For.reverse.mounting.sockets.drawing,.refer.to."Outer.dimensions,.mounting.instructions".section.(b).Plugs.supplied.with.8.locking.pins.and.2.coding.pins.COP-F-1,.the.BRE.contacts.pins.are.to.be.ordered.separately.(c).Plugs.supplied.with.4.locking.pins,.the.BRE.contacts.pins.are.to.be.ordered.separately.(d).Cable.length:.2m/.6.6".-.Conductors.section:.2.5.mm²,.all..conductors.marked.(marking.starting.with.0.on.the.equipment.side).. Caution:.The. prewired.test.leads.must.be.connected.to.the.equipment.prior.to.the.insertion.of.the.ESSAILEC ® .prewired.plug.on.the.socket. Sockets Plugs Prewired plugs ..The.BRE.contacts.pins.are.to.be.ordered. separately ESSAILEC ® Voltage range 12 | ABB

ES0010 1 2 4 3 17 18 15 11 8 20 10 14 6 7 9 13 16 12 19 21 5 Lids Covers Plugs CPT -1 CPT -2 CPT -5 CPT -4 FI-2/4-DIA4 Universal plug FIT -2/4-2 FIT -2/4-1 FIT -1/4-D FIT -1/4-G FIT -2/4-I reverse mounting I Mounting Sockets TH35 Rail TC-TH35-VL • • • • • • • • • Base Half-base TO-DS-VL • • • (•) (•) • • TC-DS-VL • • • • • (•) (•) TF-DS-VL • • • • Flush TO-E-VA • • (•) (•) • • TC-E-VA • • • • (•) (•) TF-E-VA • • • Half-base TO-D-VA • • (•) (•) • • TC-D-VA • • • • (•) (•) TF-D-VA • • • Reverse TO-I-VA • Flush with lid TC-E-VA-2.2 • • • Selection guide Accessories Rep. Description Type Order code Packaging Weight kg For sockets 1 Lid CPT-1 1SNA 166 646 R0500 1 Lid with electrical continuity CPT-2 1SNA 166 577 R2000 1 2 Cover (a) CPT-5 1SNA 166 930 R2600 1 0.07 Cover with electrical continuity (a) CPT-4 1SNA 166 733 R2400 1 0.08 3 Ring-tongue lug for 10 mm² wire CS-10 1SNA 167 700 R1100 10 4 Socket interlocking peg CVABM 1SNA 183 436 R0500 10 5 TH35 rail mounting kit KEM-3 1SNA 166 962 R0000 10 0.02 6 Mounting kit for DIN 1 rail (a) FX 1SNA 167 682 R2300 10 7 Replacement kit for flush mounting (b) KEM-1 1SNA 166 928 R2000 50 0.02 8 Comb-type jumper bar (b) PCVA 1SNA 167 496 R1100 10 9 Comb-type jumper bar IP20 (c) PCVL 1SNA 167 681 R2200 10 10 Jumper bar for 2 sockets (c) BJ-VL 1SNA 167 680 R0500 10 For plugs 11 Pin 0.22-0.34 mm² BRE-T-0.34 1SNA 168 160 R1400 50 Pin 0.75 mm² BRE-T-0.75 1SNA 167 779 R1300 50 Pin 1 mm² BRE-T-1 1SNA 164 921 R1700 50 Pin 1.5 mm² BRE-T-1.5 1SNA 164 922 R1000 50 Pin 2.5 mm² BRE-T-2.5 1SNA 164 923 R1100 50 Pin 6 mm² BRE-T-6 1SNA 168 147 R0300 50 12 Pin extraction tool EXBR1 1SNA 167 008 R0300 1 13 Crimping tool for BRE pins 1 to 2.5mm² PSC 1SNA 173 181 R1300 1 For test Ø 4 mm test plugs 14 IP20 with mobile protection Red FC4-1 1SNA 167 927 R1000 10 0.01 15 IP20 with permanent protection Black FC4-5 1SNA 167 931 R1400 10 0.01 Red FC4-4 1SNA 167 930 R2700 10 0.01 16 Bayonet security test plug Black FCB-1 1SNA 167 690 R0700 10 0.01 Red FCB-2 1SNA 167 692 R2500 10 0.01 17 Isolating cap for FCB plug CA 1SNA 167 697 R2200 10 18 Straight adaptor IR1 1SNA 167 622 R2600 5 19 H adaptor IR2 1SNA 167 623 R2700 5 20 Isolating cap for IR1 & IR2 adaptors DI 1SNA 167 981 R1700 10 0.01 21 Adaptor between FCB plug and ring-tongue test interface IR3 1SNA 167 624 R2000 10 (a) Compatible with base mounting only.(b) Compatible with ring-tongue connection type socket only (VA).(c) Compatible with screw connection type socket only (VL). Nota: CPT-4 and CPT-5 compatible with TO-DS-VL, TC-DS-VL and TF-DS-VL sockets only in "base" mounting option. (•) Compatible with some restrictions, please consult us. ESSAILEC ® Voltage range ABB | 13

ES0014 PC-DS-VL PC-E-VA PC-E-VA-8.8 FIP-2/4-1. FIP-2/4-2. FIP-1/4-G. FIP-1/4-D. COR-P-1. FI-2/4-DIA4 Ordering details Description Type Order code Packaging Weight kg Sockets .(a) Half-base.mounting./.base.mounting Screw opened.contacts PO-DS-VL 1SNA 166 757 R0400 1 short-circuited.contacts PC-DS-VL 1SNA 166 758 R1500 1 closed.contacts PF-DS-VL 1SNA 166 506 R2200 1 Flush.mounting R.tongue opened.contacts PO-E-VA 1SNA 166 759 R1600 1 short-circuited.contacts PC-E-VA 1SNA 166 763 R0200 1 closed.contacts PF-E-VA 1SNA 166 761 R0000 1 Half-base.mounting R.tongue opened.contacts PO-D-VA 1SNA 166 760 R1300 1 short-circuited.contacts PC-D-VA 1SNA 166 764 R0300 1 closed.contacts PF-D-VA 1SNA 166 762 R0100 1 Flush.mounting.with.lid R.tongue short-circuited.contacts.andprecoded.8.8 PC-E-VA-8.8 1SNA 166 630 R0100 1 Other.preequipped.sockets:.consult.us Plugs Plug.2x4.poles.(b) FIP-2/4-2 1SNA 166 939 R2300 1 0.11 Plug.2x4.poles.(b) FIP-2/4-1 1SNA 166 559 R0600 1 0.09 Plug.4.poles.-.insertion.1-2-3-4.(c) FIP-1/4-G 1SNA 166 556 R2300 1 Plug.4.poles.-.insertion.01-02-03-04.(c) FIP-1/4-D 1SNA 166 555 R2200 1 Plug.2x4.poles,.with.direct.insertion.Dia..4.mm FI-2/4-DIA4 1SNA 167 936 R1100 1 0.064 Please.refer.to.selection.guide.for.socket.compatibility Prewired plugs .(d) 2x4.poles.prewired.plug.(precoded.8.8).made.of: COR-P-1 1SNA 166 642 R0100 1 0.87 1.plug.2x4.poles Blue.. FIP-2/4-1 4.bayonet.security.test.plugs Red.. FCB.. 4.bayonet.security.test.plugs Blue.. FCB.. Contacts:. -.Make.before.break.. . -.Opened. . . -.Closed. Polarity.range.color.code:.Blue.Body:.Polycarbonate.Conductive.parts:.Silver-plated (a).The.various.accessories.necessary.for.each.mounting.option.are.supplied.with.the.socket.as.well.as.the.2.coding.pins.COP-E-1.(see.coding.section).(b).Plugs.supplied.with.8.locking.pins.and.2.coding.pins.COP-F-1,.the.BRE.contacts.pins.are.to.be.ordered.separately.(c).Plugs.supplied.with.4.locking.pins,.the.BRE.contacts.pins.are.to.be.ordered.separately.(d).Prewired.plug.cable.length:.2.m./ 6.6".-.Wire.section.2.5.mm² Sockets Plugs Prewired plugs Technical data IEC Socket Plug Screw.clamp.(VL) Ring-tongue.(VA) Pin.BRE Connecting capacity Rigid.conductor 0.2.-.6.mm² Flexible.conductor 0.22.-.4.mm² 0.34.-.10.mm² Wire.stripping.length 9.5.mm./..370" . wire.0.22.-.0.34.mm² See.Datasheet . wire.0.75.-.6.mm² 1SNC 169 040 D1701 Recommended.screwdriver 4.mm./..157" Recommended.torque 0.5-0.8.Nm./.4.4-7.1 lb.in Ø Ø.3.mm Width 7.5.mm Rated.voltage 400.V Impulse.withstand.voltage 4.KV Pollution.degree 3 Rated.current 8.A Short-circuit.current 25.A/5.s.-.800.A/25.ms Storage.temperature.range -25.°C.~.+70.°C Working.temperature.range -10.°C.~.+55.°C Front.panel.protection with.cover IP40 without.cover IP20 ..The.BRE.contacts.pins.are.to.be.ordered. separately ESSAILEC ® Polarity range 14 | ABB

ES0014 1 4 3 16 17 14 10 7 19 9 13 5 6 8 12 15 11 18 2 Selection guide Accessories Rep. Description Type Order code Packaging Weight kg For sockets 1 Lid CPP-1 1SNA 166 647 R0600 1 Lid.with.electrical.continuity CPP-2 1SNA 166 645 R0400 1 2 Ring-tongue.lug.for.10.mm².wire CS-10 1SNA 167 700 R1100 10 3 Socket.interlocking.peg CVABM 1SNA 183 436 R0500 10 4 Mounting.kit.for.DIN.1.rail.(a) FX 1SNA 167 682 R2300 10 5 Replacement.kit.for.flush.mounting.(b) KEM-1 1SNA 166 928 R2000 50 0.02 6 Comb-type.jumper.bar.(b) PCVA 1SNA 167 496 R1100 10 7 Comb-type.jumper.bar.IP20.(c) PCVL 1SNA 167 681 R2200 10 8 Jumper.bar.for.2.sockets.(c) BJ-VL 1SNA 167 680 R0500 10 For plugs 9 Pin.0.22-0.34.mm² BRE-T-0.34 1SNA 168 160 R1400 50 Pin.0.75.mm² BRE-T-0.75 1SNA 167 779 R1300 50 Pin.1.mm² BRE-T-1 1SNA 164 921 R1700 50 Pin.1.5.mm² BRE-T-1.5 1SNA 164 922 R1000 50 Pin.2.5.mm² BRE-T-2.5 1SNA 164 923 R1100 50 Pin.6.mm² BRE-T-6 1SNA 168 147 R0300 50 10 Pin.extraction.tool EXBR1 1SNA 167 008 R0300 1 11 Crimping.tool.for.BRE.pins 1.to.2.5mm² PSC 1SNA 173 181 R1300 1 For test Ø.4.mm.test.plugs 13 IP20.with.mobile.protection Red. FC4-1 1SNA 167 927 R1000 10 0.01 14 IP20.with.permanent.protection Black. FC4-5 1SNA 167 931 R1400 10 0.01 Red. FC4-4 1SNA 167 930 R2700 10 0.01 14 Bayonet.security.test.plug Black. FCB-1 1SNA 167 690 R0700 10 0.01 Red. FCB-2 1SNA 167 692 R2500 10 0.01 15 Isolating.cap.for.FCB.plug CA 1SNA 167 697 R2200 10 16 Straight.adaptor IR1 1SNA 167 622 R2600 5 17 H.adaptor IR2 1SNA 167 623 R2700 5 18 Isolating.cap.for.IR1.&.IR2.adaptors DI 1SNA 167 981 R1700 10 0.01 19 Adaptor.between.FCB.plug.and. ring-tongue.test.interface IR3 1SNA 167 624 R2000 10 Lids Plugs CPP-1 CPP-2 FI-2/4-DIA4 FIP-2/4-2 FIP-2/4-1 FIP-1/4-D FIP-1/4-G Mounting Sockets Base..Half-base PO-DS-VL • • (•) (•) • • PC-DS-VL • • • • (•) (•) PF-DS-VL • • • • Flush PO-E-VA • • (•) (•) • • PC-E-VA • • • • (•) (•) PF-E-VA • • • • Half-base PO-D-VA • • (•) (•) • • PC-D-VA • • • • (•) (•) PF-D-VA • • • • Flush.with.lid PC-E-VA-2.2 • • (a).Compatible.with.base.mounting.only.(b).Compatible.with.ring-tongue.connection.type.socket.only.(VA).(c).Compatible.with.screw.connection.type.socket.only.(VL). (•) .Compatible.with.some.restrictions,.please.consult.us. ESSAILEC ® Polarity range ABB | 15

ES0016 DEO-D-VA DEF-D-VA DEO-E-VA FIDE-2/4. FIDE-1/4-G. FIDE-1/4-D. FIDE-2/4-2. FI-2/4-DIA4. Ordering details Description Type Order code Packaging Weight kg Sockets .(a) Flush.mounting R.tongue opened.contacts DEO-E-VA 1SNA 166 878 R0600 1 Half-base.mounting R.tongue opened.contacts DEO-D-VA 1SNA 166 874 R2200 1 closed.contacts DEF-D-VA 1SNA 166 896 R1100 1 Other.sockets:.consult.us Plugs . Plug.2x4.poles.(b) FIDE-2/4 1SNA 166 877 R2500 1 0.09 Plug.2x4.poles.(b) FIDE-2/4-2 1SNA 166 943 R2700 1 0.11 Plug.4.poles.-.insertion.1-2-3-4.(c) FIDE-1/4-G 1SNA 166 898 R2300 1 Plug.4.poles.-.insertion.01-02-03-04.(c) FIDE-1/4-D 1SNA 166 897 R1200 1 Plug.2x4.poles,.with.direct.insertion.Dia..4.mm FI-2/4-DIA4 1SNA 167 936 R1100 1 0.064 Contacts:. -.Opened.. . -.Closed. . Trip.range.color.code:.Orange.Body:.Polycarbonate.Conductive.parts:.Silver-plated (a).The.various.accessories.necessary.for.each.mounting.option.are.supplied.with.the.socket.as.well.as.the.2.coding.pins.COP-E-1.(see.coding.section).(b).Plugs.supplied.with.8.locking.pins.and.2.coding.pins.COP-F-1,.the.BRE.contacts.pins.are.to.be.ordered.separately.(c).Plugs.supplied.with.4.locking.pins,.the.BRE.contacts.pins.are.to.be.ordered.separately. Sockets Technical data IEC Socket Plug Screw.clamp.(VL) Ring-tongue.(VA) Pin.BRE Connecting capacity Rigid.conductor 0.2.-.6.mm² Flexible.conductor 0.22.-.4.mm² 0.34.-.10.mm² Wire.stripping.length 9.5.mm./..370" . wire.0.22.-.0.34.mm² See.Datasheet . wire.0.75.-.6.mm² 1SNC 169 040 D1701 Recommended.screwdriver 4.mm./..157" Recommended.torque 0.5-0.8.Nm./.4.4-7.1 lb.in Ø Ø.3.mm Width 7.5.mm Rated.voltage 400.V Impulse.withstand.voltage 4.KV Pollution.degree 3 Rated.current 8.A Short-circuit.current 25.A/5.s.-.800.A/25.ms Storage.temperature.range -25.°C.~.+70.°C Working.temperature.range -10.°C.~.+55.°C Front.panel.protection with.cover IP40 without.cover IP20 Plugs ..The.BRE.contacts.pins.are.to.be.ordered. separately ESSAILEC ® Trip range 16 | ABB

ES0016 1 4 3 16 17 14 10 7 19 9 13 5 6 8 12 15 11 18 2 Accessories Rep. Description Type Order code Packaging Weight kg For sockets 1 Lid CPDE-1 1SNA 166 876 R2400 1 Lid.with.electrical.continuity CPDE-2 1SNA 166 926 R1600 1 2 Ring-tongue.lug.for.10.mm².wire CS-10 1SNA 167 700 R1100 10 3 Socket.interlocking.peg CVABM 1SNA 183 436 R0500 10 4 Mounting.kit.for.DIN.1.rail.(a) FX 1SNA 167 682 R2300 10 5 Replacement.kit.for.flush.mounting.(b) KEM-1 1SNA 166 928 R2000 50 0.02 6 Comb-type.jumper.bar.(b) PCVA 1SNA 167 496 R1100 10 7 Comb-type.jumper.bar.IP20.(c) PCVL 1SNA 167 681 R2200 10 8 Jumper.bar.for.2.sockets.(c) BJ-VL 1SNA 167 680 R0500 10 For plugs 9 Pin.0.22-0.34.mm² BRE-T-0.34 1SNA 168 160 R1400 50 Pin.0.75.mm² BRE-T-0.75 1SNA 167 779 R1300 50 Pin.1.mm² BRE-T-1 1SNA 164 921 R1700 50 Pin.1.5.mm² BRE-T-1.5 1SNA 164 922 R1000 50 Pin.2.5.mm² BRE-T-2.5 1SNA 164 923 R1100 50 Pin.6.mm² BRE-T-6 1SNA 168 147 R0300 50 10 Pin.extraction.tool EXBR1 1SNA 167 008 R0300 1 11 Crimping.tool.for.BRE.pins 1.to.2.5mm² PSC 1SNA 173 181 R1300 1 For test Ø.4.mm.test.plugs 12 IP20.with.mobile.protection Red. FC4-1 1SNA 167 927 R1000 10 0.01 13 IP20.with.permanent.protection Black. FC4-5 1SNA 167 931 R1400 10 0.01 Red. FC4-4 1SNA 167 930 R2700 10 0.01 14 Bayonet.security.test.plug Black. FCB-1 1SNA 167 690 R0700 10 0.01 Red. FCB-2 1SNA 167 692 R2500 10 0.01 15 Isolating.cap.for.FCB.plug CA 1SNA 167 697 R2200 10 16 Straight.adaptor IR1 1SNA 167 622 R2600 5 17 H.adaptor IR2 1SNA 167 623 R2700 5 18 Isolating.cap.for.IR1.&.IR2.adaptors DI 1SNA 167 981 R1700 10 0.01 19 Adaptor.between.FCB.plug.and. ring-tongue.test.interface IR3 1SNA 167 624 R2000 10 (a).Compatible.with.base.mounting.only.(b).Compatible.with.ring-tongue.connection.type.socket.only.(VA).(c).Compatible.with.screw.connection.type.socket.only.(VL). ESSAILEC ® Trip range ABB | 17

ES0019 M10-D-C5A FIM10-I-1. FIM10-1. M10-I-C5A-1 1 2 4 3 Ordering details Description Type Order code Packaging Weight kg Sockets . Half-base.mounting Q-connect M10-D-C5A 1SNA 166 513 R1000 10 0.06 Rack.mounting Q-connect M10-R-C5A 1SNA 166 566 R2500 10 Reverse.mounting Q-connect M10-I-C5A-1 1SNA 166 774 R0500 10 Reverse.mounting Q-connect M20-I-C5A 1SNA 166 777 R0000 1 Extension.mounting Q-connect M10-P-C5A 1SNA 166 772 R0300 1 Other.sockets:.consult.us Plugs . Plug.for.M10-D-C5A.socket FIM10-1 1SNA 166 516 R1300 10 0.06 Plug.for.M10-R-C5A.socket FIM10-R 1SNA 166 573 R2400 1 Plug.for.M10-I-C5A-1.socket FIM10-I-1 1SNA 166 574 R2500 1 Plug.for.M20-I-C5A.socket FIM20-I 1SNA 166 576 R2700 1 Accessories Rep. Description Type Order code Packaging Weight kg For sockets 1 Socket.interlocking.peg CVABM 1SNA 183 436 R0500 10 For plugs 2 Pin.0.22-0.34.mm² BRE-T-0.34 1SNA 168 160 R1400 50 Pin.0.75.mm² BRE-T-0.75 1SNA 167 779 R1300 50 Pin.1.mm² BRE-T-1 1SNA 164 921 R1700 50 Pin.1.5.mm² BRE-T-1.5 1SNA 164 922 R1000 50 Pin.2.5.mm² BRE-T-2.5 1SNA 164 923 R1100 50 Pin.6.mm² BRE-T-6 1SNA 168 147 R0300 50 3 Pin.extraction.tool EXBR1 1SNA 167 008 R0300 1 4 Crimping.tool.for.BRE.pins 1.to.2.5mm² PSC 1SNA 173 181 R1300 1 Technical data IEC Socket Plug Quick-connect.(C5A) Pin.BRE Connecting capacity Rigid.conductor Flexible.conductor 2.5.mm² Wire.stripping.length See.Datasheet . wire.0.22.-.0.34.mm² 1SNC 169 040 D1701 . wire.0.75.-.6.mm² Quick-connect 5.x.0.8.mm Rated.voltage 400.V Impulse.withstand.voltage 4.KV Pollution.degree 3 Rated.current 8.A Short-circuit.current 25.A/5.s.-.800.A/25.ms Storage.temperature.range -25.°C.~.+70.°C Working.temperature.range -10.°C.~.+55.°C Front.panel.protection IP.20 Application:.High.density.panel.board.wiring..Alternative.to.large.terminal.strips. Body:.Polycarbonate.Conductive.parts:.Silver-plated Sockets Plugs The.various.accessories.necessary.for.each.mounting.option.are.supplied.with.the.socket.as.well.as.the.2.coding.pins.COP-E-1.(see.coding.section). ..The.BRT.contacts.pins.are.to.be.ordered. separately ESSAILEC ® Multicircuits range 10, 20 points 18 | ABB

ES0020 COP-E-1 COP-FI-1 1 2 1 Description Type Order code Packaging Weight kg Socket.coding.pin COP-E-1 1SNA 167 379 R1200 10 Plug.coding.pin COP-FI-1 1SNA 167 378 R1100 10 Supplied.with.sockets.and.plugs Socket Plug Coding.pins.index On socket: Insert.completely.the.coding.pin.COP-E-1.in.its.housing. Choose.a.coding.code.(12-12.for.instance). Position.12 On plug: In. order. to. guarantee. a. perfect. compatibility.between.the.socket.coding.and.the.plug.coding,.the.following.must.be.done: Place.the.COP-FI-1.coding.pin.in.the.opening.left.by.the.socket.coding.pin. Connect.the.plug.on.the.socket.in.order.to.insert.the.plug.coding.pin.in.its.housing. index.for. initial.position. identification reading.direction Reading.direction 2 ESSAILEC ® Coding ABB | 19

ES0018 44 80.2 51.5 59 63 35 73 = = 2 x M3 4 x M4 1 2 1 2 44 80.2 49.5 63 Socket Flush mounting The.flush.mounting.kit.must.be.mounted.on.the.socket.prior.to.the.installation.on.the.panel. Half-base mountingRack mounting Base mounting G32 rail mounting Plugs Reverse mounting Lid Cover Pin installation on plug BRE.pin Locking.pin,. supplied.with.the.plug Tightening.torque.=.0.5.Nm.maxi. 0.5.Nm. .Tightening.torque. .0.8.Nm 0.5.Nm. .Tightening.torque. .0.8.Nm The.rack.mounting.is.supplied.with.2.additional.guiding.pins. TH35 rail mounting Base mounting with KEM-3 Assembly.. Disassembly ESSAILEC ® Outer dimensions, mounting instructions 20 | ABB

ES0021 ESSAILEC ® Index 1SNA.164.921.R1700. BRE-T-1. 13 1SNA.164.922.R1000. BRE-T-1.5. 13 1SNA.164.923.R1100. BRE-T-2.5. 13 1SNA.166.500.R0000. CC-DS-VL. 10 1SNA.166.503.R2700. TF-DS-VL. 12 1SNA.166.506.R2200. PF-DS-VL. 14 1SNA.166.513.R1000. M10-D-C5A. 18 1SNA.166.516.R1300. FIM10-1. 18 1SNA.166.523.R1200. CC-R-VA. 10 1SNA.166.525.R1400. FIC-2/4-1. 10 1SNA.166.529.R2000. FIC-2/4-R. 10 1SNA.166.546.R2100. FIT-1/4-D. 12 1SNA.166.547.R2200. FIT-1/4-G. 12 1SNA.166.550.R0100. FIT-2/4-1. 12 1SNA.166.555.R2200. FIP-1/4-D. 14 1SNA.166.556.R2300. FIP-1/4-G. 14 1SNA.166.559.R0600. FIP-2/4-1. 14 1SNA.166.566.R2500. M10-R-C5A. 18 1SNA.166.573.R2400. FIM10-R. 18 1SNA.166.574.R2500. FIM10-I-1. 18 1SNA.166.576.R2700. FIM20-I. 18 1SNA.166.577.R2000. CPT-2. 13 1SNA.166.578.R0100. CPC-1. 11 1SNA.166.589.R2500. FIC-2/4-I. 10 1SNA.166.625.R2000. CC-E-VA-6.6. 10 1SNA.166.627.R2200. TC-E-VA-2.2. 12 1SNA.166.630.R0100. PC-E-VA-8.8. 14 1SNA.166.638.R0500. COR-C-1. 10 1SNA.166.639.R0600. COR-T-1. 12 1SNA.166.640.R1300. COR-T-4-1. 12 1SNA.166.642.R0100. COR-P-1. 14 1SNA.166.643.R0200. COR-C-3. 10 1SNA.166.645.R0400. CPP-2. 15 1SNA.166.646.R0500. CPT-1. 13 1SNA.166.647.R0600. CPP-1. 15 1SNA.166.672.R0700. FIT-2/4-I. 12 1SNA.166.733.R2400. CPT-4. 13 1SNA.166.734.R2500. CPC-7. 11 1SNA.166.737.R2000. CC-E-VA. 10 1SNA.166.738.R0100. CC-D-VA. 10 1SNA.166.741.R0400. TO-DS-VL. 12 1SNA.166.742.R0500. TC-DS-VL. 12 1SNA.166.743.R0600. TO-E-VA. 12 1SNA.166.744.R0700. TO-D-VA. 12 1SNA.166.745.R0000. TF-E-VA. 12 1SNA.166.746.R0100. TF-D-VA. 12 1SNA.166.747.R0200. TC-E-VA. 12 1SNA.166.748.R1300. TC-D-VA. 12 1SNA.166.757.R0400. PO-DS-VL. 14 1SNA.166.758.R1500. PC-DS-VL. 14 1SNA.166.759.R1600. PO-E-VA. 14 1SNA.166.760.R1300. PO-D-VA. 14 1SNA.166.761.R0000. PF-E-VA. 14 1SNA.166.762.R0100. PF-D-VA. 14 1SNA.166.763.R0200. PC-E-VA. 14 1SNA.166.764.R0300. PC-D-VA. 14 1SNA.166.772.R0300. M10-P-C5A. 18 1SNA.166.774.R0500. M10-I-C5A-1. 18 1SNA.166.777.R0000. M20-I-C5A. 18 1SNA.166.778.R1100. COR-C-2. 10 1SNA.166.819.R2300. FIC-2/1-1. 10 1SNA.166.821.R1500. FIT-2/1-1. 12 1SNA.166.874.R2200. DEO-D-VA. 16 1SNA.166.876.R2400. CPDE-1. 17 1SNA.166.877.R2500. FIDE-2/4. 16 1SNA.166.878.R0600. DEO-E-VA. 16 1SNA.166.896.R1100. DEF-D-VA. 16 1SNA.166.897.R1200. FIDE-1/4-D. 16 1SNA.166.898.R2300. FIDE-1/4-G. 16 1SNA.166.926.R1600. CPDE-2. 17 1SNA.166.928.R2000. KEM-1. 11 1SNA.166.930.R2600. CPT-5. 13 1SNA.166.936.R1000. FIC-2/4-2. 10 1SNA.166.937.R1100. FIT-2/4-2. 12 1SNA.166.939.R2300. FIP-2/4-2. 14 1SNA.166.941.R2500. CC-I-VA-2. 10 1SNA.166.943.R2700. FIDE-2/4-2. 16 1SNA.166.945.R2100. TO-I-VA-2. 12 1SNA.166.962.R0000. KEM-3. 11 1SNA.166.963.R0000. CC-TH35-VL-6.6. 10 1SNA.166.964.R0000. TC-TH35-VL. 12 1SNA.167.008.R0300. EXBR1. 11 1SNA.167.260.R1700. BRE-C-2.5. 11 1SNA.167.264.R0700. BRE-C-1. 11 1SNA.167.265.R0000. BRE-C-1.5. 11 1SNA.167.378.R1100. COP-FI-1. 19 1SNA.167.379.R1200. COP-E-1. 19 1SNA.167.496.R1100. PCVA. 11 1SNA.167.622.R2600. IR1. 11 1SNA.167.623.R2700. IR2. 11 1SNA.167.624.R2000. IR3. 11 1SNA.167.680.R0500. BJ-VL. 11 1SNA.167.681.R2200. PCVL. 11 1SNA.167.682.R2300. FX. 11 1SNA.167.690.R0700. FCB-1. 11 1SNA.167.692.R2500. FCB-2. 11 1SNA.167.697.R2200. CA. 11 1SNA.167.700.R1100. CS-10. 11 1SNA.167.779.R1300. BRE-T-0.75. 13 1SNA.167.927.R1000. FC4-1. 11 1SNA.167.930.R2700. FC4-4. 11 1SNA.167.931.R1400. FC4-5. 11 1SNA.167.932.R1500. COR-C-4. 10 1SNA.167.933.R1600. COR-T-5. 12 1SNA.167.934.R1700. COR-C-5. 10 1SNA.167.935.R1000. COR-T-4-4. 12 1SNA.167.936.R1100. FI-2/4-DIA4. 12 1SNA.167.937.R0000. FIC-2/4-DIA4. 10 1SNA.167.981.R1700. DI. 11 1SNA.168.146.R0200. BRE-C-6. 11 1SNA.168.147.R0300. BRE-T-6. 13 1SNA.168.160.R1400. BRE-T-0.34. 13 1SNA.173.181.R1300. PSC. 11 1SNA.183.436.R0500. CVABM. 11 1SNA.205.876.R0400. BRE-C-4. 11 B BJ-VL. 1SNA.167.680.R0500. 11 BRE-C-1. 1SNA.167.264.R0700. 11 BRE-C-1.5. 1SNA.167.265.R0000. 11 BRE-C-2.5. 1SNA.167.260.R1700. 11 BRE-C-4. 1SNA.205.876.R0400. 11 BRE-C-6. 1SNA.168.146.R0200. 11 BRE-T-0.34. 1SNA.168.160.R1400. 13 BRE-T-0.75. 1SNA.167.779.R1300. 13 BRE-T-1. 1SNA.164.921.R1700. 13 BRE-T-1.5. 1SNA.164.922.R1000. 13 BRE-T-2.5. 1SNA.164.923.R1100. 13 BRE-T-6. 1SNA.168.147.R0300. 13 C CA. 1SNA.167.697.R2200. 11 CC-DS-VL. 1SNA.166.500.R0000. 10 CC-D-VA. 1SNA.166.738.R0100. 10 CC-E-VA. 1SNA.166.737.R2000. 10 CC-E-VA-6.6. 1SNA.166.625.R2000. 10 CC-I-VA-2. 1SNA.166.941.R2500. 10 CC-R-VA. 1SNA.166.523.R1200. 10 CC-TH35-VL-6.6.1SNA.166.963.R0000. 10 COP-E-1. 1SNA.167.379.R1200. 19 COP-FI-1. 1SNA.167.378.R1100. 19 COR-C-1. 1SNA.166.638.R0500. 10 COR-C-2. 1SNA.166.778.R1100. 10 COR-C-3. 1SNA.166.643.R0200. 10 COR-C-4. 1SNA.167.932.R1500. 10 COR-C-5. 1SNA.167.934.R1700. 10 COR-P-1. 1SNA.166.642.R0100. 14 COR-T-1. 1SNA.166.639.R0600. 12 COR-T-4-1. 1SNA.166.640.R1300. 12 COR-T-4-4. 1SNA.167.935.R1000. 12 COR-T-5. 1SNA.167.933.R1600. 12 CPC-1. 1SNA.166.578.R0100. 11 CPC-7. 1SNA.166.734.R2500. 11 CPDE-1. 1SNA.166.876.R2400. 17 CPDE-2. 1SNA.166.926.R1600. 17 CPP-1. 1SNA.166.647.R0600. 15 CPP-2. 1SNA.166.645.R0400. 15 CPT-1. 1SNA.166.646.R0500. 13 CPT-2. 1SNA.166.577.R2000. 13 CPT-4. 1SNA.166.733.R2400. 13 CPT-5. 1SNA.166.930.R2600. 13 CS-10. 1SNA.167.700.R1100. 11 CVABM. 1SNA.183.436.R0500. 11 D DEF-D-VA. 1SNA.166.896.R1100. 16 DEO-D-VA. 1SNA.166.874.R2200. 16 DEO-E-VA. 1SNA.166.878.R0600. 16 DI. 1SNA.167.981.R1700. 11 E EXBR1. 1SNA.167.008.R0300. 11 F FC4-1. 1SNA.167.927.R1000. 11 FC4-4. 1SNA.167.930.R2700. 11 FC4-5. 1SNA.167.931.R1400. 11 FCB-1. 1SNA.167.690.R0700. 11 FCB-2. 1SNA.167.692.R2500. 11 FI-2/4-DIA4. 1SNA.167.936.R1100. 12 FIC-2/1-1. 1SNA.166.819.R2300. 10 FIC-2/4-1. 1SNA.166.525.R1400. 10 FIC-2/4-2. 1SNA.166.936.R1000. 10 FIC-2/4-DIA4. 1SNA.167.937.R0000. 10 FIC-2/4-I. 1SNA.166.589.R2500. 10 FIC-2/4-R. 1SNA.166.529.R2000. 10 FIDE-1/4-D. 1SNA.166.897.R1200. 16 FIDE-1/4-G. 1SNA.166.898.R2300. 16 FIDE-2/4. 1SNA.166.877.R2500. 16 FIDE-2/4-2. 1SNA.166.943.R2700. 16 FIM10-1. 1SNA.166.516.R1300. 18 FIM10-I-1. 1SNA.166.574.R2500. 18 FIM10-R. 1SNA.166.573.R2400. 18 FIM20-I. 1SNA.166.576.R2700. 18 FIP-1/4-D. 1SNA.166.555.R2200. 14 FIP-1/4-G. 1SNA.166.556.R2300. 14 FIP-2/4-1. 1SNA.166.559.R0600. 14 FIP-2/4-2. 1SNA.166.939.R2300. 14 FIT-1/4-D. 1SNA.166.546.R2100. 12 FIT-1/4-G. 1SNA.166.547.R2200. 12 FIT-2/1-1. 1SNA.166.821.R1500. 12 FIT-2/4-1. 1SNA.166.550.R0100. 12 FIT-2/4-2. 1SNA.166.937.R1100. 12 FIT-2/4-I. 1SNA.166.672.R0700. 12 FX. 1SNA.167.682.R2300. 11 I IR1. 1SNA.167.622.R2600. 11 IR2. 1SNA.167.623.R2700. 11 IR3. 1SNA.167.624.R2000. 11 K KEM-1. 1SNA.166.928.R2000. 11 KEM-3. 1SNA.166.962.R0000. 11 M M10-D-C5A. 1SNA.166.513.R1000. 18 M10-I-C5A-1. 1SNA.166.774.R0500. 18 M10-P-C5A. 1SNA.166.772.R0300. 18 M10-R-C5A. 1SNA.166.566.R2500. 18 M20-I-C5A. 1SNA.166.777.R0000. 18 P PC-DS-VL. 1SNA.166.758.R1500. 14 PC-D-VA. 1SNA.166.764.R0300. 14 PC-E-VA. 1SNA.166.763.R0200. 14 PC-E-VA-8.8. 1SNA.166.630.R0100. 14 PCVA. 1SNA.167.496.R1100. 11 PCVL. 1SNA.167.681.R2200. 11 PF-DS-VL. 1SNA.166.506.R2200. 14 PF-D-VA. 1SNA.166.762.R0100. 14 PF-E-VA. 1SNA.166.761.R0000. 14 PO-DS-VL. 1SNA.166.757.R0400. 14 PO-D-VA. 1SNA.166.760.R1300. 14 PO-E-VA. 1SNA.166.759.R1600. 14 PSC. 1SNA.173.181.R1300. 11 T TC-DS-VL. 1SNA.166.742.R0500. 12 TC-D-VA. 1SNA.166.748.R1300. 12 TC-E-VA. 1SNA.166.747.R0200. 12 TC-E-VA-2.2. 1SNA.166.627.R2200. 12 TC-TH35-VL. 1SNA.166.964.R0000. 12 TF-DS-VL. 1SNA.166.503.R2700. 12 TF-D-VA. 1SNA.166.746.R0100. 12 TF-E-VA. 1SNA.166.745.R0000. 12 TO-DS-VL. 1SNA.166.741.R0400. 12 TO-D-VA. 1SNA.166.744.R0700. 12 TO-E-VA. 1SNA.166.743.R0600. 12 TO-I-VA-2. 1SNA.166.945.R2100. 12 Order code Type Page Order code Type Page Type Order code Page Type Order code Page
