2 www.prysmiancable.com.au | www.prysmiancable.co.nz All sizes and values without tolerances are reference values. Specifications are for product as supplied by Prysmian Group: any modification or alteration afterwards of product may give diffe-rent result. The information contained within this document must not be copied, reprinted or reproduced in any form, either wholly or in part, without the written consent of Prysmian Group. The information is believed to be correct at the time of issue. Prysmian Group reserves the right to amend this specification without prior notice. This specification is not contractually valid unless specifically authorised by Prysmian Group. Prysmian offers a comprehensive range of flexible cable solutions with Class 5 conductors for fixed installations. With Flexible XLPE and Fire Performance cables, Prysmian has a full suite of cables for the entire Construction market.  Cost savings through flexibility Our cables … •  Are easy to handle and install•  Are easy to bend and are less stiff•  Require no bending tools•  Require fewer people to installMeaning electrical contractors are now able to work in  tight spaces and complete their projects faster – resulting  in significant savings through time and labour costs.  Superior cable management •  Product availability•  Shorter lead times•  Cables can be cut to length•  Reactive local support Long-life performance •  Australian designed and made•  Cables made from premium components•  Superior performance Safety – performance that ensures peace of mind •  High flexibility ensures easier handling – reducing the risk  of work place injury and fatigue •  Firestop cables exceed the fire & mechanical performance  requirements in AS/NZS 3013 Quality – superior manufacturing and support •  Independently certified by a NATA accredited facility•  Exceeds Australian Standards•  Expert quality control•  Quality technical after-sales support and service We’re flexible so you won’t have to be.  With our improved range of flexible cables we’ve brought flexibility to a completely new level.  From now on it’ll be a lot easier to get into those tight corners with less equipment, less  people and in half the time . With a 50% decrease in installation time, imagine what you  could do with those savings ... Australian made? Yes, of course. Dependant on job type and in comparison with rigid cables.

3 www.prysmiancable.com.au | www.prysmiancable.co.nz Flexible XLPE For mains, submains and subcircuits unenclosed, enclosed  in conduit, buried or in underground ducts for building and  industrial plants where not subject to mechanical damage.  Suitable where space is at a premium and/or where conditions of overload may occur. Green star accredited. Single core cablesFlexible 90 °C XLPE •  XLPE/PVC (SDI) X-90 Orange 0.6/1kV Flexible 110 °C XLPE •  RE-110 (SDI) 110 °C Black 0.6/1kV Flexible 90 °C PVC Earth •  PVC V-90 Green/Yellow 0.6/1kV Applicable standardsAS/NZS 5000.1 Product rangeAvailable in the conductor range 10 to 630 mm 2 ,   95 to 630 mm 2  products available from stock.   Earths available in the range 10 to 630 mm 2 ,   120 to 630 mm 2  available from stock. Flexible Firestop Firestop is easy to install fire safety cable range fully com-plying with the latest Australian standard AS/NZS 3013  and Building Code of Australia requirements. This range  is designed to save lives and help protect property in  the event of a fire. Single core cables Flexible 110 °C Firestop FS110 •  HFS-110 TP Red 0.6/1kV •  Fire performance – AS/NZS 3013 WS52W compliant Applicable standardsAS/NZS 3013 Product rangeAvailable in the conductor range 10 to 630 mm 2 ,   95 to 630 mm 2  products available from stock.  OP ER ATI NG TEMPERATU RE CO NSTANT AT 90 ˚C OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE Flexible 90˚C XLPE Flexible 110˚C XLPE Flexible 110˚C Firestop OP ER ATI NG TEMPERATU RE CO NSTANT AT 90 ˚C OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE Flexible 90˚C XLPE Flexible 110˚C XLPE Flexible 110˚C Firestop OP ER ATI NG TEMPERATU RE CO NSTANT AT 90 ˚C OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE Flexible 90˚C XLPE Flexible 110˚C XLPE Flexible 110˚C Firestop OP ER ATI NG TEMPERATU RE CO NSTANT AT 90 ˚C OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 OP ER ATI NG TEMPERATU RE CO NSTANT AT 110 ˚C 110 BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE BE N DIN G R ADIU S FOR FIXED A PP LIC AT IO N S FL EXI BLE XLPE CABLE Flexible 90˚C XLPE Flexible 110˚C XLPE Flexible 110˚C Firestop Green Star is a national, voluntary environmental rating system that evaluates the environmental impact of product design, manufacture and life-cycle and so  reduced the amount of materials going to landfill and into water systems. WS52W requires the cable to maintain circuit integrity when tested for  two hours in a furnace attaining a maximum temperature of 1050 °C, followed by a three minute water spray. The cable is also classified as having moderate mechanical resistance.

4 www.prysmiancable.com.au | www.prysmiancable.co.nz XLPE/PVC (SDI) X-90 FLEXIBLE CABLES 0.6/1 kV Application Flexible single core X-90 XLPE insulated and PVC sheathed cable for mains, submains and subcircuits unenclosed, en-closed in conduit, buried or in underground ducts for building and industrial plants where not subject to mechanical dam-age. Suitable where space is at a premium and/or where conditions of overload may occur Approvals Suitable for fixed applications only in accordance  with AS/NZS 3000 + AS/NZS 5000.1 Behaviour in flame and fire: Flame propagation - AS/NZS 1660.5.6 Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C Minimum bending radius Installed cables:   OD≤25 mm 4D      OD 25 mm 6D  During installation:   OD≤25 mm 6D      OD 25 mm 9D Resistance to Chemical exposure:  Occasional Mechanical impact:   Light Water exposure:   Occasional condensation   Solar radiation and  weather exposure:   Occasional Cable design Conductor:   Flexible bunched annealed copper conductor    to AS/NZS 1125 (Class 5).Insulation:   X-90 XLPE (Flexible XLPE)   Colour: NaturalSheath:    5V-90 PVC   Colour: Orange Installation conditions In free air In conduit In trench In ground with protection In duct

5 www.prysmiancable.com.au | www.prysmiancable.co.nz For fixed installation Product   code Conductor Cable Min.   installed   bending   radius  mm Nominal C.S.A. mm² Nominal diameter mm Nominal insulation thickness mm Overall diameter Approx.   mass   kg/100 m Minimum  mm Maximum  mm 351CFF90 35 7.7 0.9 11.9 12.7 38.7 76 501CFF90 50 9.3 1.0 13.7 14.5 53.5 87 701CFF90 70 11.1 1.0 15.7 16.5 72.9 99 951CFF90 95 12.8 1.0 17.5 18.4 94.2 110 1201CFF90 120 14.5 1.2 19.4 20.3 118.6 122 1501CFF90 150 16.3 1.4 21.7 22.7 147.4 136 1851CFF90 185 18.0 1.6 23.8 24.8 178.0 149 2401CFF90 240 20.8 1.7 26.9 28.0 231.8 168 3001CFF90 300 23.4 1.8 29.8 30.9 288.3 186 4001CFF90 400 26.8 2.0 33.8 35.0 376.2 210 5001CFF90 500 30.3 2.2 37.8 39.1 474.5 235 6301CFF90 630 35.1 2.4 43.2 44.6 628.9 268 Current ratings Nominal  conductor   area mm 2 Unenclosed Enclosed Thermal insulation Buried  direct Underground   wiring   enclosure Three phase   voltage drop (@ 50Hz & 90 °C) mV/A.m Spaced Spaced  from   surface Touching Exposed  to sun Wiring  enclosure  in air Partially  surrounded  by   thermal   insulation Completely   surrounded  by   thermal  insulation 10 80  69  64  48  55  45  32  67  66  79  4.22 4.22 16 106  91  85  63  73  58  43  117  85  101  2.68 2.68 25 142  121  114  83  94  77  58  151  109  132  1.73 1.74 35 177  151  141  103  118  96  72  180  134  158  1.24 1.24 50 223  191  178  128  144  114  - 214  163  190  0.869 0.875 70 283  241  225  161  183  146  - 262  203  232  0.622 0.630 95 341  290  271  192  214  176  - 313  237  276  0.483 0.492 120 406  346  322  226  256  209  - 356  279  320  0.388 0.399 150 470  400  372  260  291  236  - 400  316  358  0.325 0.338 185 540  459  427  296  334  268  - 452  357  413  0.280 0.295 240 651  553  514  352  391  320  - 523  416  477  0.233 0.251 300 752  637  591  402  458  375  - 589  479  552  0.207 0.227 400 909  764  709  477  533  427  - 668  554  626  0.183 0.204 500 1062  884  821  546  630  506  - 752  642  707  0.169 0.192 630 1256  1030  956  630  719  571  - 843  729  820  0.157 0.181 Note: Refer to Cable Selection in Technical Cable Guide for more information and data based on AS/NZS 3008.1.1. Physical & electrical characteristics FLEXIBLE CABLES 0.6/1 kV – XLPE/PVC (SDI) X-90

6 www.prysmiancable.com.au | www.prysmiancable.co.nz Application Flexible single core RE-110 insulated and HFS-110-TP sheathed cable for mains, submains and subcircuits unen-closed, enclosed in conduit, buried or in underground ducts for building and industrial plants where not subject to me-chanical damage. Suitable where space is at a premium and/or where conditions of overload may occur. Approvals Suitable for fixed applications only in accordance  with AS/NZS 3000 + AS/NZS 5000.1 Behaviour in flame and fire: Flame propagation - AS/NZS 1660.5.6 Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +110 °C Minimum operating temperature: -25 °C Minimum bending radius Installed cables:   OD≤25 mm 4D      OD 25 mm 6D  During installation:   OD≤25 mm 6D      OD 25 mm 9D Resistance to Chemical exposure:  Occasional Mechanical impact:   Light Water exposure:   Occasional condensation   Solar radiation and  weather exposure:   Occasional Cable design Conductor:   Flexible bunched annealed copper conductor    to AS/NZS 1125 (Class 5).Insulation:  RE-110   Colour: NaturalSheath:   HFS-110-TP   Colour: Black Installation conditions In free air In conduit In trench In ground with protection In duct RE-110 (SDI) 110°C FLEXIBLE CABLES 0.6/1 kV

7 www.prysmiancable.com.au | www.prysmiancable.co.nz For fixed installation Product   code Conductor Cable Min.   installed   bending   radius  mm Nominal C.S.A. mm² Nominal diameter mm Nominal insulation thickness mm Overall diameter Approx.   mass   kg/100 m Minimum  mm Maximum  mm 351CFF110 35 7.7 1.2 12.5 13.3 40.3 80 501CFF110 50 9.3 1.4 14.5 15.3 55.9 92 701CFF110 70 11.1 1.4 16.4 17.2 75.0 103 951CFF110 95 12.8 1.6 18.6 19.4 97.9 116 1201CFF110 120 14.5 1.6 20.2 21.1 122.0 127 1501CFF110 150 16.3 1.8 22.6 23.6 151.1 141 1851CFF110 185 18.0 2.0 24.8 25.8 183.1 155 2401CFF110 240 20.8 2.2 28.2 29.3 239.0 176 3001CFF110 300 23.4 2.4 29.9 31.1 290.0 186 4001CFF110 400 26.8 2.6 35.2 36.5 386.2 219 5001CFF110 500 30.3 2.8 39.3 40.6 485.7 244 6301CFF110 630 35.1 2.8 44.1 45.6 637.3 273 Current ratings Nominal  conductor   area mm 2 Unenclosed Enclosed Thermal insulation Buried  direct Underground   wiring   enclosure Three phase   voltage drop (@ 50Hz & 110 °C) mV/A.m Spaced Spaced  from   surface Touching Exposed  to sun Wiring  enclosure  in air Partially  surrounded  by   thermal   insulation Completely   surrounded  by   thermal  insulation 10 99  85  80  67  70  57  40  77  76  88  4.48 4.48 16 130  112  105  88  91  74  53  130  97  115  2.84 2.85 25 173  149  139  116  121  100  72  168  125  148  1.84 1.84 35 214  184  172  143  148  121  88  201  151  176  1.31 1.31 50 270  233  217  179  190  146  - 237  188  212  0.921 0.926 70 340  292  273  224  234  187  - 291  229  259  0.658 0.665 95 410  353  329  269  277  228  - 348  268  315  0.509 0.518 120 487  418  390  317  331  269  - 396  316  357  0.408 0.419 150 562  482  450  365  378  306  - 445  357  400  0.340 0.353 185 644  553  516  417  438  359  - 503  404  461  0.293 0.307 240 775  665  620  499  538  439  - 583  481  533  0.242 0.259 300 895  766  714  572  612  501  - 657  542  617  0.213 0.232 400 1079  918  855  682  757  575  - 746  648  700  0.187 0.208 500 1260  1064  990  786  864  692  - 843  729  815  0.172 0.194 630 1493  1240  1154  913  993  787  - 947  828  920  0.159 0.182 Note: Refer to Cable Selection in Technical Cable Guide for more information and data based on AS/NZS 3008.1.1. Physical & electrical characteristics FLEXIBLE CABLES 0.6/1 kV – RE-110 (SDI) 110°C

8 www.prysmiancable.com.au | www.prysmiancable.co.nz FIRESTOP FS110 FLEXIBLE CABLES 0.6/1 kV Application Flexible single core cable. Power supply to essential circuits such as mains, sub mains and other areas where circuit  integrity is essential in the event of a fire.•  Classified (WS52W) meaning the scope of testing is   designed to confirm performance when installed in  a wiring system.  •  Circuit integrity up to an extreme temperature of 1050 °C  at the end of 2 hours.  •  LSZH - Suitable for confined and high people density   areas such as airports and other public buildings. Approvals Suitable for fixed applications only in accordance with  AS/NZS 3000 + AS/NZS 5000.1. Certification to  AS/NZS 3013 by a NATA accredited facility. Behaviour in flame and fire: Fire performance rating WS52W - AS/NZS 3013 Flame propagation - AS/NZS 1660.5.6 Halogen free/Low smoke emission – AS/NZS 4507 Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +110 °C Minimum operating temperature: -25 °C Minimum bending radius Installed cables:   8D  During installation:   12D Resistance to Chemical exposure:  Occasional Mechanical impact:   Moderate Water exposure:   Spray   Solar radiation and  weather exposure:   Occasional Cable design Conductor:   Flexible bunched plain annealed copper (Class 5).Insulation:   Mica glass tape fire barrier, XHF-110   Colour: NaturalSheath:   HFS-110-TP   Colour: Red Installation conditions In free air In duct Internal wiring External building

9 www.prysmiancable.com.au | www.prysmiancable.co.nz For fixed installation Product code Nominal C.S.A.  mm² Nominal Cable O.D. Approx. mass  kg/100 m AS/NZS 3013 WS Rating 251CFFFS110 25 13.7 36.0 WS52W 351CFFFS110 35 14.8 46.0 WS52W 501CFFFS110 50 16.4 61.0 WS52W 701CFFFS110 70 18.2 81.0 WS52W 951CFFFS110 95 20.1 103.0 WS52W 1201CFFFS110 120 21.8 128.0 WS52W 1501CFFFS110 150 24.0 157.0 WS52W 1851CFFFS110 185 26.1 189.0 WS52W 2401CFFFS110 240 29.3 245.0 WS52W 3001CFFFS110 300 32.2 303.0 WS52W 4001CFFFS110 400 36.3 394.0 WS52W 5001CFFFS110 500 40.4 495.0 WS52W 6301CFFFS110 630 45.9 654.0 WS52W Cable selection – For fixed installation Nominal C.S.A.  mm² Resistance Ω/km Reactance   at 50Hz trefoil  Ω/km Impedance   trefoil touching   at 110°C  Ω/km Voltage drop three phase mV/A.m D.C. at 20°C A.C. at 110°C Lay flat touching Trefoil touching 25 0.780 1.06 0.0973 1.065 1.85 1.84 35 0.554 0.750 0.0930 0.757 1.31 1.31 50 0.386 0.523 0.0901 0.532 0.926 0.921 70 0.272 0.369 0.0869 0.380 0.665 0.659 95 0.206 0.280 0.0849 0.294 0.519 0.510 120 0.161 0.219 0.0828 0.236 0.418 0.408 150 0.129 0.176 0.0830 0.196 0.352 0.340 185 0.106 0.145 0.0821 0.169 0.306 0.292 240 0.0801 0.111 0.0808 0.140 0.259 0.242 300 0.0641 0.0898 0.0800 0.123 0.232 0.213 400 0.0486 0.0699 0.0788 0.108 0.208 0.187 500 0.0384 0.0571 0.0780 0.0993 0.194 0.172 630 0.0287 0.0495 0.0770 0.0938 0.186 0.162 Physical & electrical characteristics FLEXIBLE CABLES 0.6/1 kV – FIRESTOP FS110

10 www.prysmiancable.com.au | www.prysmiancable.co.nz Current carrying capacity (a) Nominal C.S.A.  mm² Unenclosed Enclosed metallic wiring enclosure in air   A Underground ducts Spaced   A Spaced from   surface  A Touching  A One duct  A Two duct  A Three duct  A Two (2) Single Core Firestop Flexible Cables FS110 25 178 170 139 133 143 163 - 35 221 210 172 167 176 195 - 50 279 263 218 207 215 236 - 70 351 329 273 263 266 288 - 95 422 395 329 312 312 352 - 120 500 466 390 364 359 400 - 150 577 536 450 426 414 448 - 185 660 611 516 481 464 517 - 240 794 732 621 583 548 600 - 300 916 841 716 - 631 694 - 400 1105 1006 860 - 734 790 - 500 1290 1164 999 - 855 921 - 630 1529 1359 1168 - 977 1045 - Three (3) Single Core Firestop Flexible Cables FS110 25 173 149 139 121 125 - 148 35 214 184 172 148 151 - 176 50 270 233 217 190 188 - 212 70 340 292 273 234 229 - 259 95 410 353 329 277 268 - 315 120 487 418 390 331 316 - 357 150 562 482 450 378 357 - 400 185 644 553 516 438 404 - 461 240 775 665 620 538 481 - 533 300 895 766 714 612 542 - 617 400 1079 918 855 757 648 - 700 500 1260 1064 990 864 729 - 815 630 1493 1240 1154 993 828 - 920 (a) Based on 90°C conductor temperature, 40°C ambient air temperature and where applicable, burial depth of 0.5m, soil temperature   of 25°C and soil thermal resistivity of 1.2°C.m/W. Refer to AS/NZS 3008.1 for other installation conditions. Physical & electrical characteristics FLEXIBLE CABLES 0.6/1 kV – FIRESTOP FS110

A lot of companies say they can make cables. But we’re the leading green star manufacturer of cables.  So if sustainable responsibility is part of your business you can count us in. Australian made? Yes, of course.  See a star! We’re Green Star certified.

12 www.prysmiancable.com.au | www.prysmiancable.co.nz Voltage drop Conductor  size  mm² Three phase voltage drop (Vc) at 50hz, mV/A.m Conductor temperature °C 45 60 75 90 110 Max. 0.8 p.f. Max. 0.8 p.f. Max. 0.8 p.f. Max. 0.8 p.f. Max. 0.8 p.f. 0.5 74.2 - 78.2 - 82.2 - 86.1 - 91.4 - 0.75 49.5 - 52.1 - 54.8 - 57.4 - 61.0 - 1 37.1 - 39.1 - 41.1 - 43.1 - 45.7 - 1.5 25.3 - 26.7 - 28.0 - 29.4 - 31.2 - 2.5 15.2 - 16.0 - 16.8 - 17.6 - 18.7 - 4 9.42 - 9.92 - 10.4 - 10.9 - 11.6 - 6 6.28 - 6.62 - 6.95 - 7.29 - 7.74 - 10 3.64 - 3.83 - 4.03 - 4.22 - 4.48 16 2.31 - 2.43 - 2.56 - 2.68 - 2.84 - 25 1.50 - 1.57 - 1.65 - 1.73 - 1.84 - 35 1.07 - 1.12 - 1.18 - 1.24 - 1.31 - 50 0.754 - 0.792 - 0.831 - 0.869 - 0.921 - 70 0.543 0.569 0.596 0.622 0.658 95 0.425 0.443 0.463 0.483 0.509 120 0.344 0.358 0.373 0.388 0.408 150 0.291 0.302 0.313 0.325 0.340 185 0.254 0.263 0.272 0.280 0.293 240 0.215 0.214 0.221 0.221 0.227 0.227 0.233 0.233 0.242 0.242 300 0.194 0.190 1.098 0.195 0.203 0.200 0.207 0.205 0.213 0.212 400 0.175 0.166 0.178 0.170 0.180 0.174 0.183 0.178 0.187 0.183 500 0.164 0.151 0.165 0.154 0.167 0.157 0.169 0.160 0.172 0.164 630 0.154 0.137 0.155 0.139 0.156 0.141 0.157 0.143 0.159 0.146 Note: These Vc values apply to a balanced three phase circuit in which no current flows in the neutral conductor.   To determine the singe phase Vc the current in the neutral conductor needs to be considered by multiplying the three phase value   2   — √3 = 1.155.  Ref: AS/NZS 3008.1.1 FLEXIBLE CABLES 0.6/1 kV Technical information

13 www.prysmiancable.com.au | www.prysmiancable.co.nz Cable selection – Safe working force Cables subjected to straight tension without significant bending or flexing - Safety factor 4:1 Nominal conductor  area  mm² Single core  kN Two core  kN Three core  kN Four core  kN More than four cores  kN 0.5 0.015 0.030 0.045 0.060 0.015 x N 0.75 0.023 0.045 0.068 0.090 0.023 x N 1.0 0.030 0.060 0.090 0.12 0.030 x N 1.5 0.045 0.090 0.14 0.18 0.045 x N 2.5 0.075 0.15 0.23 0.30 0.075 x N 4 0.12 0.24 0.36 0.48 0.12 x N 6 0.18 0.36 0.54 0.72 0.18 x N 10 0.30 0.60 0.90 1.2 0.30 x N 16 0.48 0.96 1.4 1.9 0.48 x N 25 0.75 1.5 2.3 3.0 0.75 x N 35 1.1 2.1 3.2 4.2 1.1 x N 50 1.5 3.0 4.5 6.0 1.5 x N 70 2.1 4.2 6.3 8.4 2.1 x N 95 2.9 5.7 8.6 11 2.9 x N 120 3.6 7.2 11 14 3.6 x N 150 4.5 9 14 18 4.5 x N 185 5.6 11 17 22 - 240 7.2 14 22 - - 300 9 18 - - - Where N equals the number of cores of the same size. Cable Selection – 3-phase formulae Desired data Single phase Three phase When kVA is known  kVA 1000   Eo  kVA 1000   √3 E When kW is known  kW 1000   (Eo pf)  kW 1000   √3 E pf When hp is known  hp 746/  (Eo pf)  hp 746/  √3 E pf kVA  I Eo   1000  I E √3   1000 kW  I Eo pf   1000  I E √3 pf   1000 hp  I Eo pf   746  I E √3 pf   746 Table lists formulae commonly used for determining various   parameters of an electrical system.Where: Eo  =  Single phase voltage, in volts. E.g. 240V E  =  Three phase line voltage, in volts. E.g. 415V (E = √3 x Eo) I  =  Current in amperes %Eff  =  Percent efficiency in decimals (varies from 85 % for       small motors to 90 % and over in large motors) pf  =  Power factor in decimals kVA  = Kilovolt-amperehp  = HorsepowerkW  = KilowattsPower Output = Power Input x %Eff√3  = 1.732 FLEXIBLE CABLES 0.6/1 kV Technical information

14 www.prysmiancable.com.au | www.prysmiancable.co.nz Cable selection The following are some simplified procedures for cable  selection. Refer to the Wiring Rules and AS/NZS 3008.1.1 for detailed information. The four main electrical criteria for cable selection are: 1.  Current rating  2.  Voltage drop 3.  Earth loop impedance 4.  Short-circuit capacity Generally speaking, for:Short route length, current-carrying capacity requirement will dictate the cable size selection. Long route length, voltage drop or earth loop impedance requirement will dictate the cable size selection. The short-circuit capacity of a cable shall be such that all short-circuit current occurring at any point of a circuit shall not cause the cable conductor temperature to exceed the maximum permissible limit. Current rating Current rating of a cable depends on: 1.  Installation method, e.g., In air or ground, enclosed or  unenclosed, etc. 2.  Installation environment, e.g., ambient temperature, depth of laying, presence of other cables or circuits  nearby, etc. 3.  Limiting temperatures of the cables for normal use,  e.g., PVC and XLPE insulated cables are 75 °C and 90 °C respectively. 4.  Type of overcurrent protective device used, appropriate derating factor:- 0.8 for semi-enclosed (rewireable) fuses - 0.9 for fuses, e.g. AS 2005 series fuses, with I2 = 1.6 x IN  - No derating is required for circuit breakers, e.g. AS/NZS 4898 circuit breakers, with I2 = 1.45 x IN Where:   I2 = convertional overcurrent fusing or tripping current.   IN = nominal current of the fuse or circuit breaker. Current ratings in this technical manual are extracted from AS/NZS 3008.1.1 Voltage drop Wiring Rules stipulate a maximum voltage drop of 5 % of the nominal voltage between the point of supply and any point in the installation when the conductors are carrying maximum demand. Voltage drops in this technical manual are based on: 1.  Maximum conductor temperatures of 75 °C, 90 °C and 110 °C as indicated. 2.  Load power factor to give maximum voltage drop. 3.  Single core cables are touching in trefoil or flat formation. 4.  Supply frequency of 50Hz. An Equation to determine minimum required cable size due to voltage drop is:Vc = Vd x 1000/I x L millivolts/ampere metre Where:  Vc = Millivolts drop/ampere metre as given in the tables  Vd = Maximum permissible voltage drop in volts I = Current in Amperes L = Route length in metres A Cable can now be selected such that Vc is equal to or less than calculated, and check that it will carry the current Earth loop impedance and short circuit capacity When relevant information on calculating these values is required please consult the Prysmian “Technical Cable Guide”. General information FLEXIBLE CABLES 0.6/1 kV

15 www.prysmiancable.com.au | www.prysmiancable.co.nz Ambient temperature  The temperature of the medium in the immediate neighbourhood of the installed cable:  for current - carrying capacity:  1. including any increase in temperature due to materials or equipment to which the cables     are connected, or are to be connected; but    2. excluding any increase in temperature which may be due to the heat arising from     the cables at that point. AS/NZS 1125:   Conductors in insulated electric cables and flexible cords. AS/NZS 1995:   Welding Cables AS/NZS 3000:   Australian/New Zealand Wiring Rules AS/NZS 3008.1.1:   Australian/New Zealand Standard - Electrical installations - Selection of cables     Part 1.1: Cables for alternating voltages up to and including 0.6/1kV     - Typical Australian installation conditions AS/NZS 3191:   Electric flexible cords AS 3147:   Superseded by AS/NZS 5000 AS/NZS 3198:   Superseded by AS/NZS 5000 AS/NZS 5000:   Australian/New Zealand Standard    • Electric Cables    • Polymeric insulated    Part 1: For working voltages up to and including 0.6/1kV    Part 2: For working voltages up to and including 450/750V Bending radius, installed:   Refers to minimum bending radius to which the cable can be subjected to in     its final position or location. Bending radius, installing:   Refers to minimum bending radius to which the cable can be subjected to     during the installation process. Conductor:   That portion of a cable which has specific function of carrying current. Cu:   Copper conductor, usually refers to plain annealed copper. Elastomer:   Synthetic Rubber Thermosetting Polymer LV:   Low voltage:     • A.C. = 50V and = 1000V;     • D.C. = 120V and =1500V Overcurrent:   A current exceeding the rated value. PACW:   Plain annealed copper wire. PE:   Polyethylene (see thermoplastic material) Point of Supply:   The junction of the electricity distributor’s conductors with the consumers mains     (formerly known as consumer terminals). PVC:   Polyvinyl Chloride R-EP-90:   A cross-linked compound based on ethylene propylene copolymer or terpolymer,     suitable for a maximum continuous operating temperature of 90°C. Short-circuit current:   A fault current resulting from a fault of negligible impedance between live conductors     having a difference in potential under normal operating conditions. TACW:   Tinned annealed copper wire TCu:   Tinned copper conductor Thermoplastic material:   A material that can be readily softened and re softened by repeated heating e.g. PVC and PE. Thermosetting material:   A material which cures by chemical reaction and when cured, or crosslinked, cannot be     melted and reshaped e.g. XLPE. XLPE:   Cross linked polyethylene. For LV application, usually refers to X-90 grade     (see thermosetting material). Glossary of terms FLEXIBLE CABLES 0.6/1 kV
