ABB Home Range Catalogue

Many applications, one range With the new Home Range you have at your disposal a complete range of circuit-breakers for building applications: the advance technology of an industrial leader, ABB is now applied to the residential sector too. High protection and versatility  SH200 MCB’s and FH200 RCD’s guarantee the two essential protections in the residential sector: protection for circuits and appliances against over currents and short-circuits, as well as protection for people and installations against earth fault currents. The new DSN201 RCBO is designed to fulfil the requirements of domestic circuit protection by providing the latest technology residual current protection combined with over-current circuit protection (thermal and magnetic short circuit protection). Quick and safe installation All the necessary technical and installation information can be found directly on the devices.  You just need to unpack and install them! Caring for the environment ABB has always paid attention to producing devices with the lowest environmental impact, guaranteeing the reusability of the materials employed during fabrication. A range for all building installation requirements. Versatile, easy to install and suitable for integration with  ABB products. Home range Advanced range, complete protection

Components and benefits Recognisable quality, visible effectiveness Terminals for  flexible cabling The terminals accept notonly wires but also busbars.Supply is possible both from top and bottom terminals.  Space for insulated  screwdrivers The larger neutral hole allows the use of an insulated screwdriver to tighten the screws of both phase and neutral terminals, ensuring maximum safety of the operation.  Product coding All the necessary technical and installation information can be found directly on the devices. Product range, tripping characteristics, rated currents, sensitivity, type, breaking capacity, rated voltage, order code, EAN code, electrical scheme, reference standards and many other specification are laser printed in the front and on the side of the units. Anti-counterfeiting Each DSN201 is equipped with a RFid tag containing a unique serial number assigned by ABB according to ISO/IEC FCD 15693-3 standard in order to authenticate the product. Through this unique serial number, ABB can easily identify counterfeited products and verify the authenticity of each single device.  Test button Test button allows regular checking of the functionality of the device. Label carrier for a  clear identification Complex systems require easier identification of the sections corresponding to each single unit installed in the switchboard. With the practical label carrier fitted in the new RCBO you can guarantee maximum visibility to information relating the protected loads.

Domestic and light commercial MCB’s and isolators  MCB - 6kA - C curve /  complies with AS/NZS 60898 Rated Current 1 Pole 3 Pole  6A SH201C6 SH203C6 8A SH201C8 SH203C8 10A SH201C10 SH203C10 13A SH201C13 SH203C13 16A SH201C16 SH203C16 20A SH201C20 SH203C20 25A SH201C25 SH203C25 32A SH201C32 SH203C32 40A SH201C40 SH203C40   Isolating Switches / complies with IEC 60947-3 Rated Current 1 Pole 3 Pole 63A E20163RD E20363RD 80A E20180RD E20380RD 100A E201100RD E203100RD Residential MCB’s - 6kA - C curveMCB’s protect installations against overload and short circuits Isolating switchesSuitable for under load operations

Domestic and light commercial RCBO’s and RCD’s   2 Module RCBO (6kA, 30mA) / complies with AS/NZS 61009 Rated Current 1 P + N 6A DS201BSC6 10A DS201BSC10 16A DS201BSC16 20A DS201BSC20 25A DS201BSC25 32A DS201BSC32 40A DS201BSC40   RCD (6kA, 30mA) / complies with AS/NZS 61008 Rated Current 2 Pole  Pole 25A FH20225 FH20425 40A FH20240 FH20440 63A FH20263 FH20463 Compact Single Pole RCBO (1P+N, 6kA, 30mA) / complies with  AS/NZS 61009 Rated Current 1 Pole 6A DSN201C6 10A DSN201C10 16A DSN201C16 20A DSN201C20 RCBO’s - 6kA - C curve - 30mARCBO’s combine in a single device the residual current function and the overcurent protection function typical of MCB’s RCD’s - 6kA - 30mARCD’s assure a protection to people and installations against fault current to earth

Busbars For use with SH200, DS200 and FH200 Busbars not to be cut to length (closed design) no end caps required Phases No of pins Capacity mm 2 Amps Order Code 1 12 10 63 PS 1/12 3 12 10 63 PS 3/12 1 phase busbars suitable to cut to length - use end caps PS-END 0 Phases No of pins Capacity mm 2 Amps Order Code 1 12 10 63 PS 1/12N End cap to suit PS 1/12N busbar PS-END 0 3 phase busbars suitable to cut to length - use end caps PS-END  Phases No of pins Capacity mm 2 Amps Order Code 3 60 16 80 PS 3/60/16 End cap to suit PS 3/60/16 busbar PS-END  Busbars For use with DSN201 Basbars not to be cut to length (closed design) no end caps required Phases No of pins Capacity mm 2 Amps Order Code 1 12 10 63 BS9 1/12 1 12 10 63 BS9 1/12NA 3 tunnel link for fitting to RCD’s Order Code 3 x 10mm 2  tunnels (1 screw) F200LINK 3 Terminal connector   for RCD FH200 Locking device Lock out device for MCB’s, RCD’s and RCBO’S Order Code Locking device - suits SH200, FH200 S2C-PD-S200 Locking device - suits DS201 S2C-PD-DS201 Locking device - suits DSN201 S2C-PD-DSN201 Domestic and light commercial Accessories

Domestic and light commercial Consumer units and load centres  Metal load centres Pole Capacity Dimensions h x w x d (mm) Order Code 12 way (1 x 12P) 250 x 340 x 70 ABBM12SM 18 way (1 x 18P) 250 x 490 x 70 ABBM18SM 24 way (2 x 12P) 420 x 340 x 70 ABBM24SM  Plastic consumer units Pole Capacity Description Order Code 12 way (1 x 12P) flush mount, white door LC12FMW flush mount, transparent door LC12FMT surface mount, white door LC12SW surface mount, transparent door LC121ST 18 way (1 x 18P) flush mount, white door LC18FMW flush mount, transparent door LC18FMT surface mount, white door LC18SW surface mount, transparent door LC18ST 24 way (2 x 12P) flush mount, white door LC24FMW flush mount, transparent door LC24FMT surface mount, white door LC24SW surface mount, transparent door LC24ST

Contact us The data and illustrations are not binding. We reserve the right to modify the contents of this document on the basis of technical development of the products, without prior notice. Copyright 2013 ABB. All rights reserved. ABB Australia Pty LimitedVictoria601 Blackburn RoadNotting Hill VIC 3168AustraliaTel:  1300 660 299 Fax:  1300 853 138 Email:  [email protected]:   www.abbaustralia.com.au/lowvoltage AUABBLPEDHR02042013
