Crompton Lighting LED Floodlights

XL-LED Performance IP66 Mini Floodlights                             58LED Weatherproof Floodlights                                              60 Floodlights

Flo o d lig hts 58 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 The LED Technology XL-LED IP 66  Mini Floodlight The Crompton XL-LED IP66 Floodlight has been uniquely developed  and  engineered  to  incorporate  the  latest  in  LED  technology  and  design. Complete with inbuilt LED module and driver, the Crompton LED IP66  Floodlight  is  class  leading  in  energy  efficiency  and  photometrics.  This is achieved by the use of an “in house“ designed high output  reflector  system  which  gives  superior  surface  light  together  with  controlled  beam  direction,  to  ensure  efficiency  and  suitability  for  general purpose floodlighting requirements. Crompton XL-LED IP66 Floodlights are suitable for a wide range of  domestic,  commercial  and  industrial  applications.  These  include  installations requiring total protection from dirt and dust or protection  from water penetration such as sprinklers or water jets. Available  in  three  popular  colours  to  enhance  any  traditional  or  contemporary  installation,  Crompton XL-LED IP66 Downlights have been designed for the future.

Flo o d lig hts 59 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 XL-FLED25 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 115mA Power Factor 0.98 Total Input Power 24W Lamp Power 24W MATERIALS Heatsink Aluminium Rear Gear Body Polycarbonate Terminal Cover Polycarbonate Mounting Bracket Steel Lens / Diffuser Glass Electronic Components & PCB’s RoHS compliant THERMAL Ambient Temperature Rating 40 o C Maximum Surface Temp 80 o C Ingress Protection Rating IP66 OPTICAL / PHOTOMETRIC Luminous Flux 1640 lumens CRI 65 Colour Temperature 4100K Beam Angle Vertical (Medium): 40° Horizontal (Wide): 70° WEIGHT / LIFE Fitting 950g Life 35,000HR XL-LED Performance weatherproof 24W  mini floodlight ▪   Heavy duty die-cast aluminium heatsink      with LED engine ▪   3mm tempered glass diffuser ▪   Powder coated zinc plated steel       mounting bracket ▪   Complete with inbuilt LED module and      LED driver ▪   Prewired to 1.2m flex and plug PRODUCT SPECIFICATIONS PRODUCT FEATURES REFERENCE COLOUR CODE XL-FLED25W White 27010 XL-FLED25B Black 27011 XL-FLED25S Silver 27012 ENERGY SAVING 70% 35,000 4100K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L XL-LED Performance IP66 Mini Floodlight  143 168.7 Bracket variable angle: 261°  96 (mm) IP66 24W 1640 LUMENS  Compared to a standard 150W linear halogen lamp

Flo o d lig hts 60 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 The Crompton LED IP65 Floodlight has been uniquely developed and engineered to incorporate  the latest in LED technology and design. Complete  with  inbuilt  LED  module  and  driver,  the  Crompton  LED  IP65  Floodlight  has  been  developed  as  a  cost  effective  energy  saving  lighting  solution  for  many  exterior  and  interior  applications. Crompton  LED  IP65  Floodlights  are  suitable  for  a  wide  range  of  domestic,  commercial  and  industrial applications. These include installations requiring total protection from dirt and dust, or  protection from low pressure water penetration such as sprinklers or water spray. Available in popular graphite finish, the Crompton IP65 LED Floodlight will enhance any traditional  or  contemporary  installation,  with  strong  aesthetic  appeal  achieved  through  modern  design  and solid state lighting technology. The LED Technology Crompton IP65 LED Floodlight Series

Flo o d lig hts 61 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 FL10 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3800K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L 10W IP65 LED Weatherproof Floodlights IP 65 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50Hz Supply Current 280mA Power Factor 0.82 Total Input Power 11.5W Secondary Output Voltage 30V Secondary Output Current 320mA Lamp Power 1 x 10W MATERIALS Body Aluminium Diffuser Tempered glass THERMAL Thermal Protection Fully protected Ambient Temperature Rating -20°C to 80°C Maximum Surface Temp 65°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 1100 lumens CRI 70 Colour Temperature 3800K Beam Angle 120° WEIGHT / LIFE Fitting 500g LED Lamp Life 40,000 HR Controller Life 50,000 HR ▪   LED weatherproof floodlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Inbuilt driver for direct connection to       240V supply ▪  Prewired to 1.5m flex & plug ▪   Weather resistant IP65 ▪  Includes 1 x 10W LED module 10W 1100 LUMENS REFERENCE COLOUR CODE FL10W White 27103 FL10B Black 27104 80% ENERGY SAVING LAMP LIFE 40,000 HOURS 115 85 90 (mm)  Compared to a standard 150W R7s linear halogen     lamp

Flo o d lig hts 62 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12  Compared to a standard 300W R7s linear halogen     lamp FL20 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3800K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L 20W IP65 LED Weatherproof Floodlights ▪  LED weatherproof floodlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Inbuilt driver for direct connection to       240V supply ▪  Prewired to 1.5m flex & plug ▪   Weather resistant IP65 ▪  Includes 1 x 20W LED module REFERENCE COLOUR CODE FL20W White 27105 FL20B Black 27106 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50Hz Supply Current 280mA Power Factor 0.83 Total Input Power 22W Secondary Output Voltage 30V Secondary Output Current 640mA Lamp Power 1 x 20W MATERIALS Body Aluminium Diffuser Tempered glass THERMAL Thermal Protection Fully protected Ambient Temperature Rating -20°C to 80°C Maximum Surface Temp 67°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 2200 lumens CRI 70 Colour Temperature 3800K Beam Angle 120° WEIGHT / LIFE Fitting 1Kg LED Lamp Life 40,000 HR Controller Life 50,000 HR IP 65 20W 2200 LUMENS 80% ENERGY SAVING LAMP LIFE 40,000 HOURS 180 140 105 (mm)

Flo o d lig hts 63 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12  Compared to a standard 300W R7s linear halogen     lamp FL20S PRODUCT SPECIFICATIONS PRODUCT FEATURES 3800K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L 20W IP65 LED Weatherproof Sensor  Floodlights ▪  LED weatherproof sensor floodlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Inbuilt driver for direct connection to       240V supply ▪  Prewired to 1.5m flex & plug ▪   Weather resistant IP65 ▪  Includes 1 x 20W LED module PIR sensor features: ▪  10W - 100W PIR sensor ▪  Suitable for temperature -20°C to 40°C ▪  Weather resistant IP44 ▪  Adjustable 180° up or down ▪  Detection distance 2-6m ▪  Time-delay: Min 5sec, Max 6min REFERENCE COLOUR CODE FL20WS White 27115 FL20BS Black 27116 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50Hz Supply Current 280mA Power Factor 0.83 Total Input Power 22W Secondary Output Voltage 30V Secondary Output Current 640mA Lamp Power 1 x 20W MATERIALS Body Aluminium Diffuser Tempered glass THERMAL Thermal Protection Fully protected Ambient Temperature Rating -20°C to 80°C Maximum Surface Temp 67°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 2200 lumens CRI 70 Colour Temperature 3800K Beam Angle 120° WEIGHT / LIFE Fitting 1Kg LED Lamp Life 40,000 HR Controller Life 50,000 HR IP 65 20W 2200 LUMENS 80% ENERGY SAVING LAMP LIFE 40,000 HOURS INBUILT SENSOR 180 140 45 55 70 105 (mm)

Flo o d lig hts 64 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12  Compared to a standard 500W R7s linear halogen     lamp FL50 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3800K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L 50W IP65 LED Weatherproof Floodlight ▪  LED weatherproof floodlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Inbuilt driver for direct connection to       240V supply ▪  Prewired to 1.5m flex & plug ▪   Weather resistant IP65 ▪  Includes 1 x 50W LED module REFERENCE COLOUR CODE FL50W White 27107 FL50B Black 27108 ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50Hz Supply Current 280mA Power Factor 0.85 Total Input Power 52.5W Secondary Output Voltage 30V Secondary Output Current 1600mA Lamp Power 1 x 50W MATERIALS Body Aluminium Diffuser Tempered glass THERMAL Thermal Protection Fully protected Ambient Temperature Rating -20°C to 80°C Maximum Surface Temp 67°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 5500 lumens CRI 70 Colour Temperature 3800K Beam Angle 120° WEIGHT / LIFE Fitting 2.3Kg LED Lamp Life 40,000 HR Controller Life 50,000 HR IP 65 50W 5500 LUMENS 80% ENERGY SAVING LAMP LIFE 40,000 HOURS 285 235 140 (mm)

Flo o d lig hts 65 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 EX2601 PRODUCT SPECIFICATIONS PRODUCT FEATURES 3000K - WARM 1 0 0 0 K 7 0 0 0 K W A RM C O O L REFERENCE COLOUR CODE EX2601 Graphite 27054 9W IP65 LED Weatherproof Floodlight ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 0.105A Power Factor 0.6 Total Input Power 12.5W Secondary Output Voltage 24V Lamp Power 9 x 1W MATERIALS Body Aluminium Diffuser Glass THERMAL Thermal Protection 135°C, fully protected Ambient Temperature Rating 40°C Maximum Surface Temp 75°C Ingress Protection Rating IP65 OPTICAL / PHOTOMETRIC Luminous Flux 511 lumens CRI 75-80 Colour Temperature 3000K Beam Angle 60° WEIGHT / LIFE Fitting 1.12Kg LED Lamp Life 30,000 HR Controller Life 30,000 HR ▪   9W CREE LED weatherproof floodlight ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   Adjustable head ▪   Silicon rubber gasket ▪   Inbuilt driver for direct connection to       240V supply ▪   Weather resistant IP65 ▪   9 x 1W LED’s 108 95 95 150 (mm) IP 65 9W 511 LUMENS ENERGY SAVING LAMP LIFE 30,000 HOURS
