Crompton Lighting LED Exterior & Landscape

Exterior / Landscape XL-LED Performance Exterior wall Lights                                 68LED Exterior Wall Lights & Ceiling Mounted Downlights           76LED Landscape Lighting                                                     97LED Exterior Bricklight Kits                                                     98LED Exterior Path Lights                                                      101LED 'WALK-OVER' Inground Uplights                                     102LED Inground Garden Spotlights                                        104LED Deck Light Kits                                                           106LED Bollard                                                                       108LED Bollard Kit                                                                  113

Ex te rio r /  La nd sc a p e 68 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 The LED Technology XL-LED Exterior Lighting Crompton Lighting brings to market a wide range of energy saving cost effective exterior lighting  solutions incorporating the latest in LED design and technology. For many years, exterior designers have been restricted with traditional fixtures incorporating older  lamp  technologies,  due  to  the  restrictions  on  the  luminaire  manufacturer  to  accommodate  factors such as heat dissipation and size of traditional light sources. The  Crompton  LED  Exterior  range  combines  the  latest  technology  with  aesthetically  pleasing  luminaire designs, to offer an unequalled experience and product offer. Utilizing  LED  chips  and  control  systems  from  leading  international  manufacturers,  Crompton  Lighting creates endless opportunities to extend the living experience from indoor to outdoor,  whilst  ensuring  only  quality  components  and  materials  are  used  for  longevity  and  actual  luminaire performance. A  full  range  of  luminaires  in  various  shapes  and  designs  are  available,  as  well  as  different  wattages, to meet the needs of differing desired effects for the highlighting or enhancement of  any exterior area.

Ex te rio r /  La nd sc a p e 69 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 XL-EX649 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.15A Power Factor 0.9 Total Input Power 22W Secondary Output Voltage 24V DC Secondary Output Current 0.7A Lamp Power 20W MATERIALS Body Dry powder coated die-cast  aluminium Diffuser UV stabilised polycarbonate Controller Base & Cover Thermoplastic THERMAL Thermal Protection Fully protected Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 1100 lumens CRI 80 Colour Temperature 3000K WEIGHT / LIFE Fitting 2.35Kg LED Lamp Life 50,000HR XL-LED Performance Bunker / Wall Light ▪   Matt finish dry powder coated die-cast       aluminium base with heat sink ▪   UV stabilized opal polycarbonate diffuser ▪   20W integral LED module ▪   Dimmable with most trailing edge       dimmers PRODUCT SPECIFICATIONS PRODUCT FEATURES 0% 100% 50,000 IP65 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE XL-EX649W White 26849 XL-EX649G Graphite 26850 270 147 270 (mm) ENERGY AVE XL-LED PerformanceExterior Bunker / Wall Light  20W 1100 LUMENS

Ex te rio r /  La nd sc a p e 70 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 25,000 EXLED1865 ELECTRICAL Supply Voltage 100-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.6 Total Input Power 3W Secondary Output Voltage 0.5V - 10V DC Secondary Output Current 350mA Lamp Power 3 x 1W MATERIALS Body Powder coated die-cast  aluminium Diffuser Polycarbonate THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 300 lumens CRI 75 Colour Temperature 4100K WEIGHT / LIFE Fitting 550g LED Lamp Life 25,000HR XL-LED Performance Exterior Wall Light ▪   3 x 1W LED exterior wall light ▪   Black powder coated die-cast aluminium     body and base ▪   Clear polycarbonate diffuser ▪   Internally mounted driver and 3 x 1W       LED’s on the base PRODUCT SPECIFICATIONS PRODUCT FEATURES 4100K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXLED1865 Black 26823 165 (mm) Projection: 90 ENERGY AVE XL-LED Performance Exterior  Round Wall Light   3W 300 LUMENS

Ex te rio r /  La nd sc a p e 71 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 25,000 EXLED1866 ELECTRICAL Supply Voltage 100-240Vac Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.6 Total Input Power 3W Secondary Output Voltage 0.5V - 10V DC Secondary Output Current 350mA Lamp Power 3 x 1W MATERIALS Body Powder coated die-cast  aluminium Diffuser Polycarbonate THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 300 lumens CRI 75 Colour Temperature 4100K WEIGHT / LIFE Fitting 550g LED Lamp Life 25,000HR XL-LED Performance Exterior Wall Light ▪   3 x 1W LED exterior wall light ▪   Black sqaure powder coated die-cast       aluminium body and base ▪   Clear polycarbonate diffuser ▪   Internally mounted driver and 3 x 1W       LED’s on the base PRODUCT SPECIFICATIONS PRODUCT FEATURES 4100K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXLED1866 Black 26824 150 (mm) 150 Projection: 76 ENERGY AVE XL-LED Performance ExteriorSquare Wall Light   3W 300 LUMENS

Ex te rio r /  La nd sc a p e 72 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 30,000 EX862R ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 10mA Power Factor 0.6 Total Input Power 1.2W Secondary Output Voltage 12V DC Secondary Output Current 100mA Lamp Power 10 x 0.12W MATERIALS Body Glass, satin chrome Diffuser Polycarbonate THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens CRI 75 Colour Temperature 6000K WEIGHT / LIFE Fitting 575g LED Lamp Life 30,000HR ▪   10 X 0.12W 6000K LED exterior wall light ▪   Clear round shape glass ▪   Round satin chrome plate ▪   Clear round base with 10 LED’s ▪   Built in driver PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX862R Clear 26883 120 Depth: 50 Glass Thickness: 10 (mm) 120 ENERGY SAVING 70%  Compared to a 15W incandescent wall light XL-LED Performance Exterior Round Wall Light 1.2W 40 LUMENS

Ex te rio r /  La nd sc a p e 73 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 30,000 EX862S ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 10mA Power Factor 0.6 Total Input Power 1.2W Secondary Output Voltage 12V DC Secondary Output Current 100mA Lamp Power 10 x 0.12W MATERIALS Body Glass, satin chrome Diffuser Polycarbonate THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens CRI 75 Colour Temperature 6000K WEIGHT / LIFE Fitting 575g LED Lamp Life 30,000HR ▪   10 X 0.12W 6000K LED exterior wall light ▪   Clear square shape glass ▪   Round satin chrome plate ▪   Clear round base with 10 LED’s ▪   Built in driver PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX862S Clear 26884 120 Depth: 50 Glass Thickness: 10 (mm) 120 ENERGY SAVING 70%  Compared to a 15W incandescent wall light XL-LED Performance Exterior Square Wall Light 1.2W 40 LUMENS

Ex te rio r /  La nd sc a p e 74 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 30,000 EX2381/1 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.04A Power Factor 0.5 Total Input Power 9.6W Secondary Output Voltage 21V maximum Secondary Output Current 350mA Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 384 lumens CRI 80 Colour Temperature 3000K WEIGHT / LIFE Fitting 1.36Kg LED Lamp Life 30,000HR ▪   6W XL-LED Performance exterior wall      light ▪   Powder coated die-cast aluminium       rectangular body and square base ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Built in driver ▪   6 x 1W LED’s PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2381/1 Silver 26954 90 90 90 (mm) Projection:130 ENERGY AVE XL-LED Performance Exterior Wall Light   6W 384 LUMENS

Ex te rio r /  La nd sc a p e 75 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 30,000 EX2381/2 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.08A Power Factor 0.5 Total Input Power 19.8W Secondary Output Voltage 42V maximum Secondary Output Current 350mA Lamp Power 12 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 705 lumens CRI 78 Colour Temperature 3000K WEIGHT / LIFE Fitting 1.94Kg LED Lamp Life 30,000HR ▪   12W XL-LED Performance exterior   up/down wall light  ▪   Powder coated die-cast aluminium       rectangular body and square base ▪   Tempered clear glass diffusers ▪   Silicon rubber gaskets ▪   Built in driver ▪   6 x 1W LED’s in each diffuser PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2381/2 Silver 26913 130 (mm) Projection:120 90 90 ENERGY AVE XL-LED Performance Exterior Up/Down Wall Light   12W 705 LUMENS

Ex te rio r /  La nd sc a p e 76 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX5671 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.035A Power Factor 0.6 Total Input Power 4.2W Secondary Output Voltage 11V Lamp Power 3 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 87 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 120° ▪   3W CREE LED exterior wall light ▪   Powder coated die-cast aluminium body     and base ▪   Frosted glass diffuser ▪   Silicon rubber gasket ▪   Weather resistant IP54 ▪   Inbuilt driver for direct connection to       240V supply ▪   3 x 1W LED’s PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX5671 Graphite 27039 LED Exterior Wall Light LAMP LIFE 30,000 HOURS IP 54 WEIGHT / LIFE Fitting 720g LED Lamp Life 30,000 HR Controller Life 30,000 HR 136 82 106 (mm) 3W 87 LUMENS ENERGY SAVING

Ex te rio r /  La nd sc a p e 77 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 LAMP LIFE 30,000 HOURS IP 54 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.061A Power Factor 0.6 Total Input Power 6.7W Secondary Output Voltage 12V Lamp Power 2 x 3W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 240 lumens CRI 75-80 Colour Temperature 3000K Beam Angle Top: 35°, Bottom: 82° EX2551 ▪   6W exterior up/down wall light ▪   Powder coated die-cast aluminium body     and base ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   2 x 3W LED’s PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2551 Graphite 27036 LED Exterior Up/Down Wall Light WEIGHT / LIFE Fitting 450g LED Lamp Life 30,000 HR Controller Life 30,000 HR 173 109 Projection: 63 (mm) 6W 240 LUMENS ENERGY SAVING

Ex te rio r /  La nd sc a p e 78 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2611 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2611 Graphite 27041 80% ENERGY SAVING LED Exterior Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.6 Total Input Power 6.9W Secondary Output Voltage 12V Lamp Power 2 x 3W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 314 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 92° WEIGHT / LIFE Fitting 910g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W CREE LED exterior wall light ▪   Powder coated die-cast aluminium       rectangular body and square base ▪   Clear glass diffuser ▪   Silicon rubber gasket ▪   Weather resistant IP54 ▪   Inbuilt driver for direct connection to       240V supply ▪   2 x 3W LED’s 65 90 90 110 65 (mm) 6W 314 LUMENS IP 54  Compared to a standard 11W GU10 CFL lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 79 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2541-LED PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2541-LED Graphite 27048 LED Exterior Up/Down Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.126A Power Factor 0.6 Total Input Power 15.6W Secondary Output Voltage 42V Lamp Power 12 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 628 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 40° WEIGHT / LIFE Fitting 1.51Kg LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   12W LED exterior up/down wall       light ▪   Powder coated die-cast aluminium       rectangular body ▪   Tempered clear glass diffusers ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s in each diffuser 112 (mm) 108 108     12W 628 LUMENS IP 54  Compared to a standard 11W GU10 CFL lamp 80% ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 80 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2622 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2622 Graphite 27038 LED Exterior Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.051A Power Factor 0.6 Total Input Power 5W Secondary Output Voltage 24V Lamp Power 1 x 5W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 159 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 56° WEIGHT / LIFE Fitting 530g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   5W LED exterior wall light ▪   Powder coated die-cast aluminium       rectangular body ▪   Clear glass diffuser ▪   Silicon rubber gasket ▪   Weather resistant IP54 ▪   Inbuilt driver for direct connection to       240V supply ▪   1 x 5W LED 95 (mm) 62 82     5W 159 LUMENS IP 54 70% ENERGY SAVING  Compared to a standard 7W GU10 CFL lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 81 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2621 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2621 Graphite 27037 LED Exterior Up/Down Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.091A Power Factor 0.6 Total Input Power 10.8W Secondary Output Voltage 42V Lamp Power 2 x 5W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 317 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 56° WEIGHT / LIFE Fitting 770g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   10W LED exterior up/down wall light ▪   Powder coated die-cast aluminium       rectangular body ▪   Clear glass diffusers ▪   Silicon rubber gasket ▪   Weather resistant IP54 ▪   Inbuilt driver for direct connection to       240V supply ▪   1 x 5W LED in each diffuser 145 (mm) 61 82   10W 317 LUMENS IP 54 70% ENERGY SAVING  Compared to a standard 7W GU10 CFL lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 82 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2562 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2562 Graphite 27043 LED Exterior Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.033A Power Factor 0.6 Total Input Power 3.8W Secondary Output Voltage 4V Lamp Power 1 x 3W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 64 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 75° WEIGHT / LIFE Fitting 260g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   3W CREE LED exterior wall light ▪   Powder coated die-cast aluminium       rectangular body ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   1 x 3W LED 88 (mm) 40 65 3W 64 LUMENS IP 54 80% ENERGY SAVING  Compared to a standard 7W GU10 CFL lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 83 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2561 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2561 Graphite 27042 LED Exterior Up/Down Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.6 Total Input Power 6.9W Secondary Output Voltage 12V Lamp Power 2 x 3W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 126 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 55° WEIGHT / LIFE Fitting 600g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W CREE LED exterior up/down wall       light ▪   Powder coated die-cast aluminium       rectangular body ▪   Tempered clear glass diffusers ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   1 x 3W LED in each diffuser 125 (mm) 90 43 6W 126 LUMENS IP 54 80% ENERGY SAVING  Compared to a standard 7W GU10 CFL lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 84 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2232 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2232 Graphite 27045 LED Exterior Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.07A Power Factor 0.6 Total Input Power 7.7W Secondary Output Voltage 24V Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 370 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 10° WEIGHT / LIFE Fitting 980g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W LED exterior wall light ▪   Powder coated die-cast aluminium       cylindrical body and round base ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s 96 134 100 Ø90 (mm)     6W 370                      LUMENS IP 54  Compared to a standard 18W GU10 CFL lamp 70% ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 85 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2231 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2231 Graphite 27044 LED Exterior Up/Down Wall Light ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.134A Power Factor 0.6 Total Input Power 16.7W Secondary Output Voltage 42V Lamp Power 12 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 729 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 10° WEIGHT / LIFE Fitting 1.43Kg LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   12W LED exterior up/down wall light ▪   Powder coated die-cast aluminium       cylindrical body and round base ▪   Tempered clear glass diffusers ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s in each diffuser 96 134 134 Ø90 (mm)   12W 729 LUMENS IP 54  Compared to a standard 18W GU10 CFL lamp 70% ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 86 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2235N PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2235N Graphite 27046 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.07A Power Factor 0.6 Total Input Power 7.7W Secondary Output Voltage 24V Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 370 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 10° WEIGHT / LIFE Fitting 750g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W LED exterior ceiling mounted       downlight ▪   Powder coated die-cast aluminium       cylindrical body ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s 100 Ø90 (mm) LED Exterior Ceiling Mounted Downlight     6W 370 LUMENS IP 54  Compared to a standard 18W GU10 CFL lamp 70% ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 87 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2385 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2385 Graphite 27047 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.07A Power Factor 0.6 Total Input Power 7.7W Secondary Output Voltage 24V Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 370 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 10° WEIGHT / LIFE Fitting 800g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W LED exterior ceiling mounted       downlight ▪   Powder coated die-cast aluminium       rectangular body ▪   Tempered clear glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s 92 90 90 (mm) LED Exterior Ceiling Mounted Downlight     6W 370 LUMENS IP 54  Compared to a standard 18W GU10 CFL lamp 70% ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 88 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 IP 65 EX4181 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.01A Power Factor 0.6 Total Input Power 1.4W Secondary Output Voltage 6V Secondary Output Current 200mA Lamp Power 14 x 0.1W MATERIALS Body Aluminium die-cast housing,  thermoplastic mounting  enclosure Diffuser Polycarbonate THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 56 lumens CRI 85 Colour Temperature 5500K - 6000K WEIGHT / LIFE Fitting 350g LED Lamp Life 20,000HR ▪   Energy saving LED circular / square wall      light ▪   Aluminium die-cast housing ▪   Matt black powder coated finish ▪   Tapered thermoplastic mounting enclosure ▪   Clear diffuser ▪   Inbuilt driver for direct connection to 240V     supply ▪   IP65 ▪   14 x 0.1W white LED’s  PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L 120 60 (mm) LED Circular / Square Exterior Wall Light EX4182 120 120 60 (mm) 1.4W 56 LUMENS REFERENCE SHAPE COLOUR CODE EX4181 Circular Black 25624 EX4182 Square Black 25625 ENERGY SAVING LAMP LIFE 20,000 HOURS

Ex te rio r /  La nd sc a p e 89 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 ▪   Mini LED circular / square wall light ▪   Aluminium die-cast housing ▪   Matt grey / matt white powder coated finish ▪   Tapered thermoplastic mounting enclosure ▪   Clear diffuser ▪   Inbuilt driver for direct connection to 240V     supply ▪   6 x 0.2W LED’s  EX4181S EX4182S ELECTRICAL Supply Voltage 240V AC Supply Frequency 50-60Hz Supply Current 50mA Power Factor 0.28 Total Input Power 1.5W Secondary Output Voltage 19.5V Secondary Output Current 46mA Lamp Power 6 x 0.2W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Protection Overload Ambient Temperature Rating 25°C Maximum Surface Temp 45°C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 70 lumens CRI 60 Colour Temperature 3000K Beam Angle 120° PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L WEIGHT / LIFE Fittting 89g LED Lamp Life 50,000HR LED Mini Circular / Square Exterior Wall Light   1.2W 70 LUMENS REFERENCE SHAPE COLOUR CODE EX4182SW Circular Matt White 27125 EX4181SW Square Matt White 27126 EX4182SG Circular Matt Grey 27127 EX4181SG Square Matt Grey 27128 83 83 27 (mm) 80 80 27 (mm) ENERGY SAVING LAMP LIFE 50,000 HOURS

Ex te rio r /  La nd sc a p e 90 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX1860 ELECTRICAL Supply Voltage 100-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.6 Total Input Power 3W Secondary Output Voltage 0.5V - 10V DC Secondary Output Current 350mA Lamp Power 3 x 1W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Ambient Temperature Rating 50 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 120 lumens CRI 85 Colour Temperature 4100K WEIGHT / LIFE Fitting 550g LED Lamp Life  20,000HR ▪   LED wall light ▪   Silver powder coated die-cast aluminium    body and cover ▪   Clear polycarbonate lens ▪   Built in driver ▪   IP44 ▪   3 x 1W 4100K white LED’s PRODUCT SPECIFICATIONS PRODUCT FEATURES 4100K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX1860 Silver 26404 120 180 (mm) 70 LED Exterior Wall Light     3W 120 LUMENS ENERGY SAVING LAMP LIFE 20,000 HOURS

Ex te rio r /  La nd sc a p e 91 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2571S ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.5 Total Input Power 12W Secondary Output Voltage 12V Secondary Output Current 0.5A Lamp Power 2 x 3W MATERIALS Body Aluminium Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 45 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 223 lumens CRI 77 Colour Temperature 3000K WEIGHT / LIFE Fitting 450g LED Lamp Life 30,000HR PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2571S Silver 26951 LED Exterior Wall Light ▪   Round powder coated die-cast aluminium     body and base ▪   Tempered clear glass lens ▪   Silicon rubber gaskets ▪   Built in driver ▪   IP44 ▪   2 x 3W LED’s 130 (mm) Projection:68 130     6W 223 LUMENS ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 92 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXST581 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.01A Power Factor 0.6 Total Input Power 1.2W in each diffuser Lamp Power 12 x 0.1W in each difuser Input Capacitance of Driver 4.7nF MATERIALS Body Stainless Steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 44 lumens CRI 85 Colour Temperature 4000K WEIGHT / LIFE Fitting 1.25Kg LED Lamp Life 20,000HR ▪   LED up/down wall light  ▪   Stainless steel housing and base  ▪   Glass diffusers ▪   Integral LED driver for direct connection     to 240V supply  ▪   IP44 ▪   12 x 0.1W white LED’s in each diffuser  ▪   Matching garden bollard available   (code 25643) PRODUCT SPECIFICATIONS PRODUCT FEATURES 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST581 Stainless Steel 25641 222 60 Projection:112  (mm) STAINLESS STEEL LED Exterior Up/Down Wall Light 1.2W 44 LUMENS ENERGY SAVING LAMP LIFE 20,000 HOURS

Ex te rio r /  La nd sc a p e 93 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX8011 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 20mA Power Factor 0.6 Total Input Power 1W Lamp Power 1W Input Capacitance of Driver 4.7nF MATERIALS Body 304 stainless Steel Diffuser Frosted acrylic THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens CRI 70 Colour Temperature 5000K WEIGHT / LIFE Fitting 480g LED Lamp Life 20,000HR ▪   LED wall light ▪   304 grade stainless steel construction ▪   Frosted acrylic diffuser ▪   Inbuilt driver for direct connection to       240V supply ▪   IP44 ▪   1W white LED ▪   Matching garden bollard available   (code 25312) PRODUCT SPECIFICATIONS PRODUCT FEATURES 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX8011 Stainless Steel 25589 300 (mm) 85 38 STAINLESS STEEL LED Exterior Wall Light 1W 40 LUMENS ENERGY SAVING LAMP LIFE 20,000 HOURS

Ex te rio r /  La nd sc a p e 94 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXST4001 ELECTRICAL Supply Voltage 85-240V AC Supply Frequency 50-60Hz Supply Current 20mA Power Factor 0.6 Total Input Power 2W Lamp Power 2 x 1W Input Capacitance of Driver 4.7nF MATERIALS Body Stainless Steel Diffuser Toughened glass THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 80 lumens CRI 70 Colour Temperature 5000K WEIGHT / LIFE Fitting 1.125Kg LED Lamp Life 10,000HR ▪   LED up/down wall light ▪   Stainless steel construction ▪   Toughened glass diffusers ▪   Inbuilt driver for direct connection to       240V supply ▪   IP65 ▪   2 x 1W white LED’s  PRODUCT SPECIFICATIONS PRODUCT FEATURES REFERENCE COLOUR CODE EXST4001 Stainless Steel 25318 Projection: 90  (mm) 150 54 43 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L STAINLESS STEEL IP 65 LED Exterior Up/Down Wall Light 2W 80 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 95 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXST4002 ELECTRICAL Supply Voltage 85-240V AC Supply Frequency 50-60Hz Supply Current 20mA Power Factor 0.6 Total Input Power 1W Lamp Power 1W Input Capacitance of Driver 4.7nF MATERIALS Body Stainless Steel Diffuser Toughened glass THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens CRI 70 Colour Temperature 5000K WEIGHT / LIFE Fitting 560g LED Lamp Life 10,000HR ▪   LED wall light ▪   Stainless steel construction ▪   Toughened glass diffuser ▪   Inbuilt driver for direct connection to   240V supply ▪   IP65 ▪   1W white LED  PRODUCT SPECIFICATIONS PRODUCT FEATURES 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST4002 Stainless Steel 25319 STAINLESS STEEL IP 65 90 54 Projection: 90  (mm) 43 LED Exterior Wall Light 1W 40 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 96 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXST4003 ELECTRICAL Supply Voltage 85-240V AC Supply Frequency 50-60Hz Supply Current 20mA Power Factor 0.6 Total Input Power 1W Lamp Power 1W Input Capacitance of Driver 4.7nF MATERIALS Body Stainless Steel Diffuser Toughened glass THERMAL Ambient Temperature Rating 25 o C Nominal Maximum Surface Temp 45 o C Nominal Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens CRI 70 Colour Temperature 5000K WEIGHT / LIFE Fitting 572g LED Lamp Life 10,000HR ▪   LED adjustable wall light ▪   Stainless steel construction ▪   Toughened glass diffuser ▪   Inbuilt driver for direct connection to   240V supply ▪   IP65 ▪   1W white LED   PRODUCT SPECIFICATIONS PRODUCT FEATURES 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST4003 Stainless Steel 25320 STAINLESS STEEL IP 65 54 32 (mm) 42 90 Projection: 152 LED Exterior Adjustable Wall Light 1W 40 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 97 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 Crompton  Lighting  brings  to  market  a  wide  range  of  energy  saving  cost  effective  exterior  landscape lighting solutions incorporating the latest in LED design and technology. For many years , landscapers have been limited with traditional fixtures incorporating older lamp  technologies,  due  to  the  restrictions  on  the  luminaire  manufacturer  to  accommodate  factors  such as heat dissipation and size of traditional light sources. The  Crompton  LED  Landscape  Lighting  range  combines  the  latest  technology  with  both  traditional  and  contemporary  luminaire  designs,  to  offer  a  modern  range  of  energy  efficient,  cost effective lighting solutions. Utilizing  LED  chips  and  control  systems  from  leading  international  manufacturers,  Crompton  Lighting  creates  endless  opportunities  to  extend  the  living  experience  from  indoor  to  outdoor,  whilst  ensuring  only  quality  components  and  materials  are  used  for  longevity  and  actual  luminaire performance. A  full  range  of  luminaires  in  various  shapes  and  designs  are  available,  as  well  as  different  wattages, to meet the needs of differing desired effects for the highlighting or enhancement of  the exterior area. The LED Technology Crompton LED Landscape Lighting

Ex te rio r /  La nd sc a p e 98 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 STAINLESS STEEL IP 67 EXST4081K ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.025A Power Factor 0.45 Total Input Power 1.2W Secondary Output Voltage 12V Secondary Output Current 300mA Lamp Power 12 x 0.1W each MATERIALS Body 316 stainless steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 45 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 80 lumens each CRI 70 Colour Temperature 6000K ▪   LED low voltage bricklight kit ▪   3 stainless steel bricklights with glass       diffuser  ▪   Low voltage cable with connectors ▪   10VA IP44 driver with flex and plug ▪   IP67 ▪   12 x 0.1W white LED’s in each brickllight PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST4081K 316 Stainless Steel 25314 WEIGHT / LIFE Fittting 2.8Kg LED Lamp Life 10,000HR Cut-out: 65 x 123 135 (mm) 75 LED Bricklight Kit 3.6W 240 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 99 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 IP 67 WEIGHT / LIFE Fittting 2.8Kg LED Lamp Life 10,000HR 100 60 (mm) EX8031K ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.45 Total Input Power 5.4W Secondary Output Voltage 12V Secondary Output Current 300mA Lamp Power 3 x 1.8W MATERIALS Body Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 45 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens each CRI 70 Colour Temperature 6000K ▪   LED low voltage bricklight kit ▪   3 x 1.8W square frosted glass bricklights ▪   IP67 ▪   10 metres of 4 core low voltage cable ▪   10VA LED converter IP44 PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX8031K White 25315 LED Bricklight Kit 5.4W 120 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 100 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2583 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2583 Graphite 27049 LED Bricklight IP 65 114 65 226 (mm) ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.072A Power Factor 0.6 Total Input Power 8.3W Secondary Output Voltage 24V Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 266 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 60° WEIGHT / LIFE Fitting 810g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W CREE LED exterior bricklight ▪   Powder coated die-cast aluminium body ▪   Tempered clear glass diffusers ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   6 x 1W LED’s 6W 266 LUMENS ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 101 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX5673 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX5673 Graphite 27040 LED Path Light IP 54 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.035A Power Factor 0.6 Total Input Power 4.2W Secondary Output Voltage 11V Lamp Power 3 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 87 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 120° WEIGHT / LIFE Fitting 1.02Kg LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   3W CREE LED exterior path light ▪   Powder coated die-cast aluminium body ▪   Frosted glass diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   3 x 1W LED’s 138 108 181 (mm) 3W 87 LUMENS ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 102 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 108 (mm) 110 96 STAINLESS STEEL IP 67 EXST5025 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.025A Power Factor 0.45 Total Input Power 1.2W Secondary Output Voltage 12V Secondary Output Current 300mA Lamp Power 12 x 0.1W MATERIALS Body 316 stainless steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 80 lumens CRI 70 Colour Temperature 5000K ▪   1.2W LED round ‘Walk-Over’ inground     uplight ▪   Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use ▪   External housing of thermoplastic material     for direct burial is supplied with the fitting ▪   6mm thick 316 grade stainless steel rim ▪   8mm thick heat tempered safety glass       diffuser ▪   Silicone rubber gasket ▪   PG11 nickel plated brass cable gland       (allows for through wiring) ▪   IP67  ▪   Includes 1.2W/12V 12 diode LED array:     bluish colour PRODUCT SPECIFICATIONS PRODUCT FEATURES 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L For DIY installation require LED driver and cable. (See page 136 & 137) REFERENCE COLOUR CODE EXST5025 316 Stainless Steel 24916 WEIGHT / LIFE Fittting  700g LED Lamp Life 10,000HR LED Round ‘WALK-OVER’ Inground Uplight 1.2W 80 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 103 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 STAINLESS STEEL IP 67 100 110 96 (mm) EXST5026 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.025A Power Factor 0.45 Total Input Power 1.2W Secondary Output Voltage 12V Secondary Output Current 300mA Lamp Power 12 x 0.1W MATERIALS Body 316 stainless steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 80 lumens CRI 70 Colour Temperature 5000K ▪   1.2W LED square ‘Walk-Over’ inground     uplight ▪   Die-cast aluminium body, powder coated   with a pre-treatment for outdoor use ▪   External housing of thermoplastic material     for direct burial is supplied with the fitting ▪   6mm thick 316 grade stainless steel trim ▪   8mm thick heat tempered safety glass       diffuser ▪   Silicone rubber gasket ▪   PG11 nickel plated brass cable gland       (allows for through wiring) ▪   IP67 ▪   Includes 1.2W/12V 12 diode LED array:     bluish colour PRODUCT SPECIFICATIONS PRODUCT FEATURES 5000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L For DIY installation require LED driver and cable. (See page 136 & 137) REFERENCE COLOUR CODE EXST5026 316 Stainless Steel 24917 WEIGHT / LIFE Fittting 750g LED Lamp Life 10,000HR LED Square ‘WALK-OVER’ Inground Uplight 1.2W 80 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 104 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2201 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2201 Graphite 27052 LED Inground Garden Spotlight Ø66 355 93 (mm) ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.044A Power Factor 0.6 Total Input Power 4.1W Secondary Output Voltage 11V Lamp Power 3 x 1W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 163 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 25° WEIGHT / LIFE Fitting 490g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   3W LED inground garden spotlight ▪   Powder coated die-cast aluminium       construction ▪   Clear polycarbonate diffuser ▪   Adjustable head and inground spike ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   Weather resistant IP54 ▪   3 x 1W LED’s 3W 163 LUMENS IP 54 70% ENERGY SAVING  Compared to a standard 35W MR16 lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 105 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2591 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2591 Graphite 27053 LED Inground Garden Spotlight IP 65 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.074A Power Factor 0.6 Total Input Power 8.6W Secondary Output Voltage 24V Lamp Power 6 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 330 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 40° WEIGHT / LIFE Fitting 930g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   6W CREE LED inground garden spotlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Adjustable head and inground spike ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   Weather resistant IP65 ▪   6 x 1W LED’s Ø101 Ø105 352 (mm) 6W 330 LUMENS 70% ENERGY SAVING  Compared to a standard 35W MR16 lamp LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 106 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 40 35 (mm) Cut-Out: 30 EXST4144K ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.45 Total Input Power 3.6W Secondary Output Voltage 12V Secondary Output Current 0.9A Lamp Power 6 x 0.6W MATERIALS Body 304 stainless steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens each CRI 70 Colour Temperature 6000K WEIGHT / LIFE Fitting 1900g LED Lamp Life 10,000HR ▪   LED low voltage deck light kit ▪   6 x 0.6W round face deck lights ▪   304 grade stainless steel ▪   IP67 ▪   10 metres of low voltage cable ▪   10VA LED converter IP44 ▪   Replacement driver (code 85487) PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST4144K 304 Stainless Steel 25316 LED Round Face Deck Light STAINLESS STEEL IP 67 3.6W 240 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 107 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 40 35 (mm) Cut-Out: 30 STAINLESS STEEL IP 67 EXST4145K ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.45 Total Input Power 3.6W Secondary Output Voltage 12V Secondary Output Current 0.9A Lamp Power 6 x 0.6W MATERIALS Body 304 stainless steel Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP67 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens each CRI 70 Colour Temperature 6000K WEIGHT / LIFE Fitting 1900g LED Lamp Life 10,000HR ▪   LED low voltage deck light kit ▪   6 x 0.6W square face deck lights ▪   304 grade stainless steel ▪   IP67 ▪   10 metres of low voltage cable ▪   10VA LED converter IP44 ▪   Replacement driver (code 85487) PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST4145K 304 Stainless Steel 25317 LED Square Face Deck Light 3.6W 240 LUMENS ENERGY SAVING LAMP LIFE 10,000 HOURS

Ex te rio r /  La nd sc a p e 108 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2491A PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2491A Graphite 27050 LED Wall Light 220 180 76 (mm) ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.089A Power Factor 0.6 Total Input Power 10.1W Secondary Output Voltage 24V Lamp Power 3 x 3W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 192 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 78° WEIGHT / LIFE Fitting 910g LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   9W LED wall light ▪   Powder coated die-cast aluminium body ▪   Frosted polycarbonate diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   3 x 3W LED’s 9W 192 LUMENS IP 54 ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 109 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2493A PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2493A Graphite 27051 LED Bollard ▪   9W CREE LED bollard ▪   Powder coated die-cast aluminium body ▪   Frosted polycarbonate diffuser ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   3 x 3W LED’s ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.089A Power Factor 0.6 Total Input Power 10.1W Secondary Output Voltage 24V Lamp Power 3 x 3W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP54 OPTICAL / PHOTOMETRIC Luminous Flux 192 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 78° WEIGHT / LIFE Fitting 1.94Kg LED Lamp Life 30,000 HR Controller Life 30,000 HR 650 176 77 170 (mm) 9W 192 LUMENS IP 54 ENERGY SAVING LAMP LIFE 30,000 HOURS

Ex te rio r /  La nd sc a p e 110 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 STAINLESS STEEL 450 (mm) 58 115 EXST583 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.01A Power Factor 0.6 Total Input Power 1.2W Secondary Output Voltage 12V Secondary Output Current 0.018A Lamp Power 12 x 0.1W Input Capacitance of Driver 4.7µF MATERIALS Body Stainless steel Lens / Diffuser Glass THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 45 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 80 lumens CRI 70 Colour Temperature 5500K - 6000K ▪   LED bollard ▪   Stainless steel housing ▪   Glass diffuser ▪   Integral converter for direct connection      to 240V supply ▪   Floating terminal block in protective casing ▪   IP44 ▪   12 x 0.1W white LED’s   ▪   Matching exterior wall light available       (EXST581) PRODUCT SPECIFICATIONS PRODUCT FEATURES 6000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXST583 Stainless Steel 25643 WEIGHT / LIFE Fittting 1.125Kg LED Lamp Life 50,000 HR LED Bollard 1.2W 80 LUMENS ENERGY SAVING LAMP LIFE 50,000 HOURS

Ex te rio r /  La nd sc a p e 111 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXB2533 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.03A Power Factor 0.5 Total Input Power 8W Secondary Output Voltage 16V maximum Secondary Output Current 350mA Lamp Power 4 x 1W Input Capacitance of Driver 0.033µF MATERIALS Body Aluminium Lens / Diffuser Glass THERMAL Ambient Temperature Rating 40 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 145 lumens CRI 77 Colour Temperature 3000K ▪   LED bollard ▪   Powder coated die-cast aluminium body     and base ▪   Tempered clear glass lens ▪   Silicon rubber gasket ▪   Integral converter for direct connection      to 240V supply ▪   IP44 ▪   4 x 1W LED’s PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXB2533 Silver 26953 WEIGHT / LIFE Fittting 2040g LED Lamp Life 20,000HR LED Bollard 120 170 (mm) 600 4W 145 LUMENS ENERGY SAVING LAMP LIFE 20,000 HOURS

Ex te rio r /  La nd sc a p e 112 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EXB614742 ELECTRICAL Supply Voltage 230-240V AC Supply Frequency 50-60Hz Supply Current 0.15A Power Factor 0.9 - 0.98 Total Input Power 20W Secondary Output Voltage 24V DC Secondary Output Current 700mA Lamp Power 20W MATERIALS Body Aluminium Diffuser Polycarbonate THERMAL Ambient Temperature Rating -20 o C to +45 o C Maximum Surface Temp 75 o C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 1100 lumens CRI 80 Colour Temperature 3000K ▪   LED garden bollard ▪   Matt black powder coated die-cast       aluminium body ▪   UV stabilized white spherical polycarbonate     diffuser with inbuilt Philips fortimo LED       module ▪   IP65 ▪  10%-100% dimmable 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EXB614742 Matt Black 26998 WEIGHT / LIFE Fittting 3.2Kg LED Lamp Life 50,000 HR LED Bollard PRODUCT SPECIFICATIONS PRODUCT FEATURES (mm) 216 210 396 IP 65 DIMMABLE 10% 100% 20W 1100 LUMENS ENERGY SAVING LAMP LIFE 50,000 HOURS

Ex te rio r /  La nd sc a p e 113 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 STAINLESS STEEL 350 175 150 (mm) 38 EX8012K ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.06A Power Factor 0.45 Total Input Power 3.6W Secondary Output Voltage 12V Secondary Output Current 750mA Lamp Power 3 x 1W MATERIALS Body 304 stainless steel Diffuser Acrylic THERMAL Ambient Temperature Rating 25 o C Maximum Surface Temp 45 o C Ingress Protection Rating IP44 OPTICAL / PHOTOMETRIC Luminous Flux 40 lumens each ▪   LED low voltage garden bollard kit ▪   3 stainless steel bollards with frosted       acrylic diffusers and ground spikes ▪   10 metres of 4 core low voltage cable ▪   10VA LED converter ▪   Remote control unit to change light       colour to any of the seven available       colours ▪   304 grade stainless steel ▪   IP44 ▪   Replacement driver (code 85487) PRODUCT SPECIFICATIONS PRODUCT FEATURES COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX8012K Stainless Steel 25312 WEIGHT / LIFE Fittting 3.6Kg LED Lamp Life 10,000HR LED Garden Bollard Kit              3W 120 LUMENS ENERGY SAVING LAMP LIFE 30,000 HOURS
