Crompton fluorescent lamps
F Fluorescent
Triphosphor T8 26mm Lamps ....................................379Triphosphor T5 16mm Lamps ....................................380Rapid Start T12 MCFE Fluorescent Lamps ...............381Fluorescent Plant Growth Lamps ...............................381Miniature T5 and T8 Fluorescent Lamps ...................382Fluorescent T4 Linkable Lamps .................................383Fluorescent T8 26mm Coloured Lamps ...................384Fluorescent Blacklight Blue and Blacklight Lamps ...385Circular Fluorescents ...................................................386T5 Circular Fluorescents ..............................................387Protect-O-Sleeve with End Caps .................................388Fluorescent Starters ....................................................388Fluorescent Compact PL/PLC Lamps .........................389Fluorescent Electronic Energy Saving Lamps ..........390
379 E.&.O.E. CC 04/11 F Fluorescent Lamps Tri-phosphor T8 26mm Lamps This extensive range of tri-phosphor T8 fluorescent lamps comply with the Minimum Energy Performance Standards (MEPS) for fluorescent lamps as set by the Australian Government. Their long effective lamp life combined with their superb colour rending capabilities makes them a value for money solution to lighting applications Features •High colour rendering capabilities create a more natural and vibrant working environment (to DIN 5035 Group 1B, Ra 80-89) (except for 70 series) •Higher light output over lamp life combined with more constant lumen maintenance (Luminous efficacy of up to 104 lm/W) •Maximum luminous flux is achieved at around 35°C •May be operated with standard control gear and starters or with electronic control gear. Maximum efficacy is achieved with electronic control gear •Colour temperature of 3000K to 6000K •Manufactured to Australian Standard AS/NZS 4782.1:2004 Applications •For domestic, commercial and industrial general lighting applications where performance and high colour rendering capabilities are important •Ideally suited to use in shop lighting where colour rendition is important for product display •Suitable for use indoors and in enclosed exterior fittings Lamp Life •The recommended economical service life is 10000 hours with standard control gear and up to 18000 hours with warm start electronic control gear Burning Position •Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity FLUORESCENT TRIPHOSPHOR SUPER 80 T8 26MM LINEAR 18W WARM WHITE BI-PIN 26 x 600 3000K 1350 F18W830 11163 25 18W COOL WHITE BI-PIN 26 x 600 4000K 1350 F18W840 11164 25 18W NATURAL BI-PIN 26 x 600 5000K 1300 F18W850 10076 25 18W DAYLIGHT BI-PIN 26 x 600 6000K 1300 F18W860 15489 25 30W COOL WHITE BI-PIN 26 x 900 4000K 2000 F30W840 24759 25 30W NATURAL BI-PIN 26 x 900 5000K 2300 F30W850 12759 25 30W DAYLIGHT BI-PIN 26 x 900 6000K 2250 F30W860 15948 25 36W WARM WHITE BI-PIN 26 x 1200 3000K 3350 F36W830 17735 25 36W COOL WHITE BI-PIN 26 x 1200 4000K 3350 F36W840 11178 25 36W NATURAL BI-PIN 26 x 1200 5000K 3300 F36W850 14160 25 36W DAYLIGHT BI-PIN 26 x 1200 6000K 3250 F36W860 15488 25 58W WARM WHITE BI-PIN 26 x 1500 3000K 5200 F58W830 11190 25 58W COOL WHITE BI-PIN 26 x 1500 4000K 5200 F58W840 11191 25 58W NATURAL BI-PIN 26 x 1500 5000K 5100 F58W850 14159 25 58W DAYLIGHT BI-PIN 26 x 1500 6000K 5000 F58W860 16905 25
F 380 E.&.O.E. CC 04/11 Fluorescent Lamps Tri-phosphor T5 16mm Lamps This extensive range of tri-phosphor T5 fluorescent lamps features higher light output for the same energy consumption as standard T5 fluorescent, with a lower rate of light loss with age. Their longer effective lamp life combined with their superb colour rendering capabilities makes them a value for money solution to lighting applications Features •High colour rendering capabilities, create a more natural and vibrant working environment (to DIN 5035 Group 1B, Ra 80-89) •Higher light output over lamp life combined with more constant lumen maintenance (Luminous efficacy of up to 94 lm/W) •Maximum luminous flux is achieved at around 35°C •Higher luminaire efficiency as a result of the small tube size offering better optical control •Suitable only for electronic control gear •Colour temperature of 3000K and 4000K Applications •For domestic and commercial task and accent lighting applications where performance and high colour rendering capabilities are important •Ideally suited to use in cabinet lighting and emergency luminaires •Suitable for use indoors and in enclosed exterior fittings Lamp Life •The recommended economical service life is 10000 hours with standard control gear and up to 18000 hours with warm start electronic control gear Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity FLUORESCENT TRI-PHOSPHOR T5 16MM LINEAR 14W WARM WHITE BI-PIN 16 x 563 3000K 1200 T514W830 24651 25 14W COOL WHITE BI-PIN 16 x 563 4000K 1200 T514W840 18070 25 21W WARM WHITE BI-PIN 16 x 863 3000K 1900 T521W830 24652 25 21W COOL WHITE BI-PIN 16 x 863 4000K 1900 T521W840 18071 25 28W WARM WHITE BI-PIN 16 x 1163 3000K 2470 T528W830 24653 25 28W COOL WHITE BI-PIN 16 x 1163 4000K 2470 T528W840 18072 25 35W WARM WHITE BI-PIN 16 x 1463 3000K 3135 T535W830 24654 25 35W COOL WHITE BI-PIN 16 x 1463 4000K 3135 T535W840 18073 25
381 E.&.O.E. CC 04/11 F Fluorescent Lamps Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity FLUORESCENT 20W COOL WHITE BI-PIN 38 x 600 4000K 1350 F20T12 24590 25 40W COOL WHITE BI-PIN 38 x 1200 4000K 3200 F40T12 24591 25 Rapid Start Tri-phosphor 80 Series T12 MCFE Fluorescent Lamps Low pressure discharge lamps with a clear 38mm tube internally coated with fluorescent powder Features • Colour temperature of 4000K • For use on rapid start control gear - does not require a starter • Complies with Minimum Energy Performance Standard: AS/NZS 4782.2:2004 Applications • For commercial applications where rapid start control systems are utilised • Suitable for indoor use only Burning Position • Universal Fluorescent Plant Growth These 26mm fluorescent plant growth tubes provide the correct balance of red and blue wave lengths essential for germination, propagation, growth and photosynthesis in indoor plants Features • Provides essential energy for plant growth and maintenance by providing the correct balance of light in the red and blue spectrums • Energy efficient and cost effective when compared to incandescent plant growth lamps • Internally fused for safety Applications • May be used as a supplementary or complete light source for plants in greenhouses, horticulture and indoor gardens • May also be used in lighting aquariums (not to be used in the water itself) • Suitable for indoor use only Burning Position • Universal Watts Finish Base Dimensions (mm) Reference Code Carton Quantity FLUORESCENT PLANT GROWTH LAMP 18W Lumoflor Bi-Pin 26 x 600 18WLUM 15486 25 30W Lumoflor Bi-Pin 26 x 920 30WLUM 15485 25 36W Lumoflor Bi-Pin 26 x 1220 36WLUM 15484 25 58W Lumoflor Bi-Pin 26 x 1520 58WLUM 14158 25
F 382 E.&.O.E. CC 04/11 Fluorescent Lamps Minature T5 and T8 Fluorescent Lamps This range of quality 16mm and 26mm diameter low wattage fluorescent lamps is suitable for use in emergency, cabinet and task lighting applications Features • Range of colour temperatures, wattages and lengths to suit all applications Applications • For domestic and commercial task and accent lighting applications where a compact and efficient source of light is required • Ideally suited for use in cabinet lighting and emergency luminaires • Suitable for indoor use only Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity T5 MINATURE LOW WATTAGE LINEAR 4W COOL WHITE G5 16 x 150 4000K 130 F4T5CW 16939 100 6W COOL WHITE G5 16 x 225 4000K 260 F6T5CW 16940 50 8W COOL WHITE G5 16 x 300 4000K 380 F8T5CW 14936 50 13W COOL WHITE G5 16 x 525 4000K 800 F13T5CW 11157 50 FLUORESCENT STANDARD T8 16MM LINEAR 10W COOL WHITE BI-PIN 26 x 343 4000K 600 F10T8CW 16984 25 10W DAYLIGHT BI-PIN 26 x 343 6500K 550 F10T8D 16985 25 15W COOL WHITE BI-PIN 26 x 450 4000K 900 F15W8CW 10086 25 15W DAYLIGHT BI-PIN 26 x 450 6500K 850 F15WD 16902 25
383 E.&.O.E. CC 04/11 F Fluorescent Lamps Fluorescent T4 Linkable Lamps These T4 fluorescent lamps are available in four wattages and are specially designed for use in undershelf and cabinet lighting systems Features • Compact size • Insulated caps for your safety • Require electronic control gear • Colour temperature of 3000K and 6500K Applications • For domestic and commercial undershelf and cabinet lighting applications • Replacement tubes for Crompton's quality range of linkable fluorescent fittings • Suitable for indoor use only Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity T4 LINKABLES 6W Warm White G5 13 x 230 3000K 230 F6T43 25075 500 10W Warm White G5 13 x 350 3000K 330 F10T43 25076 200 16W Warm White G5 13 x 480 3000K 600 F16T43 25077 200 20W Warm White G5 13 x 570 3000K 1230 F20T43 25078 200 6W Daylight G5 13 x 230 6500K 230 F6T465 23827 10/50 10W Daylight G5 13 x 350 6500K 330 F10T465 23828 10/50 16W Daylight G5 13 x 480 6500K 600 F16T465 23829 10/50 20W Daylight G5 13 x 570 6500K 1230 F20T465 23830 10/50
F 384 E.&.O.E. CC 04/11 Fluorescent Lamps Fluorescent - T8 26mm Coloured Lamps A range of low pressure discharge lamps with a 26mm tube internally coated with a fluorescent powder which converts the UV radiation into light and contains a pigment which filters out unwanted wave lengths to produce a vibrant light of a selected hue Features • Fluorescent coating is mixed with a pigment which filters out unwanted wave lengths to produce light that is either blue, red, green or yellow Applications • For commercial special effect lighting applications • Commonly used in stage lighting, window lighting, disco lighting and festive lighting • Suitable for indoor use only Usage Notes • Not to be used in potentially explosive environments Burning Position • Universal Watts Finish Base Dimensions (mm) Reference Code Carton Quantity FLUORESCENT COLOURED T8 26MM LINEAR 18W Blue Bi-Pin 26 x 600 18WBLUE 16091 25 18W Red Bi-Pin 26 x 600 18WRED 16090 25 18W Green Bi-Pin 26 x 600 18WGREEN 16092 25 18W Yellow Bi-Pin 26 x 600 18WYELLOW 16093 25 36W Blue Bi-Pin 26 x 1200 36WBLUE 16095 25 36W Red Bi-Pin 26 x 1200 36WRED 16094 25 36W Green Bi-Pin 26 x 1200 36WGREEN 16096 25 36W Yellow Bi-Pin 26 x 1200 36WYELLOW 16097 25
385 E.&.O.E. CC 04/11 F Fluorescent Lamps Fluorescent Blacklight Blue and Blacklight Lamps A range of low pressure mercury discharge lamps, internally coated with a white fluorescent powder that excites UV radiation in the 350-400 nanometre or UV-A region of the spectrum. These lamps are available in a range of specialised lengths and configurations to suit a number of applications Features • Blacklight Blue Tubes: These 16mm and 26mm lamps are made from a special blue glass that filters out most of the visible light letting only the ultra violet light pass through. They can be used in standard fluorescent fittings • Blacklight: These blacklight tubes are specially designed to work as attracting flying insects to the electrified grill Applications • Blacklight blue tubes are used in a number of commercial applications including forensic science chemical analysis, archaeology, banking, medicine and special effect lighting in discos and night clubs • Blacklight tubes are most commonly used as replacement lamps for the insect killers Burning Position • Universal Watts Finish Base Dimensions (mm) Reference Code Carton Quantity BLACKLIGHT BLUE TUBES 4W Blacklight Blue Bi-Pin 16 x 150 4WBLB 10123 10 6W Blacklight Blue Bi-Pin 16 x 230 6WBLB 10124 10 8W Blacklight Blue Bi-Pin 16 x 300 8WBLB 10125 10 15W Blacklight Blue Bi-Pin 26 x 450 15WBLB 10126 25 18W Blacklight Blue Bi-Pin 26 x 600 18WBLB 11166 25 36W Blacklight Blue Bi-Pin 26 x 1220 36WBLB 11180 25 BLACKLIGHT 4W Blacklight Bi-Pin 16 x 150 F4T5BL 10084 10 6W Blacklight Bi-Pin 16 x 230 F6T5BL 10085 10 8W Blacklight Bi-Pin 16 x 300 F8T5BL 10087 10 15W Blacklight Bi-Pin 26 x 450 F158BL 10089 25 18W Blacklight Bi-Pin 32 x 600 F18T9BL 10091 10 40W Blacklight Bi-Pin 32 x 1220 F40T10BL 10099 10 BLACKLIGHT FOR SPECIAL LENGTH 20W Blacklight Bi-Pin 26 x 580 FL20T9BLS 14614 25
F 386 E.&.O.E. CC 04/11 Fluorescent Lamps Circular Fluorescents This range of quality 29mm diameter circular fluorescent lamps offer the same advantages as linear fluorescent tubes. These lamps are available in both standard and triphosphor variants in a choice of three colour temperatures Features • Range of colour temperatures and wattages available • The Triphosphor version offers higher light output for the same energy consumption as the standard version with a lower rate of light loss as it ages • The Triphosphor version also offers excellent colour rendition capabilities • May be operated with standard control gear and starters or with electronic control gear Applications • For use in both domestic and commercial applications • Illuminated signs and displays • Suitable for indoor use only Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity 3000 HOUR FLUORESCENT CIRCULAR STANDARD 29MM 22W COOL WHITE G10q 29 x 210 4000K 805 3000 FCL22CW 16067 10 32W COOL WHITE G10q 29 x 300 4000K 1355 3000 FCL32CW 16070 10 32W DAYLIGHT G10q 29 x 300 6000K 1325 3000 FCL32D 16072 10 40W COOL WHITE G10q 29 x 400 4000K 1840 3000 FCL40CW 16073 10 3000 HOUR FLUORESCENT CIRCULAR TRIPHOSPHOR 29MM 22W NATURAL G10q 29 x 210 5000K 940 3000 FCL22NEX 16076 10 32W NATURAL G10q 29 x 300 5000K 1930 3000 FCL32CWNEX 16077 10 32W DAYLIGHT G10q 29 x 300 6000K 1660 3000 FCL32DEX 16080 10 40W NATURAL G10q 29 x 400 5000K 3210 3000 FCL40NEX 16078 10
387 E.&.O.E. CC 04/11 F Fluorescent Lamps T5 Circular Fluorescents This range of quality slimline circular fluorescent lamps offer the same advantages as linear fluorescent tubes Features • The Triphosphor version offers higher light output for the same energy consumption as the standard version with a lower rate of light loss as it ages • Up to 20% more efficient than T8 lamps Applications • For use in both domestic and commercial applications • Illuminated signs and displays • Suitable for indoor use only Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity T5 FLUORESCENT CIRCULAR STANDARD 16MM 22W COOL WHITE G10q 16 x 210 4000K 1375 8000 FCT522W840 26106 10 32W COOL WHITE G10q 16 x 250 4000K 2435 8000 FCT532W840 26107 10 40W COOL WHITE G10q 16 x 300 4000K 2755 8000 FCT540W840 26108 10
F 388 E.&.O.E. CC 04/11 Fluorescent Lamps Protect-O-Sleeve with End Caps Re-usable 'Protect-O-Sleeves' enclose standard fluorescent tubes to insulate and improve lighting efficiency at low temperatures. High tensile, polycarbonate strength protects people, equipment and products from lamp breakages and contamination. The 'Protect-O-Sleeves' are supplied with end caps that fit between lamp and sleeve and feature a release channel that allows gases to disperse Features •Meets safety requirements •Insulates lamps up to 2.5 times at -6°C •Can be used with lamps up to 58W Applications •For domestic, commercial and industrial applications where the prevention of injury or contamination from broken glass is essential • Especially suited to food preparation areas and medical environments • For insulation of fluorescent tubes in cold environments Watts Base Dimensions (mm) Reference Code Carton Quantity PROTECT-0-SLEEVE (WITH END CAPS) To Suit 18W Bi-Pin 610MM 2FPOS 15181 48 To Suit 36W Bi-Pin 1220MM 4FPOS 15127 48 To Suit 58W Bi-Pin 1520MM 5FPOS 15128 48 Fluorescent Starters Starters for fluorescent lamps offer fast, flicker free ignition for both older style 38mm fluorescent tubes as well as the new energy saving 26mm tubes. The FSU is designed for single tube operation 4W-65W. The FS2 is also designed for series operation 18W-20W Features •Complies with RoHS standards - lead and mercury free • Manufactured to Australian Standards AS/NZS 60155:2000 and AS 4111-1993 Applications • For use with both T8 and T12 tubes ranging from 2W-65W Usage notes • For maximum tube life replace the starter at the same time as the fluorescent tube • Ensure the power is turned off before replacing the tube and starter Watts Description Reference Code Carton Quantity FLUORESCENT STARTERS BOTTLE TYPE 2W - 22W FS2 Single Series FS2 11447 25/100 4W - 65W FSU Universal FSU 11452 25/500 2W - 22W FS2 Blister Pack - 2 starters FS2/2 25123 25 4W - 65W FSU Blister Pack - 2 starters FSU/2 22791 25 Sleeve Tube in Sleeve
389 E.&.O.E. CC 04/11 F Fluorescent Lamps Fluorescent Compact PL/PLC Lamps This extensive range of compact fluorescent lamps offers the same benefits of standard fluorescent tubes with the advantage that their compact size makes them suitable for use in shallow or miniature luminaires. Like standard fluorescent tubes these lamps can only be used in luminaires with an appropriate lamp holder and ballast Features • Compact size makes them suitable for use in a variety of applications where incandescent or discharge light sources were traditionally used • Large range of colour temperatures and wattages available •High quality, long life, energy saving lamps •Manufactured to Australian Standard AS/ NZS 60901:2003 Applications • For commercial applications where a compact, energy saving and efficient light source is required •Ideal for downlights and wall lights in office buildings, foyers and hotels • Suitable for indoor use or in protected exterior applications Burning Position • Universal Watts Finish Base Dimensions (mm) Colour Temperature Lumen Output Reference Code Carton Quantity COMPACT SINGLE PL (OVAL BASE) 7W COLOUR 827 G23 31 x 18 x 137 2700K 400 CRO7WPL827 11101 50 7W COLOUR 840 G23 31 x 18 x 137 4000K 400 CRO7WPL840 11102 50 9W COLOUR 827 G23 31 x 18 x 137 2700K 600 CRO9WPL27 11103 50 9W COLOUR 840 G23 31 x 18 x 137 4000K 600 CRO9WPL840 11104 50 11W COLOUR 827 G23 31 x 18 x 237 2700K 900 CRO11WPL827 11093 50 11W COLOUR 840 G23 31 x 18 x 237 4000K 900 CRO11WPL840 11094 50 18W COLOUR 840 2G11 31 x 18 x 137 4000K 1200 CRO18WPL840 14615 10 36W COLOUR 840 2G11 31 x 18 x 137 4000K 2900 CRO36WPL840 11100 10 COMPACT DOUBLE PLC (SQUARE BASE) 10W COLOUR 827 G24d-1 34 x 34 x 110 2700K 600 CRO10WPLC827 11105 50 10W COLOUR 840 G24d-1 34 x 34 x 110 4000K 600 CRO10WPLC840 15175 50 13W COLOUR 827 G24d-1 34 x 34 x 137 2700K 900 CRO13WPLC827 11106 50 13W COLOUR 840 G24d-1 34 x 34 x 137 4000K 900 CRO13WPLC840 11107 50 18W COLOUR 827 G24d-2 34 x 34 x 153 2700K 1200 CRO18WPLC827 11108 50 18W COLOUR 840 G24d-2 34 x 34 x 153 4000K 1200 CRO18WPLC840 11109 50 26W COLOUR 827 G24d-3 34 x 34 x 172 2700K 1800 CRO26WPLC827 11110 50 26W COLOUR 840 G24d-3 34 x 34 x 172 4000K 1800 CRO26WPLC840 14612 50 ELECTRONIC COMPACT DOUBLE PLC (SQUARE BASE) 18W COLOUR 827 G24q-2 34 x 34 x 146 2700K 1200 CRO18WPLC/E827 25617 50 18W COLOUR 840 G24q-2 34 x 34 x 146 4000K 1200 CRO18WPLC/E840 25618 50 26W COLOUR 827 G24q-3 34 x 34 x 170 2700K 1800 CRO26WPLC/E827 25619 50 26W COLOUR 840 G24q-3 34 x 34 x 170 4000K 1800 CRO26WPLC/E840 25620 50
F 390 E.&.O.E. CC 04/11 Fluorescent Lamps Electronic Fluorescent Energy Saving Lamps Lamps are available in a wide range of shapes and wattages, designed to replace common incandescent lamps found in the home such as old GLS, candle, spherical and reflector lamps. By replacing these lamps the energy consumption will be reduced by up to 80%. These lamps provide the benefits of fluorescent light, with the ease of installation of standard incandescent and halogen lamps Features • Comparative standard base types allows them to fit into existing luminaires • Integral control gear allows them to be operated directly on a mains voltage supply without the need for installing control gear and starters • Compact size makes them suitable for use in a variety of applications where incandescent or discharge light sources were traditionally used • Triphosphor fluorescent with excellent colour rendering (Ra83 or Ra85) • Soft start and flicker free operation • Long life: 5000 to 8000 hours • Manufactured to Australian Standards AS/NZS 60968:2001 and AS/NZS 60969:2001 Applications • For domestic and commercial applications where an energy efficient and high output light source is needed to replace conventional lamp types • Ideal for use in downlights, table lamps, pendants and wall brackets - any fitting where conventional lamps were traditionally used • Suitable for indoor or protected exterior applications only • Not suitable for dimming or for use with photocell switches LIGHTSTAR COMPACT FLUORESCENT LAMP 5W 11W 15W 20W INCANDESCENT EQUIVALENT 25W 60W 75W 100W COMPARATIVE LAMP WATTAGE Electronic Fluorescent Energy Saving Lamps Range 80% ENERGY SAVING
391 E.&.O.E. CC 04/11 F Fluorescent Lamps Electronic Fluorescent Energy Saving Lamps CFST2 Lamps A range of spiral long life, energy efficient, compact fluorescent lamps. Their many advantages makes them a perfect replacement for standard lamps Features • Up to 80% power saving • 6000 - 8000 average rated life hours • Integral ballast and starter • Soft start • Protected from electrical surge • High lumen output • Available in 15W and 23W BC or ES base Applications • For domestic and commercial lighting • Outdoor security lighting in weatherproof fittings • Not suitable for dimming or for use with photocell switches • For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity CFST2 - BC BASE ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 15W 240V BC B22 108 x 43 3000K 825 8000 CFST2-15WBC3K 26126 50 15W 240V BC B22 108 x 43 5000K 825 6000 CFST2-15WBC5K 26127 50 23W 240V BC B22 121 x 52 3000K 1500 8000 CFST2-23WBC3K 26130 50 23W 240V BC B22 121 x 52 5000K 1500 8000 CFST2-23WBC5K 26131 50 CFST2 - ES BASE ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 15W 240V ES E27 108 x 43 3000K 825 8000 CFST2-15WES3K 26124 50 15W 240V ES E27 108 x 43 5000K 825 6000 CFST2-15WES5K 26125 50 23W 240V ES E27 121 x 52 3000K 1500 8000 CFST2-23WES3K 26128 50 23W 240V ES E27 121 x 52 5000K 1500 8000 CFST2-23WES5K 26129 50
F 392 E.&.O.E. CC 04/11 Fluorescent Lamps Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity BC BASE ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 11W 240V BC B22 110 x 50 5000K 625 8000 CFL-311WBC 25542 6 15W 240V BC B22 120 x 50 5000K 795 8000 CFL-315WBC 25544 6 20W 240V BC B22 120 x 60 3000K 1070 8000 CFL-420WBC 25604 6 20W 240V BC B22 120 x 60 5000K 1095 8000 CFL-420WBC 25546 6 ES BASE ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 11W 240V ES E27 110 x 50 3000K 625 8000 CFL-311WES 25601 6 11W 240V ES E27 110 x 50 5000K 625 8000 CFL-311WES 25543 6 15W 240V ES E27 120 x 50 3000K 865 8000 CFL-315WES 25602 6 15W 240V ES E27 120 x 50 5000K 795 8000 CFL-315WES 25545 6 20W 240V ES E27 120 x 60 3000K 1070 8000 CFL-420WES 25603 6 20W 240V ES E27 120 x 60 5000K 1095 8000 CFL-420WES 25547 6 Electronic Fluorescent Energy Saving LampsCFL-3 and CFL-4 Lamps A range of long life, energy efficient, compact fluorescent lamps. Their compact size and many advantages makes them a perfect replacement for standard lamps Features • Up to 80% power saving • 8000 average rated life hours • Integral ballast and starter • Soft start • Protected from electrical surge • High lumen output • Available in 11W, 15W and 20W BC or ES base Applications • For domestic and commercial lighting • Outdoor security lighting in weatherproof fittings • Not suitable for dimming or for use with photocell switches • For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal CFL-4 CFL-3
393 E.&.O.E. CC 04/11 F Fluorescent Lamps Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 15W 240V BC B22 130 x 65 3000K 685 8000 CFG15WBC 25606 24 15W 240V BC B22 130 x 65 5000K 735 8000 CFG15WBC 25525 24 15W 240V ES E27 130 x 65 3000K 685 8000 CFG15WES 25605 24 15W 240V ES E27 130 x 65 5000K 735 8000 CFG15WES 25526 24 Electronic Fluorescent Energy Saving LampsCFG15 Lamps A range of long life, energy efficient, compact fluorescent lamps. Their compact size and many advantages makes them a perfect replacement for standard lamps Features • Up to 80% power saving •8000 average rated life hours •Integral ballast and starter •Soft start •Protected from electrical surge •High lumen output •Available in 15W BC or ES base Applications • For domestic and commercial lighting • Outdoor security lighting in weatherproof fittings • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal
F 394 E.&.O.E. CC 04/11 Fluorescent Lamps Watts Voltage Base Dimensions (mm) Colour Average Life Hours Reference Code Carton Quantity ELECTRONIC FLUORESCENT COLOURED ENERGY SAVING LAMP 9W 240V BC B22 120 x 60 BLUE 8000 CCW9B 25780 8 9W 240V BC B22 120 x 60 GREEN 8000 CCW9G 25781 8 9W 240V BC B22 120 x 60 RED 8000 CCW9R 25782 8 9W 240V BC B22 120 x 60 YELLOW 8000 CCW9Y 25783 8 Electronic Fluorescent Energy Saving LampsColoured CCW Lamps Coloured mains voltage CCW lamps for festive occasions. Features • Energy Saving 9W lamps • Manufactured to AS/ NZS 2325-1993 and AS/NZS60968 • Lamp colours - Blue, Yellow, Red and Green •8000 hours lamp life Applications • For decorative and special effect lighting • Festive lighting for entertainment areas, amusement parks, gardens, Christmas trees and parties • Suitable for both indoor use or in protected exterior applications Burning Position • Universal Watts Voltage Finish Base Dimensions Average Life Lamp Hours Reference Code Carton Quantity BC BASE 9W 240V Coloured BC B22 10M 8000 LSPL10 25860 1 Electronic Fluorescent Energy Saving LampsColoured CCW Party Light Kit Coloured mains voltage CCW lamp kit for festive occasions. Kit includes lamps, lampholders and cable with two pin plug Features • Manufactured to AS/NZ60598.2.20 • BC thermoplastic lampholders permanently attached to 10 metres of 1.5mm² core PVC supply cable fitted with a moulded two pin plug • 8 electronic fluorescent energy saving lamps: - Blue, Yellow, Red and Green (two of each)
395 E.&.O.E. CC 04/11 F Fluorescent Lamps Electronic Fluorescent Energy Saving LampsCFG20 Spherical Lamps Long life, energy efficient, compact fluorescent spherical lamps. Their many advantages makes them a perfect replacement for standard lamps Features •Up to 80% power saving •8000 average rated life hours •Integral ballast and starter •Soft start •Protected from electrical surge •High lumen output •Available in 20W BC or ES base Applications •For domestic and commercial lighting •Suitable for indoor use only •Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity SPHERICAL ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 20W 240V BC B22 170 x 125 5000K 1280 8000 CFG-20WBC 25527 16 20W 240V ES E27 170 x 125 5000K 1280 8000 CFG-20WES 25528 16
F 396 E.&.O.E. CC 04/11 Fluorescent Lamps Electronic Fluorescent Energy Saving LampsCCD Candle and CFG Fancy Round Lamps A range of long life, energy efficient, compact fluorescent lamps. Their compact size and many advantages makes them a perfect replacement for standard fancy round lamps Features • Up to 80% power saving •Integral ballast and starter •Soft start •Protected from electrical surge •Candles available in 5W BC, SBC or SES base •Fancy rounds available in 5W BC or ES base Applications • For domestic and commercial lighting • Suitable for indoor use only • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity CANDLE ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 5W 240V BC B22 110 x 35 3000K 185 6000 CCD-5WBC 25609 50 5W 240V BC B22 110 x 35 5000K 185 6000 CCD-5WBC 25523 50 5W 240V SBC B15 110 x 35 3000K 185 6000 CCD-5WSBC 25610 50 5W 240V SBC B15 110 x 35 5000K 185 6000 CCD-5WSBC 25524 50 5W 240V SES E14 110 x 35 3000K 185 6000 CCD-5WSES 25613 50 5W 240V SES E14 110 x 35 5000K 185 6000 CCD-5WSES 25612 50 Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity FANCY ROUND ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 5W 240V BC B22 95 x 50 3000K 210 6000 CFG-5WBC 25611 50 5W 240V BC B22 95 x 50 5000K 230 6000 CFG-5WBC 25540 50 5W 240V ES E27 95 x 50 5000K 230 6000 CFG-5WES 25541 50
397 E.&.O.E. CC 04/11 F Fluorescent Lamps Electronic Fluorescent Energy Saving LampsCGU GU10 Lamps A range of long life, energy efficient, compact fluorescent lamps. Their many advantages makes them a perfect replacement for standard GU10 base halogen lamps Features • Up to 80% power saving •8000 average rated life hours •Integral ballast and starter •Soft start •Protected from electrical surge •Available in 7W, 9W, 11W and 18W with GU10 base Applications • Direct retrofit for GU10 halogen lamps • For domestic and commercial lighting • Suitable for indoor use only • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity GU10 ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 7W 240V GU10 75 x 50 5000K 150 8000 CGU-7W 25553 24 9W 240V GU10 75 x 50 3000K 200 8000 CGU-9W 25334 24 9W 240V GU10 75 X 50 5000K 200 8000 CGU-9W 25269 24 11W 240V GU10 75 X 50 3000K 240 8000 CGU-11W 25336 24 11W 240V GU10 75 X 50 5000K 240 8000 CGU-11W 25335 24 18W 240V GU10 90 X 50 3000K 400 8000 CGU-18W 25714 24 18W 240V GU10 90 X 50 5000K 400 8000 CGU-18W 25715 24 CGU 7W 9W CGU 18W CGU 11W
F 398 E.&.O.E. CC 04/11 Fluorescent Lamps Electronic Fluorescent Energy Saving LampsCFR Reflector Lamps A range of long life, energy efficient, compact fluorescent reflector lamps. Their many advantages makes them a perfect replacement for standard reflector lamps Features • Up to 80% power saving •8000 average rated life hours •Integral ballast and starter •Soft start •Protected from electrical surge •Available in R50 9W SES, R63 11W ES and R80 15W ES base Applications • For domestic and commercial lighting • Suitable for indoor use only • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity REFLECTOR ELECTRONIC FLUORESCENT ENERGY SAVING LAMP - R50 R63 R80 9W 240V SES E14 99 x 50 3000K Frosted 250 8000 CFR-50/9WSES 25688 24 11W 240V ES E27 125 x 63 5000K Frosted 260 8000 CFR-63/11WES 25549 24 15W 240V ES E27 125 x 80 3000K Frosted 480 8000 CFR-80/15WES 25607 24 15W 240V ES E27 125 x 80 5000K Clear 583 8000 CFR-80/15WES 25550 24 CFR Clear CFR Frosted
399 E.&.O.E. CC 04/11 F Fluorescent Lamps Electronic Fluorescent Energy Saving LampsCFP PAR Lamps Long life, energy efficient, compact fluorescent PAR lamps. Their many advantages makes them a perfect replacement for standard PAR38 lamps Features • Up to 80% power saving •8000 average rated life hours •Integral ballast and starter •Soft start •Protected from electrical surge •Available in 20W with ES base Applications • For domestic and commercial lighting • Suitable for external use in weatherproof fittings • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Dimensions (mm) Colour Temperature Lumen Output Average Life Hours Reference Code Carton Quantity PAR38 SOFT GLASS ALUMINIUM REFLECTOR ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 20W 240V ES E27 150 x 114 3000K 900 8000 CFP-20WES 25712 16 20W 240V ES E27 150 x 114 5000K 905 8000 CFP-20WES 25548 16
F 400 E.&.O.E. CC 04/11 Fluorescent Lamps Electronic Fluorescent Energy Saving LampsGX53 CFL Lamp Long life, energy efficient, compact fluorescent GX53 lamp. It's many advantages makes it a perfect lamp in lighting applications where halogen bi-pin lamps and fittings are traditionally used Features • Up to 80% power saving •Integral ballast and starter •Soft start •Protected from electrical surge •Prismatic clear glass diffuser and PBT housing Applications • Cabinet and undershelf lighting • Not suitable for dimming or for use with photocell switches •For optimum efficiency and lamp life it is recommended to use these lamps in applications where the lamp is not frequently switched Burning Position • Universal Watts Voltage Base Diameter (mm) Colour Average Life Hours Reference Code Carton Quantity GX53 ELECTRONIC FLUORESCENT ENERGY SAVING LAMP 7W 240V GX53 74 4000K 8000 GX537W 26110 10 9W 240V GX53 74 4000K 8000 GX539W 26111 10 11W 240V GX53 74 4000K 8000 GX5311W 26112 10
