Gear up for the future. OptiC@t®5e cables will take you there. OptiC t5e OptiC t5e @

All sizes and values without tolerances are reference values. Specifications are for product as supplied by Prysmian Group: any modification or alteration afterwards of product may give differ-ent result. The information contained within this document must not be copied, reprinted or reproduced in any form, either wholly or in part, without the written consent of Prysmian Group. The information is believed to be correct at the time of issue. Prysmian Group reserves the right to amend this specification without prior notice. This specification is not contractually valid unless specifically authorised by Prysmian Group. HYBRID MULTI-PURPOSE COMMUNICATION CABLE  OptiC@t®5e Application For use indoors. Typical application is to connect an  Optical Network Termination (ONT) to an existing  LAN or telephone network. Cable design Copper pairs:   Conductor: Bare annealed copper wire, Ø 0.50 mm   Insulation: PE insulation   Core colour: white/blue; white/orange;    white/green; white/brown.  Optical unit:   Tight buffer: Each fibre has a LSZH buffering   Strength member: Aramid yarn   Sheath: Blue LSZH Outer sheath / Core wrapping:   Core wrapping: Polyester tape   Outer sheath: Pebble white LSZH Sheath marking:   PRYSMIAN (YEAR) OPTIC@T5E 4P + 2SM BBXS xxxxM Packing:   “Reel in a Box” for easy dispensing. Delivery lengths:    Standard delivery length is 305 metres marked from 305    to 0, so you always know exactly how much you have left. Optical unit PET tape Outer sheath Copper conductor Insulation ofcopper conductor Gear up for the future. Future-proof your home! The communication cable OptiC@t®5e is a combo of a four pair Cat5e and two bend-insensitive fibres. Not only will it’s capability for super high-speed make the building attractive to future owners, the Low Smoke Zero Halogen sheath makes the building much safer, too. Plus, the cables insensitivity to bending makes it a lot easier and less expensive to install. Copper and optic fibre links the present to the future and gives you the better of two worlds.

Technical data OptiC@t®5e Hybrid Cable - 4x 2 x 0.5+2SM BBXS Copper pairs   (4 pairs) Conductor diameter: 0.50 mm Insulation thickness: 0.21 mm Insulation diameter: 0.92 mm Twist pitch: ≤ 25 mm Optical unit   (2 fibres) Buffer diameter: 0.9 mm Sheath diameter: 2.5 mm Outer sheath/Core wrapping Sheath thickness: nominal 0.6 mm Cable diameter: Ø 6.1  mm Cable weight 40 kg/km Min. bending radius (mm) 10 x cable diameter (no load). 15 x cable diameter (with load) Temperature range Installation: -15 to +55 °C.  Transport: -40 to +70 °C.  Operation: -30 to +70 °C   Flame propagation IEC 60332-1 All dimensions and weights are nominal. Electrical characteristics Conductor DC resistance (20 °C) ≤ 95 Ω/km Resistance unbalance ≤ 2 % Mean characteristic impedance 100 Ω ± 15 Ω (100 MHz) Mutual capacitance ≤ 56 nF/Km Insulation resistance (20 ± 5 °C, 500 VDC) ≥ 5000M Ω .km Propagation delay ≤ 534+36/sqrt(f) ns/100 m Delay skew ≤ 45 ns/100 m Velocity propagation Approx 67 % Dielectric strength (1.5kVdc) 1KV DC 1 min (core-core) Optical characteristics Refer to the optical fibre data sheet C24 for G657A2 BBXS

Identification Pair 1 Pair 2 Pair 3 Pair 4 Copper pairs Colour code A wire blue orange green brown B wire white/blue white/orange white/green white/brown Optical unit Buffer colours Fibre no 1 blue Fibre no 2 orange Transmission characteristics for copper pair Frequency  MHz Attenuation  dB/100 m max NEXT  dB/100 m min PS-NEXT (only for 4 pairs)  dB/100 m min ELFEXT  dB/100 m min PS-ELFEXT (only for 4 pairs)  dB/100 m min Return loss  dB min 1 2.1 65 62 64 61 20 4 4.1 56 53 52 49 23 10 6.5 50 47 44 41 25 16 8.2 47 44 41 37 25 20 9.2 46 43 38 35 25 31.25 11.7 43 40 34 31 24 62.5 17.0 38 35 28 25 22 100 22.0 35 32 24 21 20

“Reel in a Box” – for easy dispensing High speed internet will soon be available to most businesses and homes with the government initiative to roll out a national fibre network. OptiC@t®5e  Hybrid Multi-Purpose Communication Cable allows the project owner and installer to “future proof”  their next project. Buildings that are “fibre ready” will have a distinct advantage when preparing to sell or promote their new project. OptiC@t®5e cable allows immediate connection to  existing twisted pair telecommunication networks  via the cat 5e cable, the high quality BendBrightXS™ fibres sit in the safety of a Low Smoke Halogen sheathed cable, ready to be connected to super  high speed internet when available.  The quality of BendBrightXS™ fibre optic BendBrightXS™ the latest in Bend-Insensitive fibre from Prysmian and Draka. BendBrightXS™ optical  fibres are specially manufactured using Draka’s  patented EPVC (Enhanced Plasma Vapour Deposition) process and complies with the ITU-T G.657.A2  standard. This market leading technology makes BendBrightXS™ virtually insensitive both to  MICRO and MACRO bending, making it perfect for  installation in compact and tight installation areas.  OptiC@t®5e can be installed in; • New housing estates  • Major home renovations  • Commercial fit outs of old buildings  • New commercial building installs  • New or old refits of residential units Why not get your next project ready for the optical fibre revolution, install OptiC@t®5e Hybrid Multi-Purpose Communication Cable. Watch the “how to prepare OptiC@t®5e Hybrid Multi-Purpose Communication  Cable” video on our website.
