Crompton Lighting LED Spotlights

Shoplighters XL-LED Performance Spot Shoplighter Kits                     40XL-LED Performance Flood Shoplighter Kits                    41

Sh o p lig hte rs 39 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 The LED Technology Crompton XL-LED Shoplighter has been uniquely designed and styled by Crompton Lighting as  an  energy  saving  retrofit  fixture  to  enhance  any  existing  or  new  installation  that  currently  uses  older metal halide technology. Available in two versions of both Spot and Flood for optimum performance, the LED kit comes  complete with pre-wired driver and housing making installation and replacement easy. The XL-LED Shoplighter is available in two popular colour choices, 3000K and 4000K It is fully and  easily adjustable. The new slimline housing is solid powder coated cast aluminium, incorporating  a white coated tempered glass diffuser to ensure good aesthetic ceiling appearance. Suitable for shops, restaurants, cafes and any retail or commercial area requiring a modern and  stylish appearance to enhance product display or merchandise. XL-LED Shoplighters

40 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 Sh o p lig hte rs XL-SL510W WEIGHT / LIFE Fitting 1.72Kg LED Lamp Life 50,000HR Controller Life 50,000HR PRODUCT SPECIFICATIONS PRODUCT FEATURES ENERGY AVE 50,000 3000K - WARM 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L XL-LED Performance Spot Shoplighter Kits 30W 2700/3000 LUMENS ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 650mA Power Factor 0.95 Total Input Power 33W Secondary Output Voltage 46V Secondary Output Current 200mA Lamp Power 30W MATERIALS Heatsink Aluminium Body Aluminium Diffuser Glass Controller Base & Cover Thermoplastic THERMAL Protection Overload, short-circuit Ambient Temperature Rating 25.3° Maximum Surface Temp 70° Ingress Protection Rating IP41 OPTICAL / PHOTOMETRIC Colour Temperature 3000K 4000K Luminous Flux 2700 lumens 3000 lumens CRI 80 80 Beam Angle 60° 60° REFERENCE COLOUR CODE 3000K XL-SL510W3K White 27090 4000K XL-SL510W4K White 27091 XL-LED Performance Spot shoplighter ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   46V, 200mA LED driver prewired to       1.5m flex plug and 600 mm secondary       leads ▪   Includes 2 x 15W LED modules 230 140 85 (mm)

Sh o p lig hte rs 41 Fittings do not include lamps unless specifically stated. E.&.O.E.      LED 07/12 WEIGHT / LIFE Fitting 1.72Kg LED Lamp Life 50,000HR Controller Life 50,000HR ENERGY AVE 50,000 3000K - WARM 4000K - COOL 1 0 0 0 K 7 0 0 0 K W A RM C O O L 30W 2700/3000 LUMENS ELECTRICAL Supply Voltage 220-240V AC Supply Frequency 50-60Hz Supply Current 650mA Power Factor 0.95 Total Input Power 33W Secondary Output Voltage 46V Secondary Output Current 200mA Lamp Power 30W MATERIALS Heatsink Aluminium Body Aluminium Diffuser Glass Controller Base & Cover Thermoplastic THERMAL Protection Overload, short-circuit Ambient Temperature Rating 25.3° Maximum Surface Temp 70° Ingress Protection Rating IP41 OPTICAL / PHOTOMETRIC Colour Temperature 3000K 4000K Luminous Flux 2700 lumens 3000 lumens CRI 80 80 Beam Angle 120° 120° XL-FL510W PRODUCT SPECIFICATIONS PRODUCT FEATURES XL-LED Performance Flood Shoplighters REFERENCE COLOUR CODE 3000K XL-FL510W3K White 27092 4000K XL-FL510W4K White 27093 XL-LED Performance Flood shoplighter ▪   Powder coated die-cast aluminium       construction ▪   Tempered clear glass diffuser ▪   46V, 200mA LED driver prewired to       1.5m flex plug and 600 mm secondary       leads ▪   Includes 2 x 15W LED modules 230 140 85 (mm)
