Crompton Lighting - Exterior luminaires

350 O MR11 SLIMLINE DO IT YOURSELF DIY ELECTRONIC E IRC ENERGY SAVING 350° rotation   MR11 halogen dichroic lamp fitting Product with slimline design Ingress protection rating - 54  Ingress protection rating - 55  Ingress protection rating - 65  Ingress protection rating - 66  Ingress protection rating - 67  Electronic product Product with IRC lamp Do It Yourself product Energy Saving product LED product XL-LED colour temperature 4000K  XL-LED colour temperature 3000K  Glass is safe to touch in operation Stainless steel construction Product with inbuild sensor T5 fluorsecent lamp product Touch base for on/off Intelligent Lighting ProductEnergy Saving out of the box (No commissioning required) STAINLESS STEEL INBUILT SENSOR T5 TOUCHLAMPon/off Symbols Guide INGRESS PROTECTION IP66 INGRESS PROTECTION IP55 INGRESS PROTECTION IP65 INGRESS PROTECTION IP67 INGRESS PROTECTION IP54

Floodlights F

Floodlights.............................................................261Halogen Floodlights.........................................................264Discharge  Floodlights  ....................................................269

261 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights 100  Head dimensions (no lamp): 120(l)mm x 65(w)mm Base diameter:  65 mm 0 8 1 EX007 - PAR 38 single floodlight - Die-cast aluminium construction - Powder coated finish - Ceramic lampholder - High temperature silicone rubber gasket - Rotates 360° and pivots through 250° - IP44  - Includes 120W hard glass PAR 38 lamp - Also suitable for 150W PAR38 lamp EX007B Black CODE: 19363 EX007S Silver CODE: 19365   DTF1150MBFP - PAR38 portable work light - Thermoplastic body - Ceramic lampholder - High temperature silicone rubber gasket - Double insulated - Fully adjustable - Flex and Plug - IP44 - Includes 150W hard glass PAR38 lamp DTF1150MBFP Black CODE: 26435   202 Base Width: 97mm Max. Projection: 225mm Head Width: Ф66mm 170 DTF1150MB - PAR38 single floodlight - Thermoplastic body - Ceramic lampholder - High temperature silicone rubber gasket - Double insulated - Fully adjustable - IP44 - Includes 150W hard glass PAR38 lamp 100 2 0 2 Base: Ф68mm Max. Projection: 225mm Head Width: Ф66mm DTF1150MB Black CODE: 26297   DTF150B - PAR38 single floodlight - UV stabilised flame retardant black plastic body - Ceramic lampholder  - High temperature silicon rubber gasket  - Head rotates 160° and pivots to 250°  - IP44    Suitable for 150W PAR38 lamp DTF150B Black CODE: 25206   PAR38 Floodlights Crompton PAR38 floodlights provide bright and efficient illumination and are suitable for a diverse range of applications  without undue expense. PAR38 hard glass lamps are recommended for use in exposed exterior applications. Soft  glass lamps and energy saving compact fluorescent PAR38 lamps are only recommended for protected exterior   installations under eaves or balconies or for indoor use in display and feature lighting. Compact fluorescent PAR38  lamps should not be used on sensor floodlights as the lamps are not suitable for constant on and off switching.   255 120 165 255 120 165 DTF150GB  - PAR38 single floodlight - UV stabilised flame retardant black plastic body  - Ceramic lampholder - High temperature silicon rubber gasket - Head rotates 160° and pivots to 250°  - IP44  - Includes 150W PAR38 soft glass lamp Suitable for exterior floodlighting in protected applications DTF150GB Black CODE: 25205

F 262 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Floodlights DTF2150GB  - PAR38 twin floodlight - UV stabilised flame retardant black plastic body - Ceramic lampholders - High temperature silicon rubber gasket - Lamp heads rotate 160°and pivot through 250° - IP44 - Includes 150W soft glass PAR38 lamps Suitable for exterior floodlighting in protected applications 120 140 DTF2150GB Black CODE: 25207   105  27  105  Head dimensions (no lamp):  97(L)mm x 55(W)mm Sensor dimensions: 230mm (L) DTF2150S  - PAR 38 twin floodlight with sensor  - UV stabilised flame retardant black plastic body - Ceramic lampholders - Sensor range 12m at 110° - Delay on from 6 seconds to 10 minutes with   manual override - High temperature silicon rubber gasket - Lamp heads rotate 160°and pivot through 250° - IP44 Suitable for 2 x 150W PAR38 lamps DTF2150SB Black CODE: 88012 DTF2150SW White CODE: 25208   DTF2150B - PAR38 twin floodlight - UV stabilised flame retardant black plastic body - Ceramic lampholders - High temperature silicon rubber gasket - Lamp heads rotate 160°and pivot through 250° - IP44 Suitable for 2 x 150W PAR38 lamps 105 0 0 1 30 110 Head dimensions (no lamp):  100(l)mm x 60(w)mm Base diameter : 110mm DTF2150B Black CODE: 16978   DIYPAR38B  - ‘Do It Yourself’ PAR38 single floodlight - Attaches to a standard batten fix holder  - UV stabilised flame retardant black plastic body - Ceramic lampholder  - High temperature silicon rubber gasket  - Head rotates 160° and pivots through 250° - Batten holder cover included  - IP44 Suitable for 150W PAR38 lamp 255 120 165 DIYPAR38B Black CODE: 25209   200 110 165 DIYPAR38SB - ‘Do It Yourself’ PAR38 single floodlight with sensor - Attaches to a standard batten fix holder  - UV stabilised flame retardant black plastic body - Ceramic lampholder  - High temperature silicon rubber gasket  - Sensor range 18.3m at 110° - Delay on from 5 seconds to 8 minutes with   manual override - Head rotates 160° and pivots through 250° - Batten holder cover included  - IP44 Suitable for 150W PAR38 lamp DIYPAR38SB Black CODE: 25210   INBUILT SENSOR INBUILT SENSOR

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   263 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights CS1100 - Automated switching system - No minimum load requirement - Mounting between 2.5 and 3.5 metres above ground - PIR sensor with a range of 12m - Horizontal arc sensitivity of 180° - Adjustable controls for sensitivity (Lux) and time (Dwell) - Suitable for 24/7 operation - Manual override mode to bypass PIR sensor - IP44 - Suitable for protected exterior applications, walls and   under eaves CS1021W - Manual overide to bypass PIR sensor - Adjustable knobs for lux (sensitivity) and time - Mounting between 2 and 4.5 metres above the ground - Detection distance 10m (at 24°C ambient temp.) - Horizontal arc sensitivity of 180° - Ambient light: 20Lux to 2000Lux - Working Temperature:  -10°C ~ 40°C - Working humidity:  93%RH - Time-delay: Min 5sec(±3 sec), Max 7min(±2min) - 1200W passive infrared motion sensor - Thermoplastic body with cable entry and grommet bush - Adjustable up/down and horizontal on a pivot - IP44 - Suitable for protected exterior applications, walls and   under eaves CS1020W - Manual overide to bypass PIR sensor - Adjustable knobs for lux (sensitivity) and time - Mounting between 3 and 5.5 metres above the ground - Detection distance 12m (at 24°C ambient temp.) - Horizontal arc sensitivity of 360° - Ambient light: 15Lux to daylight - Working Temperature:  -20°C ~ 40°C - Working humidity:  93%RH - Time-delay: Min 8sec(±3 sec), Max 7min(±2min) - 1200W passive infrared motion sensor - Thermoplastic body with internal electronic switch   circuit and sensor - IP44 - Suitable for protected exterior applications, walls and   under eaves CS1015W - Manual overide to bypass PIR sensor - Adjustable knobs for lux (sensitivity) and time - Mounting between 0.5 and 3.5 metres above the ground - Detection distance 12m (at 24°C ambient temp.) - Horizontal arc sensitivity of 140° - Ambient light: 3Lux to daylight (adjustable) - Working Temperature:  -20°C ~ 40°C - Working humidity:  93%RH - Time-delay: Min 8sec(±3 sec), Max 7min(±2min) - 1000W passive infrared motion sensor - Thermoplastic body with 12mm cable entry hole and   grommet bush - Back plate detachable for wall mounting using screws - IP44 - Suitable for protected exterior applications, walls and   under eaves 70 95 85 92 55 65 (mm) 90 103 60 (mm) 106 106 53 (mm) CS1100B Black CODE: 25198 CS1100W White CODE: 25201 CS1100S Grey CODE: 26296   CS1021W White CODE: 26536   CS1015W White CODE: 26537   CS1020W White CODE: 26535   INBUILT SENSOR INBUILT SENSOR INBUILT SENSOR INBUILT SENSOR

F 264 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Floodlights EX410 Series - Shovel faced floodlight - Die-cast aluminium construction - Aluminium alloy reflector - Safety glass cover - Head is adjustable over 90° - Ceramic lampholder - Aluminium alloy reflector - IP23 - For mounting in protected exterior locations - Includes 240V linear halogen lamp EX4105B Black CODE: 20039 EX4105G Green CODE: 20040 EX4105S Silver CODE: 20041 EX4105BE Beige CODE: 20038 EX4105W White CODE: 20042   EX4105 150W 78mm LINEAR HALOGEN LAMP EX4106B Black CODE: 20044 EX4106G Green CODE: 20045 EX4106S Silver CODE: 20046 EX4106BE Beige CODE: 20043 EX4106W White CODE: 20047   EX4106 300W 118mm LINEAR HALOGEN LAMP EX4102B Black CODE: 20032 EX4102G Green CODE: 20033 EX4102S Silver CODE: 20034 EX4102BE Beige CODE: 20031 EX4102W White CODE: 20035   EX4102 500W 118mm LINEAR HALOGEN LAMP EX4106SEB - Shovel faced floodlight with sensor - Die-cast aluminium construction - Aluminium alloy reflector - Safety glass cover - Head is adjustable over 90° - Ceramic lampholder - IP23 - For mounting in protected exterior locations - Includes 300W 118mm 240V linear halogen lamp 310 65 160 60 EX4106SEB Black CODE: 25199   280 130 130 60 Base (wall mount)  dimensions: Length to head: 130mm Diameter: 70mm 310 165 170 60 Base (wall mount)    dimensions: Length to head: 145mm Diameter: 70mm 310 165 170 60 Base (wall mount)  dimensions: Length to head: 145mm Diameter: 70mm Halogen Crompton linear halogen floodlights are an ideal choice for providing security and area lighting in domestic  and small commercial applications. Linear halogen floodlights that feature sensors provide added security  by activating only when movement is detected and help save energy by only turning on the light when it is  required.   INBUILT SENSOR

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   265 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights 140 95 98 Total height: 175mm Dimensions of base: 107mm (w) 180 145 137 Total height: 260mm Dimensions of base: 110mm (w) EX4108B Black CODE: 20049   EX4107  - 150W oval faced halogen floodlight - Die-cast aluminium floodlight construction - Patterned aluminium alloy reflector - Safety glass cover  - Ceramic lampholder - Cable entry gland - IP44 - Includes 150W 78mm 240V linear halogen lamp EX4108  - 500W oval faced halogen floodlight - Die-cast aluminium floodlight construction - Patterned aluminium alloy reflector - Safety glass cover  - Ceramic lampholder - Cable entry gland - IP44 - Includes 500W 118mm 240V linear halogen lamp EX4109  - 150W oval faced halogen floodlight with sensor -  Die-cast aluminium floodlight construction -  Patterned aluminium alloy reflector -  Sensor range 12m at 120º -  Delay on from 6 seconds to 10 minutes with   manual override -  Safety glass cover  -  Ceramic lampholder -  Cable entry gland -  IP44 -  Includes 150W 78mm 240V linear halogen lamp EX4110  - 500W oval faced halogen floodlight with sensor - Die-cast aluminium floodlight construction -  Patterned aluminium alloy reflector -  Sensor range 12m at 120º -  Delay on from 6 seconds to 10 minutes with    manual override -  Safety glass cover  -  Ceramic lampholder -  Cable entry gland -  IP44 -  Includes 500W 118mm 240V linear halogen lamp 142 100 98 Total height: 215mm Dimensions of base: 107mm (w) 14 5 137 180 Total height: 260mm Dimensions of base: 110mm (w) EX4110 Black CODE: 20051   EX4107B Black    CODE: 20048   EX4109 Black CODE: 20050   INBUILT SENSOR INBUILT SENSOR Halogen

F 266 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Floodlights 140 85 98 107 92 190 181 120 146 260 140 QLC150W White CODE: 12467 QLC150B Black CODE: 12461 QLC150BE Beige CODE: 12463 QLC150G Green CODE: 12464 QLC150S Silver CODE: 20023   QLC500W White CODE: 14629 QLC500B Black CODE: 14625 QLC500BE Beige CODE: 14627 QLC500G Green CODE: 14628 QLC500S Silver CODE: 20028 QLC500WG Wire Guard CODE: 12486   345 170 230 360 Total height: 360mm Dimensions of bracket: 130mm(h) x 230( l)  QLC1500B Black CODE: 12459   165 110 140 QLB150 - Powder coated die-cast aluminium body  - Clear glass diffuser  - IP44 - Includes 1 x 150W linear 78mm halogen lamp  QLB150B Black CODE: 25202 QLB150W White CODE: 25200   QLB150S - Sensor floodlight - Powder coated die-cast aluminium body  - Clear glass diffuser  - IP44  - Includes 1 x 150W linear 78mm halogen lamp 165 110 140 QLB150SB Black CODE: 25203 QLB150SW White CODE: 25204   QLC Series - Rectangular halogen floodlight - Die-cast aluminium construction - Patterned aluminium alloy reflector - Safety glass cover  - Ceramic lampholder - Cable entry gland - Adjustable head - IP54 - All types include 240V linear halogen lamp  - Optional wire guard for QLC500 range QLC150 150W 78mm LINEAR HALOGEN LAMP QLC500 500W 118mm LINEAR HALOGEN LAMP QLC1500 500W 254mm LINEAR HALOGEN LAMP INBUILT SENSOR Halogen INGRESS PROTECTION IP54

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   267 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights QLC500MS - Rectangular halogen floodlight with sensor - Die-cast aluminium construction - Patterned aluminium alloy reflector - Sensor range 12m at 180º - Delay on from 6 seconds to 10 minutes with   manual override - Safety glass cover  - Ceramic lampholder - Cable entry gland - Adjustable head - IP44  - Includes 500W 118mm 240V linear halogen lamp QLP150 - Portable 150W halogen work light - Black die-cast aluminium head - Safety glass and wire guard - Ceramic lampholder - Yellow metal stand, complete with soft   grip handle - 1.8 meter flex and plug - IP44 - Includes 150W 78mm linear halogen lamp QLP500 - Portable 500W halogen work light - Black die-cast aluminium head - Safety glass and wire guard - Ceramic lampholder - Yellow metal stand, complete with soft   grip handle - 1.8 meter flex and plug - IP44 - Includes 500W 118mm linear halogen lamp 250 150 1  0 4 1  0  8  QLC500MS Black CODE: 88075   QLP150 Black/Yellow CODE: 12496   QLP500 Black/Yelliow CODE: 12498   1 65  175  170  250  Head dimensions:   135(w)mm x 100(h)mm  230  200  320  Head dimensions:   185(w)mm x 145(h)mm                  Crompton mains voltage double ended halogen lamps feature:  - Instant start  - Dimmable  - Lamp life of 2000 hours  - 3000K colour temperature  - Reinforced filament designed to withstand vibration  - Available in 60W to 1500W in lengths of 78mm, 118mm, 189mm     and 254m LINEAR HALOGEN LAMPS SAFETY  NOTE:  The  glass  protective  shields  supplied  with  the  QLP150  and  QLP500 are essential to their operation  and must not be removed. The standard  covering  this,  AS/NZS60598.1:2003,  makes it mandatory to have glass shields  fitted on all luminaires designed to take  lamps that do not feature an integral glass  envelope, such as linear halogen lamps.  The  glass  shield  is  designed  to  prevent  potential hazards that may occur in the  unlikely event that the lamp explodes. INBUILT SENSOR Halogen (See page 374)

F 268 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Floodlights DG9601 - Single 240V G9 halogen floodlight   - Black powder coated or satin nickel metal body   with hood - Twist lock face with clear glass diffuser - Plastic mounting plate - IP44 - Includes 1 x 75W (maximum) G9 halogen lamp 113 195 Head Size: 135mm x 89mm DG9601B BLACK CODE: 25804 DG9601C SATIN NICKEL CODE: 25806   DG9601S - Single 240V G9 halogen floodlight with sensor   - Black powder coated or satin nickel metal body    with hood - Twist lock face with clear glass diffuser - Plastic mounting plate - IP44 - Includes 1 x 75W (maximum) G9 halogen lamp 113 195 Head Size: 135mm x 89mm DG9601BS BLACK CODE: 25789 DG9601CS SATIN NICKEL CODE: 25791   DG9602 - Twin 240V G9 halogen floodlight   - Black powder coated or satin nickel metal body   with hood - Twist lock face with clear glass diffuser - Plastic mounting plate - IP44 - Includes 2 x 75W (maximum) G9 halogen lamps Head Size: 135mm x 89mm 113 195 DG9602B BLACK CODE: 25805 DG9602C SATIN NICKEL CODE: 25807   DG9602S - Twin 240V G9 halogen floodlight with sensor   - Black powder coated or satin nickel metal body   with hood - Twist lock face with clear glass diffuser - Plastic mounting plate - IP44 - Includes 2 x 75W (maximum) G9 halogen lamps Head Size: 135mm x 89mm 113 195 DG9602BS BLACK CODE: 25788 DG9602CS SATIN NICKEL CODE: 25790   INBUILT SENSOR INBUILT SENSOR Halogen

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   269 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights Head Dimensions Height:  255mm  Width: 270mm Depth:  265mm Bracket Dimensions Height: 120mm  Width: 220mm DLPC Series - HID floodlight - Lightweight and durable UV stabilized   polycarbonate body - Plain aluminium reflector - Polycarbonate vandal resistant diffuser - Heavy duty bracket - Silicon seal and knock out cable entry - Includes integral Tridonic control gear  - IP55 Suitable for 70W SON/E ES elliptical high pressure sodium lamp with internal ignitor     or 80W MBFU mercury vapour lamp     or 125W MBFU mercury vapour lamp DLPC70HPS 70W HPS CODE: 17027 DLPC80MV 80WMV CODE: 17025 DLPC125MV 125WMV CODE: 17026    MOD series - HID metal halide floodlight - UV stabilised heat resistant polycarbonate    frame and housing - Symmetrical patterned aluminium alloy reflector - Impact resistant tempered safety glass - Heavy duty galvanised mounting bracket - Integral Tridonic control gear - IP55 Suitable for  70W RX7s 4000K tubular double ended metal halide lamp      or 150W RX7s 4000K tubular double ended metal halide lamp Head Dimensions Height:  350mm  Width: 290mm Depth:  165mm Bracket Dimensions Height:  130mm  Width: 320mm MOD70MH 70W MH CODE: 24187 MOD150MH 150WMH CODE: 24186   Outdoor floodlighting has become a necessary and cost effective way of improving safety and security. Crompton’s quality and economical range of discharge floodlights are an ideal solution for a large range of  commercial and industrial applications. The NISO series of floodlights are also suitable for internal use.    Discharge INGRESS PROTECTION IP55 INGRESS PROTECTION IP55

F 270 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Floodlights NISO RANGE of metal halide floodlights - Polycarbonate housing  - Tempered safety glass - Polished aluminium reflector - Black thermo plastic black frame - Front opening for lamp replacement - Mounting bracket - Integral control gear - Includes lamp - Weatherproof to IP66 NISO70MH 70W metal halide symmetrical floodlight complete with integral control gear and 70W 4000K tubular double  ended lamp NISO70MH Symmetrical CODE: 25753   260 354 296 130 Power Supply: - Voltage: 230V-240V 50HZ - Gear included with 0.9 power factor correction    capacitor, igniter and ballast - Stiff wires 1.75mm² section with glass silicon sheathing - Terminals 2p for a maximum conductor section of 6mm² - Class II insulation - does not require earthing Easy Maintenance The front opening clip closure system facilitates  maintenance as the safety glass does not have to  be supported.   Precise Lighting The floodlights can be precisely adjusted with the  graduated scale on the fixture handle. A high quality range of floodlights for lighting of parks,  car parks, yards, monuments, sport and recreation areas.  Materials: - Thermoplastic housing P.B.T. F.V. 30% - 99.9 aluminium reflector - Silicon foam seal cast-in seating - Screen printed tempered glass, 4mm for Niso   70W and 5mm for other types - Stainless steel bracket and plastic nut caps - Goniometric device for light orientation - 3mm thick aluminium plate accessory holder - Stainless steel screws - 66 polyamide cable gland V0 self-extinguishing IP66:   PG9 (cable diam. 5-8mm) PG11    (cable diam. 9-11mm) - Metal halide lamps included                                                                                 Discharge INGRESS PROTECTION IP66

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   271 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   F Floodlights NISO400WW 400W metal halide floodlight complete with integral  control gear and 400W 4000K tubular E40 base lamp NISO250MHA Asymmetrical CODE: 25775 NISO250MHS Symmetrical CODE: 25751   385 473 402 148 NISO150MH  150W metal halide symmetrical floodlight complete  with integral control gear and 150W 4000K tubular double ended lamp NISO150MH Symmetrical CODE: 25752   NISO250WMH 250W metal halide floodlight complete with integral  control gear and 250W 4000K tubular E40 base lamp NISO400MHA Asymmetrical CODE: 25774 NISO400MHS Symmetrical CODE: 25750   475 535 458 135 475 535 458 135 Discharge

High Bay H

Crombay ..........................................................................274

H 274 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   High Bay High Bay Crompton’s range of “CROMBAY’ high bay fittings are an ideal and economical solution for lighting large areas  with high ceiling heights. Units come complete with suspension hook and factory fitted flex and plug.Available  in both 400W mercury vapour and metal halide lamp types with optional blocking inductor. An optional glass  cover is also available. ‘CROMBAY’ HIGH BAY 400W - An economical range of commercial interior   high bay fixtures - White powder coated metal housing - Integral control gear and lampholder - Aluminium reflector - Hook flex and plug - Blocking inductor option - Includes 400W mercury vapour or   400W metal halide lamp Lamp re-order codes:  400W mercury vapour Code: 14538 400W metal halide Code: 25172 Note: Orders in multiples of six units ‘CROMBAY’ HIGH BAY ENCLOSURE - Reflector enclosure for the 400W high bay fittings - Four mounting brackets with fixing screws - Glass cover and gasket - Safety lanyard HB400MV Mercury Vapour CODE: 25729 HB400MVBI Mercury Vapour CODE: 25770 HB400MH Metal Halide CODE: 25731 HB400MHBI Metal Halide CODE: 25767 HBRE400 Glass Enclosure CODE: 25711 240 250 410 490 412 5

Exterior Bunkers & Wall Lights  E

Bunkers and Wall Lights ................................................277Fluorescent Bunkers and Wall Lights...........................290GX53 Compact Fluorescent Wall Lights.......................296GU10 Compact Fluorescent Wall Lights.......................298Halogen Wall Lights ......................................................299LED Wall Lights ..............................................................306Stainless Steel Maintenance .......................................309

277 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX6200 – ‘Carlton’ Round Bunker Series - Large round exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 240V 70W ES lamp EX6100 – ‘Carlton’ Round Bunker Series - Small round exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 240V 42W ES lamp EX6100B Plain White CODE: 20536 EX6100B Plain Black CODE: 20534 EX6100B Plain Green CODE: 20535 EX6100B Plain Beige CODE: 20533 EX6100B Plain Silver CODE: 22526 EX6100A Caged White CODE: 20532 EX6100A Caged Black CODE: 20530 EX6100A Caged Beige CODE: 20529 EX6100D Louvred White CODE: 20544 EX6100D Louvred Black CODE: 20542 EX6100D Louvred Green CODE: 20543 EX6100D Louvred Beige CODE: 20541 EX6100D Louvred Silver CODE: 22528   EX6200B Plain White CODE: 20552 EX6200B Plain Black CODE: 20550 EX6200B Plain Green CODE: 20551 EX6200B Plain Beige CODE: 20549 EX6200B Plain Silver CODE: 22530 EX6200A Caged White CODE: 20548 EX6200A Caged Black CODE: 20546 EX6200A Caged Beige CODE: 20545 EX6200D Louvred White CODE: 20560 EX6200D Louvred Black CODE: 20558 EX6200D Louvred Green CODE: 20559 EX6200D Louvred Beige CODE: 20557 EX6200D Louvred Silver CODE: 22532   180 95 180 Exterior Bunkers and Wall Lights Crompton Lighting has an extensive range of exterior wall lights that are suitable for many varied outdoor  applications. They are also available in a wide range of finishes and colours. Planned and efficient exterior  lighting gives the benefits of improved safety and security as well as visually enhancing the area. 180 95 180 240 120 240 240 130 240 180 100 180 240 125 240

E 278 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX7100 – ‘Carlton’ Oval Bunker Series - Small oval exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 240V 42W ES lamp EX7100B Plain White CODE: 20577 EX7100B Plain Black CODE: 20575 EX7100B Plain Green CODE: 20576 EX7100B Plain Beige CODE: 20574 EX7100B Plain Silver CODE: 22522 EX7100A Caged White CODE: 20573 EX7100A Caged Black CODE: 20571 EX7100A Caged Green CODE: 20572 EX7100A Caged Beige CODE: 20570 EX7100A Caged Silver CODE: 22521 EX7100D Louvred White CODE: 20585 EX7100D Louvred Black CODE: 20583 EX7100D Louvred Green CODE: 20584 EX7100D Louvred Beige CODE: 20582 EX7100D Louvred Silver CODE: 22524   EX7200B Plain White CODE: 20602 EX7200B Plain Black CODE: 20600 EX7200B Plain Green CODE: 20601 EX7200B Plain Beige CODE: 20599 EX7200B Plain Silver CODE: 22518 EX7200A Caged White CODE: 20598 EX7200A Caged Black CODE: 20596 EX7200A Caged Green CODE: 20597 EX7200A Caged Beige CODE: 20595 EX7200A Caged Silver CODE: 22517 EX7200D Louvred White CODE: 20610 EX7200D Louvred Black CODE: 20608 EX7200D Louvred Green CODE: 20609 EX7200D Louvred Beige CODE: 20607 EX7200D Louvred Silver CODE: 22520   EX7200 – ‘Carlton’ Oval Bunker Series - Large oval exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 240V 70W ES lamp 210 90 110 210 95 110 210 80 110 285 120 160 280 130 160

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   279 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX3072/3/4 – ‘Aurora’ Round Bunker Series - Small round exterior bunker - Powder coated die-cast aluminium - Polycarbonate diffuser - Ceramic lampholder - IP54  Suitable for 1 x maximum 240V 42W fancy round ES lamp 190 95 EX3072W Plain White CODE: 20431 EX3072B Plain Black CODE: 20429 EX3072S Plain Silver CODE: 20430 EX3073W Half Eye White CODE: 20434 EX3073B Half Eye Black CODE: 20432 EX3073S Half Eye Silver CODE: 20433 EX3074W Grill White CODE: 20437 EX3074B Grill Black CODE: 20435 EX3074S Grill Silver CODE: 20436   EX4072/3/4 – ‘Aurora’ Round Bunker Series - Large round exterior bunker - Powder coated die-cast aluminium - Polycarbonate diffuser - Ceramic lampholder - IP54  Suitable for 1 x maximum 240V 70W ES lamp 190 100 105 190 260 130 260  130  EX4073W Half Eye White CODE: 20485 EX4073B Half Eye Black CODE: 20483 EX4073S Half Eye Silver CODE: 20484 EX4074W Grill White CODE: 20488 EX4074B Grill Black CODE: 20486 EX4074S Grill Silver CODE: 20487

E 280 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX3082/3/4 – ‘Aurora’ Oval Bunker Series - Small oval exterior bunker - Powder coated die-cast aluminium - Polycarbonate diffuser - Ceramic lampholder - IP54  Suitable for 1 x maximum 240V 42W fancy round ES lamp 210 145 100 EX3082W Plain White CODE: 20455 EX3082B Plain Black CODE: 20453 EX3082S Plain Silver CODE: 20454 EX3083W Half Eye White CODE: 20458 EX3083B Half Eye Black CODE: 20456 EX3083S Half Eye Silver CODE: 20457 EX3084W Grill White CODE: 20461 EX3084B Grill Black CODE: 20459 EX3084S Grill Silver CODE: 20460   EX4083/4 – ‘Aurora’ Oval Bunker Series - Large oval exterior bunker - Powder coated die-cast aluminium - Polycarbonate diffuser - Ceramic lampholder - IP54  Suitable for 1 x maximum 240W 70W ES lamp 145 210 115 145 210 115 330 130 210 330 135 210 EX4083W Half Eye White CODE: 20494 EX4083B Half Eye Black CODE: 20492 EX4083S Half Eye Silver CODE: 20493 EX4084W Grill White CODE: 20497 EX4084B Grill Black CODE: 20495 EX4084S Grill Silver CODE: 20496

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   281 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EXB777 - Recessed rectangular bricklight - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x 40W T29 ES tubular lamp EXB777W White CODE: 20396 EXB777B Black CODE: 20394 EXB777S Silver CODE: 20395   225 130 80 Cut-out: 120x215mm  EXB333 - Grilled recessed bricklight - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 42W fancy round ES lamp  EXB333W White CODE: 20381 EXB333B Black CODE: 20375 EXB333BE Beige CODE: 20374 EXB333S Silver CODE: 20377   235 100 Cut-out: 95x225mm  80 EXB444 - Louvred recessed bricklight - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 42W fancy round ES lamp  EXB444W White CODE: 20387 EXB444B Black CODE: 20383 EXB444S Silver CODE: 20385   230 100 80 Cut-out: 90x220mm  EXB555 - Open face recessed bricklight - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 42W fancy round ES lamp  EXB555W White CODE: 20393 EXB555B Black CODE: 20389 EXB555BE Beige CODE: 20388 EXB555S Silver CODE: 20391   235  100  80  Cut-out: 90x225mm

E 282 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights MBV – Mini Securelite - Weatherproof vandal resistant bulkhead - Shock resistant grey polycarbonate base and   opal diffuser - Integral Tridonic ballast in PL model - 20mm punch or drill required to remove cable   knock out - IP65 Suitable for 1 x maximum 240V 42W ES lamp or  Suitable for 2 x 9W PL G23 fluorescent lamps MBV60GY Grey/Opal CODE: 22704 MBV29GY Grey/Opal CODE: 22563   112 220 Depth 106mm EX1824  - Recessed wall light - Die-cast aluminium - Ribbed frosted polycarbonate diffuser - IP54 Suitable for 1 x maximum 13W PLC lamp Cutout: 95mm x 252mm 263 120 45 100 EX3092 – Nova - Downward bunker - Powder coated die-cast aluminium - Opal acrylic diffuser  - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 42W ES lamp  EX3092B Black CODE: 20463 EX3092S Silver CODE: 20465   190 135 110 EXST016 - Exterior wall light  - 316 grade stainless steel construction  - Clear polycarbonate diffuser  - IP44  - Matching garden bollards available   (codes 25004, 25007) Suitable for 1 x maximum 240V 42W ES lamp 210 Projection: 299mm 232 EXST016 Stainless Steel CODE: 25003   EX1824S Silver CODE: 22876   STAINLESS STEEL

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   283 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EXST031A – Keppel - Exterior wall light - 316 grade stainless steel construction - Opal polycarbonate diffuser - IP44 - Suitable for protected exterior applications   walls and under eaves Suitable for 1 x maximum 240V 42W ES fancy round lamp EXST031A Stainless Steel CODE: 24907   220 280  Projection: 95mm EXST031F – Hamilton - Exterior grilled wall light - 316 grade stainless steel construction\ - Opal polycarbonate diffuser - IP44 - Suitable for protected exterior applications   walls and under eaves Suitable for 1 x maximum 240V 42W ES  fancy round lamp EXST031Z – Brampton - Exterior wall light - 316 grade stainless steel construction - Opal polycarbonate diffuser - IP44 - Suitable for protected exterior applications   walls and under eaves Suitable for 1 x maximum 240V 42W ES  fancy round lamp EXST031F Stainless Steel CODE: 24906   EXST031Z Stainless Steel CODE: 26538   220 280   Projection: 95mm 220 280    Projection: 95mm STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

E 284 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX1499/1 - Cylindrical wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 - Matching garden bollards available (EX1007B series) Suitable for 1 x maximum 240V 42W ES lamp  165 87 Projection: 140mm EX1499/1 Silver CODE: 24900   EX1499/2 - Cylindrical up/down wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 - Matching garden bollards available (EX1007B series) Suitable for 2 x maximum 240V 42W ES lamps 90 305 Projection: 150mm EX1499/2 Silver CODE: 24901   DLC733 - Ceiling mounted downlight - High quality aluminium construction - UV glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum75W ES PAR30 lamp 108 170 DLC733W White CODE: 24904 DLC733S Silver CODE: 24905   EXST226 - Wall light  - 316 grade stainless steel construction  - Opal polycarbonate diffuser  - IP44  - Matching garden bollard available (code 25002) Suitable for 1 x maximum 240V 42W fancy round ES lamp 390 100 Projection: 143mm EXST226 Stainless Steel CODE: 25001   STAINLESS STEEL

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   285 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EXST082 - Wall light  - 316 grade stainless steel construction  - Opal polycarbonate diffuser  - IP44  Suitable for 1 x maximum 240V 42W fancy round ES lamp 480 100 Projection: 130mm EXST082 Stainless Steel CODE: 25005   EXST028 - Louvred wall light - 316 grade stainless steel - Polycarbonate diffuser - IP44  - Matching garden bollard available (code 24120) Suitable for 1 x maximum 240V 42W fancy round ES lamp 155     120 130 380 EXST028 Stainless Steel CODE: 24136   EXST025 - Diffused wall light - 316 grade stainless steel - Polycarbonate diffuser - IP44 - Matching garden bollard available (code 24135) Suitable for 1 x maximum 240V 42W fancy round ES lamp 380 145 75 EXST025 Stainless Steel CODE: 24141   EXST028S Stainless Steel CODE: 25635   155     120 130 380 EXST028S - Louvred wall light with sensor - 304 grade stainless steel - Polycarbonate diffuser - IP44  - Matching garden bollard available (code 24120) Suitable for 1 x maximum 240V 42W fancy round ES lamp INBUILT SENSOR STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

E 286 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX3901 – Architectural - ‘Architectural’ bunker - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 70W ES lamp EX3901W White CODE: 19953 EX3901B Black CODE: 19951 EX3901S Silver CODE: 19952   180 265 Depth: 125mm EX3902 – Architectural - ‘Architectural’ grilled bunker - Die-cast aluminium - Frosted glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 240V 70W ES lamp EX3902W White CODE: 19956 EX3902B Black CODE: 19954 EX3902S Silver CODE: 19955   180 265 Depth: 125mm

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   287 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX14713/1 - Rectangular wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 100W ES PAR30 lamp  110 195  Projection: 175mm  EX14713/1 Silver CODE: 24894   EX14713/2 - Rectangular up/down wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 2 x maximum 100W ES PAR30 lamps 295 Projection: 175mm 110  EX14713/2 Silver CODE: 24895   EX14722/1 - Cylindrical wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x maximum 100W ES PAR30 lamp 107 203 Projection: 175mm EX14722/1 Silver CODE: 24898   EX14722/2 - Cylindrical up/down wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 2 x maximum 100W ES PAR30 lamps 317 107 Projection: 175mm EX14722/2 Silver CODE: 24899

E 288 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX706 - Coach light style wall light  - Die-cast aluminium - Frosted glass diffuser  - IP44  - Matching street lantern available (code 24376)   Suitable for 1 x maximum 240V 42W ES lamp 215 340 210 EX707 - Coach light style wall light  - Die-cast aluminium - Frosted glass diffuser  - IP44  - Matching street lantern available (code 24376)   Suitable for 1 x maximum 240V 42W ES lamp 215 340 210 EX706W White CODE: 18897 EX706B Black CODE: 18875 EX706BE Beige CODE: 18895   EX707B Black CODE: 20567 EX707BE Beige CODE: 18898 EX707G Green CODE: 18899   SO127 – Sorrento - Coach light style wall light  - High pressure die-cast aluminium - Powder coated finish  - Smoke coloured polycarbonate diffuser  - IP44    Suitable for 1 x maximum 240V 42W ES lamp 355 156 Projection: 115 SO127W White CODE: 25036 SO127B Black CODE: 25037 SO127AL Aluminium CODE: 25038

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   289 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights 210 210 Projection: 170mm EX1838L Grey CODE: 25633   160 160 Projection: 165mm EX1838S Grey CODE: 25632   275 Projection: 110mm 145 115 EX1841P Black CODE: 25637   275 Projection: 95mm 145 115 EX1841 Black CODE: 25636   EX1841P - Wall light with PIR sensor - Aluminium die-cast housing - Matt black powder coated finish - Opal polycarbonate diffuser - Ceramic lampholder - IP44  Suitable for 1 x maximum 240V 42W ES lamp EX1841 - Wall light - Aluminium die-cast housing - Matt black powder coated finish - Opal polycarbonate diffuser - Ceramic lampholder - IP44  Suitable for 1 x maximum 240V 42W ES lamp EX1838S - Small wall light - Grey aluminium die-cast housing - Clear polycarbonate diffuser - Thermoplastic lampholder - IP44  Suitable for 1 x maximum 240V 42W ES lamp EX1838L - Large wall light - Grey aluminium die-cast housing - Clear polycarbonate diffuser - Thermoplastic lampholder - IP44  Suitable for 1 x maximum 240V 52W ES lamp INBUILT SENSOR

E 290 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX3271/2/3 – ‘Forster’ Round Bunkers Series - Round fluorescent exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Integral ballast - IP54 Suitable for 2 x 9W PL fluorescent lamps with G23 base 280 140 EX3271B Grill Black CODE: 22548 EX3272W Plain White CODE: 22553 EX3272S Plain Silver CODE: 22552 EX3273B Half Eye Black CODE: 22554 EX3273S Half Eye Silver CODE: 22555   285 135 280 140 Compact Fluorescent Bunkers and Wall Lights  Are used for general illumination, security lighting, delineating  areas and any combinations of the above; all in exterior  environments. The number of hours operating per day  should be a major influence in the choice of lamp and fitting  combination. If use is going to be more than occasional then  fluorescent lamps are the logical choice because they last  longer and have lower running costs. 190 285 135 190 285 135 190 285 135 EX3261S Grill Silver CODE: 22540 EX3262B Plain Black CODE: 22542 EX3262S Plain Silver CODE: 22543 EX3263B Half Eye Black CODE: 22545 EX3263S Half Eye Silver CODE: 22546   EX3261/2/3 – ‘Forster’ Oval Bunkers Series - Oval fluorescent exterior bunker - Powder coated die-cast aluminium - Frosted glass diffuser - Integral ballast - IP54 Suitable for 2 x 9W PL fluorescent lamps with G23 base Fluorescent ENERGY SAVING ENERGY SAVING

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   291 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX1819/20/21 – ‘Vancouver’ Wall Light Series - Surface mounted fluorescent wall light - Die-cast aluminium - Ribbed frosted polycarbonate diffuser - Integral ballast - IP44 Suitable for 1 x 13W PLC fluorescent lamp with G24d-1 base 263 120 99 Base: 83x250mm   EX1819W Plain White CODE: 20367 EX1819B Plain Black CODE: 20365 EX1819S Plain Silver CODE: 20366 EX1820S Grilled Silver CODE: 20369 EX1821B Half Eye Black CODE: 20371   265 120 100 Base: 83x250mm  263 120 95   Base: 83x250mm  EX9100/1/2 – ‘Paris’ Round Bunker Series - Round fluorescent exterior bunker - Powder coated die-cast aluminium - Polycarbonate diffuser - Integral ballast - IP54  Suitable for 2 x 9W PL fluorescent lamps with G23 base   270 75 EX9100W Plain White CODE: 20624 EX9100B Plain Black CODE: 20620 EX9100S Plain Silver CODE: 20622 EX9101W Half Eye White CODE: 20630 EX9101B Half Eye Black CODE: 20626 EX9101S Half Eye Silver CODE: 20628 EX9102B Louvred Black CODE: 20632 EX9102S Louvred Silver CODE: 20634   270 75 270 75 Fluorescent ENERGY SAVING ENERGY SAVING

E 292 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights SL29 – Solo - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 9W PL G23 compact fluorescent lamps SL29W White CODE: 25040 SL29G Graphite CODE: 25039   270 120 EX1831LW Louvred White CODE: 25958 EX1831LS Louvred Silver CODE: 25959 EX1831LB Louvred Black CODE: 25960 EX1831GW Grilled White CODE: 25962 EX1831GB Grilled Black CODE: 25963 EX1831PW Plain White CODE: 25965 EX1831PS Plain Silver CODE: 25964 EX1831PB Plain Black CODE: 25966   EURO - Fluorescent bunker - Frosted polycarbonate diffuser - UV stabilised polymer base - Integral ballast - IP55 Suitable for 2 x 18W PLC fluorescent lamps with G24d-2 base  EURO White CODE: 24185   335 120 EX1831 - Recessed 240V fluorescent bricklight - Die-cast aluminium housing with powder   coated paint finish - Opal polycarbonate diffuser - Integral control gear - IP54 - Black reinforced plastic housing for recessed   mounting - Mounting kit - Large cable entry with rubber grommet Suitable for 1 x 18W G24d-2 PLC compact fluorescent lamp 233 80 115 Cut-out: 227x100x74mm  233 80 125 Cut-out: 227x100x74mm  233 80 125 Cut-out: 227x100x74mm  Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   293 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights SW218 – Sidewalk - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 18W PLC G24d-2 compact fluorescent lamps 300 87 300  SW218W White CODE: 25031 SW218G Graphite CODE: 25030   LK218 – Link - Compact fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 18W PLC G24d-2 fluorescent lamps 200 100 320 LK218W White CODE: 25467 LK218G Graphite CODE: 25468   Fluorescent ENERGY SAVING ENERGY SAVING

E 294 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights LA29 – Largo - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 9W PLG23 compact fluorescent lamps LA29W White CODE: 25042 LA29G Graphite CODE: 25041   240 240 112 TA126 – Tardo - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 1 x 26W PLC G24d-3 compact fluorescent lamp TA126W White CODE: 25035 TA126G Graphite CODE: 25034   325 105 CA218 – Canto - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 18W PLC G24d-2 compact fluorescent lamps 325 105 CA218W White CODE: 25033 CA218G Graphite CODE: 25032   CA226 – Canto - Commercial exterior fluorescent bulkhead  - High pressure die-cast aluminium  - High quality premium powder coated finish  - Polycarbonate diffuser  - Stainless steel screws  - Integral ballast - IP65  Suitable for 2 x 26W PLC G24d-3 compact fluorescent lamps 325 105 CA226W White CODE: 25470 CA226B Black CODE: 25469 CA226G Graphite CODE: 25471   Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING ENERGY SAVING

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   295 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights 240 280 Projection: 85mm EX1835 Grey CODE: 25629   EX1835 - Fluorescent rectangular wall light - Aluminium die-cast housing - Grey powder coated finish - Opal polycarbonate diffuser - Integral control gear - Thermoplastic lampholders  - IP44 Suitable for 2 x 26W PLC G24d-3 fluorescent lamps EX1836 Grey CODE: 25630   120 350 Projection: 120mm EX1836 - Fluorescent rectangular wall light - Aluminium die-cast housing - Grey powder coated finish - Opal polycarbonate diffuser - Integral control gear - Thermoplastic lampholders  - IP44 - Matching garden bollard available (code 25631) Suitable for 1 x 26W PLC G24d-3 fluorescent lamp  180 310 Projection: 150mm EX1834 Grey CODE: 25628   EX1834 - Fluorescent rectangular wall light - Aluminium die-cast housing - Grey powder coated finish - Opal polycarbonate diffuser - Integral control gear - Thermoplastic lampholders  - IP44 Suitable for 2 x 26W PLC G24d-3 fluorescent lamps  Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING

E 296 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights 100  102  EX6042GX53 Dark Grey CODE: 25773   EX6042GX53 - Energy saving fluorescent circular ceiling light - Aluminium die-cast housing - Dark grey powder coated finish - Clear side and face diffusers - Thermoplastic lampholder - IP44 Suitable for 1 x maximum 9W GX53 CFL lamp  GX53  Fluorescent lamps Fluorescent GX53 lamps offer a long life and energy efficient alternative for many lighting  applications where these factors are important. They are particularly suited for this range of  energy efficient external wall lights. In internal  applications they are ideal for undershelf lighting  due also to their low profile. EXLS3174 Satin Chrome CODE: 25972   EXLS3341 Grey CODE: 26115   EXLS3172 Satin Chrome CODE: 25973   EXLS3174 -  Exterior 240V 11W fluorescent wall light/bunker -  Die-cast aluminium housing with grey powder   coated paint finish -  Combination diffuser of satin chrome and acrylic - Internal lampholder and terminal block -  IP44 -  Cable entry with rubber grommet Suitable for 1 x 11W GX53 compact fluorescent lamp EXLS3341 -  Square 240V compact fluorescent exterior wall light  -  Grey powder coated die-cast aluminium -  Grilled opal polycarbonate diffuser - IP44 Suitable for 1 x 11W 240V GX53 compact  fluorescent lamp EXLS3172 -  Exterior 240V 11W fluorescent wall light/bunker -  Die-cast aluminium housing with grey powder   coated paint finish -  Combination diffuser of satin chrome and acrylic - Internal lampholder and terminal block - IP44 - Cable entry with rubber grommet Suitable for 1 x 11W GX53 compact fluorescent lamp 55 140 55 140 140 140 50 Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING ENERGY SAVING (See page 400)

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   297 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights 100 190 Projection: 150mm EX6046 Dark Grey CODE: 25638   110 143 Projection: 150mm EX6047 Dark Grey CODE: 25639   EX6046 - Energy saving fluorescent up and down wall light - Dark grey aluminium die-cast housing - Cylindrical housing on rectangular wall mounting base - Clear face and side diffusers - Thermoplastic GX53 lampholders - IP44 Suitable for 2 x maximum 9W GX53 fluorescent lamps  EX6047 - Energy saving fluorescent wall light - Dark grey aluminium die-cast housing - Cylindrical housing on rectangular wall mounting base - Clear face and side diffusers - Thermoplastic GX53 lampholder - IP44 Suitable for 1 x maximum 9W GX53 fluorescent lamp  EXLSST4232C Stainless Steel CODE: 25777   90 70 Projection: 115mm 90 145 Projection: 115mm EXLSST4231C Stainless Steel CODE: 25776   EXLSST4231C - GX53 fluorescent up/down wall light  - Stainless steel housing  - Prismatic polycarbonate screw cap diffusers - GX53 thermoplastic lampholders - IP44 Suitable for 2 x maximum11W GX53 fluorescent lamps EXLSST4232C - GX53 fluorescent wall light  - Stainless steel housing  - Prismatic polycarbonate screw cap diffuser - GX53 thermoplastic lampholder - IP44 Suitable for 1 x maximum 11W GX53 fluorescent lamp Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING ENERGY SAVING

E 298 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights 204 89 60 EXLSST5110 Stainless Steel CODE: 25594   140 89 EXLSST5108 Stainless Steel CODE: 25593   140 89 60 EXLSST5109 Stainless Steel CODE: 25595   EXLSST5109 - Energy saving compact fluorescent wall light - 304 grade stainless steel housing - Clear acrylic diffuser  - Ceramic lampholder  - IP44 - Includes 1 x maximum 9W GU10 CFL lamp  EXLSST5110 - Energy saving compact fluorescent adjustable wall light - 304 grade stainless steel housing - Clear acrylic diffuser  - Ceramic lampholder  - IP44 - Includes 1 x maximum 9W GU10 CFL lamp  EXLSST5108 - Energy saving compact fluorescent up/down wall light - 304 grade stainless steel housing - Clear acrylic diffusers  - Ceramic lampholders  - IP44 - Includes 2 x maximum 9W GU10 CFL lamps  GU10 Compact  Fluorescent  240V Lamps Their many advantages, including longer life and energy efficiency, makes them an ideal  replacement for standard and less efficient GU10 base halogen lamps. Fluorescent ENERGY SAVING ENERGY SAVING ENERGY SAVING STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL (See page 397)

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   299 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX14710/1 - Rectangular 240V GU10 halogen wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x 50W 240V GU10 halogen lamp 76 127 Projection: 126mm EX14710/1 Silver CODE: 24892   EX14710/2 - Rectangular 240V GU10 halogen up/down wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholders - IP44 Suitable for 2 x 50W 240V GU10 halogen lamps 185 Projection: 126mm 76 EX14710/2 Silver CODE: 24893   EX1493/1 - Cylindrical 240V GU10 wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x 50W 240V GU10 halogen lamp 65 135 Projection: 115mm EX1493/1 Silver CODE: 24896   EX1493/2 - Cylindrical 240V GU10 up/down wall light - Die-cast aluminium construction - Glass diffuser - Ceramic lampholders - IP44 Suitable for 2 x 50W 240V GU10 halogen lamps 170 Projection: 115mm 65 EX1493/2 Silver CODE: 24897   Halogen Wall Lights Wall lights are designed to illuminate and enhance  the appearance of wall, ceiling and architectural  structures. Depending on the product selected,  they can eliminate glare and create visual continuity  and wall ‘grazing’ lighting effects.  Halogen

E 300 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX6042 - Ceiling mounted bulkhead  - Die-cast aluminium  - 5mm tempered clear glass diffuser  - IP65  Suitable for 1 x maximum 35W 240V GU10  halogen lamp 100  102  EX6042 Grey CODE: 25324   EX6041 - Wall mounted bulkhead  - Die-cast aluminium  - 5mm tempered clear glass diffuser  - IP65  Suitable for 1 x maximum 35W 240V GU10 halogen lamp 150 110 EX6041 Grey CODE: 25325   EX3009 - GU10 up/down wall light - Copper construction - Clear glass diffusers - IP44 Suitable for 2 x maximum 35W 240V GU10  halogen lamps  146 52 EX3009 Copper CODE: 25194   EX3040 - GU10 halogen wall bracket - Copper construction - Frosted glass diffuser - IP44 Suitable for 1 x maximum 35W 240V GU10  halogen lamp  126 133 Projection: 94mm 57 EX3040 Copper CODE: 25195   Halogen

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   301 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights 235 Projection: 110mm 110 EX6040 Dark Grey CODE: 25634   EX6040 - GU10 halogen up and down wall light - Dark grey aluminium die-cast housing - Semi cylindrical housing on rectangular   wall mounting base - Clear face and side polycarbonate diffusers - Ceramic lampholders - IP44  Suitable for 2 x maximum 35W GU10 halogen lamps EXST5109 - Surface mounted 240V GU10 halogen wall light - 316 grade stainless steel construction - UV glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x 50W 240V GU10 halogen lamp 78 83 80 EXST5110 - Surface mounted 240V GU10 halogen wall light - 316 grade stainless steel construction - UV glass diffuser - Ceramic lampholder - IP44 Suitable for 1 x 50W 240V GU10 halogen lamp 78 2 6 Total  Height  140mm EXST5108 - Surface mounted 240V GU10 halogen up/down   wall light - 316 grade stainless steel construction - UV glass diffusers - Ceramic lampholders - IP44 Suitable for 2 x 50W 240V GU10 halogen lamps 168 78 80    EXST5109 Stainless Steel CODE: 24909   EXST5110 Stainless Steel CODE: 24911    EXST5108 Stainless Steel CODE: 24910   Halogen STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

E 302 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights 45 100 EX213B Black CODE: 19632   EX213 - Wall mounted 12V halogen wall washer with hood - Die-cast aluminium - Glass diffuser - Ceramic lampholder - IP44  Suitable for 1 x maximum 20W 12V halogen bi-pin  lamp EX6023 - 240V GU10 halogen spotlight - Surface mounted - High quality aluminium construction - UV glass diffuser - IP65 Suitable for 1 x 50W 240V GU10 halogen lamp 112 148 129 110 EX6023 Black CODE: 24908   EX6050B Black CODE: 25969   EX6051B Black CODE: 25970   EX6050B - Exterior up/down 240V halogen wall light - Die-cast aluminium housing with black powder   coated paint finish - Clear polycarbonate diffusers - Internal lampholders and terminal block - IP44 - Mounting kit - Matching garden bollard available (code 25971) Suitable for 2 x 35W maximum GU10 halogen lamps EX6051B - Exterior 240V halogen wall light - Die-cast aluminium housing with black powder   coated paint finish - Clear polycarbonate diffuser - Internal lampholder and terminal block - IP44 - Mounting kit - Matching garden bollard available (code 25971) Suitable for 1 x 35W maximum GU10 halogen lamp 110 155 Depth: 110 mm 110 235 Depth: 110 mm Halogen

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   303 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX210E - Recessed 12V halogen wall light with hood - Copper face - Stainless steel housing (ventilated) - Glass diffuser - Ceramic lampholder - IP44  Suitable for 1 x maximum 50W MR16 open faced halogen dichroic lamp EX210E Copper CODE: 25048   EX5023SS Stainless Steel CODE: 22620   89 128 Fitting Height: 103mm EX214 - Wall mounted 12V halogen wall washer with louvre - Die-cast aluminium - Glass diffuser - Ceramic lampholder - IP44  Suitable for 1 x maximum 20W 12V halogen bi-pin lamp 45 100 EX214B Black CODE: 19634   EX5023 - Recessed 12V halogen wall washer with hood - 316 grade stainless steel - UV glass diffuser - Black plastic housing - Ceramic lampholder - IP65 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp  92 104 Housing diameter: 53mm EX210 - Recessed 12V halogen wall light  - Copper face - Stainless steel housing (ventilated) - Glass diffuser - Ceramic lampholder - IP44  Suitable for 1 x 50W MR16 open faced halogen dichroic lamp EX210 Copper CODE: 25049   92 80 Housing diameter: 53mm Halogen STAINLESS STEEL

E 304 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights 80 152 80 EX6017S Grey CODE: 25323   EX5010SS 316 Stainless Steel CODE: 22614   EX5008B Black CODE: 22603   EX5008SS 316 Stainless Steel CODE: 22606   EX6027 - Metal halide wall mounted bulkhead - Die-cast aluminium - Tempered 4mm clear glass diffuser - Integral control gear - IP65 Suitable for 1 x 70W metal halide double ended lamp 300 150 EX6027 Black CODE: 25322   EX6017 - G9 halogen wall light - Grey die-cast aluminium construction - Acrylic diffuser - IP65 Suitable for 1 x maximum 60W G9 Halogen lamp  Total Height: 135mm 76 2 6 EX5010B Black CODE: 22611 EX5010GR Green CODE: 22612 EX5010S Silver CODE: 22613   EX5008 - Surface mounted up/down 12V halogen wall light - Choice of high quality machined aluminium   body with powder coated finish or 316 grade    stainless steel construction - UV glass diffusers - Ceramic lampholders - IP54 Suitable for 2 x maximum 20W MR16 open faced halogen dichroic lamps 77 90 135 EX5010 - Surface mounted adjustable 12V halogen wall light - Choice of high quality machined aluminium   body with powder coated finish or 316 grade    stainless steel construction - UV filtered glass face - Ceramic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp Halogen STAINLESS STEEL STAINLESS STEEL

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   305 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights EX5009SS 316 Stainless Steel CODE: 22610   20 100 GLV503ELB Black CODE: 17323 GLV503ELCO Copper CODE: 17324   GLV505 - Surface mounted 12V halogen up/down spotlight - High quality powder coated copper construction - Glass lens with black honeycomb grid diffuser - Ceramic lampholders - IP44 Suitable for 2 x maximum 20W MR16 open faced  halogen dichroic lamps  210 80 55 Total Depth: 88mm GLV505B Black CODE: 17332 GLV505CO Copper CODE: 17333   GLV503E - Eyelid accessory for GLV503 - High quality copper construction - Copper or powder coated finish GLV503B Black CODE: 17319 GLV503CO Copper CODE: 16938   87 95 60 GLV503 - Recessed 12V halogen wall light - High quality copper construction - Glass cover with black honeycomb diffuser - Ceramic lampholder - IP55  Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp  EX5009B Black CODE: 22607 EX5009GR Green CODE: 82251 EX5009S Silver CODE: 22609   65 75 85 EX5009 - Surface mounted adjustable 12V halogen wall light - Choice of high quality machined aluminium    body with powder coated finish or 316 grade    stainless steel construction - UV filtered glass face - Ceramic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp Halogen STAINLESS STEEL

E 306 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights 90 55 60 EXST4001 Stainless Steel CODE: 25318   150 45 55 Projection: 90mm  EXST4002 Stainless Steel CODE: 25319   125 55 60 EXST4003 Stainless Steel CODE: 25320   EXST4002 - LED wall light - Stainless steel construction - Toughened glass diffuser - Inbuilt driver for direct connection to 240V supply - IP65 - 1W white LED  EXST4003 - LED adjustable wall light - Stainless steel construction - Toughened glass diffuser - Inbuilt driver for direct connection to 240V supply - IP65 - 1W white LED  LED LED exterior garden lights offer an economical and long life  alternative to conventional lamp types. Many of the fittings come with an inbuilt driver which enable  direct connection to 240V supply. The main benefits of LED’s is  their low operating temperature, low energy cost and extremely  long lamp life. LED ENERGY SAVING ENERGY SAVING ENERGY SAVING EXST4001 - LED up/down wall light - Stainless steel construction - Toughened glass diffusers - Inbuilt driver for direct connection to 240V supply - IP65 - 2 x 1W white LED’s  INGRESS PROTECTION IP65 INGRESS PROTECTION IP65 INGRESS PROTECTION IP65 STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   307 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights 300 85 38 EX8011     Stainless Steel CODE: 25313   222 60 Projection: 112mm EXST582 Stainless Steel CODE: 25642   150 60 Projection: 110mm 300 60 Projection: 105mm 260 120 EXST555PS Stainless Steel CODE: 25640   EX8011 - LED wall light - 304 grade stainless steel construction - Frosted acrylic diffuser - Inbuilt driver for direct connection to 240V supply - IP44 - 1W white LED - Matching garden bollard available (code 25312) EXST582 - LED wall light  - Stainless steel housing and base  - Glass diffuser - Integral LED driver for direct connection to 240V supply  - IP44 - 12 x 0.1W white LED’s   - Matching garden bollard available (code 25643)  EXST581 - LED up/down wall light  - Stainless steel housing and base  - Glass diffusers - Integral LED driver for direct connection to 240V supply  - IP44 - 12 x 0.1W white LED’s in each diffuser  - Matching garden bollard available (code 25643)  EXST555PS -  Combined 240V GU10 and LED up/down sensor   wall light  -  Stainless steel housing and base  -  Glass diffusers -  Integral LED driver for direct connection to 240V   supply  -  LED is controlled by photocell (comes on when dark) -  GU10 lamp is controlled by PIR sensor    (detects movement) -  IP44 -  12 x 0.1W white LED’s (bottom) -  Includes 1 x maximum GU10 35W (top) LED INBUILT SENSOR EXST581 Stainless Steel CODE: 25641   ENERGY SAVING ENERGY SAVING ENERGY SAVING ENERGY SAVING STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

E 308 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Exterior Bunkers & Wall Lights EX4182 Black CODE: 25625   120 120 60 120 60 EX4181 Black CODE: 25624   EX4181 - Energy saving LED circular wall light - Aluminium die-cast housing - Matt black powder coated finish - Tapered thermoplastic mounting enclosure - Clear diffuser - Inbuilt driver for direct connection to 240V supply - IP65 - 14 x 0.1W white LED’s  EX4182 - Energy saving LED square wall light - Aluminium die-cast housing - Matt black powder coated finish - Tapered thermoplastic mounting enclosure - Clear diffuser - Inbuilt driver for direct connection to 240V supply - IP65 - 14 x 0.1W white LED’s  EXST4081K 316 Stainless Steel CODE: 25314   EX1860 Silver CODE: 26404   EXST4081K - LED low voltage bricklight kit - 3 stainless steel bricklights with glass diffuser  - Low voltage cable with connectors - 10VA IP44 driver with flex and plug - IP67 - 12 x 0.1W white LED’s in each brickllight EX1860 - LED wall light - Silver powder coated die-cast aluminium    body and cover - Clear polycarbonate lens - Built in driver - IP44 - 3 x 1W 4100K white LED’s 120 180 70 LED ENERGY SAVING ENERGY SAVING ENERGY SAVING ENERGY SAVING INGRESS PROTECTION IP65 STAINLESS STEEL Cutout: 55mm x 105mm 135 75 INGRESS PROTECTION IP67

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   309 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   E Exterior Bunkers & Wall Lights ROUTINE MAINTENANCE (CLEANING) FOR STAINLESS STEEL LUMINAIRES Stainless Steel features  as the main exterior metal of many luminaires; many of us recognise that stainless steel is  intrinsically attractive (1.) – but these fitting require maintenance like all others.  Stainless steel enjoys a strong and enduring reputation for long term appearance and structural integrity. But like  all materials stainless steel may become stained or discoloured over time, impairing the overall look. This brown  discolouration is referred to as “tea staining”.  Tea staining (2) can be defined as:  Discolouration of the surface of stainless steel that does not affect the structural integrity or the longevity  of the material. CONTRIBUTING FACTORS The relationships between the contributing factors are complex, but generally become increasingly critical closer to  marine environments ENVIRONMENTAL FACTORS Tea staining occurs most commonly within about five kilometres of the sea and becomes progressively worse  closer to the marine source.  However, wind exposure, pollution levels and higher temperatures can create  environments where tea staining might occur 20 kilometres or more from the nearest body of sea water.  Swimming pool surrounds must also be treated in the same manner; particularly indoor pools.  These same factors also increase corrosion rates of alternative materials. SURFACE FINISH Rough surface finishes promote tea staining: the smoother the surface, the better. Smoother surface finishes stay  cleaner between washes and don’t have deep surface grooves where chlorides (salts) and other contaminants can  collect and cause staining. Even smooth stainless steel finishes in coastal environments may show tea staining if not  washed regularly. SELECTING STAINLESS STEEL LUMINAIRES Care in the selection of luminaires for any application will avoid problems and disappointment; some considerations  for selection include: -  Appropriate Grade Selection. Exposure of a particular grade of stainless steel to a more aggressive environment  than it can resist will contribute to tea staining. Grade 316 should be selected as a minimum within five kilometres  of the sea. The less expensive grades (such as 304 or 430) will probably become tea stained or even suffer more  severe corrosion.  Appropriate Surface Finish. Keep in mind the maxim; ‘the smoother the better’ when selecting any stainless steel  luminaire that will be used in a marine environment. Avoid selecting items with grooves/fins and swirls as features in  the design Prevention - Perform regular maintenance Washing removes contaminants (such as salt) that can cause corrosion and is necessary to avoid tea staining. Rain  washing over the surface is helpful in reducing tea staining. For best results wash with soap or mild detergent and  warm water followed by rinsing with clean cold water. The appearance of the surface can be improved further if  the washed surface is wiped dry. Most householders wash the wall & eaves of their home a couple of times per  year to get rid of accumulations of dust, leaves and  cobwebs; take the time to ensure that the stainless steel  exteriors also be washed when cleaning of the surrounding area takes place.   More technical information about stainless steel is available from sources such as the Australian Stainless Steel Association @ www.assda.asn.au 1. 2. Stainless Steel Maintenance

Landscape Lighting L

Inground Garden Spotlights ............................................312Inground Garden Uplights  ...............................................314‘Drive-Over’ & ‘Walk-Over’  Inground Lights .........................317‘Walk-Over’ LED Inground Uplights  ..................................319LED Lights ........................................................................320Bollards and Post Lights ..................................................321LED Bollards ....................................................................328

L 312 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EX07 - 12V/20W halogen inground spotlight - Die-cast aluminium construction  - Powder coated finish - Clear safety glass diffuser - Face screws off for lamp replacement - Ceramic lampholder - Inground spike included with product - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX07A - 12V/20W halogen inground spotlight with hood - Die-cast aluminium construction  - Powder coated finish - Clear safety glass diffuser - Face screws off for lamp replacement - Ceramic lampholder - Inground spike included with product - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX07AB Black CODE: 19370 EX07AGR Green CODE: 19371   170 170 60 72 Inground Garden Spotlights This diverse range of inground halogen  garden spotlights covers a wide variety  of landscape lighting applications ranging  from accent lighting of statues and  garden features to general lighting of  pathways and entertainment areas.  With a choice of die-cast aluminium,  stainless steel and copper fittings, there  is a fitting in this range to suit most  situations. There is even an IP67 rated  fitting useful for lighting water features  and fish ponds.     To install these 12V Garden Spotlights the  following are required: • An ATCO WEATHERPROOF 240/12V     transformer, the correct wattage for the     number of lights being installed    - for instance if you are installing 10-12     50W garden spotlights, you will need     THREE 200VA IP65 rated transformers     such as the ATCLVL6-2-SPO1   (Code: 10385) • Low voltage garden cable of the correct     length and diameter for your lighting     setup. What you need to install these 12V  Garden Spotlights EX07B Black CODE: 19372 EX07GR Green CODE: 19373   170 140 60 72

313 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting CPLB120B – Pond Light - 12V/20W Halogen - Waterproof die-cast aluminium construction - Toughened glass lens diffuser with silicon seal - Three metre waterproof cable -  Product may be submerged up to one metre   below water in fresh water ponds only - Ceramic lampholder - IP67 - Includes 1 x 20W MR16 open faced MR16   halogen dichroic lamp CPLB120B Black CODE: 18843   70 6 9 Face dismeter:98mmHeight extended: 150mm GLV504 - 12V/20W halogen inground spotlight - High quality copper construction with option    of black powder coated finish - Clear safety glass with anti-glare mesh - Adjustable head and inground spike - Plastic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp GLV504B Black CODE: 17328 GLV504CO Copper CODE: 16937   380 140 5 0 1 Head    diameter: 55mm EX5011 - 12V/20W halogen inground spotlight - Clear safety glass diffuser with UV filter - 90° adjustable head and inground spike - Ceramic lampholder - IP65 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp 75 230 65 EX205 - 12V/20W halogen spotlight - Die-cast aluminium construction - Powder coated finish - Clear safety glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX205B Black CODE: 19617   70 100 100  INGRESS PROTECTION IP65 INGRESS PROTECTION IP65 EX5011SS 316 Stainless Steel CODE: 22618   EX5011B Black CODE: 22615 EX5011S Silver CODE: 22617   STAINLESS STEEL

L 314 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EX5021SS - 12V/20W halogen inground uplight - 316 grade stainless steel body and trim - External housing of thermoplastic material for     direct burial is supplied with the fitting - Heat tempered safety glass diffuser - Ceramic lampholder - IP65 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX5021SS 316 Stainless Steel CODE: 22619   103 90 Cutout:  85mm Rim Height: 6mm Height without cable entry: 80mm Diameter of body: 63mm EX211 - 12V/20W halogen inground louvred uplight - Die-cast aluminium body and rim - Powder coated finish - Heat tempered safety glass diffuser with    louvred cover - Ceramic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX211B Black CODE: 19619   100 110 Cutout: 85mm Rim Height:15mm  EX212 - 12V/20W halogen inground uplight - Die-cast aluminium body and rim - Powder coated finish - Heat tempered safety glass diffuser - Ceramic lampholder - IP54 Suitable for 1 x maximum 20W MR16 open faced halogen dichroic lamp EX212B Black CODE: 19637   96 100 Cutout: 85mm Rim Height: 15mm Inground Garden Uplights This range of standard inground halogen garden uplights covers a diverse range of landscape lighting applications  ranging from the illumination of garden beds to perimeter lighting. With a choice of 240V and 12V halogen  stainless steel uplights and 20W/12V halogen die-cast aluminium fittings, there is a light in this range to suit  most situations. It is important to note that only the stainless steel fittings should be used in coastal areas. EX7005 - 50W GU10 halogen inground uplight - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material for   direct burial is supplied with the fitting - 4mm thick 316 grade stainless steel rim - Heat tempered safety glass diffuser - Silicone rubber gasket - Thermoplastic cable gland (allows for through wiring) - IP67  Suitable for 1 x maximum 50W 240V GU10 halogen  lamp  EX7005SS 316 Stainless Steel CODE: 24912   108 144 Canister cut-out: 80mm STAINLESS STEEL STAINLESS STEEL INGRESS PROTECTION IP65

315 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EX7005LV - Inground ‘Cool Touch’ uplight - Powder coated aluminium alloy housing - 316 stainless steel fascia - Toughened 12mm glass diffuser - Glass is safe to touch in operation - Integral teroidal low voltage transformer - Black thermoplastic sleeve for inground installations - Also suitable for mounting on decking and boardwalks - IP67 Suitable for 1 x 50W MR16 halogen dichroic lamp EX7005LV Stainless Steel CODE: 25321   225 280 180 Cutout: 200mm EX7003A Silver CODE: 25626   360 220 180 155 300 320 EX7003D Black CODE: 25627   360 220 180 155 310 320 EX7003A - 26W fluorescent inground uplight - Die-cast aluminium body and grille - Silver finish - External housing of thermoplastic material for   inground installation - Safety glass diffuser - Integral control gear - IP67  Suitable for 1 x 26W PLC G24d-3 fluorescent lamp EX7003D - 26W fluorescent inground uplight - Die-cast aluminium body and grille - Black finish - External housing of thermoplastic material for   inground installation - Safety glass diffuser - Integral control gear - IP67  Suitable for 1 x 26W PLC G24d-3 fluorescent lamp STAINLESS STEEL EX7008E - 70W metal halide inground light - Black powder coated die-cast aluminium body - Thermoplastic cannister - Safety glass diffuser - Ferromagnetic control gear - Ceramic lampholder - PG13.5 cable gland - IP67  Suitable for 1 x maximum 240V 70W G12 single  metal halide lamp 360 210 Cut-Out: Ø190mm EX7008E Black CODE: 26405

L 316 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EX4382 - 9W GX53 inground light - Black powder coated die-cast aluminium body - Thermoplastic cannister - Safety glass diffuser - thermoplastic lampholder - Brass cable gland - IP67  Suitable for 1 x maximum 240V 9W GX53 CFL lamp 170 150 Cut-Out: Ø100mm EX4382 Black CODE: 26406   EX7010B Stainless Steel CODE: 25967   EX7010B - In-ground 240V 9W square uplight - Die-cast aluminium housing with black powder   coated paint finish - Stainless steel (304) fascia - Frosted glass diffuser - Internal lampholder and terminal block - IP67 - Rigid plastic canister for inground installation - Cable gland - Mounting kit Suitable for 1 x 9W maximum GX53 compact  fluorescent lamp EX7010A - In-ground 240V 9W uplight - Die-cast aluminium housing with black powder   coated paint finish - Stainless steel (304) fascia - Frosted glass diffuser - Internal lampholder and terminal block - IP67 - Rigid plastic canister for inground installation - Cable gland - Mounting kit Suitable for 1 x 9W maximum GX53 compact  fluorescent lamp EX7010A Stainless Steel CODE: 25968   Cut-out with cannister: 90mm Cut-out without cannister: 108mm   120 72 Cut-out with cannister: 90mm Cut-out without cannister: 108mm   120 72 ENERGY SAVING ENERGY SAVING ENERGY SAVING STAINLESS STEEL STAINLESS STEEL

317 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting ‘Walk-Over’ and ‘Drive-Over’ Inground Lights Crompton Lighting’s range of walk / drive-over lights  combine the benefits of 316 grade stainless steel with  toughened heat tempered safety glass to provide the ideal  solution to most drive-way lighting needs.  Weatherproof to IP67, and utilising either fluorescent or  metal halide lamps, these fittings are both durable and  economical to run.       ‘Drive-Over’ Light Facts Crompton Lighting’s ‘Drive-Over’ inground  lights are suitable for use in all driveways that  meet with the following parameters: • The lights must not be subjected to a       static weight greater than 2000kg • The maximum drive-over speed tolerated     by the lights is 25 km/hourIt is not recommended  that these lights be  used in areas where people walk around  bare footed. Drive - Over EX7009 - 150W metal halide ‘Drive-Over’ inground light - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material for direct   burial - 4mm thick 316 grade stainless steel rim - Symmetrical polished aluminium reflector - 12mm thick heat tempered safety glass - Silicone rubber gasket - Thermoplastic cable gland (allows for through wiring) - Integral control gear - IP67 Suitable for 1 x 150W 240V RX7s double ended metal halide lamp EX7008A - ‘Drive over’ inground light - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material for direct   burial - 316 grade stainless steel rim - Tempered safety glass  - Silicone rubber gasket - Thermoplastic cable gland (allows for through wiring) - IP67 Suitable for 2 x 50W 12V MR16 halogen dichroic lamps EX7009SS 316 Stainless Steel CODE: 24915   EX7008A 316 Stainless Steel CODE: 26117   300 355 250 EX7008 - 70W metal halide ‘Drive-Over’ inground light - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material   for direct burial - 4mm thick 316 grade stainless steel rim - Symmetrical polished aluminium reflector - 10mm thick heat tempered safety glass - Silicone rubber gasket - Thermoplastic cable gland (allows for through wiring) - Integral control gear - IP67 Suitable for 1 x 70W 240V RX7s double ended metal halide lamp EX7008SS 316 Stainless Steel CODE: 24914   220 280 180 225 290 180 without canister cutout: 185mm 150 255 STAINLESS STEEL STAINLESS STEEL STAINLESS STEEL

L 318 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting Walk - Over EX7007 - 13W fluorescent ‘Walk-Over’ inground light - Die-cast aluminium body, powder coated with   a pre-treatment for outdoor use - External housing of thermoplastic material for   direct burial is supplied with the fitting - 4mm thick 316 grade stainless steel rim - Symmetrical polished aluminium reflector - 10mm thick heat tempered safety glass - Silicone rubber gasket - Thermoplastic cable gland (allows for through wiring) - Integral control gear - IP67  Suitable for 1 x 13W PLC G24d-1 fluorescent lamp EX7007SS 316 Stainless Steel CODE: 24913   184 247 145 STAINLESS STEEL IP Protection Not all light fittings are designed to be used in situations where they are exposed to the  elements, such as in driveways or on the outside of a building.     It is always important to check if a product is weatherproof before selecting it for use in an  exposed situation. IP, or Ingress Protection numbers, are used to specify the degree of protection  provided by the enclosures of electrical equipment such as light fittings. These ratings are always  composed of two number, with the first referring to the degree of protection from solid objects such as dust and the  second, the protection from water.     An IP rating of 67 means that the product is completely protected against dust and the effects of temporary  immersion in water.  67

319 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EXST5025 - 1.2W LED round ‘Walk-Over’ inground uplight - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material for   direct burial is supplied with the fitting - 6mm thick 316 grade stainless steel rim - 8mm thick heat tempered safety glass diffuser - Silicone rubber gasket - PG11 nickel plated brass cable gland (allows   for through wiring) - IP67  - Includes 1.2W/12V 12 diode LED array: bluish colour EXST5025 316 Stainless Steel CODE: 24916   108 110 96 EXST5026 - 1.2W LED square ‘Walk-Over’ inground uplight - Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use - External housing of thermoplastic material for   direct burial is supplied with the fitting - 6mm thick 316 grade stainless steel trim - 8mm thick heat tempered safety glass diffuser - Silicone rubber gasket - PG11 nickel plated brass cable gland (allows   for through wiring) - IP67 - Includes 1.2W/12V 12 diode LED array: bluish colour EXST5026 316 Stainless Steel CODE: 24917   100 110 96 LED Driver and Cable - 240V/12V 36VA driver - “Quick Connect” cable set for DIY installation of    up to 4 LED inground uplights 36VA Driver Black CODE: 24969 QCCABLE Black CODE: 24970   ‘Walk-Over’ LED Uplights Crompton Lighting’s range of ‘Walk-Over’ LED lights  combine the benefits of 316 grade stainless steel with  LED lamp technology to provide the ultimate solution  to your deck, pavement and walkway lighting needs.  Weatherproof to IP67, these fittings are cool to the touch,  making them safe to use in areas where people walk  around bare foot (they are also safe to use around pets).    SAFETY WARNING   CROMPTON LIGHTING  RECOMMENDS  CHECKING FOR  SUITABILITY FOR ALL  INGROUND LIGHTS  WHERE PEOPLE MAY  ‘WALK-OVER’ WITH  EXPOSED SKIN What you need to install these LED ‘Walk-Over’ Inground Lights To install these LED ‘Walk-Over’ lights the following are required: • 240/12V 36VA driver (code 24969) - this transformer is suitable for use in     protected exterior applications.    • 10 metre ‘Quick-Connect’ cable set (code 24970) - this lead set allows for     DIY installation of up to four LED fittings. Walk - Over LED STAINLESS STEEL STAINLESS STEEL ENERGY SAVING ENERGY SAVING

L 320 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EX8031K White CODE: 25315   100 60 EXST4144K 304 Stainless Steel CODE: 25316   40 35 Cut-Out: 25mm EXST4145K 304 Stainless Steel CODE: 25317   40 35 Cut-Out: 25mm EX8031K - LED low voltage bricklight kit - 3 x 1.8W square frosted glass bricklights - IP67 - 10 metres of 4 core low voltage cable - 10VA LED converter IP44 EXST4144K - LED low voltage deck light kit - 6 x 0.6W round face deck lights - 304 grade stainless steel - IP67 - 10 metres of low voltage cable - 10VA LED converter IP44 - Replacement driver (code 85487) EXST4145K - LED low voltage deck light kit - 6 x 0.6W square face deck lights - 304 grade stainless steel - IP67 - 10 metres of low voltage cable - 10VA LED converter IP44 - Replacement driver (code 85487) LED Deck Lights An ideal energy efficient solution to deck lighting. In  square or round face these LED deck lights come  complete with low voltage cable and convertor for  ease of installation. LED STAINLESS STEEL STAINLESS STEEL ENERGY SAVING ENERGY SAVING ENERGY SAVING

321 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EXPC/OPAL - Opal acrylic sphere - Suitable for EX2001 sphere posts - Black matt plastic fitter base for post or    wall mounting - Ceramic lampholder - IP44 Suitable for 1 x ES lamp (refer table) EXPC200O 200mm 110mm 28W ES CODE: 22206 EXPC250O 250mm 145mm 42W ES CODE: 22209 EXPC300O 300mm 145mm 52W ES CODE: 22212 EXPC400O 400mm 225mm 70W ES CODE: 22215   200 - 400 Neck Diameter/Height 200mm: 110mm/210mm 250mm: 145mm/250mm 300mm: 145mm/310mm 400mm: 200mm/410mm EX2000 - Louvred bollard head - Suitable for EX2002 bollard post - Die cast aluminium construction  - Powder coated finish  - Internal glass diffuser - Ceramic lampholder - Includes screws for installation - IP44 Suitable for 1 x maximum 240V 42W ES lamp or 1 x maximum 15W CFL ES lamp  EX2000W White CODE: 19601 EX2000B Black CODE: 19598 EX2000BE Beige CODE: 19597 EX2000GR Green CODE: 19599 EX2000S Silver CODE: 19600   155 230 84 Bollard and Post Lights Due to their height, bollard and post lights are ideal for providing general lighting  to pathways, driveways and other large open outdoor spaces. Crompton Lighting  have a wide range of bollard and post lights to suit all building styles, from the  contemporary EX1007 to the traditional 3 Light Street Lantern. These fittings also  feature a variety of lamp types from standard lamps to the 70W single ended metal  halide lamps used in the EX1089 bollards. Whatever the aplication, Crompton  Lighting has a bollard or post light to suit your needs. Bollard Heads EX1076 - Bollard head - Suitable for EX2002 bollard post - Die cast aluminium construction  - Powder coated finish - Frosted glass diffuser - Ceramic lampholder - Includes screws for installation - IP44 Suitable for 1 x maximum 240V 42W ES lamp or 1 x maximum 15W CFL ES lamp EX1706G Green CODE: 20417 EX1076B Black CODE: 20416 EX1076BE Beige CODE: 20415   160 84 225

L 322 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting Garden Cable - Cabling for low voltage garden lights - Available in three different diameters - Sold by the roll as detailed  CL100GCB 3.3mm 100 metres CODE: 16983 CL106GCB 6mm 20 metres CODE: 22573 CL110GCB 10mm 20 metres CODE: 24968   EX2006 – Aluminium Base - Die-cast aluminium construction  - Powder coated finish - Complete with screws, foundation bolts and triangle - Suitable only for EX2002 post 180 120 Inner DIameter: 60mm Out er DIameter: 70mm EX2006W 78mm White CODE: 20644 EX2006B 78mm Black CODE: 20642 EX2006BE 78mm Beige CODE: 20641 EX2006GR 78mm Green CODE: 20643 EX2006S 78mm Silver CODE: 22702   EX2001/1B 60mm Sphere 1m Black CODE: 22217 EX2001/2W 60mm Sphere 2m White CODE: 22222 EX2001/2B 60mm Sphere 2m Black CODE: 22220 EX2002/1B 75mm Bollard 1m Black CODE: 19590 EX2002/1GR 75mm Bollard 1m Green CODE: 19592 EX2002/1S 75mm Bollard 1m Silver CODE: 19594 EX2002/2B 75mm Bollard 2m Black CODE: 19591   EX2001/2 Posts - Aluminium construction  - Powder coated finish - EX2001 60mm diameter to suit EXPC spheres - EX2002 75mm diameter to suit EX2000 and    EX1076 bollard heads Cable Specifications 3.3mm Voltage Drop: 0.15V/M Amperage: 24A Resistance: 0.00625 ohm/m 6mm Voltage Drop: 0.0062V/M Amperage: 40A Resistance: 0.000156 ohm/m 10mm Voltage Drop: 0.0047V/M Amperage: 50A Resistance: 0.000094 ohm/m EXPC/SMOKE - Smoked acrylic sphere - Suitable for EX2001 sphere posts - Black matt plastic fitter base for post or   wall mounting - Ceramic lampholder - IP44 Suitable for 1 x ES lamp (refer table) 200 - 400 Neck Diameter/Height 200mm: 110mm/210mm 250mm: 145mm/250mm 300mm: 145mm/310mm 400mm: 200mm/410mm EXPC200S 200mm 110mm 28W ES GLS CODE: 22208 EXPC250S 250mm 145mm 42W ES GLS CODE: 22211 EXPC300S 300mm 145mm 52W ES GLS CODE: 22214 EXPC400S 400mm 225mm 70W ES GLS CODE: 22216   Bollard Heads

323 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EX2000/KIT Bollard kit containing one each of the following: - EX2000 bollard head - 1 metre aluminium post - Black PVC base  - IP44 Suitable for 1 x maximum 240V 42W ES lamp EX2000BKIT Black CODE: 24050 EX2000GRKIT Green CODE: 24051   1180 75 160 EX1076/KIT Bollard kit containing one each of the following: - EX1076 bollard head  - 1 metre aluminium post - Black PVC base  - IP44 Suitable for 1 x maximum 240V 42W ES lamp 1000 160 74 EX1076BKIT Black CODE: 24052   Bollards EX1086B Black CODE: 25957   EX16051B Black CODE: 25971   EX1086B -  Exterior 240V bollard -  Die-cast aluminium post and louvre with black powder   coated paint finish -  Opal polycarbonate diffuser -  Internal ceramic lampholder and 3 way terminal block -  IP44 -  Mounting kit Suitable for 1 x maximum 240V 70W ES lamp EX16051B - Exterior 240V halogen bollard - Die-cast aluminium housing with black powder   coated paint finish - Clear polycarbonate diffuser - Internal lampholder and terminal block - IP44 - Mounting kit - Matching exterior wall lights available   (EX6050B / EX6051B) Suitable for 1 x maximum 35W GU10 halogen lamp 650 150 205 Bollard Width: 125 mm Head Size: 110x75x150 mmBase Size: 190x120x40 mm  1010

L 324 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EXST022 - Exterior bollard - 316 grade stainless steel construction - Opal polycarbonate diffuser - IP44 - Matching exterior wall light available (code 24141) Suitable for 1 x maximum 240V 42W fancy round ES lamp 1150 135 80 EXST022 Stainless Steel CODE: 24135   STYLE-LITE 10W halogen stainless steel bollard kit containing the following: - 6 miniature stainless steel bollards - 60VA transformer with flex and plug - IP64 - 20 metres of cable with six quick connectors for    easy installation - 6 x maximum 10W 12V halogen bi-pin lamps  - Replacement transformer (code 85412) Each of the bollard features the following: - 316 grade stainless steel construction - Clear acrylic diffuser - Head that unscrews for lamp replacement - Aluminium inground spike - Ceramic lampholder - IP44 6 BOLLARD Stainless Steel CODE: 24398   Dimensions Height: 500mm Height with Spike: 680mm   Width (Bollard): 38mm Width (Base): 75mm Bollards STAINLESS STEEL STAINLESS STEEL

325 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EXST027 - Louvred bollard - 316 grade stainless steel construction - Opal polycarbonate diffuser with louvre - IP44 - Matching exterior wall lights available   (EXST028 series) Suitable for 1 x maximum 240V 42W  fancy round ES lamp 135 1050 80 EXST027 Stainless Steel CODE: 24120   EX1002 - 50W/12V halogen bollard - Powder coated spun aluminium body with    spiked base  - Clear glass diffuser - Ceramic lampholder - IP55 Suitable for 20W - 50W 12V halogen bi-pin lamp EX1002B Black CODE: 20403 EX1002GR Green CODE: 20404 EX1002S Silver CODE: 20405   55 800 EX1081 - Louvred bollard - Die-cast aluminium construction  - Powder coated finish - Clear acrylic diffuser with louvre - IP44 Suitable for 1 x maximum 240V 70W ES lamp EX1007B/S - Small bollard - Aluminium construction  - Powder coated finish - Frosted glass diffuser - Ceramic lampholder - IP44 - Matching exterior wall lights available   (EX1499 series) Suitable for 1 x maximum 240V 70W ES lamp 520 140 90 EX1007B/S Silver CODE: 24902   1100 170 155 EX1081B Black CODE: 20420 EX1081GR Green CODE: 20421 EX1081S Silver CODE: 20422   Bollards STAINLESS STEEL INGRESS PROTECTION IP55

L 326 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EX1007B/L - Large bollard - Aluminium construction  - Powder coated finish - Frosted glass diffuser - Ceramic lampholder - IP44  - Matching exterior wall lights available   (EX1499 series) Suitable for 1 x maximum 240V 70W ES lamp  1160 140 90 EX1007B/L Silver CODE: 24903   EXST228 - Square louvred garden bollard - 316 grade stainless steel - Opal polycarbonate diffuser - IP44  - Matching exterior wall light available   (code 25001) Suitable for 1 x maximum 240V 42W  fancy round ES lamp 1100  100  Base: 105mm x 105mm EXST228SS 316 Stainless Steel CODE: 25002   EXST014-1050 - Garden bollard  - 316 grade stainless steel construction  - Clear polycarbonate diffuser  - IP44  - Matching exterior wall light available   (code 25003) Suitable for 1 x maximum 240V 42W ES lamp 1050 220 130 EXST014-1050 316 Stainless Steel CODE: 25004   190 1000 Bollard Width: 125mm 160 350 EX11836 Grey CODE: 25631   EX11836 - Fluorescent Bollard - Die-cast aluminium housing - Grey finish - Opal polycarbonate diffuser - Integral control gear - IP44 - Matching exterior wall lights available   (code 25630)   Suitable for 1 x 26W PLC G24d-3 fluorescent lamp Bollards STAINLESS STEEL STAINLESS STEEL

327 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 0411   L Landscape Lighting EX1089A - 70W metal halide bollard  - Aluminium construction - Black powder coated finish - Clear polycarbonate diffuser - Integral control gear - Ceramic lampholder - IP44  Suitable for 1 x 70W 240V single ended  metal halide lamp with G12 base 1000 203 EX1089A Black CODE: 24918   EX1089C - 70W metal halide bollard - Aluminium construction  - Black powder coated finish - Clear polycarbonate diffuser with internal    aluminium refractor - Integral control gear - Ceramic lampholder - IP44 Suitable for 1 x 70W 240V single ended  metal halide lamp with G12 base EX1089C Black CODE: 24919   1080 203 EXST016-2200 - Garden bollard  - 316 grade stainless steel construction  - Clear polycarbonate diffuser  - IP44  - Matching exterior wall light available   (code 25003) Suitable for 2 x maximum 240V 42W ES lamps 2200 626 130 Head: 332mm(H) x 210mm(W) EXST016-2200 316 Stainless Steel CODE: 25007   SOUTH HAMPTON - Three light traditional street lantern - Aluminium construction  - Powder coated finish - Clear glass diffusers - Ceramic lampholders - IP44 - Matching exterior wall lights available   (EX706 series / EX707 series) Suitable for 3 x maximum 240V 70W ES lamps 600 2270 Head Height: 340mm Head Width: 200mm SOUTH HAMPTON Black CODE: 24376   Bollards STAINLESS STEEL

L 328 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Landscape Lighting EXST8012K Stainless Steel CODE: 25312   350 175 150 38 EX8012K - LED low voltage garden bollard kit - 3 stainless steel bollards with frosted acrylic   diffusers and ground spikes - 10 metres of 4 core low voltage cable - 10VA LED converter - Remote control unit to change light colour    to any of the seven available colours - 304 grade stainless steel - IP44 - Replacement driver (code 85487) 450 58 115 EXST583 - LED bollard - Stainless steel housing - Glass diffuser - Integral converter for direct connection to    240V supply - Floating terminal block in protective casing - IP44 - 12 x 0.1W white LED’s   - Matching exterior wall lights available   (EXST582 / EXST581) EXST583 Stainless Steel CODE: 25643   LED Bollards STAINLESS STEEL STAINLESS STEEL ENERGY SAVING ENERGY SAVING

Specialty S

JUNO Heater  ..................................................................331LED Candle Set ..............................................................332Party Light Kits  .............................................................333

331 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   S Specialty JUNO 1000 - 1000W infrared room heater - Instant heat - Powder coated metal body - Grilled fascia guard - Flex & plug attached - Completed with plated metal mounting bracket   and screws - Includes 1 x 240V 1000W 5000 hour SK15 base   double ended golden coated halogen IR lamp JUNO 1500 - 1500W infrared room heater - Instant heat - Powder coated metal body - Grilled fascia guard - Flex & plug attached - Completed with plated metal mounting bracket   and screws - Includes 1 x 240V 1500W 5000 hour SK15 base   double ended golden coated halogen IR lamp JUNO1000W White CODE: 26464 JUNO1000SG Silver Grey CODE: 26465   JUNO1500W White CODE: 26466 JUNO1500SG Silver Grey CODE: 26467   JUNO1500SS Stainless Steel CODE: 26468   Juno Heater 240 173 428 Designed for fixed wall mounting, minimum  height of 1.8m Suitable for protected exterior applications  walls and under eaves STAINLESS STEEL

S 332 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   Specialty CRO2CDX4 - Rechargeable LED flickering candle set contains:  - 4 x ‘tea-light’ style rechargeable LED candles - 4 x frosted glass candle holders - 1 x recharger with flex & plug - Last 12 hours after each full recharge CRO2CDX4 White CODE: 26230   LED Candle Set

Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   333 Fittings do not include lamps unless specifically stated. E.&.O.E.      CC 04/11   S Specialty Coloured Party Light Kits Coloured mains voltage GLS lamp kits for festive occasions. Kits includes lamps, lampholders and cable  with two pin plug. Party Light Kits Watts Voltage Finish Base Dimensions Average Life Lamp Hours Reference Code Carton Quantity BC BASE  25W 240V Coloured BC B22 10M  1000 CPL10 25504 1 25W 240V Coloured BC B22 20M 1000 CPL20 25689 1 Coloured  GLS Party Light Kits Coloured mains voltage GLS lamp kits for festive occasions. Kits includes lamps, lampholders and cable with two pin plug Features • Manufactured to AS/NZ60598.2.20:2002 • Internally fused for safety • BC thermoplastic lampholders permanently attached to    1.5mm² core PVC supply cable fitted with a moulded two pin plug • Kits available in 10M (10 lamps) and 20M (20 lamps) lengths • Lamp colours - Blue, Yellow, Red, Orange and Green Applications • For decorative and special effect lighting • Festive lighting for entertainment areas, amusement parks,    gardens, christmas trees and parties • Suitable for both indoor use or in protected exterior applications Burning Position • Universal Electronic Fluorescent Energy Saving LampsColoured  CCW Party Light Kit Coloured mains voltage CCW lamp kit for festive occasions. Kit includes lamps, lampholders and cable with two pin plug Features • Manufactured to AS/NZ60598.2.20 • BC thermoplastic lampholders permanently attached to 10 metres   of 1.5mm² core PVC supply cable fitted with a moulded   two pin plug • 8 electronic fluorescent energy saving lamps:   - Blue, Yellow, Red and Green (two of each) Watts Voltage Finish Base Dimensions Average Life Lamp Hours Reference Code Carton Quantity BC BASE  9W 240V Coloured BC B22 10M  8000 LSPL10 25860 1 ENERGY SAVING
