Legrand Excel Life 2015 Catalogue

RESIDENTIAL • COMMERCIAL • MEDICAL

Residential Solutions ............................................................ 4 Commercial Solutions ........................................................ 6 Medical Solutions ................................................................ 8 3 Format Options................................................................ 10 Fastest & Safest Powerpoints To Install ................. 12 Powerpoints ....................................................................... 14 Super Fast USB Charging -  2 × 2.4A ..................... 16 Ready-Made Switches ................................................ 18 Switch Mechanisms ................................................... 20 Voice, Data, Audio & Video ...................................... 22 Signal Lights ............................................................... 24 Safety Lights .............................................................. 25 Catalogue Pages ..................................................... 26 Excel Life, the mightiest and most  comprehensive range of electrical  accessories for Residential,  Commercial and Medical  applications.

RESIDENTIAL  SOLUTIONS 4

Extra-Safe Powerpoints Great for kids’ bedrooms   and common areasSee page 14. Create USB charging hubs in kitchens See page 16. Electronic  Push-Button  Switches &  Dimmers Smooth  flicker-resistant  dimming that  is compatible  with all loads.  Program LEDs  red or blue.See page 20. Customise behind-the-TV panels See page 22. STYLED FOR CONTEMPORARY INTERIORS DESIGNED TO LAST From standard 16AX fluoro-rated rocker switches, to child-safe powerpoints, and every socket a homeowner could ever need, Excel Life brings a new level of excellence to everyday homes - from family homes in Fremantle to holiday apartments in Queenstown, and everywhere in between. With a focus on design technology and convenience, gadget guys as well as the style conscious are sure to be well pleased. HI-TECH TOUCHES Impress with innovations such as cool blue LED rings for rocker switches, stylish electronic push-button switches, and high performance, fast-charging USB powerpoints. Bring  hi-tech to the everyday. See page 18. HOME IDEAS ECCW2WPLWE + EC777XWE + EM803SURGEWE + 2 x EMRJ45C6WE + EMFFFOXWE + EMSPWE   ED770/3WE + 3 x EM770LEDWE   ED770/4GPLWE +   4 x EM883WE   ED770/3GPLUG + 3 x EMUSB2PSAUG   ED777USB2PSAWE   ED777ESWE 5 EXCEL LIFE WWW.EXCELLIFE.COM.AU

COMMERCIAL  SOLUTIONS 6

Add these charging  stations to conference  halls and meeting rooms See page 16. Try these skirting   lights in corridors See page 25. Antimicrobial  Switches Great for kitchens,   clinics, schools  and child-care   centres. See page 55. Secure  Plate  Switches Ideal for  areas prone  to vandalismSee page 10. International  standards  shaver socket See page 38. MECHANISMS FOR EVERY PROJECT IMPROVING PRODUCTIVITY AND CONVENIENCE Whether your latest project is an office, restaurant, or retail store, Excel Life has everything you need to facilitate and improve the behind-the-scenes grunt of businesses and organisations - it offers the most comprehensive range of functions, in one range, on the market.  Product Environmental Profiles (PEPs) are available for key products - outlining materials, manufacturing, distribution, usage and end-of-life product management. Visit excellife.com.au Customise the perfect panels for staff-only areas See page 22. EFFICIENCY TIPS Multimedia Panels Data, video and  audio distribution   for meeting and  function rooms.See page 22.   ES770/2GPLWE + 2 x EM770WE   EC798WE   EC787/2XWE + 2 x EMUSB2PSAWE   EC511WE ECCW2HPLWE + EC770/6GPLWE + EM800BPBLWE + EM800BPRDWE +  EMRCARDWE + EMRCAYELWE + EMRJ45C6WE + EMRJ45C6BU + ECFRAME + 2 x EM910HDMIWE + EM910USBWE   Multi - panel   EC770/4CAWE 7 EXCEL LIFE WWW.EXCELLIFE.COM.AU

MEDICAL  SOLUTIONS 8

Colour-coded  Options for easy identification, uninterruptible supply, essential supply, cleaners purposes only. See page 56. Everything you need to create the safest panels  See page 55. ADVANCED   MEDICAL RANGE  A finalist in the 2015 Good Design Awards, Excel Life Medical featuring antimicrobial technology helps reduce the spread of bacteria in hospitals and other health care environments, leading to enhanced patient care. From colour-coded powerpoints, to power indicators and heavy duty panels, Excel Life Medical gives you the power to fit-off every detail required for hospitals, laboratories, surgeries, clinics and more.  HANDY HINTS ANTIMICROBIAL ADVANTAGE Our antimicrobial technology has a kill rate against Escherichia coli and Staphylococcus aureus between 99.72% and 99.9999%. Refer to our technical data sheets for detailed information at  excellife.com.au Electresafe RCD Powerpoint 10mA.See page 14. No   Touch   Switch A simple   wave will  activate or  deactivate.See page 19.   EC787CABE   EC777NCARD   EC777NCABU   EC914WE   Heavy duty stainless steel panels available in 2-7 modules and custom plate sizes   EC777EL10CAWE 9 EXCEL LIFE WWW.EXCELLIFE.COM.AU

3 FORMAT  OPTIONS Dedicated Plate  Series (ED) When looks matter, the  Dedicated Plate Series  is your go-to product.   The slimmer profile  and contemporary  new switch designs  delight homeowners,  interior designers and  architects alike. Common Plate   Series (EC) Popular in commercial   and government  projects, this series  features a common  coverplate that can be  used across the entire  range. It’s perfect  for projects where  easy maintenance is  important. Secure Plate  Series (ES) There are times  when you need a  little extra protection  from theft and  damage. Projects  like schools,  detention centres,  and public areas -  anywhere requiring  precautions against  vandalism.  Vandal resistant Coverplate can only   be removed with a   screwdriver. ES770/3GPLWE + 3 x EM770WE   EC770/2WE   ED770/1WE 10 10

A common  coverplate for  the entire series DEDICATED PLATE SERIES Finished products come in either White (WE) or Urban Grey (UG) Additional coverplate finish options include COMMON PLATE SERIES SECURE PLATE SERIES Single and double powerpoints are available as finished products. 1-6 gang switch grid and plates are available for assembly with mechanisms. The Common Plate Series is compatible with Legrand Arteor dual modules, which enables access to 200+ advanced functions including skirting lights with sensors and the miniature emergency light with a safety torch. For more information visit legrand.com.au A secure coverplate can be fitted onto  any Common Plate Series product. EC920GPLWE + 078452   EC924WE EC920GPLWE + 572222   EC923TWE   EC510WE White (WE) Liquid Gloss Diesel (DI) BLACK (BL)(Special order only. Conditions apply) Urban Grey (UG) Liquid Gloss Ice (IC) Matt Silver (MS)   ED777UG   ED777USB2PSAWE   EDCWPLWE   EC919WE   EC770/2WE   EC777XWE   ESCWPLWE 11 EXCEL LIFE WWW.EXCELLIFE.COM.AU

SINGLE POWERPOINT  INNOVATIONS ACROSS THE SINGLE AND DOUBLE POWERPOINTS  FASTEST & SAFEST   POWERPOINTS   TO INSTALL Guided Cable Terminals Funnel shaped to guide up to 4x2.5mm 2  cables into each terminal with ease. Over-Sized Mounting Holes Flexibility in vertical adjustment, leveling  and alignment of multiple devices. Small Footprint Only 38mm wide   ED787WE Easy Install In Cabinetry Fits into 1 x  Ø40mm hole In-built Child Safety  Shutters Ensures  no accidental  contact with live  components Raised Insulation Barriers Extra protection against copper exposure  and accidental short circuit. 4.5mm  barrier 8mm extr a room 32mm 38mm 4.5mm funnel draws the cable into  the terminal 12 12

Carburised Steel Screws Super hard carburised steel and deeper  screw heads enable excellent grip. DOUBLE POWERPOINT  NEW  METICULOUSLY ENGINEERED POWERPOINTS We’ve taken a fresh look at single and double powerpoints to make them faster and safer to install than anything else on the market. You’ll love the funnel shaped terminals and super hard, deep screw heads. They’ll withstand the force of any drill action. These are just some of the exciting changes, see more below. Captive Screws Screws remain captured in the thread, you  will never lose them. Small Footprint Only 66mm wide   ED777WE Ergonomically Angled Screws Comfortable for a fast fit off. Prevents  product damage when using drills. C Easy Install In Cabinetry Fits into 2 x Ø40mm holes In-built Child Safety  Shutters Ensures  no accidental  contact with live  components 2.5mm  deep  screw  head 34mm 66mm 15° 13 EXCEL LIFE WWW.EXCELLIFE.COM.AU

  ED777EL10WE Add a surge protection module To assist in protecting valuable  devices (TV’s, computers,  amplifiers etc) from voltage spikes.   EM803SURGEWE Power supplied LED (RED) Power available LED (AMBER) POWER POINTS RCD POWERPOINT A safety switch is integrated into the powerpoint to protect users against electric shock. Available in 10mA and 30mA tripping current. SURGE PROTECTED  POWERPOINT    ED777XWE +  EM803SURGEWE 14 14

BUILT-IN SAFETY For added value and extra peace of mind, all Excel Life powerpoints include internal safety shutters to prevent accidental contact with live components. We believe in quality, and want you to be confident you are providing your customers with the safest products.  The plug needs to be rotated  during insertion giving additional  safety to a child’s room. Ideal for work stations and kitchen pantries. For a sleeker look. To avoid accidental disconnections. Extra Child-Safe Option Customisable Options With a wide selection of  indicator modules. Autoswitch Options Cable Retainer Multi Outlet PLENTY OF VERTICAL OPTIONS Quick-Fit  Leads terminated with   spade connectors for   faster installation. See the full  range on  on page 28   EMPAPS2WE   EC777XWE + EMPAPS2WE   EDV777WE   ECV777NCAWE   ED7774WE   ED777AWE    EC787XWE+ EM910RPWE   ED777ESWE 15 EXCEL LIFE WWW.EXCELLIFE.COM.AU

Choose the best in class The Exc el Life dual USB  charger is a Good Design  Awards Finalist 2014   and voted product of  the year 2015 by trade  professionals. SUPER FAST USB   CHARGING - 2 X 2.4A SUPER CHARGE TWO DEVICES SIMULTANEOUSLY  Phones, fitness bands even two tablets can be charged at top speed dramatically reducing the charging time.   ED777USB2PSAWE + ED777XPLMS 16 16

MAKE A MEGA USB CHARGING STATION Add to kitchen pantries, nooks and studies for a tidier  charging solution. Accessories now available to make fire wall box  and masonry applications a breeze. See page 52. FASTEST USB POWERPOINTS In this modern world, speed counts. Our USB powerpoints super charge at 2 x 2.4A, the fastest on the market! They have been designed to charge devices at their maximum speed including the latest Apple products . GRAB IT AS A COMPLETE UNIT From now on, this should be the standard powerpoint for kitchens, bedrooms, studies, waiting lounges, hotel rooms and conference centres. Models and accessories available for plasterboard, firewall box and masonry applications. ADD TO LIGHT SWITCHES OR DATA SOCKETS Try adding with a 2-way  switch for a convenient  bedside solution. Apple iPhone 6 / 6 Plus, iPad Mini 3, iPad Air 2, iPad 4   ED777USB2PSAWE ED770/3GPLWE +   3 x EMUSB2PSAWE   ED770/2GPLWE +   EMUSB2PSAWE + EM770WE 17 EXCEL LIFE WWW.EXCELLIFE.COM.AU

READY-MADE   SWITCHES To create rockers with the illuminated LED rings,   add the EM770LEDWE mechanism to any standard   16A or 20A EM770 rocker switch. ILLUMINATED LED  Illuminated LED rings add a contemporary tech feel.   Can be wired as always illuminated or only when the switch is  either in the ON or OFF position.   ED770/3WE + 3 x EM770LEDWE   EM770LEDWE   ED770/3WE + 3 x EM770LEDWE   ED770/3WE 18 18

Antimicrobial Switches  Use these in clinics, surgeries,  laboratories, commercial kitchens   - any hygiene sensitive area. Instant Heat Control Switches   Available in 3 and 4 gang options  to suit 2 lamp and 4 lamp Instant  Heat 3-in-1 Light, Heat and  Exhaust Fan units. Programmable Digital  Time Delay Switches  Ideal for easy control of  garden lighting, irrigation  and pool pumps. Up to 8  weekly programmes. EVERYDAY EXCELLENCE Plated, and ready for you to install in a flash, you’ve got options for tight spaces, cooktops, splash zones, shutters, blinds and curtains, as well a fantastic programmable digital time delay switch for pool pumps, garden lighting and more. Architrave Switches Available in 1-3 gang. Shutter Push-button Switches Blind or curtain controller available   in 6A via relay, and 6AX direct   control options. Standard Switches  (16AX fluoro rated) -  available in 1-6 gang   in both vertical and  horizontal formats. No Touch Switch   Great for hygiene sensitive  areas. Simply wave your  hand in front to activate or  deactivate a circuit. Weatherproof IP66 Switches Available in 1-4 gang options in  the vertical format and 1-2 gang  in the horizontal format. Double Pole Switches 40A switches for   dedicated circuits. See many  more switch  options on  page 26 & 32   EDA770/1WE   ED770/4IPWE   ED770/4FLHHCWE ED770/2HIPWE EC920WE   EC770/4CAWE   EC923TWE   EC914WE   ED770/40DPWE   EC919WE   ED770/2WE 19 EXCEL LIFE WWW.EXCELLIFE.COM.AU

SWITCH  MECHANISMS Program LEDs  red or blue. Easy programming   to set minimum   and maximum  brightness levels. SUPER SMOOTH DIMMING Enjoy the new 2 & 3 wire, flicker-resistant all load dimmers. They’re LED friendly and feature overload protection. They work brilliantly with slave switches for multi-way dimming in large rooms, stairwells and hallways. They look fantastic too.  Use with HPM Dalia, Azalea or Freesia LED downlights for the ultimate in smooth dimming.   ED770/4GPLWE + 4 x EM400A2PWE + ED770/4PLDI 20 20

THOUGHTFULLY DESIGNED Choose from a wide range of compact switch mechanisms, from the slick 5A electronic push-buttons, to 32A rockers. There is something to suit all installations, budgets, and customers. Electronic Push-button  Dimmers  Available in 2 and 3 wire  models in both White and  Urban Grey, 350VA all-load. Electronic Push-button  Switches  Available in White and  Urban Grey, 5A, 500VA. Dual Mechanism Switch  Switch two points from   one opening for easy   retro-fitting jobs. Rotary Dimmers  Available in 250VA trailing edge,  400VA trailing edge, and 700VA  trailing edge models in both  White and Urban Grey. Multi-Function Rotary Switch  All-in-one 16AX switch with 3  wiring positions: 180°, 270° and  360°. Provided with 6 marking  plate options. Use with fans,  shutters and sensors. Keylock Mechanisms   Available in removable OFF,  removable ON, and   removable ON/OFF models. Remote Dimmer  Available in 2000VA  leading edge. Digital Time Delay Switch  Ideal for stairwells. Easy  programming from 1 to 10  minutes in increments of   1 minute. Available in 2   and 3 wire options in both  White and Urban Grey. Laser Engraved  Switch Mechanisms Make switch  identification easier   for everyone. Choose  from more than 40  lasered options. See many  more switch  options on  page 33 & 35   EM820KLIOWE   EM770LIGHTWE   EM400A2PWE   EM400TRWE EM2000ERC   EM400A3PUG   EM883UG EM802TDUG   EM250TRUG   EM802TDWE   EM770DUOWE EMRSWE   EM883WE 21 EXCEL LIFE WWW.EXCELLIFE.COM.AU

SOLUTIONS FOR THE MODERN, CONNECTED ERA The world of entertainment and computing is becoming more and more demanding. Excel Life is designed to meet this demand with multiple voice, data, audio and video products to suit both homes and commercial applications such as offices, boardrooms, hotel function rooms, computing and audio shops. VOICE, DATA,   AUDIO &  VIDEO Colour code for  easier identification   ED770/4GPLUG + EMRJ45C6WE + EMRJ45C6BU + EMFFFOXUG + EMSPUG 22 22

KEYSTONE ADAPTERS Suits Clipsal, Leviton,  Siemens, Hubbel and  Krone keystone jacks Suits Panduit  keystone jacks Suits Systimax  keystone jacks Suits Tyco/AMP  jacks Suits Molex  keystone jacks See page 36. AUDIO SOCKETS Range includes all the most popular audio sockets, including brilliant NEW Hi-Fi audio sockets.  See page 37.   EM800BPBLWE   EM800BPRDWE   EMRCARDWE   EMRCAYELWE   EMRCAWEWE   EMKEYSTONEEWE   EMKEYSTONEDWE   EMKEYSTONECWE   EMKEYSTONEBWE   EMKEYSTONEAWE TV & VIDEO SOCKETS HDMI, VGA, 3.5 female audio, and loudspeaker sockets also available.  See page 37.   EMSPWE   EMPFWE   EC920VGAWE EC910J35WE EMFFFOXWE TELEPHONE AND DATA JACKS Choose from CAT 3, CAT 5E, CAT 6 jacks available in White, Yellow, Black, Blue, Green or Red. Excel Life jacks are compatible with Krone and 110 DC termination tools. Voice jacks include an additional slot for easier telephone looping.  See page 36.   EMRJ11C3WE   EMRJ11C3YE   EMRJ45C5EGR   EMRJ45C5ERD   EMRJ45C6BU   EMRJ45C6BL 23 EXCEL LIFE WWW.EXCELLIFE.COM.AU

SIGNAL  LIGHTS Bulkhead Lights Perfect for corridor navigation. Available with White, Green, Red or Blue LEDs.See page 38. VISUAL CUES FOR SAFER ENVIRONMENTS  Good signalling can increase the efficiency of a work environment, minimise costly disruptions, and most importantly, prevent accidents. These signal lights provide  a professional, low-cost solution ideal for operating theatres, studios, test labs and other special access rooms. Customise and update the graphic panel with ease. Simply print the symbol required on transparency paper and slot into window.  To make it even easier, a PDF of commonly used symbols is available.  Visit excellife.com.au or call our customer service team on 1300 369 777. See page 38.   EC524WE   EC524WE   EC524WE   EC524WE EC573WE EC570WE EC572WE EC571WE 24 24

ADVANCED SKIRTING LIGHT The light is activated by a PIR movement sensor perfect for facilities with high safety requirements such as aged care centres. Included is an optional audio function. See page 38. MINIATURE  EMERGENCY LIGHT The miniature emergency  lighting unit illuminates  automatically during a  power failure. It can also be  detached from the wall to  become a hand held torch. SKIRTING   LIGHT Create a safer environment in stairwells and low level lighting environments, or highlight potential hazards with neat Excel Life skirting lights. See page 38. SAFETY  LIGHTS   EC511WE   EC510WE EC920GPLWE + 572222 25 EXCEL LIFE WWW.EXCELLIFE.COM.AU

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 26 ED770/1WE ED770/2WE ED770/4WE ED770/2HWE Light switches - dedicated plate series ED770/2HIPWE EDA770/1WE Light switches - dedicated plate series  IP66 and architrave ED770/1IPWE ED770/2IPWE ED770/4FLHHWE Pack Cat No. Dedicated plate vertical  switches 230-240V a.c. Rocker mechanism SPDT  16A fluoro rated 16AX White Urban Grey 10 ED770/1WE ED770/1UG 1 gang switch 16AX 10 ED770/2WE ED770/2UG 2 gang switch 16AX 10 ED770/3WE ED770/3UG 3 gang switch 16AX 10 ED770/4WE ED770/4UG 4 gang switch 16AX 10 ED770/5WE ED770/5UG 5 gang switch 16AX 10 ED770/6WE ED770/6UG 6 gang switch 16AX Rocker mechanism 40A 10 ED770/40WE ED770/40UG 1 gang switch 40A 10 ED770/40DPWE ED770/40DPUG 1 gang double pole switch 40A 10 ED770/  40DPCTPWE ED770/  40DPCTPUG 1 gang double pole switch, engraved  ‘COOKTOP’ 40A For custom engraving please contact customer service. White Dedicated plate horizontal switches  230-240V a.c. Rocker mechanism SPDT 16A fluoro  rated 16AX 10 ED770/1HWE 1 gang switch 16AX 10 ED770/2HWE 2 gang switch 16AX 10 ED770/3HWE 3 gang switch 16AX 10 ED770/4HWE 4 gang switch 16AX 10 ED770/5HWE 5 gang switch 16AX 10 ED770/6HWE 6 gang switch 16AX Pack Cat No. Dedicated plate vertical  switches 230-240V a.c. Rocker mechanism SPDT  16A fluoro rated 16AX White Urban Grey 10 ED770/1IPWE ED770/1IPUG 1 gang switch 16AX IP66 10 ED770/2IPWE ED770/2IPUG 2 gang switch 16AX  IP66 10 ED770/3IPWE 3 gang switch 16AX  IP66 ED770/4IPWE 4 gang switch 16AX  IP66 White Dedicated plate horizontal switches  IP66 230-240V a.c. Rocker mechanism SPDT 16A fluoro  rated 16AX 5 ED770/1HIPWE 1 gang horizontal switch 16AX, IP66 5 ED770/2HIPWE 2 gang horizontal switch 16AX, IP66 White Dedicated plate vertical switches  230-240V a.c. Instant Heat Controller 10 ED770/3FLHWE 3 gang engraved light, fan, heat  switch 10A 5 ED770/3FLHCWE 3 gang engraved light, fan, heat  switch 10A, suits ducted device   BH2DWE/MS 10 ED770/4FLHHWE 4 gang engraved light, fan, heat  switch 10A 5 ED770/4FLHHCWE 4 gang engraved light, fan, heat,   switch 10A, suits ducted device  BH4DWE/MS White Architrave dedicated plate vertical  switches 230-240V a.c. Rocker mechanism SPDT 16A fluoro   rated 16AX 10 EDA770/1WE 1 gang architrave switch 16AX 10 EDA770/2WE 2 gang architrave switch 16AX 10 EDA770/3WE 3 gang architrave switch 16AX

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 27 Light switches - common plate series Light switches - common plate series IP66 Pack Cat No. Common plate vertical switches   230-240V a.c. Rocker mechanism SPDT   16A fluoro rated 16AX White 10 EC770/1WE 1 gang switch 16AX 10 EC770/2WE 2 gang switch 16AX 10 EC770/3WE 3 gang switch 16AX 10 EC770/4WE 4 gang switch 16AX 10 EC770/5WE 5 gang switch 16AX 10 EC770/6WE 6 gang switch 16AX Rocker mechanism 40A 10 EC770/40WE 1 gang switch 40A 10 EC770/40DPWE 1 gang double pole switch 40A 10 EC770/40DPCTPWE 1 gang double pole switch, engraved ‘COOKTOP’ 40A Pack Cat No. Common plate vertical switches IP66  230-240V a.c. Rocker mechanism SPDT   16A fluoro rated 16AX White 5 EC770/1IPWE 1 gang switch 16AX, IP66 5 EC770/2IPWE 2 gang switch 16AX, IP66 White Common plate horizontal switches IP66  230-240V a.c. Rocker mechanism SPDT  16A fluoro rated 16AX 5 EC770/1HIPWE 1 gang horizontal switch 16AX, IP66 5 EC770/2HIPWE 2 gang horizontal switch 16AX, IP66 EC770/1WE EC770/1HIPWE EC770/3WE EC770/2HIPWE

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 28 Powerpoints – dedicated plate series Pack Cat No. Dedicated plate  horizontal double  powerpoints   230-240V a.c. Internal safety shutters on all  powerpoints White Urban Grey 10 ED777WE ED777UG Double powerpoint  10A 1 ED777  USB2PSWE ED777  USB2PSUG Double powerpoint  with USB charger  2x2.1A 1 ED777  USB2PSAWE ED777  USB2PSAUG Double powerpoint  with USB charger 2x2.4A 10 ED777DPWE ED777DPUG Double powerpoint,  double pole   10A 10 ED777XWE ED777XUG Double powerpoint  with extra function hole  10A 10 ED777AWE ED777AUG Double autoswitch  powerpoint   10A 10 ED777RWE ED777RUG Double round-earth  powerpoint  10A 10 ED777ESWE ED777ESUG Double extra-safe  powerpoint  10A 10 ED777AESWE ED777AESUG Double extra-safe  autoswitch powerpoint  10A 10 ED777/15WE ED777/15UG Double powerpoint  15A 10 ED7774WE ED7774UG 4 gang powerpoint 10A Pack Cat No. Dedicated plate  horizontal USB charger  powerpoints   230-240 V a.c. Internal safety shutters on all  powerpoints White Urban Grey 1 ED777  USB2PSWE ED777  USB2PSUG Double powerpoint  with USB charger  2x2.1A 1 ED777  USB2PSAWE ED777  USB2PSAUG Double powerpoint  with USB charger  2x2.4A 1 ED777  USB2PSXWE ED777  USB2PSXUG Double powerpoint  with USB charger  2x2.4A and inline  connector (suit wall  boxes 429R or 435)  1 EAUSBEXT3WE - USB charger extension  lead 3m. To extend  distance between USB  socket and power  supply. Can be used  with EMUSB2PSXWE/UG  or ED777USB2PSXWE/UG White Urban Grey Dedicated plates  horizontal RCD protected  powerpoints 230-240V  a.c. Internal safety shutters on all  powerpoints 1 ED777EL10WE ED777EL10UG Double powerpoint  10A, 10mA RCD 1 ED777EL30WE ED777EL30UG Double powerpoint  10A, 30mA RCD White Urban Grey Dedicated plate vertical  double powerpoints   230-240V a.c. Internal safety shutters on all  powerpoints 10 EDV777WE EDV777UG Vertical double  powerpoint   10A,  10 EDV777XWE EDV777XUG Vertical double  powerpoint with extra  function hole 10A 10 EDV777AWE EDV777AUG Vertical double  autoswitch powerpoint  10A ED777WE ED7774WE ED777ESWE EDV777WE EDV777XWE ED777EL10WE NEW  AVAIL Q4-2015 NEW  AVAIL Q4-2015 ED777USB2PSAWE NOW  2X2.4A NEW  AVAIL Q4-2015

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 29 Pack Cat No. Dedicated plate horizontal  single powerpoints   230-240V a.c. Internal safety shutters on all  powerpoints White Urban Grey 10 ED787WE ED787UG Single powerpoint  10A 10 ED787XWE ED787XUG Single powerpoint with extra function hole 10A 10 ED787/2XWE ED787/2XUG Single powerpoint with  2 extra function holes 10A 10 ED787/ARWE ED787/ARUG Single round-earth  autoswitch powerpoint 10A 10 ED787RWE ED787RUG Single round-earth  powerpoint 10A 10 ED787AWE ED787AUG Single autoswitch  powerpoint   10A 10 ED787DPWE ED787DPUG Single double pole  powerpoint  10A 10 ED787/15WE ED787/15UG Single powerpoint  15A 10 ED787A/15WE ED787A/15UG Single autoswitch powerpoint 15A 10 ED787/20WE ED787/20UG Single powerpoint 20A 10 ED787/25WE ED787/25UG Single powerpoint 25A 10 ED787/32WE ED787/32UG Single powerpoint  32A Pack Cat No. Dedicated plate vertical  single powerpoints   230-240V a.c. Internal safety shutters in all  powerpoints White Urban Grey 10 EDV787WE EDV787UG Vertical single  powerpoint   10A 10 EDV787XWE EDV787XUG Vertical single  powerpoint with extra  function hole 10A 10 EDV787/2XWE EDV787/2XUG Vertical single  powerpoint with extra  function holes 10A 10 EDV787RWE EDV787RUG Vertical single round- earth powerpoint   10A 10 EDV787ARWE EDV787ARUG Vertical single  autoswitch round-earth  powerpoint 10A 10 EDV787/15WE EDV787/15UG Vertical single  powerpoint   15A 10 EDV787A/15WE EDV787A/15UG Vertical single  autoswitch powerpoint  15A ED787XWE ED787/15WE EDV787/2XWE EDV787XWE EDV787ARWE ED787/2XWE Powerpoints – dedicated plate series

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 30 Pack Cat No. Common plate horizontal double  powerpoints 230-240V a.c. Internal safety shutters in all powerpoints White 10 EC777WE Double powerpoint  10A 10 EC777XWE Double powerpoint with extra function  hole 10A 10 EC777AWE Double autoswitch powerpoint   10A 10 EC777DPWE Double powerpoint double pole   10A 10 EC777RWE Double round-earth powerpoint  10A 10 EC777/15WE Double powerpoint  15A 10 EC777/15DPWE Double powerpoint double pole   15A 10 EC777/15XWE Double powerpoint with extra function  hole 15A EC777WE EC777/15WE EC777/15XWE Powerpoints – common plate series Pack Cat No. Common plate vertical double  powerpoints 230-240V a.c. Internal safety shutters in all powerpoints WHITE 10 ECV777WE Vertical double powerpoint   10A 10 ECV777XWE Vertical double powerpoint with extra  function hole   10A 10 ECV777AWE Vertical double autoswitch powerpoint  10A ECV777WE ECV777AWE

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 31 Pack Cat No. Common plate horizontal single  powerpoints 230-240V a.c. Internal safety shutters in all powerpoints White 10 EC787WE Single powerpoint  10A 10 EC787XWE Single powerpoint with extra function  hole  10A 10 EC787/2XWE Single powerpoint with 2 extra  function holes  10A 10 EC787AWE Single autoswitch powerpoint  10A 10 EC787ARWE Single autoswitch round-earth  powerpoint   10A 10 EC787DPWE Single double pole powerpoint  10A 10 EC787RWE Single round-earth powerpoint 10A 10 EC787/15WE Single powerpoint  15A 10 EC787/15XWE Single powerpoint with extra function  hole 15A 10 EC787A/15WE Single autoswitch powerpoint  15A 10 EC787/15DPWE Single double pole powerpoint  15A 10 EC787/20WE Single powerpoint  20A 10 EC787/25WE Single powerpoint 25A White Secure plate horizontal powerpoints  230-240V a.c. Internal safety shutters in all powerpoints 10 ES777WE Double powerpoint  10A 10 ES787WE Single powerpoint  10A Pack Cat No. Common plate vertical single  powerpoints 230-240V a.c. Internal safety shutters in all powerpoints White 10 ECV787WE Vertical single powerpoint   10A 10 ECV787XWE Vertical single powerpoint with extra  function hole  10A 10 ECV787/2XWE Vertical single powerpoint with 2 extra  function holes   10A 10 ECV787RWE Vertical single round-earth powerpoint  10A 10 ECV787ARWE Vertical single autoswitch round-earth  powerpoint   10A 10 ECV787/15WE Vertical single powerpoint   15A 10 ECV787A/15WE Vertical single autoswitch powerpoint  15A EC787WE EC787/2XWE ES777WE Powerpoints – common plate series ECV787WE ECV787/2XWE

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 32 EM770IMLEDWE Pack Cat. No. Switch mechanisms  230-240V a.c. 16A rocker mechanisms White Urban Grey 10 EM770WE EM770UG Single pole double throw   16A fluoro rated 16AX 10 EM770XWE EM770XUG Single pole double throw   spring return 16A  10 EM770DPWE EM770DPUG Double pole single throw  16A fluoro rated 10AX 10 EM770  DPRDWE EM770  DPRDUG Double pole single throw with Red indicator 16A fluoro rated 10AX 10 EM770  DUOWE EM770  DUOUG 2 x single pole single  throw 16A fluoro rated  10AX  10 EM770IMWE EM770IMUG Intermediate switch 16A 10 EM770  IMLEDWE - Intermediate switch with  illuminated Blue LED ring  16A 10 EM770RDWE EM770RDUG Single pole double throw  with Red indicator 16A  fluoro rated 16AX 20A rocker mechanisms 10 EM770/20WE EM770/20UG Single pole single  throw 20A fluoro rated  20AX 10 EM770/  20RDWE EM770/  20RDUG Single pole double  throw with Red indicator  dot 20A fluoro rated 20AX 10 EM770/  20DPWE EM770/  20DPUG Double pole single throw  20A fluoro rated 10AX 25A rocker mechanisms 10 EM770/25WE EM770/25UG Single pole single throw  25A fluoro rated 20AX 32A rocker mechanisms 10 EM770/32WE EM770/32UG Single pole single throw  32A fluoro rated 20AX 10 EM770/  32RDWE EM770/  32RDUG Single pole single throw with Red indicator dot  32A fluoro rated 20AX EM770DUOWE EM770WE Mechanical mechanisms Modular solutions Excel Life modular design offers endlesspossibilities to create custom plates solutions Examples:Horizontal Single Powerpoint with Power Available LED indicator and Common coverplate Vertical Single Powerpoint with Surge Protection module and Dedicated coverplate Vertical 4 push button dimmers and Dedicated coverplate EM787WE POWERPOINT MECHANISM EMV787WE POWERPOINT VERTICAL MECHANISM EA910/1WE 1 GANG INSERT EA910/1WE 1 GANG INSERT 4 X EM400A2PWE  2 WIRE LED DIMMER EMPAWE POWER AVAILABLE LED INDICATOR EM803SURGEWE POWER  AVAILABLE LED INDICATOR ECFRAME SUPPORT  FRAME ECFRAME SUPPORT  FRAME ED770/4GPLWE  4 GANG SUPPORT  FRAME AND COVERPLATE ECCWPLWE COMMON COVERPLATE EDCWPLWEDEDICATED COVERPLATE

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 33 Pack Cat. No. Rotary switch  mechanisms   230-240V a.c. 16A rated mechanism White Urban Grey 10 EMRSWE EMRSUG Rotary switch mechanism  - (all-in-one solution),  comes with 6 marking  plate options and 180°,  270° and 360° rings.   16A White Urban Grey Keylock switch  mechanism 230-240V  a.c. 20A rated mechanism 10 EM820KLIWE EM820KLIUG Keylock switch  mechanism, key  removable in ‘ON’ only  position 20A fluoro rated 20AX 10 EM820KLOWE EM820KLOUG Keylock switch  mechanism, key  removable in ‘OFF’   only position 20A   fluoro rated 20AX 10 EM820KLIOWE EM820KLIOUG Keylock switch  mechanism, key  removable in ‘OFF’ or ‘ON’ position 20A   fluoro rated 20AX White BiLock™ switch mechanism   230-240V a.c. 20A rated mechanism Suitable for high security applications. Can be  installed on 1 gang plate or single powerpoint  with 2 extra function holes and blanking insert. 10 EM820BL1WE BiLock™ switch mechanism, key removable in ‘ON’ only position 20A fluoro rated 20AX 10 EM820BL0WE BiLock™ switch mechanism, key removable in ‘OFF’ only position 20A fluoro rated 20AX 10 EM820BL10WE BiLock™ switch mechanism, key removable in ‘OFF’ or ‘ON’ position 20A fluoro rated 20AX Key not supplied and must be sourced from approved BiLock™ locksmiths White Mechanical keytag switch  230-240V a.c. 20A rated mechanism 1 EM770/20KT Single pole single throw 20A   fluoro rated 20AX 10 EM20A/4KTWE Mechanical keycard assembly 4 single pole single throw 20A   fluoro rated 20AX Pack Cat. No. Powerpoint horizontal  mechanisms 230-240V  a.c. Internal safety shutters in  all powerpoints Used in conjunction with  ECFRAME, Inserts and  EDCWPLWE or ECCWPLWE  coverplates White Urban Grey 10 EM787AWE EM787AUG Single autoswitch  powerpoint mechanism  10A 10 EM787WE - Single powerpoint  mechanism  10A 10 EM787ARWE - Single round-earth  autoswitch powerpoint  mechanism   10A 10 EM787A/15WE - Single autoswitch  powerpoint mechanism  15A 10 EM787U/20WE - Single unswitched  powerpoint mechanism 20A 10 EM787U/25WE - Single unswitched  powerpoint mechanism 25A EMRSWE EM787WE EM787U/25WE EA910/1WE EM770/20KT EM820KLIOWE EM820BL1WE Mechanical mechanisms White Powerpoint vertical mechanisms230-240V a.c. Internal safety shutters in all  powerpoints Used in conjunction with ECFRAME, Inserts and  EDCWPLWE or ECCWPLWE coverplates 10 EMV787WE Vertical single powerpoint mechanism  10A 10 EMV787AWE Vertical single autoswitch  powerpoint mechanism   10A 10 EMV787A/15WE Vertical single autoswitch  powerpoint mechanism  15A White Urban Grey Common Frame Inserts One module inserts for custom  made applications. Insert  dimension 57mm x 25mm 10 EA910/0WE EA910/0UG Blank insert - 1 module 10 EA910/1WE EA910/1UG 1 gang insert - 1 module EA910/2WE EA910/2UG 2 gang insert - 1 module

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 34 EM770BYPASSWE EM770KITCHENWE EM770/20HWSWE EM770DAYNIGHTWE EM770/32OVENWE MARKED AS Amp  Rating Mechanism  Type Pack Cat No. White Urban Grey AIR CON 16AX SPDT 10 EM770AIRCONWE   EM770AIRCONUG   AIR CON 20A SPDT 10 EM770/20ACWE    EM770/20ACUG    AUTO/MAN 16AX SPDT 10 EM770AUTOMANWE  EM770AUTOMANUG  BED1 16AX SPDT 10 EM770BED1WE     EM770BED1UG     BED2 16AX SPDT 10 EM770BED2WE     EM770BED2UG     BED3 16AX SPDT 10 EM770BED3WE     EM770BED3UG     BED4 16AX SPDT 10 EM770BED4WE     EM770BED4UG     BYPASS 16AX SPDT 10 EM770BYPASSWE   EM770BYPASSUG   D/WASH 16AX SPDT 10 EM770DWASHWE    EM770DWASHUG    DAY/NIGHT 16AX SPDT 10 EM770DAYNIGHTWE EM770DAYNIGHTUG DINING 16AX SPDT 10 EM770DININGWE   EM770DININGUG   DOOR 16A SPST-NC 10 EM770XDOORWE    EM770XDOORUG    EXHAUST 16AX SPDT 10 EM770EXHWE      EM770EXHUG      FAN 16AX SPDT 10 EM770FANWE      EM770FANUG      FRIDGE 16AX SPDT 10 EM770FRIDGEWE   EM770FRIDGEUG   GAMES 16AX SPDT 10 EM770GAMESWE    EM770GAMESUG    HEAT 16A 2XSPST 10 EM770DUOHTWE    EM770DUOHTUG    HEAT 16AX SPDT 10 EM770HEATWE     EM770HEATUG     HOB 16AX SPDT 10 EM770HOBWE      EM770HOBUG      HOB 32A SPST 10 EM770/32HOBWE   EM770/32HOBUG   HOOD 16AX SPDT 10 EM770HOODWE     EM770HOODUG     HOT PLATE 32A SPST 10 EM770/32HOTPWE  EM770/32HOTPUG  HWS 20A SPDT 10 EM770/20HWSWE   EM770/20HWSUG   KITCHEN 16AX SPDT 10 EM770KITCHENWE  EM770KITCHENUG  LIGHT 16AX SPDT 10 EM770LIGHTWE    EM770LIGHTUG    LIVING 16AX SPDT 10 EM770LIVINGWE   EM770LIVINGUG   LOUNGE 16AX SPDT 10 EM770LOUNGEWE   EM770LOUNGEUG   MICRO 16AX SPDT 10 EM770MICROWAVWE EM770MICROWAVUG OFFICE 16AX SPDT 10 EM770OFFICEWE   EM770OFFICEUG   OVEN 32A SPST 10 EM770/32OVENWE  EM770/32OVENUG  PRESS 16A SPST-NC 10 EM770XPRESSWE   EM770XPRESSUG   RANGE 32A SPST 10 EM770/32RANGEWE EM770/32RANGEUG RESET 16A SPST-NC 10 EM770XRESETWE   EM770XRESETUG   RUMPUS 16AX SPDT 10 EM770RUMPUSWE   EM770RUMPUSUG   SENSOR 16AX SPDT 10 EM770SENSORWE   EM770SENSORUG   WASTE 16AX SPDT 10 EM770WASTEWE    EM770WASTEUG    ZONE 1 16AX SPDT 10 EM770ZONE1WE    EM770ZONE1UG    ZONE 2 16AX SPDT 10 EM770ZONE2WE    EM770ZONE2UG    ZONE 3 16AX SPDT 10 EM770ZONE3WE    EM770ZONE3UG    ZONE 4 16AX SPDT 10 EM770ZONE4WE    EM770ZONE4UG      Legend SPDT  = single pole, double throw  DPST  = double pole, single throw DPXT  = double pole cross-over  NC  = normally closed AX  = fluorescent rated switch Mechanical mechanisms engraved For custom engraving please contact customer service using   EM770PRINTWE or EM770PRINTUG Mechanical mechanisms engraved

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 35 Electronic mechanisms EM800SLAVEWE EM883WE Pack Cat No. Electronic push-button  switch mechanisms   230-240V a.c. Pilot LED can be programmed to be Blue or Red   See p45 for wiring diagrams White Urban Grey 10 EM883WE EM883UG Electronic push button  5A fluoro rated 500VA 10 EM800SLAVEWE EM800SLAVEUG Secondary control push  button White Urban Grey Push-button dimmer  mechanisms   230-240V a.c. Pilot LED can be programmed to be Blue or Red See p46 for wiring diagrams 10 EM400A2PWE EM400A2PUG Electronic push button 350VA all-load 10 EM400A3PWE EM400A3PUG Electronic push button  400VA all-load (neutral  required) White Urban Grey Rotary dimmer  mechanisms  230-240V a.c. New easy grip lower profile  knob. Automatically dims  if dimmer is overloaded or  insufficiently derated 10 EM250TRWE EM250TRUG 250VA Trailing edge 10 EM400TRWE EM400TRUG 400VA Trailing edge 10 EM700TRWE EM700TRUG 700VA Trailing edge 10 EM2000ERC 2000VA leading-edge  remote dimmer 5 EADIMKNOBWE EADIMKNOBUG    Spare dimmer knobs  (pkt of 5) White Urban Grey Fan controller mechanism  230-240V a.c. 10 EM3FCWE EM3FCUG 3 speed, 100VA  mechanism 5 EAFANKNOBWE EAFANKNOBUG    Spare fan controller  knobs (pkt of 5) EM803SURGEWE EM803LEDWE EM770LEDWE EMPAPS1WE Pack Cat No. Programmable time delay  mechanisms  230-240V a.c. White Urban Grey 10 EM802TDWE EM802TDUG Programmable time delay  switch, 2 wire all load 400VA.  Can be programmed from  1-10 minutes in steps of 1  minute.  10 EM803TDWE EM803TDUG Programmable time delay  switch, 3 wire all load 500VA.  Can be programmed from  1-60 minutes in steps of 5  minutes.  White Urban Grey Surge protection mechanism  230-240V a.c. 10 EM803 SURGEWE EM803 SURGEUG Surge protection   mechanism 500J White Urban Grey Illumination mechanisms  230-240V a.c. See p49 for wiring diagram 10 EM770  LEDWE EM770  LEDUG EM770 illumination  blue LED kit 10 EM803  LEDWE EM803  LEDUG White LED and  coloured lenses kit  10 EMPAPS1WE EMPAPS1UG Power available and 1 gang  power supplied  indicator kit  10 EMPAPS2WE EMPAPS2UG Power available and 2 gang  power supplied  indicator kit  10 EMPAWE EMPAUG Power available  indicator kit (Amber) 10 EMPS1WE EMPS1UG Power supplied to 1 outlet  indicator kit (Red) 10 EMPS2WE EMPS2UG Power supplied to 2 outlets  indicator kit

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 36 RJ45 data sockets CAT 5E Compatible with both Krone and IDC termination tools 10 EMRJ45C5EWE CAT 5E RJ45 data socket White 10 EMRJ45C5EBL CAT 5E RJ45 data socket Black 10 EMRJ45C5EBU CAT 5E RJ45 data socket Blue 10 EMRJ45C5EGR CAT 5E RJ45 data socket Green 10 EMRJ45C5ERD CAT 5E RJ45 data socket Red 10 EMRJ45C5EYE CAT 5E RJ45 data socket Yellow Pack Cat No. RJ45 data sockets CAT 6 Compatible with both Krone and IDC  termination tools 10 EMRJ45C6WE CAT 6, RJ45 data socket White 10 EMRJ45C6BL CAT 6, RJ45 data socket Black 10 EMRJ45C6BU CAT 6, RJ45 data socket Blue 10 EMRJ45C6GR CAT 6, RJ45 data socket Green 10 EMRJ45C6RD CAT 6, RJ45 data socket Red 10 EMRJ45C6YE CAT 6, RJ45 data socket Yellow Pack Cat No. RJ11 voice sockets Additional slot available for looping.  Compatible with both Krone and IDC  termination tools 10 EMRJ11C3WE CAT 3 RJ11 voice socket White 10 EMRJ11C3BL CAT 3 RJ11 voice socket Black 10 EMRJ11C3BU CAT 3 RJ11 voice socket Blue 10 EMRJ11C3GR CAT 3 RJ11 voice socket Green 10 EMRJ11C3RD CAT 3 RJ11 voice socket Red 10 EMRJ11C3YE CAT 3 RJ11 voice socket Yellow EMRJ11C3WE EMRJ11C3BL EMRJ45C6RD White Urban Grey Keystone adapters 10 EMKEYSTONEAWE EMKEYSTONEAUG Suits Clipsal,  Leviton, Hubbel,  Siemens & Krone  keystone jacks 10 EMKEYSTONEBWE EMKEYSTONEBUG Suits Panduit  keystone jacks 10 EMKEYSTONECWE EMKEYSTONECUG Suits Systimax  keystone jacks 10 EMKEYSTONEDWE EMKEYSTONEDUG Suits Tyco/AMP  keystone jacks 10 EMKEYSTONEEWE EMKEYSTONEEUG Suits Molex  keystone jacks EMRJ45C5EBU EMRJ45C5EGR EMRJ45C6YE EMKEYSTONEAWE EMKEYSTONEBWE RJ11 Cat 3 voice sockets, RJ45 Cat 5e  sockets RJ45 Cat 6 data sockets, keystone  adapters

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 37 EMFFFOXWE EMSPWE Pack Cat No. Audio and video  mechanisms Video sockets White Urban Grey 10 EMFFFOXWE EMFFFOXUG F to F TV outlet   75 ohm 3.0GHz   (Foxtel approved)  F30583 10 EMPFWE EMPFUG PAL to F TV outlet - White 10 EMSPWE EMSPUG PAL to saddle  TV outlet - White RCA sockets 10 EMRCARDWE EMRCARDUG RCA to RCA   outlet - Red 10 EMRCAWEWE EMRCAWEUG RCA to RCA   outlet - White 10 EMRCAYELWE EMRCAYELUG RCA to RCA   outlet - Yellow HDMI and USB extensions Suitable for all custom AV  applications. Used in conjunction  with Common Frame (ECFRAME),  or EC910GPLWE. Also can be  used with Panel Mount adaptors.  Insert dimension 25mm x 57mm 12 EM910USBWE - USB insert with   extension lead  150mm 12 EM910HDMIWE - HDMI insert with   extension lead  150mm 10 EM800BPBLWE EM800BPBLUG Audio “Banana”  outlet 4mm ø   – Black Marking 10 EM800BPRDWE EM800BPRDUG Audio “Banana”  outlet 4mm ø  – Red Marking EMRCARDWE EMUSB2PSAWE Pack Cat No. USB charger mechanisms   230-240V a.c. White Urban Grey 12 EMUSB2PSWE EMUSB2PSUG Dual USB Charger  Mechanism 2x2.1A 12 EMUSB2PSAWE EMUSB2PSAUG Dual USB Charger  Mechanism 2x2.4A 12 EMUSB2PSXWE EMUSB2PSXUG Dual USB Charger  Mechanism 2x2.4A  with inline connector  (suit wall boxes  429R or 435)  1 EAUSBEXT3WE - USB charger  extension lead 3m.  Can be used with  EMUSB2PSXWE/UG or  ED777USB2PSXWE/UG  To extend distance  between USB socket  and power supply Audio and video sockets and devices USB chargers NEW  AVAIL Q4-2015 NEW  AVAIL Q4-2015 NEW  AVAIL Q4-2015 NEW  2X2.4A White Audio and Video devices 10 ECUSBWE USB type A  female outlet 6 EC910J35WE 3.5mm female  audio outlet 4 EC920HDMIWE HDMI outlet rear pluggable 8 EC920LJWE Loudspeaker outlet IP41, 6mm terminal capacity 10 EC920MSVIDWE S-Video outlet mini din 10 EC920VGAWE VGA outlet female connection

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 38 Pack Cat No. Shaver outlet  230-240V a.c. White 2 EC798WE Common plate series shaver outlet 22VA   White Shutter, blind, curtain control  230-240V a.c. 8 EC919WE Common plate series push button  switch (via relay) 6A fast connection  terminals 8 EC920WE Common plate series push button  switch (direct control) 6AX (fluoro rated)  fast connection terminals   White Skirting lights 230-240V a.c. 6 EC510WE Common plate series permanent   skirting light Adjustable intensity 0.2 or 1W 4 EC511WE Common plate series skirting light  with PIR sensor 1.3W max   White Signalling 230-240V a.c. 6 EC520WE Common plate series signal light White LED 1.0W max 6 EC521WE Common plate series signal light Blue LED 1.0W max 6 EC524WE Common plate series signal light Red/Green LED 1.0W max 4 EC570WE Common plate series signal light red LED 4 EC571WE Common plate series signal light White LED 4 EC572WE Common plate series signal light Green LED 4 EC573WE Bulkhead light Blue LED EC919WE EC798WE EC924WE ECKFSWE Electronic devices EC524WE ED571WE EC510WE EC914WE Pack Cat No. Fan controller 230-240V a.c. White Urban Grey 10 ED3FCWE ED3FCUG Dedicated plate series  3 speed, 100VA plate EC918WE White Hospitality 230-240V a.c. 4 EC915WE Common plate series emergency  stop push button 1/4 turn 3AX 10 EC917WE Common plate series buzzer  240V a.c.  Sound level 80dB at 1m 6 EC918WE Common plate series electronic bell 12-48V, sound level 80dB at 1m 10 EAKEYFOB Key fob supplied with label holder for  individual hotel identification 10 ECKFSWE Common plate series electronic key  fob switch with 30 second time delay 10 EDKFSWE Dedicated plate series electronic key  fob switch with 30 second time delay 10 EC20A/4KTWE Common plate series mechanical  keycard 85mm x54mm switch white   4 x 20A  10 ED20A/4KTWE  ED20A/4KTUG Dedicated plate series mechanical  keycard 85mm x54mm switch white   4 x 20A  6 EC924WE Common plate series hotel corridor call  indicator 6A 8 EC925WE Common plate series hotel guest room  call control 10A  To be used in conjunction with single catching relay ie. Cat No. 412558 White Programmable time delay   230-240V a.c. 6 EC923TWE Common plate series programmable  time delay switch 16A. Up to 8 weekly  programmes, 20hrs working reserve White No touch switch 230-240V a.c. 6 EC914WE Common plate series  No Touch switch, 4A

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 39 Pack Cat No. Dedicated plate series  grids and coverplates White Urban Grey 10 ED770/0GPLWE ED770/0GPLUG Blank grid and  coverplate only 10 ED770/1GPLWE ED770/1GPLUG 1 gang grid and  coverplate only 10 ED770/2GPLWE ED770/2GPLUG 2 gang grid and  coverplate only 10 ED770/3GPLWE ED770/3GPLUG 3 gang grid and  coverplate only 10 ED770/4GPLWE ED770/4GPLUG 4 gang grid and  coverplate only 10 ED770/5GPLWE ED770/5GPLUG 5 gang grid and  coverplate only 10 ED770/6GPLWE ED770/6GPLUG 6 gang grid and  coverplate only White Urban Grey Architrave dedicated  plate series grid and  coverplate 10 EDA770/1GPLWE EDA770/1GPLUG 1 gang grid  and coverplate only 10 EDA770/2GPLWE EDA770/2GPLUG 2 gang grid  and coverplate only 10 EDA770/3GPLWE EDA770/3GPLUG 3 gang grid  and coverplate only 10 EDA770/4GPLWE EDA770/4GPLUG 4 gang grid  and coverplate only White Module grid and coverplates 10 EC910GPLWE Common plate1 module grid and  coverplate only, suits 1 module insert 25x57mm 10 EC920GPLWE Common plate 2 module grid and  coverplate only, suits 2 module insert 45x45mm 10 ED920GPLWE Dedicated plate 2 module grid and  coverplate only, suits 2 module insert 45x45mm Pack Cat No. Common plate series grids and  coverplates White 10 EC770/0GPLWE Blank grid and cover only 10 EC770/1GPLWE 1 gang grid and coverplate only 10 EC770/2GPLWE 2 gang grid and coverplate only 10 EC770/3GPLWE 3 gang grid and coverplate only 10 EC770/4GPLWE 4 gang grid and coverplate only 10 EC770/5GPLWE 5 gang grid and coverplate only 10 EC770/6GPLWE 6 gang grid and coverplate only 10 ECCWGPLWE Deep mounting block and coverplate  common plate series only White Secure grid and coverplates 10 ES770/0GPLWE Blank grid and coverplate only 10 ES770/1GPLWE 1 gang grid and coverplate only 10 ES770/2GPLWE 2 gang grid and coverplate only 10 ES770/3GPLWE 3 gang grid and coverplate only 10 ES770/4GPLWE 4 gang grid and coverplate only 10 ES770/5GPLWE 5 gang grid and coverplate only 10 ES770/6GPLWE 6 gang grid and coverplate only ED770/4GPLWE ED770/6GPLWE EC770/0GPLWE Grids and coverplates EC770/2GPLWE

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 40 Finish White ED787PLWE ED777PLWE ED777XPLWE ED777APLWE EDV787PLWE EDV777PLWE EDV777XPLWE EDV777APLWE Urban Grey ED787PLUG ED777PLUG ED777XPLUG EDV787PLUG EDV777PLUG EDV777XPLUG EDV777APLUG Matt Silver ED787PLMS ED777PLMS ED777XPLMS EDV787PLMS EDV777PLMS EDV777XPLMS Ice ED787PLIC ED777PLIC ED777XPLIC EDV787PLIC EDV777PLIC EDV777XPLIC Diesel ED787PLDI ED777PLDI ED777XPLDI EDV787PLDI EDV777PLDI EDV777XPLDI Finish White ED770/1PLWE ED770/2PLWE ED770/3PLWE ED770/4PLWE ED770/5PLWE ED770/6PLWE ED920PLWE EDCWPLWE Urban Grey ED770/1PLUG ED770/2PLUG ED770/3PLUG ED770/4PLUG ED770/5PLUG ED770/6PLUG ED920PLUG EDCWPLUG Matt Silver ED770/1PLMS ED770/2PLMS ED770/3PLMS ED770/4PLMS ED770/5PLMS ED770/6PLMS ED920PLMS EDCWPLMS Ice ED770/1PLIC ED770/2PLIC ED770/3PLIC ED770/4PLIC ED770/5PLIC ED770/6PLIC ED920PLIC EDCWPLIC Diesel ED770/1PLDI ED770/2PLDI ED770/3PLDI ED770/4PLDI ED770/5PLDI ED770/6PLDI - EDCWPLDI Liquid Gloss Liquid Gloss Dedicated Switches – Coverplate Only Dedicated Powerpoints – Coverplate Only ED770/4PLWE ED920PLWE EDCWPLWE ED787PLMS ED770/1PLDI ED777PLWE ED770/1PLIC ECCW4HPLWE Finish White ESCWPLWE Finish White ECCW  PLWE ECCW  2WPLWE ECCW  3WPLWE ECCW  2HPLWE ECCW  3HPLWE ECCW  4HPLWE Common Plate Series – Coverplate Only Secure Plate Series - Coverplate Only Coverplates

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 41 Pack Cat No. Cable management White Urban Grey 10 EMCCWE EMCCUG Cord clamp 10 EM910RPWE - Plug & cable  retainer module  25x57mm White Urban Grey Circuit identification 10 EMCLIDWE EMCLIDUG Blank insert with  clear cap used for  circuit identification 10 EMIDWE EMIDUG Blank insert White Accessories 10 ECFRAME Support frame. Accepts: 3 x 25x57mm inserts or 1 x 50x57mm and 1 x 25x57mm inserts 50 EAPP Transparent paint and damage protection shell 1 EA751 Insulation shroud 1 EAPWDSCREW Public works department 1-4 gang  mechanism retention kit 10 EAPWD5GKIT Public works department  5 gang mechanism retention kit 10 EAPWD6GKIT Public works department  6 gang mechanism retention kit Circuit identification labels To be used with EMCLIDWE/UG 10 10 10 10 EACIDLABELWE EACIDLABELBU EACIDLABELRED EACIDLABELYE    WHITE   BLUE    RED    YELLOW 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) 10 sheets (96 labels per sheet) EMCCWE ECFRAME EM910RPWE 140WE Pack Cat No. Panel mount adaptors  and inserts Panel mount adaptors suitable  for panel thickness of 0.7mm  to 3mm 1 Module accepts 1 x 25x57mm  inserts 2 Module accepts 50x57mm or 2 x 25x57mm inserts White Urban Grey EA910PMAWE - Panel mount adaptors -  1 module 25x57mm EA920PMAWE - Panel mount adaptors -  2 module 50x57mm White Urban Grey Support Frame Inserts One module inserts for custom  made applications. Insert  dimension 57mm x 25mm 10 EA910/0WE EA910/0UG Blank insert    1 module 10 EA910/1WE EA910/1UG 1 gang insert    1 module 10 EA910/2WE EA910/2UG 2 gang insert    1 module White Urban Grey Mounting block 10 140WE EA140UG Surface mounting  block 37mm deep,  suits powerpoints,  switches and electronic mechanisms 10 ECCWGPLWE Deep mounting  block and coverplate  common plate series  only Cable management, circuit identification  and accessories Panel mount adaptors, inserts and  mounting blocks EA751

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 42 Pack Cat No. Mounting brackets 84mm spacing centres Stud Bracket 10 143 Horizontal stud bracket 10 143/2 Horizontal stud bracket with nails 10 143/2V Vertical stud bracket with nails 10 143U Universal horizontal or vertical  stud bracket with nails 10 EA143/2W 2 gang horizontal stud bracket 10 EA143/3W 3 gang horizontal stud bracket 10 EA143/2H 2 gang vertical stud bracket 10 EA143/3H 3 gang vertical stud bracket 10 EA143/4H 4 gang vertical stud bracket Render Bracket 20 954 1 gang render bracket 10 EA503/2W 2 gang horizontal render bracket 10 EA503/3W 3 gang horizontal render bracket 10 EA503/2H 2 gang vertical render bracket 10 EA503/3H 3 gang vertical render bracket 10 EA503/4H 4 gang vertical render bracket Pack Cat No. Mounting brackets 84mm spacing centres Plaster Bracket 50 711 Plaster 6.5mm board bracket 50 712 Plaster 10mm board bracket Wall Boxes Plastic wall box 10 429R Recessed wall box with sliding nuts, retention clips and protective cover Fire and acoustic wall box 1 435 Cable entry top and rear. Fastening arms allow for 10mm to 32mm thick plaster/cement boards. 3h fire resistance  (installed on one side of the wall) Weighted sound reduction index (Rw) 62 712 429R Installation brackets Installation brackets and wall boxes EA503/2W EA143/3H

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 43 1 & 2 Way (SPDT) EM770 Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770 SPDT 1L 16A/16AX Black EM770/20 SPDT 1L 20A/20AX Black Double Pole (DPST) EM770DP Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770DP DPST 0L 16A/10AX Blue EM770/20DP DPST 0L 20A/10AX Blue Duo Series 2 x 1 Way (2 x SPST) 240V a.c.  Cat. No. Legend Loop Amp Rating Body Colour EM770DUO 2xSPST 0L 16A/10AX White 1 Way (SPST) EM770 Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770/32 SPST 1L 32A/20AX Grey Intermediate (DPXT - Crossover) EM770I Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770IM DPXT 0L 16A Red 2 1 3 4 2 1 1 2 2 1 1 2 2 1 1 2 2 2 1 3 4 2 1 1 2 2 1 1 2 2 1 1 2 2 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25 EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25 EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 3 4 2 1 1 2 2 1 1 2 2 1 1 2 2 2 1 3 4 2 1 1 2 2 1 1 2 2 1 1 2 2 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25 EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25 EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20 Mechanical switch mechanism wiring diagrams 2 1 3 4 2 1 C 2 1 1 1 2 2 1 1 2 2 1 1 2 2 Rear view EM770/20KT Rear view Rear view Rear view Rear view Rear view 1 4 2 3 Rear view 2 1 C L LOOP 2 1 1 2 1 2 C L LOOP EM770 EM770/20 EM770DP EM770/20DP MULTIWAY SWITCHING 2 SWITCHES 2 1 L LOOP EM770/25 EM770/32 2 1 C L EM770IM EM770IM EM770IM 2 1 C L 4 2 1 3 4 2 1 3 4 2 1 3 MULTIWAY SWITCHING MORE THAN 2 SWITCHES (Any quantity of intermediate switches may be used). UP POSITION EM770IM 4 2 1 3 DOWN POSITION EM770IM 1 2 1 2 EM770DUO EM770 EM770/20 EM770 EM770/20

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 44 Push Buttons (Bell Push) Single Pole - Normally Open EM770X Series 240V a.c. Cat. No. Legend Loop Amp Rating Body Colour EM770X SPST-NO 0 16A White KeyTag - 1 Way (SPST) EM770/20KT Cat. No. Legend Loop Amp Rating Motor Rating Body Colour EM770/20KT SPST 1L 20AX M120 Grey Keylock Switch Assembly - 1 & 2 Way (SPDT) 770 Series 240V a.c. Cat. No. Legend Loop Amp Rating Motor Rating Body Colour EM820KLO SPDT 1L 20A M80 Black EM820KLI SPDT 1L 20A M80 Black EM820KLIO SPDT 1L 20A M80 Black Colour code (Position in which key can be removed).WHITE  – OFF (O) GREY  – ON (I) BEIGE  – ON (I) and OFF (O) LegendSPST  = single pole, single throw SPDT  = single pole, double throw DPDT  = double pole, double throw DPST  = double pole, single throw DPXT  = double pole cross-over NC  = normally closed NO  = normally opened L  = Loop Using X RatingExcel Life series switches marked with an ‘X’ are suitable for fluorescent  installations up to the switch rating. 2 1 2 1 3 4 C Mechanical switch mechanism wiring diagrams  2 1 L LOOP 1 3 On Position LOOP L C 1 2 Rear view EM770X Rear view EM820KL Rear view EM770/20KT

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 45 LOAD ACTIVE NEUTRAL REMOTE (optional) EM883 EM800SLAVE LOAD  ACTIVE NEUTRAL REMOTE ACTIVE REMOTE LOOP LOAD ACTIVE NEUTRAL EM800SLAVE MINIMUM LOAD = 10VA FOR ALL LOAD TYPES Technical characteristics Electronic push button switch mechanism wiring diagrams Incandescent Halogen Fluorescent  tube Wirewound  transformer Electronic  transformer Compace  fluorescent LED Fan motor Max load 1200W 1200W 500VA 500VA 500VA 500VA 500VA 500VA + 50oC 230-240V a.c. 50Hz 1 x 2.5mm22 x 1.5mm2 + 0oC Important:An unlimited number of EM800SLAVE can be connected to an EM883. However, the total length of the remote wire used to interconnect all of the EM800SLAVE should not exceed 50 metres. Important:Power factor correction capacitors must be either removed or placed on the line side of the electronic push button switch. ■   Connect optional Secondary Control Buttons (EM800SLAVE) to enable switching from multiple locations. LED Indicator■  The colour of the LED indicator can be either red or blue. In addition,  when the switch is off the LED indicator can either glow faintly or be off completely. The four possible modes are as follows: ■  To change between modes, press and hold the push button for at least  10 seconds. This will select the next mode in the sequence above. MODE STATUS OF LED INDICATOR SWITCH ON SWITCH OFF 1 Bright Red Faint Red 2 Bright Blue Faint Blue 3 Bright Red Off 4 Bright Blue Off Rear view EM883

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 46 Electronic push button dimmer EM400A2P Technical characteristics Note:1. In the case of dimmable compact florescent or dimmable LED without transformer, this is the maximum number of lamps.2. Where both max power and max number of transformers/lamps are specified, both conditions must be satisfied.3. When used in ambient temperatures greater than 25ºC, the dimmer must be de-rated by 10% for every increase of 5ºC. Electronic push button dimmers and time delay switches ■    Incandescent ■    Halogen ■     Halogen or dimmable LED with electronic transformer ■     Dimmable compact fluorescent ■      Dimmable LED without transformer ■    Halogen with  wirebound  transformer Fluorescent tube Fan motor Max Power Max number of  transformers 1 Max load 1 dimmer per plate 350W 350VA 8 X X X 2 dimmers per plate 300W 300VA 8 X X X 3 or more dimmers  per plate 250W 250VA 8 X X X + 50 o C 230-240V a.c. 50Hz 1 x 2.5mm 2 2 x 1.5mm 2 + 0 o C Electronic push button dimmer EM400A3PTechnical characteristics Minimum load = 3VA for all load types ■    Incandescent ■    Halogen ■      Halogen or dimmable LED with electronic transformer ■     Dimmable compact fluorescent ■     Dimmable LED  without transformer ■       Halogen or dimmable LED with wirewound transformer 2 Fluorescent  tube Fan motor Max Power Max number of  transformers 1 Max Power Max number of  transformers Max load 1 dimmer per plate 400W 400VA 8 300VA 6 X X 2 dimmers per plate 350W 350VA 8 250VA 6 X X 3 or more dimmers  per plate 300W 300VA 8 200VA 6 X X + 50 o C 230-240V a.c. 50Hz 1 x 2.5mm 2 2 x 1.5mm 2 + 0 o C Electronic push button time delay EM802TD/EM803TDTechnical characteristics Incandescent Halogen Fluorescent  tube Wirewound  transformer Electronic  transformer Compace  fluorescent LED Fan motor Max load (802TD) 400W 400W 400VA X 400VA 400VA 400VA X Max load (803TD) 1200W 1200W 500VA 500VA 500VA 500VA 500VA 500VA MINIMUM LOAD = 10VA FOR ALL LOAD TYPES  ELECTRONIC BALLAST ONLY + 50 o C 230-240V a.c. 50Hz 1 x 2.5mm 2 2 x 1.5mm 2 + 0 o C Wiring EM802TD ACTIVE LOAD ACTIVE  LOOP  LOAD EM802TD MOMENTARY PUSH SWITCH NEUTRAL ■   Connect optional Momentary Push  Switches (EM770X) to enable switching from multiple locations. Important:An unlimited number of EM770XWE can be connected to an EM802TD. However, the total length of the load wire used to interconnect all of the EM770XWE should not exceed 50 metres. Note:For other technical details please refer to the installation instructions of each device. Load compatibility disclaimer:Although significant efforts have been made to ensure Dimmers are compatible with a large variety of drivers (CFL, LEDs), it is not possible to guarantee 100% compatibility with all devices. One-way wiring diagram

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 47 NOTE: Compact Fluorescent Lamps (CFLs) and LCDs, also known as Energy Saving Lamps, can only be dimmed if they are specifically marked as "dimmable". Dimmable CFLs may have different characteristics from brand to brand, and so each brand may require a specific type of dimmer to operate correctly. Using the incorrect dimmer may cause the CFL to flicker. Please read the documentation that comes with each CFL carefully to ensure that the CFL and dimmer are compatible. For more information, please contact HPM Legrand. In some cases, the dimmable CFL may turn off or flicker when dimmed to a very low brightness. This can be overcome by ensuring that the dimmer brightness is not set too low. See "Setting minimum brightness" for instructions on how to achieve this. EM770 EM770 EM770 Wiring for rotary dimmers One-way wiring diagram Two-way wiring diagram Important:When used in ambient temperatures greater than 25°C, the dimmer must be de-rated according to the following chart. 25 30 35 40 45 50 50 60 70 80 90 100 % Rating Installation air temperature (ºC) Rotary dimmers - EM250TR/EM400TR/EM700TR  Technical characteristics Rotary dimmers Incandescent Halogen Fluorescent  tube Wirewound  transformer Electronic  transformer Compace  fluorescent LED Fan motor Max load EM250TR 1 dimmer per plate 250W 250W X X 250VA 250VA see note X X 2 dimmers per plate 225W 225W X X 225VA 225VA see note X X 3 or more dim- mers per plate 200W 200W X X 200VA 200VA see note X X Max load EM400TR 1 dimmer per plate 400W 400W X X 400VA 400VA see note X X 2 dimmers per plate 350W 350W X X 350VA 350VA see note X X 3 dimmers per plate 300W 300W X X 300VA 300VA see note X X Max load EM700TR 1 dimmer per plate 700W 700W X X 700VA 700VA see note X X Minimum load = 10VA for all load types + 50 o C 230-240V a.c. 50Hz 1 x 2.5mm 2 2 x 1.5mm 2 + 0 o C

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 48 Installation Step 1 Step 2 Step 3 Step 4 not supplied Marking plate Locating ring 180 270 360 Rotation ring options Marking plate options 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 SELECT ONE OF THE FOLLOWING WIRING OPTIONS: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals OFF ON OFF ON Do Not Connect Terminal 2 Wiring for 360º rotation Wiring for 270º rotation 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 SELECT ONE OF THE FOLLOWING WIRING OPTIONS: POSITION WIRING 0 1 2 3 OFF ON ON ON Connect All Terminals Wiring for 180º rotation 1 1 3 2 C Front View Rear View Output 1 Input ACTIVE Output 3 Output 2 3 2 0 1 1 3 2 C Front View Rear View Output 1 3 2 1 Front View Rear View 3 2 0 Input ACTIVE Output 3 Output 2 1 3 2 C Output 1 Input ACTIVE Output 3 Output 2 SELECT ONE OF THE FOLLOWING WIRING OPTIONS: POSITION WIRING 1 2 3 ON ON ON Connect All Terminals ON OFF ON Do Not Connect Terminal 2 OFF ON ON Do Not Connect Terminal 1 ON ON OFF Do Not Connect Terminal 3 Flat side facing up Shaft flatfacing up TYPE 1 TYPE 2 TYPE 3 TYPE 4 TYPE 5 TYPE 6 Rotary switch - EMRSWE/UG

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 49 Click 1.  Standard switch 2. Remove ring 3. Insert new ring 4. Screws must be fully screwed in 5. Align the slot and push 6. Engage in slot InstallationEM770LED - LED 770 illumination kit Wiring LED Power Available/Power Supplied Indicator KitsEMPAPS2, EMPAPS1, EMPA, EMPS1, EMPS2, EM803LED Features ■  Voltage: 230-240V a.c. ■  Frequency: 50Hz ■  Current: 1.2mA per indicator ■  Operating temperature: -5°C to +50°C ■  Storage temperature: -10°C to +70°C ■  Resistant to the following agents:  Hexane, methylated spirits, soapy water, diluted ammonia, diluted pure bleach (10%), glass cleaning sustance, pre-impregnated wipes, diluted hydrogen peroxide ■  Not resistant to the  following agents: Acetone, tar remover, trichloroethylene EMPAEMPS1EM803LED EMPAPS1EMPS2 EMPAPS2 Note: Low Impedance Load examples include incandescent,   halogen, resistive loads   High Impedance Load examples include CFL’s, LED globes LOAD LOAD LOAD LED on when “OFF” (Low Impedance Load) LED on when “ON” LED on “ALWAYS” N N N A A A LOAD LED on when “OFF” (High Impedance Load) N A Connector leads MUST be fully inserted Example of afully inserted connector leads not supplied Click into  this area Connector  leads InstallationEMPAPS2, EMPAPS1, EMPA, EMPS1, EMPS2, EM803LED LED Power Available/Power Supplied Indicator Kits Wire/leadmarking LED N LED L LED R LED A EMPAPS2 Neutral Switched  Active (LHS) Switched  Active (RHS) Active EMPAPS1 Neutral Switched  active Active EMPA Neutral Active EMPS2 Neutral Switched  Active   (LHS) Switched  Active   RHS) EMPS1 Neutral Switched  active EM803LED (power available) ++ Neutral Active EM803LED (power supplied) Neutral Switched  active EM803LED (power available  without neutral) Switched  active Active ++ = In this mode the LED indicator will be ON whenever there is power available to the product. = In this mode the LED indicator will only be ON whenever the associated switch/socket is OFF.  The current required to light the indicator when the switch is ON will be bled through the load. LED N LED L LED R Active Terminal Wiring '~' = Power available (Amber)'   ' = Power supplied (Red) Example:EMPAPS2 Illuminated LED ring kits LED power supplied/power available  indicator kits

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 50 Shutter, blind, curtain control Plates and cutout dimensions Wiring Push button switch (Cat No EC919WE) Push button switch (Cat No EC920WE) Pushbutton wiring (Cat. No. EC919WE) Switch wiring (Cat. No. EC920WE) A N N Control Box 6 A - 230-240V a.c. 50/60 Hz N A 6 AX - 230-240V a.c. 50/60 Hz L Pushbutton wiring (Cat. No. EC919WE) Switch wiring (Cat. No. EC920WE) A N N Control Box 6 A - 230-240V a.c. 50/60 Hz N A 6 AX - 230-240V a.c. 50/60 Hz L Common plate seriesdimensions Maximum cutout dimensions Maximum cutout dimensions Dedicated plate seriesdimensions 74mm 118mm 10mm 96mm 56mm 74mm 118mm 10mm 96mm 56mm 77mm 121mm 10mm 96mm 56mm 77mm 121mm 10mm 96mm 56mm

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 51 Powerpoint installation details Hard Surfaces Installations Double powerpoint 10A Assembly Assembly Note: Cutout dimensions for other devices are 96mm x 56mm Single powerpoint 10A Cut-out dimensions Cut-out dimensions Product dimensions Product dimensions 66 120 10 16 34 76 38 120 10 17 76 32 4 optional  mounting holes 92.00 84.00 (STD MOUNTING HOLES) 5.00 49.00 32.00 Ø40.00 4 optional  mounting holes Ø40.00 4.00 47.00 89.00 84.00 (STD MOUNTING HOLES) 6.00

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 52 Excel Life Dual USB  Charger 2 × 2.4A Plaster board Excel Life Powerpoint  with Dual USB  Charger2 × 2.4A Plaster board USB socket Wall cavity USB Charger Brick Wall Wall cavity USB Charger USB socket A N Mains cable Connects to mains cable A N E Brick Wall Excel Life Dual USB  Charger 2 × 2.4A Plaster board Excel Life Powerpoint  with Dual USB  Charger2 × 2.4A Plaster board USB socket Wall cavity USB Charger Brick Wall Wall cavity USB Charger USB socket A N Mains cable Connects to mains cable A N E Brick Wall USB Chargers installation details  Minimum 50mm cavity required. Installation in plasterboard with wall boxes – USB Charger e.g. EMUSB2PSXWE + ED770/1GPLWE  e.g. EMUSB2PSXWE + EAUSBEXT3WE + ED770/1GPLWE Installation in brick walls with wall boxes – USB Charger e.g. ED777USB2PSAWE e.g. EMUSB2PSAWE + ED770/1GPLWE Excel Life Dual USB  Charger 2 × 2.4A EAUSBEXT3WEExtension lead (3m) USB socket Brick wall Render Ceiling cavity Masonry wall box In-line Connector Connects to mains cable USB charger with  in-line connector EMUSB2PSXWE AN Electrical conduit (Ø20mm) Wall cavity Excel Life Dual USB  Charger 2 × 2.4A Wall box Plaster board USB charger with in-line connector A N Connects to mains cable Brick Wall In-line connector USB Socket Installation in plasterboard – USB Powerpoint Installation in plasterboard – USB Charger

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 53 USB Chargers installation details Installation in plasterboard walls with wall box  - USB Charger with double powerpoint Installation in brick walls with wall box  - USB Charger with double powerpoint Installation in plasterboard walls with wall box – USB Charger with double powerpoint Excel Life Powerpoint  with Dual USB  Charger 2 × 2.4A Plasterboard USB socket Wall cavity USB driver Brick wall Connect to  mains cable A N E ED777USB2PSXWE Excel Life Powerpoint with Dual USB Charger 2 × 2.4A USB socket Render Ceiling cavity Connects to mains cable USB driver with  in-line connector ED777USB2PSXWE + EAUSBEXT3WE Installation in brick walls with wall box – USB Charger with double powerpoint A N Electrical conduit (Ø20mm) Electrical conduit (Ø20mm) A N E Masonry wall box Brick wall In-line Connector EAUSBEXT3WEExtension lead (3m)

THE   ANTIMICROBIAL   ADVANTAGE The antimicrobial advantage in the Excel  Life Medical range stems from the material  construction based on silver ions - widely  recognised as having antimicrobial  properties that contribute to the reduction  of undesired microorganisms. The Excel Life Medical range has been tested   by an independent TGA accredited laboratory   to JIS Z 2801:2010 and proven to   be an effective antibacterial agent.The results demonstrated a kill rate against  Escherichia coli and Staphylococcus aureus  between 99.72% and 99.9999% . Look for  products with the antimicrobial symbol. ELECTRICAL SAFETY  A range of Electresafe  powerpoints are available  with a built-in 10mA or 30mA  Residual Current Device  (RCD safety switch). COMPLETE MEDICAL   FUNCTIONS AND   SERVICE PANELS In stainless steel and antimicrobial plastic  for patient rooms and operating theatres.  EXCEL LIFE    MEDICAL RANGE ENHANCED SAFETY   AND WELLBEING   IN HEALTHCARE Excel Life Medical range featuring antimicrobial  technology is the complete end-to-end solution for  healthcare facilities including hospitals, laboritories,  dental clinics and aged care facilities. Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 54

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 55 Pack Cat No. Common plate switch   16AX 230-240V a.c. Standard rocker switch mechanisms,  16AX fluoro rated, chemical resistant   and antimicrobial Vertical plates 10 EC770/1CAWE 1 gang switch 16AX  White 10 EC770/2CAWE 2 gang switch 16AX  White 10 EC770/3CAWE 3 gang switch 16AX  White 10 EC770/4CAWE 4 gang switch 16AX  White Horizontal plates 10 EC770/1HCAWE 1 gang switch 16AX  White 10 EC770/2HCAWE 2 gang switch 16AX  White 10 EC770/3HCAWE 3 gang switch 16AX  White 10 EC770/4HCAWE 4 gang switch 16AX  White No Touch Switch 6 EC914WE No Touch switch, 4A 1 gang  White EC770/1CAWE EC770/2HCAWE EC770/4CAWE Pack Cat No. Common plate grid and plates Chemical resistant and antimicrobial 10 EC770/0GPLCAWE Blank grid and coverplate only   White 10 EC770/1GPLCAWE 1 gang grid and coverplate only   White 10 EC770/2GPLCAWE 2 gang grid and coverplate only   White 10 EC770/3GPLCAWE 3 gang grid and coverplate only   White 10 EC770/4GPLCAWE 4 gang grid and coverplate only   White 10 EC770/5GPLCAWE 5 gang grid and coverplate only   White 10 EC770/6GPLCAWE 6 gang grid and coverplate only   White EC770/1GPLCAWE EC770/2GPLCAWE EC770/3GPLCAWE EC770/4GPLCAWE Switch mechanisms   16AX 230-240V a.c. Single pole double throw chemical  resistant and antimicrobial 10 EM770CAWE  White 10 EM770CARED  Red In medical applications socket-outlets colour coding requirements  are as follows: Normal Supply – White (WE) Essential Supply – Red (RED) Uninterruptible Supply (UPS) – Dark blue (BU) Cleaners Sockets – Beige (BE) Excel Life – Product Type Catalogue Number Decoder EC777NIDCAWE N: NEON/LED – Power available indicator ID: Circuit Identification CA: Chemical Resistant – Antimicrobial Colour: WE: White, RD: RED, BU: Blue, BE: Beige Excel Life TM  Switches Excel Life TM  Grids & plates  and switch mechanisms

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 56 Pack Cat No. Common plate powerpoints  10A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial with power available LED  engraved ‘RCD Protected’ Double powerpoint 10 EC777NCAWE  White 10 EC777NCABU  Blue 10 EC777NCARD  Red Double powerpoint with circuit ID 10 EC777NIDCAWE  White 10 EC777NIDCABU  Blue 10 EC777NIDCARD  Red Single powerpoint 10 EC787NCAWE  White 10 EC787NCABU  Blue 10 EC787NCARD  Red Single powerpoint with circuit ID 10 EC787NIDCAWE  White 10 EC787NIDCABU  Blue 10 EC787NIDCARD  Red Pack Cat No. Common plate vertical powerpoints  10A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial with power available LED  engraved ‘RCD Protected’ Double vertical powerpoint 10 ECV777NCAWE  White 10 ECV777NCABU  Blue 10 ECV777NCARD  Red Single vertical powerpoint 10 ECV787NCAWE  White 10 ECV787NCABU  Blue 10 ECV787NCARD  Red Single vertical powerpoint with  circuit ID 10 ECV787NIDCAWE  White 10 ECV787NIDCABU  Blue 10 ECV787NIDCARD  Red EC777NIDCABU ECV777NCAWE EC787NCAWE ECV787NCAWE ECV787NCARD EC777NCAWE Excel Life TM  Powerpoints Excel Life TM  Vertical powerpoints and USB chargers USB chargers  230-240V a.c. All USB chargers are white 12 EMUSB2PSWE Dual socket USB charger  mechanism 2 x 2.1A. To be  used in any device with an extra  function mechanism hole 12 EMUSB2PSAWE Dual USB charger mechanism  2x2.4A 12 EMUSB2PSXWE Dual USB charger mechanism  2x2.4A with inline connector (suit wall boxes 429R or 435)  1 EAUSBEXT3WE USB charger extension lead  3m. To extend distance  between USB socket and   power supply. Can be used   with EMUSB2PSXWE/UG or  ED777USB2PSXWE/UG NEW AVAIL Q4-2015 NEW AVAIL Q4-2015 NEW AVAIL Q4-2015

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 57 Pack Cat No. Common plate single powerpoints  15A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial with power available LED  engraved ‘RCD Protected’ Single powerpoint 10 EC787/15NCAWE  White 10 EC787/15NCABU  Blue 10 EC787/15NCARD  Red Single vertical powerpoint 10 ECV787/15NCAWE  White 10 ECV787/15NCABU  Blue 10 ECV787/15NCARD  Red Pack Cat No. Common plate ‘cleaners’  powerpoints 10A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial, engraved ‘CLEANING  PURPOSES ONLY’ Double powerpoint 10 EC777CABE  Beige Double powerpoint with circuit ID 10 EC777IDCABE  Beige Single powerpoint 10 EC787CABE  Beige 10 EC787/15CABE  Beige Single powerpoint 15A Single powerpoint with circuit ID 10 EC787IDCABE  Beige 10mA double electresafe RCD  powerpoint 10 EC777EL10CABE  Beige 10mA double electresafe RCD  powerpoint with circuit ID 10 EC777EL10IDCABE  Beige EC787CABE EC787/15NCAWE ECV787/15NCAWE EC777CABE In medical applications socket-outlets colour coding requirements  are as follows: Normal Supply – White (WE) Essential Supply – Red (RED) Uninterruptible Supply (UPS) – Dark blue (BU) Cleaners Sockets – Beige (BE) Excel Life TM  15A powerpoints Excel Life TM  ‘Cleaners’ powerpoints

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 58 Pack Cat No. Common plate electresafe RCD  powerpoints 10A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial with power available  LED and power supplied LED 10mA double electresafe RCD  powerpoint 2 EC777EL10CAWE  White 2 EC777EL10CABU  Blue 2 EC777EL10CARD  Red 10mA double electresafe RCD  powerpoint   with circuit ID 2 EC777EL10IDCAWE  White 2 EC777EL10IDCABU  Blue 2 EC777EL10IDCARD  Red 30mA double electresafe RCD  powerpoint 2 EC777EL30CAWE  White EC777EL10CAWE EC777EL10IDCAWE In medical applications socket-outlets colour coding requirements  are as follows: Normal Supply – White (WE) Essential Supply – Red (RED) Uninterruptible Supply (UPS) – Dark blue (BU) Cleaners Sockets – Beige (BE) Excel Life TM  Electresafe   RCD powerpoints Pack Cat No. Common plate powerpoints   10A 230-240V a.c. Internal safety shutters, chemical resistant  and antimicrobial, engraved ‘RCD Protected’ Horizontal powerpoints 10 EC777CAWE Double powerpoint  White 10 EC777CABU Double powerpoint  Blue 10 EC777CARD Double powerpoint  Red 10 EC777XCAWE Double powerpoint with extra   function mechanism hole  White 10 EC777XCABU Double powerpoint with extra   function mechanism hole  Blue 10 EC777XCARD Double powerpoint with extra   function mechanism hole  Red 10 EC787CAWE Single powerpoint  White 10 EC787XCAWE Single powerpoint with extra  function mechanism hole  White Vertical powerpoints 10 ECV777CAWE Double vertical powerpoint  White 10 ECV777XCAWE Double vertical powerpoint with extra function mechanism hole  White 10 ECV787CAWE Single Vertical powerpoint  White 10 ECV787XCAWE Single Vertical powerpoint with extra function mechanism hole  White EC777CAWE EC777XCAWE EMPS2WE Excel Life TM  Powerpoints

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 59 Pack Cat No. Accessories (continued) Plaster brackets – 84mm Fixing  Centre 50 712 Plaster 10m board bracket Render brackets 20 954 1 Gang render Bracket 10 EA503/2W 2 gang horizontal render- bracket 10 EA503/3W 3 gang horizontal render- bracket 10 EA503/2H 2 gang vertical render-bracket 10 EA503/3H 3 gang vertical render-bracket 10 EA503/4H 4 gang vertical render-bracket Stud brackets 20 143 Stud bracket 20 143/2 Stud bracket horizontal w/nails 20 143/2V Stud bracket vertical w/nails 10 143U Stud bracket vertical or  horizontal w/nails 10 EA143/2W 2 gang horizontal stud-bracket 10 EA143/3W 3 gang horizontal stud-bracket 10 EA143/2H 2 gang vertical stud-bracket 10 EA143/3H 3 gang vertical stud-bracket 10 EA143/4H 4 gang vertical stud-bracket Pack Cat No. Common plate coverplates Coverplates chemical resistant   and antimicrobial 10 ECCWPLCAWE 1 gang coverplate  White 10 ECCW2HPLWE 2 gang coverplate   White 10 ECCW3HPLWE 3 gang coverplate   White 10 ECCW3HPLBU 3 gang coverplate   Blue 10 ECCW3HPLRD 3 gang coverplate   Red 10 ECCW4HPLWE 4 gang coverplate   White 10 ECCW2WPLWE 2 gang horizontal coverplate   White 10 ECCW3WPLWE 3 gang horizontal coverplate   White Accessories 10 EMCCWE Cord retention clamp 10 EMCLIDWE Blank insert with clear cap  Used for circuit ID 10 EMIDWE Blank module 10 EM910RPWE Plug and cable retainer to  be used in conjunction with  EC910GPLWE or ECFRAME Circuit Identification labels  10 sheets (96 labels per sheet) 10 10 10 10 EACIDLABELWE EACIDLABELBU EACIDLABELRED EACIDLABELYE  White  Blue    Red    Yellow   EMCCWE ECCW4HPLWE EA503/2W EA143/3H EM910RPWE In medical applications socket-outlets colour coding requirements  are as follows: Normal Supply – White (WE) Essential Supply – Red (RED) Uninterruptible Supply (UPS) – Dark blue (BU) Cleaners Sockets – Beige (BE) Excel Life TM  Coverplates   and accessories Excel Life TM  Accessories   and brackets

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 60 Pack Cat No. Standard recessed wall boxes Modular system with adjustable height  insert. Provided with earth wires. Boxes  can be joined horizontally or vertically.   To be equipped with coverplates.   (See dimensions on page 61.) Steel wall boxes 1 EABOX270 2 Gang recessed 2 module box 70mm spacing 1 EABOX370 3 Gang recessed 3 module box 70mm spacing 1 EABOX470 4 Gang recessed 4 module box 70mm spacing 1 EABOX2100 2 Gang recessed 3 module box 100mm spacing (gas only) 1 EABOX3100 3 Gang recessed 4 module box 100mm spacing (gas only) Standard wall box 10 429R Recessed plastic wall box with  sliding nuts, retention clips and  protective cover size 97 x 60 x  45mm 10 EA751 Protective shroud for panel mount Equipotential devices Earth stud plates 1 ECEES/1GCAWE 1 Gang equipotential earth stud   White 1 ECEES/2GCAWE 2 Gang equipotential earth stud   White Equipotential boxes 1 EAEPNODE Equipotential node kit supplied   with stainless steel face plate   and earth stud 1 EAEPJUNCTION Equipotential junction kit supplied   with stainless steel face plate Gas plates Chemical resistant and antimicrobial 1 ECGAS1GPLCAWE Gas outlet plate   White 1 ECGAS2GPLCAWE Gas outlet plate with scavenge   White Pack Cat No. Wall box stainless steel coverplates Standard stainless steel coverplates   to suit standard wall boxes.   (See dimensions on page 61.) Stainless steel electrical coverplates 1 EA270PLSS Stainless steel 2 gang coverplate  70mm spacing 190mm x190mm 1 EA370PLSS Stainless steel 3 gang coverplate  70mm spacing 265mm x190mm 1 EA470PLSS Stainless steel 4 gang coverplate  70mm spacing 340mm x190mm 1 EA2270PLSS Stainless steel 2+2 gang coverplate  70mm spacing 340mm x190mm 1 EA2370PLSS Stainless steel 2+3 gang coverplate  70mm spacing 415mm x190mm 1 EA3370PLSS Stainless steel 3+3 gang coverplate  70mm spacing 490mm x190mm 1 EA3470PLSS Stainless steel 3+4 gang coverplate  70mm spacing 565mm x190mm Stainless steel gas coverplates  1 EA2100PLSS Stainless steel 2 gang gas coverplate  100mm spacing 265mm x190mm 1 EA3100PLSS Stainless steel 3 gang gas coverplate  100mm spacing 340mm x190mm EA751 EAEPJUNCTION EAEPNODE EA3470PLSS Excel Life TM  Wall Boxes, equipotential  devices and gas plates Excel Life TM  Stainless steel coverplates

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 61 BOX DEPTH = 65mm (EXCLUDING HEIGHT ADJUSTMENT OF BASE) 150 150 300 225 150 190 190 265 340 70 70 70 190 100 100 130 130 102 177 252 85 83 80 88 70 70 70 490 415 340 565 190 190 130 130 177 48 102 48 177 102 48 252 Standard Wall Box   Dimensions Standard Stainless Steel   Coverplate Dimensions BOX DEPTH = 65mm (EXCLUDING HEIGHT ADJUSTMENT OF BASE) 150 150 300 225 150 Excel Life TM  Wall boxes and coverplates EABOX270 EABOX370 EABOX2100 EA270PLSS EA370PLSS EA2100PLSS EA3370PLSS EA3470PLSS EA470PLSS EA3100PLSS EA2370PLSS EA2270PLSS EABOX470 EABOX3100 190 190 265 340 70 70 70 190 100 100 130 130 102 177 252 85 83 80 88 70 70 70 490 415 340 565 190 190 130 130 177 48 102 48 177 102 48 252 190 190 265 340 70 70 70 190 100 100 130 130 102 177 252 85 83 80 88 70 70 70 490 415 340 565 190 190 130 130 177 48 102 48 177 102 48 252 190 190 265 340 70 70 70 190 100 100 130 130 102 177 252 85 83 80 88 70 70 70 490 415 340 565 190 190 130 130 177 48 102 48 177 102 48 252

Whilst most items are stock lines some products are made to order. For delivery dates, custom prints and latest prices   please contact your local HPM Legrand customer service representative 62 Pack Cat No. Common plate electresafe RCD  vertical plate 20A 230-240V a.c. Chemical resistant and antimicrobial   with power available LED and power  supplied LED 10mA electresafe RCD plate 2 ECEL10N2CAWE  White 2 ECEL10N2CABU  Blue 2 ECEL10N2CARD  Red 10mA electresafe RCD plate with  circuit ID 2 ECEL10N2IDCAWE  White 2 ECEL10N2IDCABU  Blue 2 ECEL10N2IDCARD  Red ECEL10N2IDCAWE Excel Life TM  Electresafe   RCD plates Pack Cat No. Skirting lights 230-240V a.c. Skirting lights Suitable for passage areas or installation   with obstacles 1 EC510WE Permanent skirting LED light,   0.2 or 1W max  White Skirting light with motion detector The LED lights are activated when   the PIR sensor detects movement. 1 EC511WE Skirting LED light with PIR sensor 1.3W max  White Panel mount adaptors and inserts Panel mount adaptors suitable for panel  thickness of 0.7mm to 3mm 1 Module accepts 1 x 25x57mm inserts 2 Module accepts 50x57mm or 2 x 25x57mm inserts Panel mount adaptors 10 EA910PMAWE Panel mount adaptors - 1 module   White 10 EA920PMAWE Panel mount adaptors - 2 module   White Inserts 10 EA910/0WE Blank insert - 1 module   White 10 EA910/1WE 1 gang insert - 1 module   White 10 EA910/2WE 2 gang insert - 1 module   White Illumination kits 230-240V a.c. 10 EMPAPS2WE Power available (Amber) and 2  power supplied (Red) indicators kit  White 10 EMPAWE Power available indicator kit  (Amber)    White 10 EMPS1WE Power supplied to 1 outlet   indicator kit (Red)  White 10 EMPS2WE Power supplied to 2 outlets  indicators kit (Red)  White EC510WE Excel Life TM  Skirting lights, panel mount  adapters and inserts and illumination kits

17 /08/2015 HPM Legrand AustraliaBuilding 4, Nexus Industry Park 43-47 Lyn Parade,   Prestons NSW 2170 Phone 1300 369 777 www.excellife.com.auwww.legrand.com.au HPM Legrand New Zealand106-124 Target Road Glenfield, Auckland 0627 Phone 0800 476 009 www.excellife.co.nz www.legrand.co.nz
