Medium voltage cables

Medium voltage cables April 2015

Whilst every care has been taken in the preparation of this publication, the Prysmian Group take no responsibility for any errors and or omissions. This booklet is in-tended as a guide only and reference must be made by any person using this booklet to the appropriate Australian/New Zealand Standard and or to local electricity supply authority rulings. The company reserves the right to make changes in product without notice. All rights reserved. Subject to change without notice. This manual contains technical information on a wide vari-ety of commonly used medium voltage (MV) power cables manufactured to Australian Standard AS/NZS 1429.1.  Full constructional and technical details are given for  Prysmian’s standard range of MV power cables. Other  constructions and variants are available by special order. Recommended use The cables described in this technical manual are designed  to be used for the supply of electrical energy in fixed  installations up to the indicated rated voltage at a nominal power frequency in the range 49Hz to 61Hz. Cables to AS/NZS 1429.1 and AS/NZS 4026 are intended  for use either installed in air, directly buried in the ground  or in ducts. Cables with LSOH sheath have improved fire performance when installed in air and are primarily intended for such locations. Reasonable protection against mechanical damage should be provided. Cables in this technical manual are not specifically designed for use as self-supporting aerial cables, as submarine cables, where exposure to excessive heat or corrosive products or solvent substances is involved. In case of any doubt concern-ing the suitability of a particular cable type for a particular use, guidance should be sought from Prysmian’s Customer Service Centre. 2

You might ask yourself why you should choose cables from us, and not from somewhere else? It’s a fair question. There are many very good reasons.  First of all we’re Australians. We’ve been producing tailor-made cables here since 1944. We know what it takes to deal with the many different challenges that tough Australian conditions require.  Second of all we combine this local knowledge with the strength of being a global market leader. Being the world’s largest producer of power and telecommunication cables means we have the muscles to innovate and customise our solutions to perfectly match your needs. At our disposal we have 97 manufacturing plants, 17 research and de-velopment centres and around 22 000 employees.  In addition we co-operate with universities, scien-tific institutions and, perhaps most importantly, with you. Your satisfaction is our livelihood. Based on your needs and your feedback we constantly improve to make sure our offer fits the bill.  No matter what kind of cable you need, we have it. And if not, we’ll invent it. And it doesn’t end there. In our offer you’ll find the best technical support on the market – before, during and after.  That’s why doing business with us pays off. Please accept this latest edition of the Medium voltage guide with our compliments. Prysmian Australia Pty Ltd proudly manufactures in Australia  and operates certified management systems compliant with  the requirements of:ISO 9001:2008 Quality Management SystemsAS/NZS 4801:2001  Occupational Health & Safety Management SystemsOHSAS 18001:2007 Assessment Specification for OccupationalHealth & Safety Management SystemsISO 14001:2004 Environmental Management Systems Welcome to the latest edition  of the Technical Cable Guide. Following the recent acquisition of Draka, the Prysmian Group is now the world’s largest producer of power and telecommunication cables with 97 manufacturing plants, 17 Research & Development Centres, and around  22,000 employees.  A global solutions provider, Prysmian offers a wide range of integrated solutions, such as cable systems,  system design and engineering,  project management, installation  and postsale services. Prysmian focuses on continuous product innovation and on achieving a competitive edge by focusing on research and development. This is done through Prysmian’s own research & development centres and by co-operating with universities, scientific institutions and our valued customers. Prysmian’s world-wide organisation makes and delivers advanced technological solutions to customers anywhere in the world.  Prysmian is committed to providing all of the necessary technical, installation, safety and practical information that may be required by designers, installers and users of our products in a comprehensive hand book that can easily be used  in the field.  Please accept this latest edition of the Technical Cable Guide with our compliments. Prysmian Cables & Systems Australia Pty Ltd proudly manufactures in Australia and operates certified management systems compliant with the requirements of; ISO 9001:2000  Quality Management Systems AS/NZS 4801:2001 Occupational  Health & Safety Management SystemsOHSAS 18001:1999  Assessment Specification for Occupational  Health & Safety Management SystemsISO 14001:2004 Environmental Management Systems Welcome to the latest edition  of the Technical Cable Guide. Following the recent acquisition of Draka, the Prysmian Group is now the world’s largest producer of power and telecommunication cables with 97 manufacturing plants, 17 Research & Development Centres, and around  22,000 employees.  A global solutions provider, Prysmian offers a wide range of integrated solutions, such as cable systems,  system design and engineering,  project management, installation  and postsale services. Prysmian focuses on continuous product innovation and on achieving a competitive edge by focusing on research and development. This is done through Prysmian’s own research & development centres and by co-operating with universities, scientific institutions and our valued customers. Prysmian’s world-wide organisation makes and delivers advanced technological solutions to customers anywhere in the world.  Prysmian is committed to providing all of the necessary technical, installation, safety and practical information that may be required by designers, installers and users of our products in a comprehensive hand book that can easily be used  in the field.  Please accept this latest edition of the Technical Cable Guide with our compliments. Prysmian Cables & Systems Australia Pty Ltd proudly manufactures in Australia and operates certified management systems compliant with the requirements of; ISO 9001:2000  Quality Management Systems AS/NZS 4801:2001 Occupational  Health & Safety Management SystemsOHSAS 18001:1999  Assessment Specification for Occupational  Health & Safety Management SystemsISO 14001:2004 Environmental Management Systems WARNING Cables must be installed according to the requirements of AS/NZS 3000, the Wiring Rules and any supplementary requirements of appropriate local Electricity Authorities, by an Electrician who holds a valid licence, appropriate to the State, Territory or Country where installation is to take place. The Wiring Rules are applied throughout Australia by means of State and Territory Acts and Regulations. In general these Acts and Regulations specify compliance with the Rules, however, because of local requirements, some variation to specific clauses may be called for by means of these Acts and Regulations. Note: Current ratings data contained in the cable selection category of this guide are based on Australian/New Zealand Standards (AS/NZS 3008.1.1). 1300 300 304    |   WWW.PRYSMIAN.COM.AU    105 GENERAL INFORMATION Solid conductor: A conductor consisting of a single wire. TACW:  Tinned annealed copper wire. TCu:  Tinned copper conductor. Thermoplastic material: A material that can be readily softened and resoftened by repeated heating,  eg., PVC and PE. Thermosetting material: A material which cures by chemical reaction when heated and, when cured, cannot be resoftened by heating, eg., XLPE. Tinsel conductor: A conductor comprising fine flattened copper wires assembled in combination with textile material to achieve a high degree of flexibility. TPS: Thermoplastic sheath. (See Thermoplastic material). XLPE:  Cross linked polyethylene. For LV application, usually refers to X-90 grade.  (See Thermosetting material). ACMA Approval tick.  RCM Approval tick. Whilst every care has been taken in the preparation of this publication, Prysmian takes no responsibility for any errors and or omissions. This booklet is intended as a guide only and reference must be made by any person using this booklet to the appropriate Australian/NZ Standard and or to local electricity supply authority rulings.  The company reserves the right to make changes in product without notice.  The Prysmian Guide to Cable has been completely revised and makes reference to the most recent information available. Information herein refers to common low voltage power and communication cables used by industry. For information not covered in this publication eg. High Voltage XLPE and EPR, Fibre Optics and other specialised Power and Communication cables please contact your nearest Prysmian Sales Office on 1300 300 304. Printed in Australia. Copyright © Prysmian Cables & Systems (ABN 36 096 594 080) 2012. All rights reserved. Subject to change without notice. Quality ISO 9001 Why do business with Prysmian? Because it pays off. 3

Do you always get what you see? Probably not. And that’s definitely true for cables. Cables might look the same on the outside. But it’s the inside that counts. And that can differ enormously. We have always worked with quality as our top priority, listened to our customers and customised our cables  to perfectly fit their needs. ‘Cause we have and always will continue to believe that quality pays off.  Australian made? Yes, of course.

Contents 5 Health, safety and environment  7 Exploded cable view  7 Designations 7Product code  7 Cables Copper 1.9/3.3kVSingle core light duty screened unarmoured  8 Single core heavy duty screened unarmoured  10 Three core light duty screened unarmoured  12 Three core light duty screened armoured  14 Three core heavy duty screened unarmoured  16 Three core heavy duty screened armoured  18 Aluminium 1.9/3.3kVSingle core light duty screened unarmoured  20 Single core heavy duty screened unarmoured  22 Three core light duty screened unarmoured  24 Three core light duty screened armoured  26 Three core heavy duty screened unarmoured  28 Three core heavy duty screened armoured  30 Copper 3.8/6.6kVSingle core light duty screened unarmoured  32 Single core heavy duty screened unarmoured  34 Three core light duty screened unarmoured  36 Three core light duty screened armoured  38 Three core heavy duty screened unarmoured  40 Three core heavy duty screened armoured  42 Aluminium 3.8/6.6kVSingle core light duty screened unarmoured  44 Single core heavy duty screened unarmoured  46 Three core light duty screened unarmoured  48 Three core light duty screened armoured  50 Three core heavy duty screened unarmoured  52 Three core heavy duty screened armoured  54 Copper 6.35/11kVSingle core light duty screened unarmoured  56 Single core heavy duty screened unarmoured  58 Three core light duty screened unarmoured  60 Three core light duty screened armoured  62 Three core heavy duty screened unarmoured  64 Three core heavy duty screened armoured  66 Technical Information  128 Ratings information  135 General information  138  Aluminium 6.35/11kVSingle core light duty screened unarmoured  68 Single core heavy duty screened unarmoured  70 Three core light duty screened unarmoured  72 Three core light duty screened armoured  74 Three core heavy duty screened unarmoured  76 Three core heavy duty screened armoured  78 Copper 12.7/22kVSingle core light duty screened unarmoured  80 Single core heavy duty screened unarmoured  82 Three core light duty screened unarmoured  84 Three core light duty screened armoured  86 Three core heavy duty screened unarmoured  88 Three core heavy duty screened armoured  90 Aluminium 12.7/22kVSingle core light duty screened unarmoured  92 Single core heavy duty screened unarmoured  94 Three core light duty screened unarmoured  96 Three core light duty screened armoured  98 Three core heavy duty screened unarmoured  100 Three core heavy duty screened armoured  102 Copper 19/33kVSingle core light duty screened unarmoured  104 Single core heavy duty screened unarmoured  106 Three core light duty screened unarmoured  108 Three core light duty screened armoured  110 Three core heavy duty screened unarmoured  112 Three core heavy duty screened armoured  114 Aluminium 19/33kVSingle core light duty screened unarmoured  116 Single core heavy duty screened unarmoured  118 Three core light duty screened unarmoured  120 Three core light duty screened armoured  122 Three core heavy duty screened unarmoured  124 Three core heavy duty screened armoured  126

We’ve been producing tailor-made cables in Australia since 1944, and will continue to do so.  Our great staff of highly skilled and experienced people know what it takes to make cables that  withstand everything from termites to hazardous mine sites. Just fair dinkum cables, mate. Australian made? Yes, of course.  Only the best for True Blue Aussies. Australian made quality cables.

Designations Product code 1.  Conductor nominal cross sectional area:  25, 35, 50, 70, 95, 120, 150, 185, 240, 300, 400, 500, 630 2.  Single or three core: 1C, 3C3.  Conductor material: Copper – CU, Aluminium – AL4.  Insulation material: XLPE – X, EPR – E5.  kV rating: 3–1.9/3.3, 6–3.8/6.6, 11–6.35/11, 22–12.7/22, 33–19/336.  Screen type: Light Duty – LD, Heavy Duty – HD7.  Armouring: Armoured – A, Unarmoured – blank Each cable type is identified by a reference type designation for ease of reference and a full order designation which fully identifies each cable and should be used on order documen-tation. Cables are metre marked for ease of installation and inventory control.  All cables are listed with the voltage rating for which the cable is designed, expressed in the form Uo/U, where Uo is the nominal voltage between conductor(s) and earth and U is the nominal voltage between phase conductors. When ordering, please quote the conductor nominal cross sectional area ahead of the product code which appears on each data sheet. 95 3C CU X 11 LD A CSA Product code 1. 2. 3. 4. 5. 6. 7. Example: 953CCUX11LDA:  95 mm 2  three core, copper conductor, XLPE insulated, 11kV, light duty  screen, armoured. Exploded cable view Stranded compacted copper  or aluminium conductor Semi-conductive conductor screen Semi-conductive insulation screen PVC sheath Tape binder XLPE insulation Copper wire screen Single core Stranded compacted copper  or aluminium conductor Semi-conductive conductor screen Semi-conductive insulation screen Galvanized steel wire armour PVC sheath Tape binder XLPE insulation Copper wire screen Three core People are our greatest asset. We believe everyone has the right to work and live in a healthy and safe environment.  The Prysmian Group maintains our commitment to comply with all relevant Occupational Health, Safety and Environ-mental legislation, Australian and New Zealand Standards (AS/NZS 4801 and ISO 14001) Licences and Industry Codes of Practices. Our goal is an environmentally and socially sustainable busi-ness and we believe that a safe work environment is a sign of efficiency and quality. Accidents can be prevented and we commit to continually improve, to achieve zero incidents of work related injury, illness and environmental pollution. We also aim to help our customers fulfil their environmental responsibilities by providing them with cables and associ-ated products that we believe have been manufactured as efficiently, economically sound and environmentally sus-tainable as possible. As our products are locally designed and manufactured we recognize the importance of risk as-sessment and mitigation in all mining operations.  For additional support in this area we have dedicated tech-nical staff available to provide specific product information and guidelines for use please contact: [email protected] Health, safety and environment 7

Copper 1.9/3.3kv – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D      15D (HDPE) During installation:   18D     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)     Heavy (HDPE) Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation options:    Cross Linked Polyethylene (XLPE)  Ethylene Propylene Rubber (EPR)Insulation screen:   Extruded, semi-conductive compound  Cold strippableMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath options:   Black 5V-90 PVC  Orange 5V-90 PVC – inner plus black high density    polyethylene (HDPE) outer.  Low smoke zero halogen (LSOH) Installation conditions In free air In duct In trench In ground with protection 8 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Single core light duty screened unarmoured  Product code: 1CCUX3LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx cable   diameter mm 18.6 19.6 20.7 22.3 24.0 25.4 26.8 28.6 31.0 33.5 37.2 40.9 45.2 Approx mass   kg/100m 65 75 90 110 135 160 190 225 280 340 430 535 675 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.2 1.3 1.5 1.7 2.0 2.3 2.5 2.9 3.4 3.9 4.8 5.8 7.1 Min bending radius   during installation mm 340 350 370 400 430 460 480 510 560 600 670 740 810 Min bending radius   set in position mm 220 230 250 270 290 310 320 340 370 400 450 490 540 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0983 0.0794 0.0635 0.0513 0.0419 Inductance, trefoil  touching mH/km 0.448 0.428 0.409 0.377 0.359 0.344 0.333 0.322 0.312 0.303 0.296 0.290 0.285 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.141 0.134 0.128 0.118 0.113 0.108 0.105 0.101 0.0981 0.0953 0.0930 0.0911 0.0896 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.66+  j0.0717 1.46+  j0.0669 1.32+  j0.0622 1.20+  j0.0540 1.13+  j0.0498 1.09+  j0.0461 1.06+  j0.0438 1.03+  j0.0413 1.01+  j0.0388 0.995+  j0.0367 0.982+  j0.0352 0.973+  j0.0340 0.965+  j0.0331 Capacitance, phase   to earth µF/km 0.318 0.350 0.390 0.448 0.507 0.556 0.605 0.666 0.742 0.824 0.943 0.962 0.994 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 1.02 0.929 0.850 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.209 0.233 0.267 0.303 0.332 0.361 0.398 0.443 0.492 0.563 0.574 0.594 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  Current  Rating In ground, direct buried   A 145 175 205 250 295 335 375 425 490 550 620 695 780 In ground,   in singleway  ducts   A 145 170 200 240 285 320 360 400 455 510 570 640 715 In free air,   unenclosed   & spaced   from wall   A 145 170 205 260 315 365 415 475 560 645 750 860 990 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 9 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 1.9/3.3kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)     Heavy (HDPE) Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath options:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 10 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Single core heavy duty screened unarmoured  Product code: 1CCUX3HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx cable   diameter mm 18.6 20.9 22.0 24.3 26.0 26.7 28.1 30.1 32.3 34.8 38.5 42.2 46.5 Approx mass   kg/100m 70 90 115 155 185 205 235 270 325 385 475 580 720 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.2 1.5 1.7 2.1 2.4 2.5 2.8 3.2 3.6 4.2 5.2 6.2 7.6 Min bending radius   during installation mm 340 380 400 440 470 480 510 540 580 630 690 760 840 Min bending radius   set in position mm 220 250 260 290 310 320 340 360 390 420 460 510 560 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0982 0.0793 0.0634 0.0511 0.0417 Inductance, trefoil  touching mH/km 0.448 0.442 0.421 0.395 0.375 0.354 0.343 0.333 0.321 0.311 0.303 0.297 0.291 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.141 0.139 0.132 0.124 0.118 0.111 0.108 0.105 0.101 0.0978 0.0953 0.0932 0.0914 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.51+  j0.0717 1.09+  j0.0696 0.783+  j0.0647 0.560+  j0.0575 0.485+  j0.0530 0.435+  j0.0481 0.406+  j0.0456 0.381+  j0.0430 0.358+  j0.0404 0.343+  j0.0381 0.330+  j0.0365 0.320+  j0.0351 0.312+  j0.0342 Capacitance, phase   to earth µF/km 0.318 0.350 0.390 0.448 0.507 0.556 0.605 0.666 0.742 0.824 0.943 0.962 0.994 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 1.02 0.929 0.850 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.209 0.233 0.267 0.303 0.332 0.361 0.398 0.443 0.492 0.563 0.574 0.594 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 145 175 205 250 295 335 370 415 475 530 595 660 735 In ground,   in singleway  ducts   A 145 170 195 230 270 300 325 360 405 440 490 540 595 In free air,   unenclosed   & spaced   from wall   A 145 175 210 265 320 365 415 470 555 630 725 830 945 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 11 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 12 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core light duty screened unarmoured  Product code: 3CCUX3LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 36.0 38.2 40.8 44.6 48.6 51.9 55.1 59.1 64.2 69.5 Approx mass   kg/100m 160 195 235 305 390 475 560 675 855 1050 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 4.5 5.1 5.8 7.0 8.3 9.4 11 12 14 17 Min bending radius   during installation mm 650 690 730 800 880 930 990 1060 1160 1250 Min bending radius   set in position mm 430 460 490 540 580 620 660 710 770 830 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 0.0800 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 0.262 Inductive Reactance,   @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 0.0824 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+  j0.0720 3.26+  j0.0671 3.12+  j0.0624 3.00+  j0.0542 2.93+  j0.0499 2.68+  j0.0463 2.47+  j0.0440 2.29+  j0.0415 2.13+  j0.0390 1.88+  j0.0368 Capacitance, phase   to earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 0.827 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 0.494 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.6 Contin- uous  current  rating In ground, direct buried   A 140 165 195 235 285 330 365 410 475 530 In ground,   in singleway  ducts   A 120 140 165 205 240 275 310 350 405 460 In free air,   unenclosed   & spaced   from wall   A 135 160 190 235 280 335 375 430 495 575 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 13 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 14 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core light duty screened armoured  Product code: 3CCUX3LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 43.0 45.2 49.7 53.4 57.5 61.0 64.2 68.4 73.7 Approx mass   kg/100m 320 365 460 550 660 765 870 1010 1220 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.2 8.6 10.0 12 13 14 16 19 Max pulling tension   on armour wires kN 7.5 8.3 9.8 11 13 15 17 19 22 Min bending radius   during installation mm 770 810 890 960 1040 1100 1160 1230 1330 Min bending radius   set in position mm 520 540 600 640 690 730 770 820 880 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 Inductive Reactance,   @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+  j0.0720 3.26+   j0.0671 3.12+   j0.0624 3.00+  j0.0542 2.93+  j0.0499 2.68+  j0.0463 2.47+  j0.0440 2.29+   j0.0415 2.13+   j0.0390 Capacitance, phase   to earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 Contin- uous  current  rating In ground, direct buried   A 140 165 195 235 285 330 365 410 475 In ground,   in singleway  ducts   A 120 140 165 205 240 275 310 350 405 In free air,   unenclosed   & spaced   from wall   A 135 160 190 235 280 335 375 430 495 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 15 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 16 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core heavy duty screened unarmoured  Product code: 3CCUX3HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 36.0 38.2 40.8 44.8 48.6 51.9 55.1 59.1 64.2 69.5 Approx mass   kg/100m 165 210 260 350 435 515 600 715 890 1080 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 4.5 5.1 5.8 7.0 8.3 9.4 11 12 14 17 Min bending radius   during installation mm 650 690 730 810 880 930 990 1060 1160 1250 Min bending radius   set in position mm 430 460 490 540 580 620 660 710 770 830 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 0.0800 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 0.262 Inductive Reactance,   @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 0.0824 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+  j0.0720 2.16+  j0.0671 1.56+  j0.0624 1.11+   j0.0542 1.03+  j0.0499 0.995+  j0.0463 0.966+  j0.0440 0.941+  j0.0415 0.917+  j0.0390 0.902+  j0.0368 Capacitance, phase   to earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 0.827 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 1.03 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 0.494 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 140 165 195 240 290 335 365 410 475 520 In ground,   in singleway  ducts   A 120 140 165 205 240 275 310 350 400 450 In free air,   unenclosed   & spaced   from wall   A 135 160 190 240 290 340 380 435 510 590 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 17 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 18 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 1.9/3.3kV – Three core heavy duty screened armoured  Product code: 3CCUX3HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 43.0 45.2 49.7 53.6 57.5 61.0 64.4 68.6 73.7 Approx mass   kg/100m 325 380 490 600 700 805 915 1050 1250 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.2 8.6 10 12 13 15 16 19 Max Pulling Tension   On Armour Wires kN 7.5 8.3 9.8 12 13 15 17 19 22 Min bending radius :  during installation mm 770 810 890 970 1040 1100 1160 1230 1330 Min bending radius :  set in position mm 520 540 600 640 690 730 770 820 880 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.160 0.128 0.0987 Inductance mH/km 0.380 0.364 0.348 0.321 0.307 0.295 0.287 0.278 0.270 Inductive Reactance,   @ 50Hz Ohm/km 0.119 0.114 0.109 0.101 0.0964 0.0926 0.0900 0.0874 0.0847 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+  j0.0720 2.16+   j0.0671 1.56+   j0.0624 1.11+   j0.0542 1.03+  j0.0499 0.995+  j0.0463 0.966+  j0.0440 0.941+  j0.0415 0.917+  j0.0390 Capacitance, phase   to earth µF/km 0.319 0.352 0.391 0.449 0.509 0.558 0.607 0.668 0.745 Min insulation   resistance @ 20°C   MOhm.km 8,200 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric stress at   conductor screen   kV/mm 1.19 1.17 1.14 1.11 1.09 1.08 1.07 1.06 1.04 Charging current @  rated voltage & 50 Hz   A/phase/km 0.190 0.210 0.234 0.268 0.304 0.333 0.362 0.399 0.445 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 140 165 195 240 290 335 365 410 475 In ground,   in singleway  ducts   A 120 140 165 205 240 275 310 350 400 In free air,   unenclosed   & spaced   from wall   A 135 160 190 240 290 340 380 435 510 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 19 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 20 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Single core light duty screened unarmoured Product code: 1CALX3LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx cable   diameter mm 18.6 19.6 20.6 22.3 24.0 25.4 26.7 28.5 30.8 33.5 37.2 40.9 45.1 Approx mass   kg/100m 45 55 60 70 80 90 100 110 135 155 190 225 280 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.2 1.3 1.5 1.7 2.0 2.3 2.5 2.8 3.3 3.9 4.8 5.8 7.1 Min bending radius   during installation mm 330 350 370 400 430 460 480 510 550 600 670 740 810 Min bending radius   set in position mm 220 240 250 270 290 300 320 340 370 400 450 490 540 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 0.102 0.0805 0.0640 Inductance, trefoil  touching mH/km 0.449 0.427 0.409 0.377 0.359 0.347 0.337 0.323 0.313 0.303 0.298 0.292 0.285 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.141 0.134 0.129 0.118 0.113 0.109 0.106 0.101 0.0983 0.0953 0.0935 0.0916 0.0896 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0720 1.80+  j0.0665 1.57+  j0.0623 1.38+  j0.0540 1.25+  j0.0498 1.19+  j0.0471 1.14+  j0.0448 1.10+  j0.0415 1.06+  j0.0390 1.03+  j0.0367 1.01+  j0.0357 0.996+  j0.0344 0.982+  j0.0332 Capacitance, phase   to earth µF/km 0.316 0.353 0.388 0.448 0.507 0.554 0.601 0.663 0.737 0.824 0.943 0.962 0.993 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 1.02 0.929 0.850 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.211 0.232 0.267 0.303 0.331 0.359 0.395 0.440 0.492 0.563 0.574 0.593 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 295 330 385 430 495 560 635 In ground,   in singleway  ducts   A 115 135 155 190 225 255 285 320 365 410 465 525 595 In free air,   unenclosed   & spaced   from wall   A 110 135 160 200 245 285 320 370 440 505 595 695 810 21 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 22 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Single core heavy duty screened unarmoured Product code: 1CALX3HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.2 2.4 Approx cable   diameter mm 18.6 19.6 21.9 23.6 25.3 26.7 28.0 30.0 32.1 34.8 38.5 42.2 46.4 Approx mass   kg/100m 45 55 70 95 120 135 145 160 180 200 235 270 325 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.2 1.3 1.7 2.0 2.2 2.5 2.8 3.1 3.6 4.2 5.2 6.2 7.5 Min bending radius   during installation mm 330 350 390 430 460 480 500 540 580 630 690 760 840 Min bending radius   set in position mm 220 240 260 280 300 320 340 360 390 420 460 510 560 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0804 0.0638 Inductance, trefoil  touching mH/km 0.449 0.427 0.422 0.389 0.370 0.357 0.347 0.334 0.322 0.311 0.305 0.298 0.291 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.141 0.134 0.133 0.122 0.116 0.112 0.109 0.105 0.101 0.0978 0.0958 0.0936 0.0915 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0720 1.71+  j0.0665 1.24+  j0.0649 0.871+  j0.0563 0.635+  j0.0519 0.535+  j0.0490 0.488+  j0.0466 0.446+  j0.0432 0.407+  j0.0405 0.382+  j0.0381 0.360+  j0.0369 0.343+  j0.0356 0.330+  j0.0342 Capacitance, phase   to earth µF/km 0.316 0.353 0.388 0.448 0.507 0.554 0.601 0.663 0.737 0.824 0.943 0.962 0.993 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 2,700 2,600 2,500 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 1.02 0.929 0.850 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.211 0.232 0.267 0.303 0.331 0.359 0.395 0.440 0.492 0.563 0.574 0.593 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 290 330 375 425 480 545 610 In ground,   in singleway  ducts   A 115 135 155 190 220 245 270 300 335 375 415 465 520 In free air,   unenclosed   & spaced   from wall   A 110 135 165 205 250 285 325 370 435 505 585 680 785 23 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 24 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core light duty screened unarmoured Product code: 3CALX3LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 35.9 38.4 40.7 44.6 48.6 51.8 54.9 58.8 63.9 69.5 Approx mass   kg/100m 110 130 150 180 215 250 290 335 410 490 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.2 5.8 7.0 8.3 9.4 11 12 14 17 Min bending radius   during installation mm 650 690 730 800 880 930 990 1060 1150 1250 Min bending radius   set in position mm 430 460 490 540 580 620 660 710 770 830 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 0.262 Inductive reactance,   @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 0.0824 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.84+  j0.0722 3.60+  j0.0668 3.37+  j0.0626 3.18+  j0.0542 3.05+  j0.0499 2.78+  j0.0472 2.55+  j0.0449 2.35+  j0.0416 2.18+  j0.0391 1.92+  j0.0368 Capacitance, phase   to earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 0.827 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 0.494 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.3 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.6 Contin- uous  current  rating In ground, direct buried   A 110 125 150 185 225 255 285 320 375 420 In ground,   in singleway  ducts   A 90 110 130 160 185 215 245 270 315 365 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 215 255 290 335 400 460 25 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 26 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core light duty screened armoured Product code: 3CALX3LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 43.0 45.4 49.6 53.4 57.5 60.9 64.0 68.2 73.4 Approx mass   kg/100m 270 300 375 425 485 540 595 665 770 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 10.0 12 13 14 16 19 Max pulling tension   on armour wires kN 7.4 8.3 9.8 11 13 15 17 19 22 Min bending radius   during installation mm 770 820 890 960 1040 1100 1150 1230 1320 Min bending radius   set in position mm 520 550 590 640 690 730 770 820 880 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 Inductive reactance,   @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.84+  j0.0722 3.60+  j0.0668 3.37+  j0.0626 3.18+   j0.0542 3.05+  j0.0499 2.78+  j0.0472 2.55+  j0.0449 2.35+   j0.0416 2.18+   j0.0391 Capacitance, phase   to earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.3 3.0 3.0 3.0 3.0 3.3 3.5 3.8 4.0 Contin- uous  current  rating In ground, direct buried   A 110 125 150 185 225 255 285 320 375 In ground,   in singleway  ducts   A 90 110 130 160 185 215 245 270 315 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 215 255 290 335 400 27 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 28 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core heavy duty screened unarmoured Product code: 3CALX3HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 35.9 38.4 40.7 44.8 48.6 51.8 54.9 58.8 63.9 69.5 Approx mass   kg/100m 110 130 160 205 255 290 330 375 445 520 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.2 5.8 7.0 8.3 9.4 11 12 14 17 Min bending radius   during installation mm 650 690 730 810 880 930 990 1060 1150 1250 Min bending radius   set in position mm 430 460 490 540 580 620 660 710 770 830 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 0.262 Inductive reactance,   @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 0.0824 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0722 3.39+  j0.0668 2.37+  j0.0626 1.70+  j0.0542 1.26+  j0.0499 1.09+  j0.0472 1.05+  j0.0449 1.01+  j0.0416 0.967+  j0.0391 0.942+  j0.0368 Capacitance, phase   to earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 0.827 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 3,000 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 1.03 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 0.494 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.5 3.3 4.8 6.6 8.9 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 125 150 185 225 255 285 320 375 420 In ground,   in singleway  ducts   A 90 110 130 160 185 215 240 270 315 360 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 265 300 340 400 465 29 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 30 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 1.9/3.3kV – Three core heavy duty screened armoured Product code: 3CALX3HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 Approx cable   diameter mm 43.0 45.4 49.6 53.6 57.5 60.9 64.2 68.4 73.4 Approx mass   kg/100m 270 300 385 455 520 580 640 705 810 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 10 12 13 14 16 19 Max pulling tension   on armour wires kN 7.4 8.3 9.8 12 13 15 17 19 22 Min bending radius   during installation mm 770 820 890 970 1040 1100 1160 1230 1320 Min bending radius   set in position mm 520 550 590 640 690 730 770 820 880 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.381 0.363 0.349 0.321 0.307 0.298 0.290 0.279 0.270 Inductive reactance,   @ 50Hz Ohm/km 0.120 0.114 0.110 0.101 0.0964 0.0935 0.0910 0.0875 0.0849 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0722 3.39+  j0.0668 2.37+  j0.0626 1.70+   j0.0542 1.26+   j0.0499 1.09+   j0.0472 1.05+  j0.0449 1.01+   j0.0416 0.967+  j0.0391 Capacitance, phase   to earth µF/km 0.317 0.354 0.390 0.449 0.509 0.556 0.604 0.665 0.740 Min insulation   resistance @ 20°C   MOhm.km 8,300 7,300 6,600 5,700 5,000 4,600 4,200 3,800 3,400 Electric stress at   conductor screen   kV/mm 1.19 1.16 1.14 1.11 1.09 1.08 1.07 1.06 1.05 Charging current @  rated voltage & 50 Hz   A/phase/km 0.189 0.212 0.233 0.268 0.304 0.332 0.360 0.397 0.442 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.5 3.3 4.8 6.6 8.9 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 125 150 185 225 255 285 320 375 In ground,   in singleway  ducts   A 90 110 130 160 185 215 240 270 315 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 265 300 340 400 31 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 32 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Single core light duty screened unarmoured Product code: 1CCUX6LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx cable   diameter mm 19.6 20.6 21.7 23.3 25.0 26.4 27.8 29.8 32.2 35.1 39.2 43.1 47.0 Approx mass   kg/100m 70 80 90 115 140 165 190 230 285 350 440 550 685 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.3 1.5 1.6 1.9 2.2 2.4 2.7 3.1 3.6 4.3 5.4 6.5 7.7 Min bending radius   during installation mm 350 370 390 420 450 480 500 540 580 630 700 770 850 Min bending radius   set in position mm 240 250 260 280 300 320 330 360 390 420 470 520 560 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0982 0.0793 0.0633 0.0510 0.0416 Inductance, trefoil  touching mH/km 0.459 0.439 0.418 0.386 0.367 0.352 0.341 0.331 0.320 0.313 0.307 0.301 0.293 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.144 0.138 0.131 0.121 0.115 0.110 0.107 0.104 0.101 0.0984 0.0965 0.0946 0.0922 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.66+  j0.0761 1.46+  j0.0710 1.32+  j0.0660 1.20+  j0.0575 1.13+  j0.0530 1.09+  j0.0491 1.06+  j0.0466 1.03+  j0.0439 1.01+  j0.0417 0.995+  j0.0401 0.982+  j0.0391 0.973+  j0.0375 0.965+  j0.0356 Capacitance, phase   to earth µF/km 0.266 0.292 0.324 0.371 0.418 0.458 0.497 0.546 0.586 0.607 0.651 0.682 0.762 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 1.41 1.32 1.30 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.349 0.387 0.443 0.499 0.546 0.593 0.651 0.699 0.725 0.777 0.814 0.910 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 145 175 205 250 295 335 375 425 490 550 620 700 780 In ground,   in singleway  ducts   A 145 170 200 245 285 325 360 400 460 510 575 645 720 In free air,   unenclosed   & spaced   from wall   A 145 175 210 260 320 365 415 480 565 650 755 870 995 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 33 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 34 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Single core heavy duty screened unarmoured Product code: 1CCUX6HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx cable   diameter mm 19.6 21.9 23.0 25.3 27.0 27.7 29.1 31.1 33.7 36.6 40.7 44.4 48.3 Approx mass   kg/100m 75 95 120 160 185 210 240 275 335 395 485 595 730 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.3 1.7 1.8 2.2 2.6 2.7 3.0 3.4 4.0 4.7 5.8 6.9 8.1 Min bending radius   during installation mm 350 390 410 460 490 500 520 560 610 660 730 800 870 Min bending radius   set in position mm 240 260 280 300 320 330 350 370 400 440 490 530 580 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 0.0631 0.0508 0.0414 Inductance, trefoil  touching mH/km 0.459 0.451 0.431 0.403 0.383 0.362 0.350 0.340 0.330 0.322 0.315 0.307 0.299 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.144 0.142 0.135 0.127 0.120 0.114 0.110 0.107 0.104 0.101 0.0990 0.0965 0.0940 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.51+  j0.0761 1.09+  j0.0736 0.783+  j0.0684 0.560+  j0.0608 0.485+  j0.0560 0.435+  j0.0510 0.406+  j0.0483 0.381+  j0.0456 0.358+  j0.0432 0.343+  j0.0415 0.330+  j0.0403 0.320+  j0.0385 0.312+  j0.0366 Capacitance, phase   to earth µF/km 0.266 0.292 0.324 0.371 0.418 0.458 0.497 0.546 0.586 0.607 0.651 0.682 0.762 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 1.41 1.32 1.30 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.349 0.387 0.443 0.499 0.546 0.593 0.651 0.699 0.725 0.777 0.814 0.910 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 145 175 205 250 295 335 370 415 475 530 595 665 735 In ground,   in singleway  ducts   A 145 170 195 235 270 300 330 360 405 445 495 545 600 In free air,   unenclosed   & spaced   from wall   A 145 180 210 265 320 365 415 475 555 635 730 835 950 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 35 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 36 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core light duty screened unarmoured Product code: 3CCUX6LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx cable   diameter mm 38.3 40.5 43.2 46.9 50.8 54.0 57.4 61.4 66.8 73.3 Approx mass   kg/100m 170 210 250 320 405 485 575 695 880 1080 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 5.1 5.8 6.5 7.7 9.0 10 12 13 16 19 Min bending radius   during installation mm 690 730 780 840 910 970 1030 1110 1200 1320 Min bending radius   set in position mm 460 490 520 560 610 650 690 740 800 880 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 0.0797 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 0.273 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 0.0857 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+  j0.0764 3.26+  j0.0713 3.12+  j0.0662 3.00+  j0.0577 2.72+  j0.0531 2.50+  j0.0493 2.47+  j0.0467 2.29+  j0.0441 2.13+  j0.0418 1.88+  j0.0402 Capacitance, phase   to earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 0.610 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 Charging current @  rated voltage & 50 Hz   A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 0.728 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 4.6 Contin- uous  current  rating In ground, direct buried   A 140 170 200 245 290 325 365 410 465 530 In ground,   in singleway  ducts   A 125 140 170 205 240 280 310 350 405 450 In free air,   unenclosed   & spaced   from wall   A 140 160 190 230 290 335 380 430 510 590 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 37 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 38 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core light duty screened armoured Product code: 3CCUX6LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx cable   diameter mm 45.4 49.2 51.8 55.8 60.2 63.4 66.8 70.8 78.0 Approx mass   kg/100m 340 435 490 580 695 790 900 1040 1340 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.4 9.4 11 13 14 16 18 21 Max pulling tension   on amour wires kN 8.3 9.7 11 13 15 16 18 21 25 Min bending radius   during installation mm 820 890 930 1000 1080 1140 1200 1270 1400 Min bending radius   set in position mm 540 590 620 670 720 760 800 850 940 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+  j0.0764 3.26+  j0.0713 3.12+  j0.0662 3.00+  j0.0577 2.72+  j0.0531 2.50+  j0.0493 2.47+  j0.0467 2.29+  j0.0441 2.13+  j0.0418 Capacitance, phase   to earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 Charging current @  rated voltage & 50 Hz   A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 Contin- uous  current  rating In ground, direct buried   A 140 170 200 245 290 325 365 410 465 In ground,   in singleway  ducts   A 125 140 170 205 240 280 310 350 405 In free air,   unenclosed   & spaced   from wall   A 140 160 190 230 290 335 380 430 510 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 39 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 40 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core heavy duty screened unarmoured Product code: 3CCUX6HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx cable   diameter mm 38.3 40.5 43.2 46.9 51.0 54.2 57.4 61.4 67.0 73.3 Approx mass   kg/100m 175 220 275 360 450 530 615 735 920 1120 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 5.1 5.8 6.5 7.7 9.1 10 12 13 16 19 Min bending radius   during installation mm 690 730 780 840 920 980 1030 1110 1210 1320 Min bending radius   set in position mm 460 490 520 560 610 650 690 740 800 880 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 0.0797 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 0.273 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 0.0857 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+  j0.0764 2.16+  j0.0713 1.56+  j0.0662 1.11+  j0.0577 1.03+  j0.0531 0.995+  j0.0493 0.966+  j0.0467 0.941+  j0.0441 0.917+  j0.0418 0.902+  j0.0402 Capacitance, phase   to earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 0.610 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 4,100 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 1.52 Charging current @  rated voltage & 50 Hz   A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 0.728 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 140 170 200 245 290 325 370 410 475 530 In ground,   in singleway  ducts   A 120 145 170 205 240 280 310 350 405 455 In free air,   unenclosed   & spaced   from wall   A 135 165 195 245 295 340 385 435 510 590 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 41 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 42 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 3.8/6.6kV – Three core heavy duty screened armoured Product code: 3CCUX6HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx cable   diameter mm 45.4 49.4 52.0 56.0 60.2 63.4 66.8 71.0 78.4 Approx mass   kg/100m 345 450 515 625 735 830 940 1080 1390 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.4 9.5 11 13 14 16 18 22 Max pulling tension   on amour wires kN 8.3 9.7 11 13 15 16 18 21 25 Min bending radius   during installation mm 820 890 940 1010 1080 1140 1200 1280 1410 Min bending radius   set in position mm 540 590 620 670 720 760 800 850 940 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0986 Inductance mH/km 0.393 0.377 0.360 0.332 0.317 0.304 0.295 0.286 0.278 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0954 0.0927 0.0899 0.0875 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+  j0.0764 2.16+  j0.0713 1.56+  j0.0662 1.11+  j0.0577 1.03+  j0.0531 0.995+  j0.0493 0.966+  j0.0467 0.941+  j0.0441 0.917+  j0.0418 Capacitance, phase   to earth µF/km 0.267 0.293 0.325 0.372 0.420 0.459 0.499 0.548 0.588 Min insulation   resistance @ 20°C   MOhm.km 9,700 8,800 8,000 6,900 6,100 5,500 5,100 4,600 4,300 Electric stress at   conductor screen   kV/mm 2.00 1.95 1.90 1.84 1.80 1.78 1.75 1.73 1.65 Charging current @  rated voltage & 50 Hz   A/phase/km 0.319 0.350 0.388 0.444 0.501 0.548 0.595 0.654 0.702 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 140 170 200 245 290 325 370 410 475 In ground,   in singleway  ducts   A 120 145 170 205 240 280 310 350 405 In free air,   unenclosed   & spaced   from wall   A 135 165 195 245 295 340 385 435 510 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 43 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 44 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Single core light duty screened unarmoured Product code: 1CALX6LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx cable   diameter mm 19.6 20.6 21.6 23.3 25.0 26.4 27.7 29.7 32.0 35.1 39.2 43.1 46.9 Approx mass   kg/100m 50 60 65 70 85 90 100 120 140 165 200 240 290 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.3 1.5 1.6 1.9 2.2 2.4 2.7 3.1 3.6 4.3 5.4 6.5 7.7 Min bending radius   during installation mm 350 370 390 420 450 470 500 530 580 630 700 770 840 Min bending radius   set in position mm 230 250 260 280 300 320 330 360 380 420 470 520 560 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0803 0.0638 Inductance, trefoil  touching mH/km 0.460 0.437 0.419 0.386 0.367 0.355 0.344 0.331 0.321 0.313 0.309 0.303 0.293 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.144 0.137 0.132 0.121 0.115 0.111 0.108 0.104 0.101 0.0984 0.0970 0.0950 0.0922 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0764 1.80+  j0.0706 1.57+  j0.0662 1.38+  j0.0575 1.25+  j0.0530 1.19+  j0.0500 1.14+  j0.0476 1.10+  j0.0441 1.06+  j0.0418 1.03+  j0.0401 1.01+  j0.0395 0.996+  j0.0379 0.982+  j0.0357 Capacitance, phase   to earth µF/km 0.265 0.295 0.323 0.371 0.418 0.456 0.494 0.543 0.582 0.607 0.651 0.682 0.761 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 1.41 1.32 1.30 Charging current @  rated voltage & 50 Hz   A/phase/km 0.316 0.352 0.385 0.443 0.499 0.545 0.590 0.648 0.695 0.725 0.777 0.814 0.909 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 295 330 385 435 495 560 640 In ground,   in singleway  ducts   A 115 135 155 190 225 255 285 320 365 410 465 530 595 In free air,   unenclosed   & spaced   from wall   A 110 135 160 200 245 285 325 375 440 510 600 695 810 45 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 46 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Single core heavy duty screened unarmoured Product code: 1CALX6LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 3.0 3.2 3.2 Approx cable   diameter mm 19.6 20.6 21.6 23.3 25.0 26.4 27.7 29.7 32.0 35.1 39.2 43.1 46.9 Approx mass   kg/100m 50 60 65 70 85 90 100 120 140 165 200 240 290 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.3 1.5 1.6 1.9 2.2 2.4 2.7 3.1 3.6 4.3 5.4 6.5 7.7 Min bending radius   during installation mm 350 370 390 420 450 470 500 530 580 630 700 770 840 Min bending radius   set in position mm 230 250 260 280 300 320 330 360 380 420 470 520 560 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0803 0.0638 Inductance, trefoil  touching mH/km 0.460 0.437 0.419 0.386 0.367 0.355 0.344 0.331 0.321 0.313 0.309 0.303 0.293 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.144 0.137 0.132 0.121 0.115 0.111 0.108 0.104 0.101 0.0984 0.0970 0.0950 0.0922 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0764 1.80+  j0.0706 1.57+  j0.0662 1.38+  j0.0575 1.25+  j0.0530 1.19+  j0.0500 1.14+  j0.0476 1.10+  j0.0441 1.06+  j0.0418 1.03+  j0.0401 1.01+  j0.0395 0.996+  j0.0379 0.982+  j0.0357 Capacitance, phase   to earth µF/km 0.265 0.295 0.323 0.371 0.418 0.456 0.494 0.543 0.582 0.607 0.651 0.682 0.761 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 3,800 3,700 3,300 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 1.41 1.32 1.30 Charging current @  rated voltage & 50 Hz   A/phase/km 0.316 0.352 0.385 0.443 0.499 0.545 0.590 0.648 0.695 0.725 0.777 0.814 0.909 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 295 330 385 435 495 560 640 In ground,   in singleway  ducts   A 115 135 155 190 225 255 285 320 365 410 465 530 595 In free air,   unenclosed   & spaced   from wall   A 110 135 160 200 245 285 325 375 440 510 600 695 810 47 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 48 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core light duty screened unarmoured Product code: 3CALX6LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx cable   diameter mm 38.3 40.7 43.1 46.9 50.8 53.9 57.2 61.2 66.5 73.3 Approx mass   kg/100m 120 140 160 195 230 265 305 355 430 525 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 6.5 7.7 9.0 10 11 13 15 19 Min bending radius   during installation mm 690 730 780 840 910 970 1030 1100 1200 1320 Min bending radius   set in position mm 460 490 520 560 610 650 690 730 800 880 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 0.273 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 0.0857 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.84+  j0.0766 3.60+  j0.0709 3.37+  j0.0664 3.18+  j0.0577 2.84+  j0.0531 2.60+  j0.0502 2.55+  j0.0477 2.35+  j0.0442 2.18+  j0.0420 1.92+  j0.0402 Capacitance, phase   to earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 0.610 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 0.728 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.3 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 4.6 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 320 370 420 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 360 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 255 290 330 395 450 49 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 50 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core light duty screened armoured Product code: 3CALX6LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx cable   diameter mm 45.3 49.4 51.7 55.8 60.2 63.3 66.6 70.5 77.7 Approx mass   kg/100m 290 365 400 455 520 565 630 700 895 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 11 13 14 16 17 21 Max pulling tension   on amour wires kN 8.3 9.8 11 13 15 16 18 20 25 Min bending radius   during installation mm 820 890 930 1000 1080 1140 1200 1270 1400 Min bending radius   set in position mm 540 590 620 670 720 760 800 850 930 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.84+  j0.0766 3.60+  j0.0709 3.37+  j0.0664 3.18+   j0.0577 2.84+   j0.0531 2.60+  j0.0502 2.55+  j0.0477 2.35+  j0.0442 2.18+   j0.0420 Capacitance, phase   to earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.3 3.0 3.0 3.0 3.3 3.5 3.5 3.8 4.0 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 320 370 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 255 290 330 395 51 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page. Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 52 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core heavy duty screened unarmoured Product code: 3CALX6HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.8 Approx cable   diameter mm 38.3 40.7 43.1 46.9 51.0 54.1 57.2 61.2 66.7 73.3 Approx mass   kg/100m 120 145 170 215 270 305 345 395 470 560 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 6.5 7.7 9.1 10 11 13 16 19 Min bending radius   during installation mm 690 730 780 840 920 970 1030 1100 1200 1320 Min bending radius   set in position mm 460 490 520 560 610 650 690 730 800 880 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 0.273 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 0.0857 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0766 3.39+  j0.0709 2.46+  j0.0664 1.70+  j0.0577 1.26+  j0.0531 1.09+  j0.0502 1.05+  j0.0477 1.01+  j0.0442 0.967+  j0.0420 0.942+  j0.0402 Capacitance, phase   to earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 0.610 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 4,100 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 1.52 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 0.728 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.5 3.3 4.6 6.6 8.9 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 325 375 420 In ground,   in singleway  ducts   A 95 110 130 160 190 215 240 275 320 365 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 225 260 300 340 405 460 53 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 54 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 3.8/6.6kV – Three core heavy duty screened armoured Product code: 3CALX6HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 Approx cable   diameter mm 45.3 49.4 51.9 56.0 60.2 63.3 66.6 70.7 78.1 Approx mass   kg/100m 290 370 415 480 555 605 670 740 940 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 11 13 14 16 18 21 Max pulling tension   on amour wires kN 8.3 9.8 11 13 15 16 18 21 25 Min bending radius   during installation mm 820 890 930 1010 1080 1140 1200 1270 1410 Min bending radius   set in position mm 540 590 620 670 720 760 800 850 940 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.394 0.375 0.360 0.332 0.317 0.307 0.298 0.287 0.279 Inductive Reactance,   @ 50Hz Ohm/km 0.124 0.118 0.113 0.104 0.0994 0.0964 0.0937 0.0901 0.0876 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0766 3.39+  j0.0709 2.46+  j0.0664 1.70+   j0.0577 1.26+   j0.0531 1.09+  j0.0502 1.05+   j0.0477 1.01+   j0.0442 0.967+  j0.0420 Capacitance, phase   to earth µF/km 0.266 0.296 0.324 0.372 0.420 0.458 0.496 0.545 0.584 Min insulation   resistance @ 20°C   MOhm.km 9,900 8,800 8,000 6,900 6,100 5,600 5,100 4,600 4,300 Electric stress at   conductor screen   kV/mm 2.00 1.94 1.90 1.84 1.80 1.78 1.76 1.73 1.65 Charging current @  rated voltage & 50 Hz   A/phase/km 0.317 0.353 0.387 0.444 0.501 0.547 0.592 0.650 0.697 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.5 3.3 4.6 6.6 8.9 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 325 375 In ground,   in singleway  ducts   A 95 110 130 160 190 215 240 275 320 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 225 260 300 340 405 55 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 56 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Single core light duty screened unarmoured Product code: 1CCUX11LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 21.4 22.4 23.5 25.1 26.8 28.2 29.8 31.6 34.0 36.7 40.4 43.7 47.6 Approx mass   kg/100m 75 85 100 120 150 175 200 240 295 360 445 555 690 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.6 1.7 1.9 2.2 2.5 2.8 3.1 3.5 4.0 4.7 5.7 6.7 7.9 Min bending radius   during installation mm 390 400 420 450 480 510 540 570 610 660 730 790 860 Min bending radius   set in position mm 260 270 280 300 320 340 360 380 410 440 480 520 570 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 0.0632 0.0509 0.0415 Inductance, trefoil  touching mH/km 0.477 0.456 0.435 0.402 0.382 0.365 0.355 0.343 0.332 0.322 0.314 0.304 0.296 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.150 0.143 0.137 0.126 0.120 0.115 0.112 0.108 0.104 0.101 0.0985 0.0955 0.0930 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.66+  j0.0833 1.46+  j0.0778 1.32+  j0.0724 1.20+  j0.0633 1.13+  j0.0583 1.09+  j0.0541 1.06+  j0.0513 1.03+  j0.0483 1.01+  j0.0453 0.995+  j0.0430 0.982+  j0.0409 0.973+  j0.0385 0.965+  j0.0366 Capacitance, phase   to earth µF/km 0.211 0.230 0.254 0.289 0.324 0.353 0.382 0.418 0.463 0.516 0.586 0.650 0.725 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.460 0.507 0.576 0.646 0.704 0.762 0.834 0.924 1.03 1.17 1.30 1.45 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 145 175 205 250 300 335 375 425 490 550 620 700 780 In ground,   in singleway  ducts   A 145 170 200 245 285 325 360 400 460 515 575 645 720 In free air,   unenclosed   & spaced   from wall   A 145 175 210 265 320 370 420 480 570 650 755 870 995 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 57 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 58 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Single core heavy duty screened unarmoured Product code: 1CCUX11HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 21.4 23.7 24.8 27.1 28.1 29.5 31.1 32.9 35.3 38.0 41.7 45.0 48.9 Approx mass   kg/100m 80 100 125 165 195 220 245 285 340 405 495 600 735 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 1.6 2.0 2.1 2.6 2.8 3.1 3.4 3.8 4.4 5.1 6.1 7.1 8.4 Min bending radius   during installation mm 390 430 450 490 510 530 560 590 630 680 750 810 880 Min bending radius   set in position mm 260 280 300 330 340 350 370 390 420 460 500 540 590 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0980 0.0790 0.0630 0.0507 0.0413 Inductance, trefoil  touching mH/km 0.477 0.468 0.447 0.418 0.392 0.375 0.364 0.352 0.339 0.330 0.320 0.310 0.302 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.150 0.147 0.140 0.131 0.123 0.118 0.114 0.110 0.107 0.104 0.101 0.0974 0.0948 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.51+  j0.0833 1.09+  j0.0801 0.783+  j0.0745 0.560+  j0.0663 0.475+  j0.0601 0.435+  j0.0559 0.406+  j0.0529 0.381+  j0.0498 0.358+  j0.0467 0.343+  j0.0443 0.330+  j0.0421 0.320+  j0.0395 0.312+  j0.0375 Capacitance, phase   to earth µF/km 0.211 0.230 0.254 0.289 0.324 0.353 0.382 0.418 0.463 0.516 0.586 0.650 0.725 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.460 0.507 0.576 0.646 0.704 0.762 0.834 0.924 1.03 1.17 1.30 1.45 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.5 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 145 175 205 250 295 335 370 415 475 530 595 665 735 In ground,   in singleway  ducts   A 145 170 195 235 270 300 330 365 410 450 495 545 600 In free air,   unenclosed   & spaced   from wall   A 145 180 215 270 320 370 420 480 560 640 735 835 950 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 59 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 60 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Three core light duty screened unarmoured Product code: 3CCUX11LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 42.6 44.6 47.3 51.2 55.1 58.3 61.5 65.5 70.6 76.3 Approx mass   kg/100m 195 230 270 345 440 520 610 730 915 1110 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.0 7.8 9.2 11 12 13 15 17 20 Min bending radius   during installation mm 770 800 850 920 990 1050 1110 1180 1270 1370 Min bending radius   set in position mm 510 540 570 610 660 700 740 790 850 920 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 0.0796 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 0.282 Inductive reactance,   @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 0.0885 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+  j0.0836 3.26+   j0.0781 3.12+   j0.0726 2.79+   j0.0635 2.54+   j0.0585 2.34+   j0.0543 2.17+   j0.0515 2.03+   j0.0485 1.90+   j0.0454 1.70+   j0.0431 Capacitance, phase   to earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 0.518 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging current @  rated voltage & 50 Hz   A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 1.03 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 5.1 Contin- uous  current  rating In ground, direct buried   A 140 165 195 235 280 325 365 410 475 530 In ground,   in singleway  ducts   A 120 145 170 205 240 280 310 350 405 455 In free air,   unenclosed   & spaced   from wall   A 135 160 190 235 285 330 380 435 510 580 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 61 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench  62 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Three core light duty screened armoured Product code: 3CCUX11LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 51.3 53.5 56.3 60.4 64.2 67.7 71.1 75.2 82.1 Approx mass   kg/100m 430 475 535 630 745 850 955 1100 1400 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.4 11 13 14 16 18 20 24 Max pulling tension   on amour wires kN 11 12 13 15 17 19 21 23 25 Min bending radius   during installation mm 920 960 1010 1090 1160 1220 1280 1350 1480 Min bending radius   set in position mm 620 640 680 720 770 810 850 900 980 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 Inductive reactance,   @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.46+   j0.0836 3.26+   j0.0781 3.12+   j0.0726 2.79+   j0.0635 2.54+   j0.0585 2.34+   j0.0543 2.17+   j0.0515 2.03+   j0.0485 1.90+   j0.0454 Capacitance, phase   to earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging current @  rated voltage & 50 Hz   A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 Contin- uous  current  rating In ground, direct buried   A 140 165 195 235 280 325 365 410 475 In ground,   in singleway  ducts   A 120 145 170 205 240 280 310 350 405 In free air,   unenclosed   & spaced   from wall   A 135 160 190 235 285 330 380 435 510 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 63 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 64 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Three core heavy duty screened unarmoured Product code: 3CCUX11HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 42.6 44.8 47.5 51.2 55.1 58.3 61.5 65.5 70.6 76.3 Approx mass   kg/100m 195 245 300 390 480 560 645 765 945 1140 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.0 7.9 9.2 11 12 13 15 17 20 Min bending radius   during installation mm 770 810 850 920 990 1050 1110 1180 1270 1370 Min bending radius   set in position mm 510 540 570 610 660 700 740 790 850 920 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 0.0796 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 0.282 Inductive reactance,   @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 0.0885 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+   j0.0836 2.16+   j0.0781 1.56+   j0.0726 1.11+   j0.0635 1.03+   j0.0585 0.995+   j0.0543 0.966+   j0.0515 0.941+   j0.0485 0.917+   j0.0454 0.902+   j0.0431 Capacitance, phase   to earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 0.518 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging current @  rated voltage & 50 Hz   A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 1.03 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 135 165 195 245 290 330 370 410 475 530 In ground,   in singleway  ducts   A 120 145 170 205 245 280 310 350 410 460 In free air,   unenclosed   & spaced   from wall   A 135 165 195 245 295 345 385 440 520 290 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 65 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 6.35/11kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 66 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 6.35/11kV – Three core heavy duty screened armoured Product code: 3CCUX11HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 51.3 53.7 56.3 60.4 64.4 67.9 71.3 76.7 82.1 Approx mass   kg/100m 430 495 560 675 795 890 995 1220 1440 Max pulling tension   on conductors kN 5.3 7.4 11 15 20 25 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.4 11 13 15 16 18 21 24 Max pulling tension   on amour wires kN 11 12 13 15 17 19 21 24 25 Min bending radius   during installation mm 920 970 1010 1090 1160 1220 1280 1380 1480 Min bending radius   set in position mm 620 640 680 720 770 810 860 920 980 Max conductor   resistance, dc @ 20°C   Ohm/km 0.727 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.927 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0984 Inductance mH/km 0.415 0.397 0.379 0.350 0.333 0.319 0.310 0.300 0.290 Inductive reactance,   @ 50Hz Ohm/km 0.130 0.125 0.119 0.110 0.105 0.100 0.0973 0.0942 0.0910 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.07+   j0.0836 2.16+   j0.0781 1.56+   j0.0726 1.11+   j0.0635 1.03+   j0.0585 0.995+   j0.0543 0.966+   j0.0515 0.941+   j0.0485 0.917+   j0.0454 Capacitance, phase   to earth µF/km 0.212 0.231 0.255 0.290 0.325 0.354 0.383 0.419 0.465 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric stress at   conductor screen   kV/mm 2.64 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging current @  rated voltage & 50 Hz   A/phase/km 0.422 0.461 0.509 0.578 0.648 0.706 0.764 0.837 0.927 Short  circuit  rating Phase   conductor kA, 1 sec 3.6 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 Metallic  screen kA, 1 sec 3.5 5.1 7.1 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 135 165 195 245 290 330 370 410 475 In ground,   in singleway  ducts   A 120 145 170 205 245 280 310 350 410 In free air,   unenclosed   & spaced   from wall   A 135 165 195 245 295 345 385 440 520 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 67 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 68 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Single core light duty screened unarmoured Product code: 1CALX11LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 21.4 22.4 23.4 25.1 26.8 28.2 29.7 31.5 33.8 36.7 40.4 43.7 47.5 Approx mass   kg/100m 55 65 70 80 90 100 110 125 150 175 210 245 295 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.3 1.8 1.9 2.2 2.5 2.8 3.1 3.5 4.0 4.7 5.7 6.7 7.9 Min bending radius   during installation mm 380 400 420 450 480 510 540 570 610 660 730 790 860 Min bending radius   set in position mm 260 270 280 300 320 340 360 380 410 440 480 520 570 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0803 0.0637 Inductance, trefoil  touching mH/km 0.478 0.455 0.436 0.402 0.382 0.369 0.359 0.344 0.332 0.322 0.315 0.305 0.296 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.150 0.143 0.137 0.126 0.120 0.116 0.113 0.108 0.104 0.101 0.0990 0.0960 0.0930 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0836 1.80+  j0.0774 1.57+  j0.0726 1.38+  j0.0633 1.25+  j0.0583 1.19+  j0.0551 1.14+  j0.0523 1.10+  j0.0485 1.06+  j0.0454 1.03+  j0.0430 1.01+  j0.0413 0.996+  j0.0389 0.982+  j0.0366 Capacitance, phase   to earth µF/km 0.210 0.232 0.253 0.289 0.324 0.352 0.380 0.416 0.460 0.516 0.586 0.650 0.724 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging current @  rated voltage & 50 Hz   A/phase/km 0.419 0.463 0.505 0.576 0.646 0.702 0.758 0.830 0.918 1.03 1.17 1.30 1.44 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 295 330 385 435 495 560 640 In ground,   in singleway  ducts   A 115 135 155 190 225 255 285 320 365 410 465 530 595 In free air,   unenclosed   & spaced   from wall   A 115 135 165 205 250 285 325 375 445 510 600 700 810 69 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 70 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Single core heavy duty screened unarmoured Product code: 1CALX11HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 21.4 22.4 24.7 26.4 28.1 29.5 31.0 32.8 35.1 38.0 41.7 45.0 48.8 Approx mass   kg/100m 55 65 80 100 130 145 155 170 195 220 255 290 340 Max pulling tension   on conductor kN 1.3 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.3 1.8 2.1 2.4 2.8 3.0 3.4 3.8 4.3 5.1 6.1 7.1 8.3 Min bending radius   during installation mm 380 400 450 480 510 530 560 590 630 680 750 810 880 Min bending radius   set in position mm 260 270 300 320 340 350 370 390 420 460 500 540 590 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0802 0.0636 Inductance, trefoil  touching mH/km 0.478 0.455 0.447 0.412 0.392 0.378 0.368 0.352 0.340 0.330 0.322 0.312 0.302 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.150 0.143 0.141 0.129 0.123 0.119 0.116 0.111 0.107 0.104 0.101 0.0979 0.0948 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.37+  j0.0836 1.71+  j0.0774 1.24+  j0.0747 0.871+  j0.0653 0.635+  j0.0601 0.535+  j0.0568 0.488+  j0.0539 0.446+  j0.0500 0.407+  j0.0469 0.382+  j0.0443 0.360+  j0.0425 0.343+  j0.0400 0.330+  j0.0376 Capacitance, phase   to earth µF/km 0.210 0.232 0.253 0.289 0.324 0.352 0.380 0.416 0.460 0.516 0.586 0.650 0.724 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 4,300 3,900 3,400 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 2.11 2.08 2.06 Charging current @  rated voltage & 50 Hz   A/phase/km 0.419 0.463 0.505 0.576 0.646 0.702 0.758 0.830 0.918 1.03 1.17 1.30 1.44 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 2.4 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 115 135 160 195 230 260 290 330 380 425 480 545 615 In ground,   in singleway  ducts   A 115 135 155 190 220 245 270 300 340 375 420 470 525 In free air,   unenclosed   & spaced   from wall   A 115 135 165 210 250 290 330 375 440 510 590 685 790 71 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 72 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core light duty screened unarmoured Product code: 3CALX11LD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 42.3 44.8 47.2 51.2 55.1 58.2 61.3 65.3 70.3 76.3 Approx mass   kg/100m 140 160 185 220 265 295 340 390 465 550 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 9.2 11 12 13 15 17 20 Min bending radius   during installation mm 760 810 850 920 990 1050 1100 1170 1270 1370 Min bending radius   set in position mm 510 540 570 610 660 700 740 780 840 920 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 0.282 Inductive reactance,   @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 0.0885 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0839 3.60+  j0.0777 3.37+  j0.0728 2.97+  j0.0635 2.66+  j0.0585 2.44+  j0.0553 2.26+  j0.0525 2.09+  j0.0487 1.95+  j0.0456 1.74+  j0.0431 Capacitance, phase   to earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 0.518 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 1.03 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.5 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 5.1 Contin- uous  current  rating In ground, direct buried   A 110 130 155 185 220 250 285 325 370 420 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 360 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 255 290 340 400 460 73 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 74 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core light duty screened armoured Product code: 3CALX11LDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 51.2 53.7 56.2 60.4 64.2 67.5 70.9 75.0 81.8 Approx mass   kg/100m 375 415 450 505 570 625 685 760 960 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 11 14 16 18 20 23 Max pulling tension   on amour wires kN 11 12 13 15 17 19 21 23 25 Min bending radius   during installation mm 920 970 1010 1090 1160 1220 1280 1350 1470 Min bending radius   set in position mm 610 640 670 720 770 810 850 900 980 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 Inductive reactance,   @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.48+  j0.0839 3.60+  j0.0777 3.37+  j0.0728 2.97+  j0.0635 2.66+  j0.0585 2.44+  j0.0553 2.26+  j0.0525 2.09+  j0.0487 1.95+  j0.0456 Capacitance, phase   to earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.5 3.0 3.0 3.3 3.5 3.8 4.0 4.3 4.6 Contin- uous  current  rating In ground, direct buried   A 110 130 155 185 220 250 285 325 370 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 In free air,   unenclosed   & spaced   from wall   A 105 125 145 180 220 255 290 340 400 75 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 76 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core heavy duty screened unarmoured Product code: 3CALX11HD Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 42.5 44.8 47.4 51.2 55.1 58.2 61.3 65.3 70.3 76.3 Approx mass   kg/100m 145 165 195 240 300 335 375 425 500 585 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 9.2 11 12 13 15 17 20 Min bending radius   during installation mm 770 810 850 920 990 1050 1100 1170 1270 1370 Min bending radius   set in position mm 510 540 570 610 660 700 740 780 840 920 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 0.130 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 0.282 Inductive reactance,   @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 0.0885 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.18+  j0.0839 3.39+  j0.0777 2.46+  j0.0728 1.70+  j0.0635 1.26+  j0.0585 1.09+  j0.0553 1.05+  j0.0525 1.01+  j0.0487 0.967+  j0.0456 0.942+  j0.0431 Capacitance, phase   to earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 0.518 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 4,900 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 2.14 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 1.03 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 2.8 3.3 4.6 6.6 8.9 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 325 370 420 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 360 In free air,   unenclosed   & spaced   from wall   A 105 130 150 190 230 265 300 345 405 465 77 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 78 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 6.35/11kV – Three core heavy duty screened armoured Product code: 3CALX11HDA Nominal conductor   area mm 2 25 35 50 70 95 120 150 185 240 Nominal conductor  diameter mm 6.1 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 Nominal insulation  thickness mm 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 Approx cable   diameter mm 51.2 53.7 56.2 60.4 64.4 67.7 71.1 76.5 81.8 Approx mass   kg/100m 380 415 460 525 610 665 725 880 990 Max pulling tension   on conductors kN 3.8 5.3 7.5 11 14 18 23 25 25 Max pulling tension   on stocking grip kN 3.8 5.3 7.5 11 14 16 18 20 23 Max pulling tension   on amour wires kN 11 12 13 15 17 19 21 24 25 Min bending radius   during installation mm 920 970 1010 1090 1160 1220 1280 1380 1470 Min bending radius   set in position mm 610 640 670 720 770 810 850 920 980 Max conductor   resistance, dc @ 20°C   Ohm/km 1.20 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.54 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.162 Inductance mH/km 0.416 0.396 0.380 0.350 0.333 0.322 0.313 0.300 0.290 Inductive reactance,   @ 50Hz Ohm/km 0.131 0.124 0.119 0.110 0.105 0.101 0.0983 0.0944 0.0912 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 4.18+  j0.0839 3.39+  j0.0777 2.46+  j0.0728 1.70+  j0.0635 1.26+  j0.0585 1.09+  j0.0553 1.05+  j0.0525 1.01+  j0.0487 0.967+  j0.0456 Capacitance, phase   to earth µF/km 0.211 0.233 0.254 0.290 0.325 0.353 0.381 0.417 0.462 Min insulation   resistance @ 20°C   MOhm.km 12,000 11,000 10,000 8,900 7,900 7,200 6,600 6,000 5,400 Electric stress at   conductor screen   kV/mm 2.65 2.56 2.49 2.40 2.33 2.29 2.25 2.22 2.18 Charging current @  rated voltage & 50 Hz   A/phase/km 0.420 0.465 0.507 0.578 0.648 0.704 0.760 0.833 0.921 Short  circuit  rating Phase   conductor kA, 1 sec 2.4 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 Metallic  screen kA, 1 sec 2.8 3.3 4.6 6.6 8.9 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 110 130 155 190 225 255 285 325 370 In ground,   in singleway  ducts   A 95 110 130 160 185 215 245 275 320 In free air,   unenclosed   & spaced   from wall   A 105 130 150 190 230 265 300 345 405 79 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 80 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Single core light duty screened unarmoured Product code: 1CCUX22LD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 26.6 27.7 29.5 31.2 32.8 34.2 36.2 38.4 41.1 44.8 48.1 52.0 Approx mass   kg/100m 100 115 140 165 195 225 265 320 385 475 585 725 Max pulling tension   on conductor kN 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 2.5 2.7 3.1 3.4 3.8 4.1 4.6 5.2 5.9 7.0 8.1 9.4 Min bending radius   during installation mm 480 500 530 560 590 620 650 690 740 810 860 940 Min bending radius   set in position mm 320 330 350 370 390 410 430 460 490 540 580 620 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 0.0628 0.0504 0.0410 Inductance, trefoil  touching mH/km 0.492 0.470 0.435 0.414 0.397 0.384 0.372 0.357 0.346 0.335 0.324 0.315 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.155 0.148 0.137 0.130 0.125 0.121 0.117 0.112 0.109 0.105 0.102 0.0988 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.46+  j0.0913 1.32+  j0.0851 1.20+  j0.0751 1.13+  j0.0693 1.09+  j0.0645 1.06+  j0.0611 1.03+  j0.0575 1.01+  j0.0538 0.995+  j0.0509 0.982+  j0.0481 0.973+  j0.0451 0.965+  j0.0426 Capacitance, phase   to earth µF/km 0.164 0.179 0.200 0.223 0.241 0.259 0.282 0.310 0.343 0.386 0.426 0.473 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 2.78 2.73 2.68 Charging current @  rated voltage & 50 Hz   A/phase/km 0.652 0.713 0.799 0.888 0.961 1.03 1.12 1.24 1.37 1.54 1.70 1.89 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 175 205 250 300 335 375 425 490 550 625 705 790 In ground,   in singleway  ducts   A 170 200 245 290 325 360 405 460 515 580 650 730 In free air,   unenclosed   & spaced   from wall   A 180 215 270 325 375 425 490 575 660 765 880 1005 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 81 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 82 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Single core heavy duty screened unarmoured Product code: 1CCUX22HD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 27.9 29.0 30.8 32.5 34.1 35.5 37.5 39.9 42.4 46.3 49.4 53.5 Approx mass   kg/100m 115 140 185 215 240 270 310 370 430 525 630 770 Max pulling tension   on conductor kN 2.5 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 2.5 2.9 3.3 3.7 4.1 4.4 4.9 5.6 6.3 7.5 8.5 10 Min bending radius   during installation mm 500 520 550 590 610 640 670 720 760 830 890 960 Min bending radius   set in position mm 330 350 370 390 410 430 450 480 510 560 590 640 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 0.0627 0.0503 0.0408 Inductance, trefoil  touching mH/km 0.502 0.479 0.444 0.422 0.405 0.392 0.379 0.365 0.353 0.342 0.330 0.321 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.158 0.151 0.140 0.133 0.127 0.123 0.119 0.115 0.111 0.108 0.104 0.101 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.09+  j0.0931 0.783+  j0.0868 0.550+  j0.0767 0.475+  j0.0708 0.435+  j0.0660 0.406+  j0.0625 0.381+  j0.0589 0.358+  j0.0550 0.343+  j0.0520 0.330+  j0.0491 0.320+  j0.0460 0.312+  j0.0435 Capacitance, phase   to earth µF/km 0.164 0.179 0.200 0.223 0.241 0.259 0.282 0.310 0.343 0.386 0.426 0.473 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 2.78 2.73 2.68 Charging current @  rated voltage & 50 Hz   A/phase/km 0.652 0.713 0.799 0.888 0.961 1.03 1.12 1.24 1.37 1.54 1.70 1.89 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 5.0 7.1 10 10 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 175 205 250 295 335 370 415 480 535 600 670 740 In ground,   in singleway  ducts   A 170 195 235 275 305 335 370 415 460 510 560 615 In free air,   unenclosed   & spaced   from wall   A 185 220 270 330 375 425 485 565 645 740 845 960 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 83 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 84 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Three core light duty screened unarmoured Product code: 3CCUX22LD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 54.5 57.1 60.9 64.7 68.0 71.2 75.1 80.3 86.2 Approx mass   kg/100m 300 340 420 515 605 690 820 1010 1220 Max pulling tension   on conductors kN 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 7.4 11 13 15 16 18 20 23 25 Min bending radius   during installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min bending radius   set in position mm 650 690 730 780 820 850 900 960 1030 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 0.316 0.306 Inductive reactance,   @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 0.0993 0.0962 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.87+   j0.0916 2.73+   j0.0854 2.45+   j0.0754 2.24+   j0.0695 2.08+   j0.0647 1.95+   j0.0613 1.83+   j0.0577 1.64+   j0.0540 1.55+   j0.0511 Capacitance, phase   to earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 0.311 0.344 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 Charging current @  rated voltage & 50 Hz   A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 1.24 1.37 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 5.3 5.6 Contin- uous  current  rating In ground, direct buried   A 165 190 235 275 325 360 410 475 530 In ground,   in singleway  ducts   A 145 170 205 245 280 315 360 410 460 In free air,   unenclosed   & spaced   from wall   A 160 190 240 290 335 380 430 515 585 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 85 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 86 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Three core light duty screened armoured Product code: 3CCUX22LDA Nominal conductor   area mm 2 35 50 70 95 120 150 185 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 63.6 66.5 70.2 74.3 79.4 82.6 87.0 Approx mass   kg/100m 605 660 760 875 1080 1190 1350 Max pulling tension   on conductors kN 7.4 11 15 20 25 25 25 Max pulling tension   on stocking grip kN 7.4 11 15 19 22 24 25 Max pulling tension   on amour wires kN 17 18 20 23 25 25 25 Min bending radius   during installation mm 1150 1200 1260 1340 1430 1490 1570 Min bending radius   set in position mm 760 800 840 890 950 990 1040 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 Inductive reactance,   @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.87+   j0.0916 2.73+   j0.0854 2.45+   j0.0754 2.24+   j0.0695 2.08+   j0.0647 1.95+   j0.0613 1.83+   j0.0577 Capacitance, phase   to earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 Charging current @  rated voltage & 50 Hz   A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 Metallic  screen kA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 Contin- uous  current  rating In ground, direct buried   A 165 190 235 275 325 360 410 In ground,   in singleway  ducts   A 145 170 205 245 280 315 360 In free air,   unenclosed   & spaced   from wall   A 160 190 240 290 335 380 430 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 87 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 88 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Three core heavy duty screened unarmoured Product code: 3CCUX22HD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 54.5 57.1 60.9 64.7 68.0 71.2 75.1 80.3 86.2 Approx mass   kg/100m 310 360 455 550 640 725 850 1040 1240 Max pulling tension   on conductors kN 7.4 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 7.4 11 13 15 16 18 20 23 25 Min bending radius   during installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min bending radius   set in position mm 650 690 730 780 820 850 900 960 1030 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 0.0981 0.0791 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 0.316 0.306 Inductive reactance,   @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 0.0993 0.0962 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.16+   j0.0916 1.56+   j0.0854 1.11+   j0.0754 1.03+   j0.0695 0.995+   j0.0647 0.966+   j0.0613 0.941+   j0.0577 0.917+   j0.0540 0.902+   j0.0511 Capacitance, phase   to earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 0.311 0.344 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 2.91 2.85 Charging current @  rated voltage & 50 Hz   A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 1.24 1.37 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 5.1 7.1 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 170 200 240 290 330 365 410 475 530 In ground,   in singleway  ducts   A 145 170 210 245 285 320 360 415 465 In free air,   unenclosed   & spaced   from wall   A 170 200 250 305 350 390 445 520 590 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 89 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 12.7/22kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 90 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 12.7/22kV – Three core heavy duty screened armoured Product code: 3CCUX22HDA Nominal conductor   area mm 2 35 50 70 95 120 150 185 Nominal conductor  diameter mm 7.0 8.2 9.8 11.5 12.9 14.3 16.1 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 63.6 66.5 70.6 74.5 79.4 82.8 87.0 Approx mass   kg/100m 615 680 805 915 1110 1230 1380 Max pulling tension   on conductors kN 7.4 11 15 20 25 25 25 Max pulling tension   on stocking grip kN 7.4 11 15 19 22 24 25 Max pulling tension   on amour wires kN 17 18 20 23 25 25 25 Min bending radius   during installation mm 1150 1200 1270 1340 1430 1490 1570 Min bending radius   set in position mm 760 800 850 890 950 990 1040 Max conductor   resistance, dc @ 20°C   Ohm/km 0.524 0.387 0.268 0.193 0.153 0.124 0.0991 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.668 0.494 0.342 0.247 0.196 0.159 0.128 Inductance mH/km 0.438 0.418 0.386 0.367 0.351 0.340 0.328 Inductive reactance,   @ 50Hz Ohm/km 0.138 0.131 0.121 0.115 0.110 0.107 0.103 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.16+   j0.0916 1.56+   j0.0854 1.11+   j0.0754 1.03+   j0.0695 0.995+   j0.0647 0.966+   j0.0613 0.941+   j0.0577 Capacitance, phase   to earth µF/km 0.164 0.179 0.201 0.223 0.242 0.260 0.283 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric stress at   conductor screen   kV/mm 3.64 3.49 3.33 3.21 3.12 3.06 2.99 Charging current @  rated voltage & 50 Hz   A/phase/km 0.655 0.715 0.802 0.891 0.964 1.04 1.13 Short  circuit  rating Phase   conductor kA, 1 sec 5.0 7.2 10.0 13.6 17.2 21.5 26.5 Metallic  screen kA, 1 sec 5.1 7.1 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 170 200 240 290 330 365 410 In ground,   in singleway  ducts   A 145 170 210 245 285 320 360 In free air,   unenclosed   & spaced   from wall   A 170 200 250 305 350 390 445 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 91 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Single core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 92 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Single core light duty screened unarmoured Product code: 1CALX22LD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 26.6 27.6 29.5 31.2 32.8 34.1 36.1 38.2 41.1 44.8 48.1 51.9 Approx mass   kg/100m 80 85 95 110 120 130 150 170 200 235 275 330 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.8 2.5 3.1 3.4 3.8 4.1 4.6 5.1 5.9 7.0 8.1 9.4 Min bending radius   during installation mm 480 500 530 560 590 610 650 690 740 810 860 930 Min bending radius   set in position mm 320 330 350 370 390 410 430 460 490 540 580 620 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.102 0.0800 0.0634 Inductance, trefoil  touching mH/km 0.491 0.471 0.435 0.414 0.400 0.388 0.372 0.358 0.346 0.337 0.326 0.315 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.154 0.148 0.137 0.130 0.126 0.122 0.117 0.112 0.109 0.106 0.102 0.0989 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.80+  j0.0908 1.57+  j0.0853 1.38+  j0.0751 1.25+  j0.0693 1.19+  j0.0654 1.14+  j0.0622 1.10+  j0.0577 1.06+  j0.0540 1.03+  j0.0509 1.01+  j0.0485 0.996+  j0.0455 0.982+  j0.0426 Capacitance, phase   to earth µF/km 0.165 0.178 0.200 0.223 0.240 0.258 0.280 0.308 0.343 0.386 0.426 0.472 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 2.78 2.73 2.68 Charging current @  rated voltage & 50 Hz   A/phase/km 0.657 0.710 0.799 0.888 0.958 1.03 1.12 1.23 1.37 1.54 1.70 1.88 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 135 160 195 230 260 295 330 385 435 495 565 640 In ground,   in singleway  ducts   A 135 155 190 225 255 285 320 370 415 470 530 600 In free air,   unenclosed   & spaced   from wall   A 140 170 210 255 295 330 380 450 520 605 705 815 93 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Single core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 94 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Single core heavy duty screened unarmoured Product code: 1CALX22HD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 26.6 28.9 30.8 32.5 34.1 35.4 37.4 39.7 42.4 46.3 49.4 53.4 Approx mass   kg/100m 80 95 120 150 165 180 195 220 245 285 320 375 Max pulling tension   on conductor kN 1.8 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 1.8 2.5 3.3 3.7 4.1 4.4 4.9 5.5 6.3 7.5 8.5 10 Min bending radius   during installation mm 480 520 550 590 610 640 670 720 760 830 890 960 Min bending radius   set in position mm 320 350 370 390 410 430 450 480 510 560 590 640 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 0.101 0.0799 0.0633 Inductance, trefoil  touching mH/km 0.491 0.480 0.444 0.422 0.409 0.396 0.380 0.366 0.353 0.344 0.331 0.321 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.154 0.151 0.140 0.133 0.128 0.124 0.119 0.115 0.111 0.108 0.104 0.101 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.71+  j0.0908 1.24+  j0.0871 0.871+  j0.0767 0.635+  j0.0708 0.535+  j0.0669 0.488+  j0.0636 0.446+  j0.0590 0.407+  j0.0553 0.382+  j0.0520 0.360+  j0.0495 0.343+  j0.0465 0.330+  j0.0435 Capacitance, phase   to earth µF/km 0.165 0.178 0.200 0.223 0.240 0.258 0.280 0.308 0.343 0.386 0.426 0.472 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 6,500 5,900 5,300 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 2.78 2.73 2.68 Charging current @  rated voltage & 50 Hz   A/phase/km 0.657 0.710 0.799 0.888 0.958 1.03 1.12 1.23 1.37 1.54 1.70 1.88 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 3.3 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 135 160 195 230 260 290 330 380 425 485 545 615 In ground,   in singleway  ducts   A 135 155 190 220 245 270 305 345 380 430 480 530 In free air,   unenclosed   & spaced   from wall   A 140 170 210 255 295 330 380 445 515 595 690 795 95 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core light duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 96 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core light duty screened unarmoured Product code: 3CALX22LD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 54.7 57.0 60.9 64.7 67.8 71.0 74.9 80.0 86.2 Approx mass   kg/100m 230 255 295 340 380 420 480 565 660 Max pulling tension   on conductors kN 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.5 11 14 16 18 20 22 25 Min bending radius   during installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min bending radius   set in position mm 660 680 730 780 810 850 900 960 1030 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 0.317 0.306 Inductive reactance,   @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 0.0995 0.0962 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.21+   j0.0911 2.98+   j0.0856 2.63+   j0.0754 2.37+   j0.0695 2.18+   j0.0657 2.03+   j0.0624 1.89+   j0.0579 1.69+   j0.0542 1.59+   j0.0511 Capacitance, phase   to earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 0.309 0.344 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 Charging current @  rated voltage & 50 Hz   A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 1.23 1.37 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 5.3 5.6 Contin- uous  current  rating In ground, direct buried   A 125 145 190 235 255 285 320 370 420 In ground,   in singleway  ducts   A 110 130 160 190 220 245 275 320 360 In free air,   unenclosed   & spaced   from wall   A 125 145 190 230 265 300 345 405 465 97 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core light duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for low fault level or  fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 98 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core light duty screened armoured Product code: 3CALX22LDA Nominal conductor   area mm 2 35 50 70 95 120 150 185 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 63.8 66.4 70.2 74.3 79.3 82.4 86.8 Approx mass   kg/100m 535 570 630 700 855 920 1010 Max pulling tension   on conductors kN 5.3 7.5 11 14 18 23 25 Max pulling tension   on stocking grip kN 5.3 7.5 11 14 18 23 25 Max pulling tension   on amour wires kN 17 18 20 23 25 25 25 Min bending radius   during installation mm 1150 1190 1260 1340 1430 1480 1560 Min bending radius   set in position mm 770 800 840 890 950 990 1040 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 Inductive reactance,   @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.21+   j0.0911 2.98+   j0.0856 2.63+   j0.0754 2.37+   j0.0695 2.18+   j0.0657 2.03+   j0.0624 1.89+   j0.0579 Capacitance, phase   to earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 Charging current @  rated voltage & 50 Hz   A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 Metallic  screen kA, 1 sec 3.5 3.5 3.8 4.0 4.3 4.6 4.8 Contin- uous  current  rating In ground, direct buried   A 125 145 190 235 255 285 320 In ground,   in singleway  ducts   A 110 130 160 190 220 245 275 In free air,   unenclosed   & spaced   from wall   A 125 145 190 230 265 300 345 99 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core heavy duty screened unarmoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 100 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core heavy duty screened unarmoured Product code: 3CALX22HD Nominal conductor   area mm 2 35 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 54.7 57.0 60.9 64.7 67.8 71.0 74.9 80.0 86.2 Approx mass   kg/100m 230 260 310 370 415 455 510 590 685 Max pulling tension   on conductors kN 5.3 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 5.3 7.5 11 14 16 18 20 22 25 Min bending radius   during installation mm 980 1030 1100 1170 1220 1280 1350 1440 1550 Min bending radius   set in position mm 660 680 730 780 810 850 900 960 1030 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 0.317 0.306 Inductive reactance,   @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 0.0995 0.0962 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.21+   j0.0911 2.46+   j0.0856 1.76+   j0.0754 1.26+   j0.0695 1.09+   j0.0657 1.05+   j0.0624 1.01+   j0.0579 0.967+   j0.0542 0.942+   j0.0511 Capacitance, phase   to earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 0.309 0.344 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 8,100 7,300 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 2.92 2.85 Charging current @  rated voltage & 50 Hz   A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 1.23 1.37 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 3.5 4.6 6.3 8.9 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 125 145 190 225 250 285 325 375 420 In ground,   in singleway  ducts   A 110 130 160 190 225 250 280 325 365 In free air,   unenclosed   & spaced   from wall   A 125 145 190 230 265 305 350 410 470 101 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core heavy duty screened armoured Application Electricity distribution network cable typically used  as primary supply to Commercial, Industrial and urban  residential networks. Suitable for high fault level  systems rated up to 10kA/1sec. Higher fault current  rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 102 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 12.7/22kV – Three core heavy duty screened armoured Product code: 3CALX22HDA Nominal conductor   area mm 2 35 50 70 95 120 150 185 Nominal conductor  diameter mm 7.1 8.1 9.8 11.5 12.9 14.2 16.0 Nominal insulation  thickness mm 5.5 5.5 5.5 5.5 5.5 5.5 5.5 Approx cable   diameter mm 63.8 66.4 70.4 74.5 79.3 82.6 86.8 Approx mass   kg/100m 535 580 655 735 890 955 1040 Max pulling tension   on conductors kN 5.3 7.5 11 14 18 23 25 Max pulling tension   on stocking grip kN 5.3 7.5 11 14 18 23 25 Max pulling tension   on amour wires kN 17 18 20 23 25 25 25 Min bending radius   during installation mm 1150 1190 1270 1340 1430 1490 1560 Min bending radius   set in position mm 770 800 850 890 950 990 1040 Max conductor   resistance, dc @ 20°C   Ohm/km 0.868 0.641 0.443 0.320 0.253 0.206 0.164 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 1.11 0.822 0.568 0.411 0.325 0.265 0.211 Inductance mH/km 0.437 0.419 0.386 0.367 0.354 0.343 0.329 Inductive reactance,   @ 50Hz Ohm/km 0.137 0.132 0.121 0.115 0.111 0.108 0.103 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 3.21+   j0.0911 2.46+   j0.0856 1.76+   j0.0754 1.26+   j0.0695 1.09+   j0.0657 1.05+   j0.0624 1.01+   j0.0579 Capacitance, phase   to earth µF/km 0.165 0.179 0.201 0.223 0.241 0.259 0.281 Min insulation   resistance @ 20°C   MOhm.km 16,000 14,000 13,000 11,000 10,000 9,700 8,900 Electric stress at   conductor screen   kV/mm 3.63 3.50 3.33 3.21 3.13 3.06 2.99 Charging current @  rated voltage & 50 Hz   A/phase/km 0.659 0.712 0.802 0.891 0.962 1.03 1.12 Short  circuit  rating Phase   conductor kA, 1 sec 3.3 4.7 6.6 9.0 11.3 14.2 17.5 Metallic  screen kA, 1 sec 3.5 4.6 6.3 8.9 10 10 10 Contin- uous  current  rating In ground, direct buried   A 125 145 190 225 250 285 325 In ground,   in singleway  ducts   A 110 130 160 190 225 250 280 In free air,   unenclosed   & spaced   from wall   A 125 145 190 230 265 305 350 103 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Single core light duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 104 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Single core light duty screened unarmoured Product code: 1CCUX33LD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 33.1 34.7 36.6 38.0 39.6 41.4 43.8 46.5 50.2 53.5 57.4 Approx mass   kg/100m 140 165 195 225 255 295 355 420 515 625 770 Max pulling tension   on conductor kN 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 3.5 4.2 4.7 5.1 5.5 6.0 6.7 7.6 8.8 10 12 Min bending radius   during installation mm 600 630 660 680 710 740 790 840 900 960 1030 Min bending radius   set in position mm 400 420 440 460 480 500 530 560 600 640 690 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 0.127 0.0976 0.0786 0.0625 0.0500 0.0405 Inductance, trefoil  touching mH/km 0.507 0.469 0.447 0.428 0.415 0.400 0.385 0.372 0.359 0.346 0.335 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.159 0.147 0.140 0.134 0.130 0.126 0.121 0.117 0.113 0.109 0.105 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.32+  j0.0975 1.20+  j0.0868 1.13+  j0.0802 1.09+  j0.0749 1.06+  j0.0711 1.03+  j0.0670 1.01+  j0.0627 0.995+  j0.0591 0.982+  j0.0556 0.973+  j0.0521 0.965+  j0.0491 Capacitance, phase   to earth µF/km 0.139 0.155 0.170 0.183 0.196 0.212 0.231 0.254 0.284 0.312 0.344 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.923 1.02 1.09 1.17 1.26 1.38 1.52 1.70 1.86 2.06 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 205 250 300 335 380 425 490 555 625 705 795 In ground,   in singleway  ducts   A 200 245 290 325 360 405 465 520 585 655 735 In free air,   unenclosed   & spaced   from wall   A 220 275 330 380 435 495 580 665 770 885 1015 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 105 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Single core heavy duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 106 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Single core heavy duty screened unarmoured Product code: 1CCUX33HD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 23.5 26.6 30.3 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 34.4 36.2 37.9 39.5 40.9 42.9 45.1 47.8 51.5 54.8 58.7 Approx mass   kg/100m 165 210 240 270 300 340 400 465 560 675 815 Max pulling tension   on conductor kN 3.5 4.9 6.7 8.4 11 13 17 21 25 25 25 Max pulling tension   on stocking grip kN 3.5 4.6 5.0 5.5 5.9 6.4 7.1 8.0 9.3 10 12 Min bending radius   during installation mm 620 650 680 710 740 770 810 860 930 990 1060 Min bending radius   set in position mm 410 430 460 470 490 510 540 570 620 660 700 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 0.0470 0.0366 0.0283 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 0.127 0.0976 0.0785 0.0624 0.0500 0.0404 Inductance, trefoil  touching mH/km 0.515 0.478 0.454 0.436 0.422 0.407 0.391 0.378 0.365 0.352 0.340 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.162 0.150 0.143 0.137 0.133 0.128 0.123 0.119 0.115 0.110 0.107 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 0.783+  j0.0989 0.550+  j0.0881 0.475+  j0.0815 0.435+  j0.0762 0.406+  j0.0723 0.381+  j0.0681 0.358+  j0.0638 0.343+  j0.0601 0.330+  j0.0566 0.320+  j0.0530 0.312+  j0.0499 Capacitance, phase   to earth µF/km 0.139 0.155 0.170 0.183 0.196 0.212 0.231 0.254 0.284 0.312 0.344 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.923 1.02 1.09 1.17 1.26 1.38 1.52 1.70 1.86 2.06 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 57.2 71.5 90.1 Metallic  screen kA, 1 sec 7.1 10 10 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 205 250 295 335 370 420 480 535 605 675 750 In ground,   in singleway  ducts   A 200 235 275 310 340 375 425 470 520 575 630 In free air,   unenclosed   & spaced   from wall   A 220 275 335 380 430 490 575 655 750 855 970 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 107 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Three core light duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 108 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Three core light duty screened unarmoured Product code: 3CCUX33LD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 68.5 72.4 76.3 79.5 82.7 86.7 91.8 97.6 Approx mass   kg/100m 435 525 620 715 810 940 1140 1350 Max pulling tension   on conductors kN 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 11 15 20 22 24 25 25 25 Min bending radius   during installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min bending radius   set in position mm 820 870 920 950 990 1040 1100 1170 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 0.358 0.344 0.332 Inductive reactance,   @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 0.112 0.108 0.104 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.32+   j0.0978 2.09+   j0.0871 1.92+   j0.0805 1.79+   j0.0752 1.69+   j0.0714 1.59+   j0.0672 1.44+   j0.0629 1.37+   j0.0593 Capacitance, phase   to earth µF/km 0.140 0.155 0.171 0.184 0.197 0.212 0.232 0.255 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 Charging current @  rated voltage & 50 Hz   A/phase/km 0.834 0.927 1.02 1.10 1.17 1.27 1.39 1.52 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 4.3 4.6 4.8 5.1 5.3 5.6 6.1 6.3 Contin- uous  current  rating In ground, direct buried   A 190 235 280 320 365 410 484 545 In ground,   in singleway  ducts   A 170 210 245 280 310 355 401 452 In free air,   unenclosed   & spaced   from wall   A 195 245 295 340 390 440 544 620 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 109 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Three core light duty screened armoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 110 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Three core light duty screened armoured Product code: 3CCUX33LDA Nominal conductor   area mm 2 50 70 95 120 150 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 79.9 84.1 88.0 91.4 94.8 Approx mass   kg/100m 920 1040 1160 1280 1400 Max pulling tension   on conductors kN 11 15 20 25 25 Max pulling tension   on stocking grip kN 11 15 20 25 25 Max pulling tension   on amour wires kN 25 25 25 25 25 Min bending radius   during installation mm 1440 1510 1580 1640 1710 Min bending radius   set in position mm 960 1010 1060 1100 1140 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 Inductive reactance,   @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.32+   j0.0978 2.09+   j0.0871 1.92+   j0.0805 1.79+   j0.0752 1.69+   j0.0714 Capacitance, phase   to earth µF/km 0.140 0.155 0.171 0.184 0.197 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 Charging current @  rated voltage & 50 Hz   A/phase/km 0.834 0.927 1.02 1.10 1.17 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 Metallic  screen kA, 1 sec 4.3 4.6 4.8 5.1 5.3 Contin- uous  current  rating In ground, direct buried   A 190 235 280 320 365 In ground,   in singleway  ducts   A 170 210 245 280 310 In free air,   unenclosed   & spaced   from wall   A 195 245 295 340 390 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 111 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Three core heavy duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 112 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Three core heavy duty screened unarmoured Product code: 3CCUX33HD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 16.1 18.2 20.6 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 68.7 72.4 76.3 79.5 82.7 86.7 91.8 97.6 Approx mass   kg/100m 455 560 655 745 840 970 1160 1380 Max pulling tension   on conductors kN 11 15 20 25 25 25 25 25 Max pulling tension   on stocking grip kN 11 15 20 22 24 25 25 25 Min bending radius   during installation mm 1240 1300 1370 1430 1490 1560 1650 1760 Min bending radius   set in position mm 820 870 920 950 990 1040 1100 1170 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 0.0991 0.0754 0.0601 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 0.128 0.0978 0.0788 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 0.358 0.344 0.332 Inductive reactance,   @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 0.112 0.108 0.104 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.56+   j0.0978 1.11+   j0.0871 1.03+   j0.0805 0.995+   j0.0752 0.966+   j0.0714 0.941+   j0.0672 0.917+   j0.0629 0.902+   j0.0593 Capacitance, phase   to earth µF/km 0.140 0.155 0.171 0.184 0.197 0.212 0.232 0.255 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 3.36 3.26 3.16 Charging current @  rated voltage & 50 Hz   A/phase/km 0.834 0.927 1.02 1.10 1.17 1.27 1.39 1.52 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 26.5 34.3 42.9 Metallic  screen kA, 1 sec 7.1 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 195 240 285 330 370 410 486 547 In ground,   in singleway  ducts   A 170 210 250 280 320 360 402 452 In free air,   unenclosed   & spaced   from wall   A 195 250 305 350 395 450 550 627 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 113 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Copper 19/33kV – Three core heavy duty screened armoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Plain circular compacted copperConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 114 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Copper 19/33kV – Three core heavy duty screened armoured Product code: 3CCUX33HDA Nominal conductor   area mm 2 50 70 95 120 150 Nominal conductor  diameter mm 8.2 9.8 11.5 12.9 14.3 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 80.1 84.1 88.0 91.4 94.8 Approx mass   kg/100m 940 1070 1190 1310 1430 Max pulling tension   on conductors kN 11 15 20 25 25 Max pulling tension   on stocking grip kN 11 15 20 25 25 Max pulling tension   on amour wires kN 25 25 25 25 25 Min bending radius   during installation mm 1440 1510 1580 1640 1710 Min bending radius   set in position mm 960 1010 1060 1100 1140 Max conductor   resistance, dc @ 20°C   Ohm/km 0.387 0.268 0.193 0.153 0.124 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.494 0.342 0.247 0.196 0.159 Inductance mH/km 0.457 0.422 0.401 0.384 0.371 Inductive reactance,   @ 50Hz Ohm/km 0.143 0.133 0.126 0.121 0.117 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.56+   j0.0978 1.11+   j0.0871 1.03+   j0.0805 0.995+   j0.0752 0.966+   j0.0714 Capacitance, phase   to earth µF/km 0.140 0.155 0.171 0.184 0.197 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric stress at   conductor screen   kV/mm 4.07 3.85 3.67 3.55 3.46 Charging current @  rated voltage & 50 Hz   A/phase/km 0.834 0.927 1.02 1.10 1.17 Short  circuit  rating Phase   conductor kA, 1 sec 7.2 10.0 13.6 17.2 21.5 Metallic  screen kA, 1 sec 7.1 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 195 240 285 330 370 In ground,   in singleway  ducts   A 170 210 250 280 320 In free air,   unenclosed   & spaced   from wall   A 195 250 305 350 395 The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. 115 MEDIUM VOLTAGE CABLES Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Single core light duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 116 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Single core light duty screened unarmoured Product code: 1CALX33LD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 33.0 34.7 36.6 38.0 39.5 41.3 43.6 46.5 50.2 53.5 57.3 Approx mass   kg/100m 110 120 135 150 165 180 205 235 275 320 375 Max pulling tension   on conductor kN 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 2.5 3.5 4.7 5.0 5.5 6.0 6.7 7.6 8.8 10 11 Min bending radius   during installation mm 590 630 660 680 710 740 790 840 900 960 1030 Min bending radius   set in position mm 400 420 440 460 470 500 520 560 600 640 690 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.129 0.101 0.0797 0.0630 Inductance, trefoil  touching mH/km 0.508 0.469 0.447 0.431 0.419 0.401 0.386 0.372 0.361 0.348 0.336 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.160 0.147 0.140 0.136 0.132 0.126 0.121 0.117 0.113 0.109 0.105 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.57+  j0.0978 1.38+  j0.0868 1.25+  j0.0802 1.19+  j0.0759 1.14+  j0.0722 1.10+  j0.0672 1.06+  j0.0629 1.03+  j0.0591 1.01+  j0.0561 0.996+  j0.0526 0.982+  j0.0492 Capacitance, phase   to earth µF/km 0.139 0.155 0.170 0.183 0.195 0.211 0.230 0.254 0.284 0.312 0.344 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging current @  rated voltage & 50 Hz   A/phase/km 0.828 0.923 1.02 1.09 1.16 1.26 1.37 1.52 1.70 1.86 2.05 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 Contin- uous  current  rating In ground, direct buried   A 160 195 230 265 295 330 385 435 495 565 645 In ground,   in singleway  ducts   A 155 190 225 255 285 320 370 415 470 535 605 In free air,   unenclosed   & spaced   from wall   A 170 215 260 295 335 385 455 520 610 705 820 117 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Single core heavy duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 118 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Single core heavy duty screened unarmoured Product code: 1CALX33HD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 400 500 630 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 23.5 26.6 30.2 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 34.3 36.2 37.9 39.5 40.8 42.8 44.9 47.8 51.5 54.8 58.6 Approx mass   kg/100m 125 150 175 195 210 230 250 280 320 365 420 Max pulling tension   on conductor kN 2.5 3.5 4.8 6.0 7.5 9.3 12 15 20 25 25 Max pulling tension   on stocking grip kN 2.5 3.5 4.8 5.5 5.8 6.4 7.1 8.0 9.3 10 12 Min bending radius   during installation mm 620 650 680 710 730 770 810 860 930 990 1050 Min bending radius   set in position mm 410 430 460 470 490 510 540 570 620 660 700 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 0.0778 0.0605 0.0469 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.129 0.101 0.0797 0.0629 Inductance, trefoil  touching mH/km 0.516 0.478 0.454 0.439 0.426 0.408 0.392 0.378 0.366 0.353 0.340 Inductive reactance,   trefoil touching   @ 50Hz Ohm/km 0.162 0.150 0.143 0.138 0.134 0.128 0.123 0.119 0.115 0.111 0.107 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 1.24+  j0.0992 0.871+  j0.0881 0.635+  j0.0815 0.535+  j0.0771 0.488+  j0.0734 0.446+  j0.0683 0.407+  j0.0640 0.382+  j0.0601 0.360+  j0.0570 0.343+  j0.0534 0.330+  j0.0500 Capacitance, phase   to earth µF/km 0.139 0.155 0.170 0.183 0.195 0.211 0.230 0.254 0.284 0.312 0.344 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 8,800 8,000 7,200 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 3.06 2.99 2.93 Charging current @  rated voltage & 50 Hz   A/phase/km 0.828 0.923 1.02 1.09 1.16 1.26 1.37 1.52 1.70 1.86 2.05 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 37.8 47.2 59.5 Metallic  screen kA, 1 sec 4.7 6.6 8.9 10 10 10 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 160 195 230 260 290 330 380 425 485 550 620 In ground,   in singleway  ducts   A 155 190 220 245 275 305 345 385 435 485 540 In free air,   unenclosed   & spaced   from wall   A 175 215 260 295 335 385 450 515 600 690 800 119 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Three core light duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 120 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Three core light duty screened unarmoured Product code: 3CALX33LD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 68.4 72.4 76.3 79.4 82.5 86.5 91.5 97.6 Approx mass   kg/100m 350 400 445 490 535 600 690 795 Max pulling tension   on conductors kN 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 7.5 11 14 18 23 25 25 25 Min bending radius   during installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min bending radius   set in position mm 820 870 920 950 990 1040 1100 1170 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 0.359 0.345 0.332 Inductive reactance,   @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 0.113 0.108 0.104 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.57+   j0.0981 2.27+   j0.0871 2.05+   j0.0805 1.89+   j0.0762 1.77+   j0.0724 1.66+   j0.0674 1.49+   j0.0632 1.41+   j0.0593 Capacitance, phase   to earth µF/km 0.139 0.155 0.171 0.183 0.196 0.211 0.231 0.255 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.927 1.02 1.09 1.17 1.26 1.38 1.52 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 4.3 4.6 4.8 5.1 5.3 5.6 6.1 6.3 Contin- uous  current  rating In ground, direct buried   A 150 180 220 250 280 315 377 426 In ground,   in singleway  ducts   A 130 160 190 225 250 275 313 353 In free air,   unenclosed   & spaced   from wall   A 155 190 230 270 300 340 424 484 121 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Three core light duty screened armoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  low fault level or fast fault clearing cable systems. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 3kA for 1 second.    See table next page.Armouring:   Galvanised steel wires Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 122 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Three core light duty screened armoured Product code: 3CALX33LDA Nominal conductor   area mm 2 50 70 95 120 150 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 79.8 84.1 88.0 91.3 94.6 Approx mass   kg/100m 830 910 980 1050 1120 Max pulling tension   on conductors kN 7.5 11 14 18 23 Max pulling tension   on stocking grip kN 7.5 11 14 18 23 Max pulling tension   on amour wires kN 25 25 25 25 25 Min bending radius   during installation mm 1440 1510 1580 1640 1700 Min bending radius   set in position mm 960 1010 1060 1100 1140 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 Inductive reactance,   @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.57+   j0.0981 2.27+   j0.0871 2.05+   j0.0805 1.89+   j0.0762 1.77+   j0.0724 Capacitance, phase   to earth µF/km 0.139 0.155 0.171 0.183 0.196 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.927 1.02 1.09 1.17 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 Metallic  screen kA, 1 sec 4.3 4.6 4.8 5.1 5.3 Contin- uous  current  rating In ground, direct buried   A 150 180 220 250 280 In ground,   in singleway  ducts   A 130 160 190 225 250 In free air,   unenclosed   & spaced   from wall   A 155 190 230 270 300 123 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Three core heavy duty screened unarmoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Light (PVC only)   Heavy (HDPE)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Sheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground with protection 124 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Three core heavy duty screened unarmoured Product code: 3CALX33HD Nominal conductor   area mm 2 50 70 95 120 150 185 240 300 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 16.0 18.1 20.6 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 68.6 72.4 76.3 79.4 82.5 86.5 91.5 97.6 Approx mass   kg/100m 355 410 470 520 565 630 715 820 Max pulling tension   on conductors kN 7.5 11 14 18 23 25 25 25 Max pulling tension   on stocking grip kN 7.5 11 14 18 23 25 25 25 Min bending radius   during installation mm 1230 1300 1370 1430 1490 1560 1650 1760 Min bending radius   set in position mm 820 870 920 950 990 1040 1100 1170 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 0.164 0.125 0.100 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 0.211 0.161 0.130 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 0.359 0.345 0.332 Inductive reactance,   @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 0.113 0.108 0.104 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.46+   j0.0981 1.76+   j0.0871 1.28+   j0.0805 1.09+   j0.0762 1.05+   j0.0724 1.01+   j0.0674 0.967+   j0.0632 0.942+   j0.0593 Capacitance, phase   to earth µF/km 0.139 0.155 0.171 0.183 0.196 0.211 0.231 0.255 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 12,000 11,000 9,900 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 3.36 3.26 3.16 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.927 1.02 1.09 1.17 1.26 1.38 1.52 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 17.5 22.7 28.3 Metallic  screen kA, 1 sec 4.6 6.3 8.6 10 10 10 10 10 Contin- uous  current  rating In ground, direct buried   A 145 190 225 255 285 320 380 428 In ground,   in singleway  ducts   A 130 160 195 225 250 280 314 354 In free air,   unenclosed   & spaced   from wall   A 150 185 235 270 305 350 430 491 125 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Aluminium 19/33kV – Three core heavy duty screened armoured Application Electricity distribution or sub-transmission networks  cable typically used as primary supply to Commercial,  Industrial and urban residential networks. Suitable for  high fault level systems rated up to 10kA/1sec. Higher  fault current rated constructions are available on request. Approvals Approved by all major power Utilities and industrial  customers in Australia.  Behaviour in flame and fire: PVC or LSOH outer sheath exceeds  the requirements of IEC 60332-1. Temperature range Minimum installation temperature: 0 °C  Maximum operating temperature: +90 °C Minimum operating temperature: -25 °C  Minimum bending radius Installed cables:   12D (PVC only)      15D (HDPE) During installation:   18D (PVC only)     25D (HDPE) Resistance to Chemical exposure:  AccidentalMechanical impact:   Heavy (Armoured)Water exposure:   XLPE – Spray       EPR – Immersion/Temporary coverage Solar radiation and  weather exposure:   Suitable for direct exposure. Cable design Conductor:   Circular compacted aluminiumConductor screen:   Extruded semi-conductive compound, bonded    to the insulation and applied in the same operations    as the insulation. Insulation:    Cross Linked Polyethylene (XLPE) – standard  Ethylene Propylene Rubber (EPR) – alternativeInsulation screen:   Extruded, semi-conductive compoundMetallic screen:   Plain annealed copper wire: nominal 10kA for 1 second.    See table next page.Armouring:   Galvanised steel wiresSheath:   Black 5V-90 polyvinyl chloride (PVC) – standard  Orange 5V-90 PVC inner plus black high density    polyethylene (HDPE) outer – alternative  Low smoke zero halogen (LSOH) – alternative Installation conditions In free air In duct In trench In ground 126 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Aluminium 19/33kV – Three core heavy duty screened armoured Product code: 3CALX33HDA Nominal conductor   area mm 2 50 70 95 120 150 Nominal conductor  diameter mm 8.1 9.8 11.5 12.9 14.2 Nominal insulation  thickness mm 8.0 8.0 8.0 8.0 8.0 Approx cable   diameter mm 80.0 84.1 88.0 91.3 94.6 Approx mass   kg/100m 835 920 1010 1080 1150 Max pulling tension   on conductors kN 7.5 11 14 18 23 Max pulling tension   on stocking grip kN 7.5 11 14 18 23 Max pulling tension   on amour wires kN 25 25 25 25 25 Min bending radius   during installation mm 1440 1510 1580 1640 1700 Min bending radius   set in position mm 960 1010 1060 1100 1140 Max conductor   resistance, dc @ 20°C   Ohm/km 0.641 0.443 0.320 0.253 0.206 Conductor resistance,   ac @ 90°C & 50 Hz   Ohm/km 0.822 0.568 0.411 0.325 0.265 Inductance mH/km 0.457 0.422 0.401 0.387 0.375 Inductive reactance,   @ 50Hz Ohm/km 0.144 0.133 0.126 0.121 0.118 Zero seq. impedance @ 20°C & 50 Hz  Ohm/km 2.46+   j0.0981 1.76+   j0.0871 1.28+   j0.0805 1.09+   j0.0762 1.05+   j0.0724 Capacitance, phase   to earth µF/km 0.139 0.155 0.171 0.183 0.196 Min insulation   resistance @ 20°C   MOhm.km 18,000 16,000 15,000 14,000 13,000 Electric stress at   conductor screen   kV/mm 4.08 3.85 3.67 3.56 3.46 Charging current @  rated voltage & 50 Hz   A/phase/km 0.831 0.927 1.02 1.09 1.17 Short  circuit  rating Phase   conductor kA, 1 sec 4.7 6.6 9.0 11.3 14.2 Metallic  screen kA, 1 sec 4.6 6.3 8.6 10 10 Contin- uous  current  rating In ground, direct buried   A 145 190 225 255 285 In ground,   in singleway  ducts   A 130 160 195 225 250 In free air,   unenclosed   & spaced   from wall   A 150 185 235 270 305 127 MEDIUM VOLTAGE CABLES The cables described in this technical manual are designed to be used for the supply of electrical energy in fixed applications up to the rated voltages at a nominal power frequency between 49Hz and 61Hz. All values in this catalogue are for XLPE cables only. Increased radius required for HDPE and nylon incorporating designs. Physical & electrical characteristics www.prysmiancable.com.au

Cable Selection  Cables should be selected and used such that the product does not present an unacceptable risk or danger to life or property when used in its intended manner. Cables should also be selected so that they are suitable for the operating environment conditions e.g. use in petrochemical works, need for fire performance, the need for protection against attack by rodents, termites, etc, equipment classifi-cation and any other external influences which may exist. They should also be selected according to the appropriate rated voltage and the cross-sectional area of every conduc-tor such that its current carrying capacity is not less than the maximum sustained current which would normally flow through it, and the short circuit current rating of conductor and screen is adequate for the prospective short circuit and time for which it persists. In addition, consideration should be given to other relevant factors, such as:•  voltage drop requirements•  operating characteristics of connected equipment•  economics Environmental protection The standard cable finishes are adequate for normal envi-ronmental conditions. However, there are many installations where conditions are much more onerous than normal and some brief notes for protection of cables against hostile environments are given below. Once the type of protective covering to meet environmental conditions has been decid-ed, it is generally possible taking voltage and current ratings into account, to arrive at the type of cable insulation to be used. Oil refineries and chemical plants Polymeric and elastomeric cables are not compatible with hydrocarbon oils and organic solvents. Such oils and sol-vents particularly at elevated temperatures are absorbed by the insulation and sheathing materials leading to swelling and resultant damage. Semi-conductive components on high voltage cables may lose their conductive properties. It follows that where poly-meric and elastomeric cables are used in locations where exposure to hydrocarbon oils and organic solvents is likely,  a lead sheath is required. The most satisfactory protection for the lead sheath would be a high density polyethylene sheath with steel wire armour. For casual contact with oil spills, a Nitrile or CSP rubber sheath can be used. PVC sheaths offer good protection against chemical attack. Specifiers should contact Prysmian for recommendations regarding the protection of cables against harsh chemical environments. Termites, teredoes & rodents Special constructions are necessary to resist insects such as termites, as all cables with normal finishes are susceptible to their attack. If cables are installed in locations where  termite attack is likely, protection may take the form of  one of the following:•  Two helically applied brass tapes, the upper one over- lapping the gap in the lower one, may be incorporated into the cable design. In the case of armoured cable  the brass tapes may be applied under the bedding of  the armour. For unarmoured cable the brass tapes can  be applied over the normal PVC or other extruded sheath followed by a PVC sheath over the brass tapes. •  A nylon jacket may be applied over the PVC or other   extruded sheath followed by a sacrificial layer of  extruded PVC over the nylon to protect it from damage during installation. •  Termitex™ technology incorporated into the cable design,  for long term protection. Chemical treatment of the backfill is no longer recommended because of damage to the environment and the risk to health. The teredo worm is prevalent in tropical, subtropical and temperate oceans and estuaries. Protection is usually  attained by incorporating two brass tapes under the armour of all submarine cables. In areas liable to attack by rodents, galvanised steel wire armour provides an effective barrier. A layer of nylon  covering under the armour provides additional protection from insects. Prysmian have expertise in designing cables to resist  boring insect and rodent attack. Please call the Customer Service Team for advice. Technical Information 128 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Exposure to mechanical damage  1. Slight exposure to impact and to tensile stresses.   The application of a high density polyethylene sheath can give appreciable added mechanical protection to cables with the normal PVC sheath. This method is suitable for single and multi-core cables. 2. Moderate exposure to impact and to tensile stresses.   Single core cables can be armoured with non-ferrous  armour wire, usually hard drawn aluminium. For Multicore cables a single layer of galvanised steel wire armour is recommended. The steel wire is necessary if there is  likely to be a moderate tensile stress applied to the cable during pulling in or during service. Steel wire armoured cables offer good protection against rugged installation conditions. 3. Severe exposure to impact and tensile stresses.   The double wire armour finish offers a very high level of protection against mechanical damage whether it be  impact or longitudinal tensile stress such as in subsidence areas and submarine installations on an uneven sea floor. 4. Polymeric protection against impact.   Prysmian developed AIRBAG™, which provides enhanced mechanical/impact protection keeping the handling and installation characteristics of unprotected cables. Exposure to ultra violet radiation Prysmian has special materials designed to prevent UV  degradation when exposed to sunlight. To be sure the correct material is used it is necessary to state at the time of enquiry and ordering that the cable will be exposed to sunlight. Fire situations The performance of a cable in a fire situation can be a major factor in the choice of cable type. When correctly selected, located and installed cables do not present a fire hazard but in the case of fire initiated elsewhere, cables provide a source of fuel and a possible means of propagation along its length.  Additionally cables can contribute to the emission of smoke and noxious gases injurious to equipment and human health. Evolution of smoke can reduce visibility, which can cause panic and create serious problems in evacuating personnel. The presence of acid gas in the smoke can result in corrosion, damage of electronic and other equipment and can cause intense irritation to the eyes and lungs. Cables manufactured from PVC and some other traditional materials when exposed to fire will produce dense black smoke and harmful fumes and may propagate fire when installed in bundles. Where these factors are of concern,  the use of LSOH sheathed cables is recommended.  On the basis of standards in current use, cables can be divided into the following categories in relation to their behaviour in the presence of fire: Flame propagation (single cable) – when tested singly, the cable should self-extinguish within a short period of time and within a short distance from the point of application of a Bunsen burner flame. Such cables meet AS/NZS 1660.5.6 and IEC 60332 Part 1 and are often called flame retardant. Such cables will not necessarily prevent propagation along bunches of cables installed together on vertical racks and exposed to a large-scale fire source. Flame propagation (cable bunches) – when tested installed in defined bunches on a vertical ladder, the cables should not propagate flame more than a limited distance from the point of application of a ribbon burner flame front. Such cables meet AS/NZS 1660.5.1 and IEC 60332 Part 3 and are often called reduced propagation. Three categories exist in AS/NZS 1660.5.1 according to the volume of combustible material tested, Category A (7 l/m), Category B (3.5 l/m) and Category C (1.5 l/m). It should how-ever be noted that propagation of fire is often a function of installation conditions and appropriate care should be taken to ensure that the test category chosen is representative of the actual installed condition. Low smoke zero halogen cables – have controlled limits on smoke evolution when cable samples are burnt in a closed 3m cube smoke chamber and controlled limits on acidic and corrosive gases when subject to material pyrolysis in a tube furnace. Such cables meet AS/NZS 1660.5.2 (IEC 61034) for smoke emission and AS/NZS 1660.5.4 (IEC 754-2) for deter-mination of degree of acidity by measurement of pH and conductivity and are often called LSOH. By nature of their typical intended use the MV power  cables of this type may be used where the performance of the cable in case of fire is important, either for limitation  of the propagation of flame along cable bunches or  the limitation of smoke and corrosive gas emissions. Reduced flame propagation variants of all cables in this technical manual can be supplied with LSOH sheaths for situations where limiting the emission of smoke and corro-sive gas from the cables if affected by fire is desirable. 129 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Voltage rating  It is important to know whether the system to which the cable is connected is classified as earthed or unearthed. Supply authority systems are generally, though not always, earthed design. Mining systems are usually the unearthed design. Prysmian products are suitable for voltages that are commonly used in Australia. Voltage is usually expressed in the form Uo/U and Um.  Uo is the rms power frequency voltage between phase  and earth.  U is the rms power frequency voltage between phases.  Um is the maximum continuous rms power frequency  voltage between any two phases for which the cable is  designed. It excludes momentary variations due to fault conditions or sudden disconnection of large loads. The selection of standard cables for particular supply systems depends on the system voltage and earthing arrangements. Category A – system in which any phase conductor that comes in contact with earth or an earth conductor is discon-nected from the system within 1 minute. Category B – system which, under fault conditions, is oper-ated for a short time with one phase earthed, not exceeding 8 hours on any occasion and total duration of earth faults in any year not exceeding 125 hours. Category C – system which does not fall into Categories A and B. Note: If an earth fault is not automatically and promptly isolated, the extra stresses on the cable insulation during the fault reduce the life of the cable to a certain degree.  If the system is expected to be operated fairly often with  a permanent earth fault, it may be advisable to classify  the system in Category C. Cable voltages Cable selection Rated voltages of cables Max continuous operating voltage Um kV General cables  Uo/U kV Mining cables Uo/U kV 1.9/3.3 3.3/3.3 3.6 3.8/6.6 6.6/6.6 7.2 6.35/11 11/11 12 12.7/22 22/22 24 19/33 33/33 36 38/66 – 72 Max system voltage (Um) kV Min rated (phase to earth) Voltage of cable (Uo) kV Category A & B Category C 3.6 1.9 3.8 7.2 3.8 6.35 12.0 6.35 12.7 24.0 12.7 19 130 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Current ratings  The current ratings indicated in this manual have been based on the calculation procedures as recommended in  IEC 60287 and the following assumptions. Rating factors should be applied to cover any variation.•  Max. continuous conductor temp. = 90 °C•  Ambient air temperature = 40 °C•  Ambient ground temperature = 25 °C•  Depth of laying = 0.8 m•  Thermal resistivity of soil = 1.2 °C.m/W•  Balanced load, comprising either a single three core cable  or three single core cables, in trefoil formation touching throughout, with the screens bonded at both ends of  the route. •  Installation conditions: 1.  Direct Buried:  Cables are installed direct in the ground, with suitable compacted backfill 2.  Buried Singleway Ducts:  Cables are installed with one cable per duct 3.  In Free Air:  Cables installed shielded from direct sunlight and  with a minimum clearance from any vertical wall of 0.3xCable Dia. and 0.5xCable Dia. for single and three core cables respectively to ensure free air circulation. In order to select the appropriate cable for a given application, consideration must be given to the nature of the installation. It is not possible to provide a definitive guide to specifying the correct cable type for every situation, this choice must be made by the specifier and/or installer based upon a knowledge of the installation, applicable regulations and the characteristics of available cable designs. General guidance on the use of cable types included has been given above,  but for further information and guidance it is recommended  to make reference to the appropriate cable standard  (e.g. AS/NZS 1429.1 or AS/NZS 4026). Temperature limits In respect of thermal effects the temperature limit given for each cable type is the maximum temperature due to any combination of the heating effect of current in the conduc-tors and ambient conditions. All insulation and sheathing materials become stiffer as their temperature is lowered and due regard has been taken of this factor in the guidance on minimum installation temperature. The materials used for these cables are compatible with temperatures of 90 °C for continuous operation and 250 °C for short circuit conditions of up to 5 seconds. The fault ratings for the conductors and the metallic screens are provided for a time period of 1 second. When other times (t) between 0.2 and 5 seconds are required, the appropriate rating may be obtained by multiplying the 1 second rating  by the factor: 1/√t. The ratings for the screens are based upon the traditional adiabatic method, which provides a substantial safety  margin when account is taken of the heat loss occurring in practice. The non-adiabatic method to IEC standards can  be used according to AS/NZS 1429.1 when agreed between the purchaser and supplier. This can provide substantial  systems savings. Short circuit capacity that is related to the energy expended during a short circuit. It is equated to the mass x specified heat capacity x temperature change in the conductor. Two types of conditions have to be considered – symmetrical and earth short circuit currents. Various cable designs have different nominated maximum temperatures after short circuit,  depending usually on the type of insulation and sheathing, and these temperatures should not be exceeded.  Economics important criteria related to cable economics are the initial system cost and annual cost of losses. Economics are generally considered on a present value calculation based on initial cost and discounted cost of losses. Data pro-vided in the tables assists specifiers to estimate purchase and running costs. 131 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Cable installation It is recommended that all cables described in this manual be installed in accordance with the Electricity supply authority Specifications or Regulations, the Wiring Rules and any other appropriate national regulations or legislation. In installing cables, care should be taken to ensure that  the ambient and cable temperature has been above 0°C  for the previous 24 hours to avoid the risk of cracking of  the oversheath. For groups of parallel single core circuits, the cables should be installed in trefoil touching formation as hereunder: i) Two conductors per phase. ii) Three conductors per phase. A A B C C B A A A B C B C B C Recommended minimum bending radiiIt is good practice when planning ducts or trenches to pre-scribe a bending radius of 3 metres for 11kV, 22kV and 33kV cables and 2 metres for cables below 11kV.  The following tables set out the recommended minimum bending radii for single or multicore polymeric insulated  cables greater than 1.1/1.1kV:  Duct sizesRecommended duct sizes are given in the following table:  Maximum recommended pulling tensionsUsing a pulling eye on the conductor: Copper   – 0.07 kN/mm 2  of conductor  Aluminium, Stranded   – 0.05 kN/mm 2  of conductor Using a pulling eye on the Steel wire armour: P = 0.005 D 2 Using a Stocking grip:  P = 0.0035 D 2   Where:   P = Tension in kN    D = Cable diameter in mm Notes:1.  When considering the use of a stocking grip the tension  should not exceed the values given for a pulling eye on the conductor(s). 2. Refer also to Maximum Sidewall Bearing Pressure. Using bond pulling: By this method the cable is tied at intervals to a steel hawser which is coiled onto a take-up winch in the normal manner. The hawser would be twice the length of the cable being pulled. In this way the pulling load on the cable is kept to a low value and risk of damage to the cable is minimised.  Where: D = Overall diameter of cable in mm. D = Diameter over Nylon jacket component in mm. The radius is related to the inner surface of the cable and  not the axis. The recommendation for installation allows for the cable to be pulled under tension. Where cables are placed in position adjacent to joints and terminations and the bending is care-fully controlled, the controlled bending radius as given in  the data tables may be used. Sidewall Bearing Pressures  need to be considered also. Cable description During installation Setting at final position or location Nylon Jacketed 30D 20D HDPE Sheathed 25D 15D PVC Sheathed and LSOH Sheathed 18D 12D Nominal internal duct   diameter (mm) Cable diameter (mm) 100 Up to 65 125 Over 65, up to 90 150 Over 90, up to 115 132 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Maximum sidewall bearing pressure  Another factor which can limit the maximum tension that a cable can withstand is the sidewall bearing pressure exerted on a cable in duct bends and elbows. The sidewall bearing pressure formula is expressed as: SWBP = [W 2  + (T/(0.0098 x R)) 2 ]   (equation 1) as most of the time, [T/(0.0098 x R)] 2    W 2    equation 1 can therefore be simplified as follows: SWBP ≈ T/(0.0098 x R)   (equation 2)  From eqn. 2 = T = 0.0098 x R x SWBP   (equation 3)  From eqn. 2 = R = T / (0.0098 x SWBP)   (equation 4) Where:   SWBP = sidewall bearing pressure (kg/m)    W = weight of cable per unit length (kg/m)    T = cable pulling tension (kN)    R = radius of the bend or elbow (m) The recommended maximum SWBP for sheathed cables shall be 1450kg/m. Examples:To find out the maximum pulling tension of a 12.7/22kV 240mm 2  copper single core PVC sheathed cable based on   its minimum recommended bending radius: 1. First calculate the minimum recommended bending  radius without considering SWBP:     = 18 x Cable diameter      = 18 x 40.5mm      = 729mm Then calculate the maximum pulling tensions:a) Maximum pulling tension for straight pull:   T  = 0.07 kN/mm 2  x 240 mm 2       = 16.8 kN b) Maximum pulling tension when taking maximum  SWBP into consideration.From Equation 3:  T  = 0.0098 x 0.729 x 1450     = 10.4 kN We have to select the lesser of the two pulling tensions, i.e. 10.4kN. In this example, the maximum SWBP dictates the maximum pulling tension. 2. To find out the minimum bending radius for the same cable if we do need a pulling tension of 16.8kN:From Equation 4:  R  = 16.8 / (0.0098 x 1450)     = 1.2m Joints and terminationsWhilst jointing and terminating of Medium Voltage Polymeric Cables is routine, care is needed to maintain clean working conditions and in ensuring that the insulation semiconduct-ing screen is completely removed and properly connected  at the stress control areas. Reference should be made to literature for suitable systems available from Prysmian. Tests after installationHigh Voltage d.c. testing of primary insulation is not  recommended and can be detrimental to the cable and  accessories. AS/NZS 1429.1 describes an a.c. voltage test  at power frequency that should be applied for 24 hours  at the normal operating voltage of the system. A sheath integrity test (e.g. with a 1000 Volt minimum rated insulation resistance tester) may be applied between the outer-most metallic layer and the earth to identify post-installation damage, provided the metallic layer is isolated from earth  at the joints, terminations, etc. Short circuit forces When single core cables are installed touching, special atten-tion should be given to cleating and strapping arrangements to contain the repulsive forces under short circuit conditions. Longitudinal thrust and tensions in cable conductors may  be considerable and may cause buckling of conductors and other damage in a joint or termination. When cables are  installed, provision should be made to accommodate the resulting longitudinal forces on terminations and joints. Sharp bends and fixings at a bend should be avoided. Prevention of moisture ingress Care should be exercised during installation to avoid any damage to cable coverings. This is important in wet or other aggressive environments. The protective cap should not  be removed from the ends of the cable until immediately prior to termination or jointing. When the caps have been removed the unprotected ends of the cable should not be exposed to moisture. The possibility of damage to moisture seals during handling and installation or during storage of the cable should be considered and where such damage may have occurred,  the seals should be inspected and remade if necessary. 133 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Cable design service Prysmian offer their customers a full cable design service, either to give advice on the selection of the most appropriate cable from this technical manual for a particular application  or to design a specific cable for any particular installation  condition. This service is backed by an experienced team  of design engineers working under a Quality Management  System approved to AS/NZS ISO 9001. The Prysmian commitment to new product introduction  and development ensures effective and reliable designs are developed and assessed in our own research laboratories. Prysmian is also able to offer aerial cables including OPGW, water blocked designs and high voltage cables to 400kV.  Cable termination and identification systems are also  available as part of the Prysmian systems approach. Quality assurance All Prysmian MV power cables are manufactured under  the Prysmian Quality Management System. This system  has received certification by Quality Assurance Services  that it meets the requirements of AS/NZS ISO 9001. 134 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Variation in ground temperature Ground temperature °C 10 15 20 25 30 35 40 Rating factor 1.11 1.07 1.03 1.00 0.97 0.93 0.89 Variation in thermal resistivity of soil Values of ‘g’ °C m/W Nominal area of conductor mm 2 0.8 0.9 1.0 1.2 1.5 2.0 2.5 3.0 Rating factor Single core cables Up to 150 1.16 1.11 1.07 1.00 0.91 0.81 0.73 0.67 From 185 - 400 1.17 1.12 1.07 1.00 0.90 0.80 0.72 0.66 Above 400 1.18 1.13 1.08 1.00 0.90 0.79 0.71 0.65 Three core cables Up to 16 1.09 1.06 1.04 1.00 0.95 0.87 0.79 0.74 From 25 - 150 1.14 1.10 1.07 1.00 0.93 0.84 0.76 0.70 From 185 - 400 1.16 1.11 1.07 1.00 0.92 0.82 0.74 0.68 Rating factors – 1.9/3.3kV to 19/33kV, single and three core cables, armoured or unarmoured 1. Cables buried direct in the ground: Ratings information Variation in depth of laying Depth of laying m Up to 300 mm 2 Above 300 mm 2 0.8 1 1 1 0.98 0.97 1.25 0.96 0.95 1.5 0.95 0.94 1.75 0.94 0.92 2 0.92 0.90 2.5 0.91 0.89 3.0 or more 0.90 0.88 Measured to centre of cable or trefoil group of cables. Variation in depth of laying Depth of laying m Up to 300 mm 2 Above 300 mm 2 0.8 1 1 1 0.98 0.97 1.25 0.96 0.95 1.5 0.95 0.94 1.75 0.94 0.92 2 0.92 0.90 2.5 0.91 0.89 3.0 or more 0.90 0.88 Measured to centre of cable or trefoil group of cables. 135 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Variation in thermal resistivity of soil Values of ‘g’ °C m/W Nominal area of conductor mm 2 0.8 0.9 1.0 1.2 1.5 2.0 2.5 3.0 Rating factor Single core cables Up to 150 1.10 1.07 1.05 1.00 0.94 0.87 0.81 0.75 From 185 - 400 1.11 1.08 1.06 1.00 0.94 0.86 0.79 0.73 Above 400 1.13 1.09 1.06 1.00 0.93 0.84 0.77 0.70 Three core cables Up to 16 1.05 1.04 1.03 1.00 0.97 0.92 0.87 0.83 From 25 - 150 1.07 1.05 1.03 1.00 0.96 0.90 0.85 0.78 From 185 - 400 1.09 1.06 1.04 1.00 0.95 0.87 0.82 0.76 Group rating factors for circuits of three single core cables,   in trefoil touching, horizontal formation Circuit spacing – metres spacing Voltage range of cables No. of circuits Touching 0.15 0.30 0.45 0.60 From 1.9/3.3kV   to 12.7/22kV 2 0.78 0.81 0.85 0.88 0.90 3 0.66 0.71 0.76 0.80 0.83 4 0.60 0.65 0.72 0.76 0.80 19/33kV 2 0.79 0.81 0.85 0.88 0.90 3 0.67 0.71 0.76 0.80 0.83 4 0.62 0.65 0.72 0.76 0.80 These spacings may not be possible for some of the larger diameter cables. Group rating factors for three core cables, in horizontal formation Circuit spacing – metres spacing Voltage range of cables No. of circuits in group Touching 0.15 0.30 0.45 0.60 From 1.9/3.3kV   to 12.7/22kV 2 0.80 0.85 0.89 0.90 0.92 3 0.69 0.75 0.80 0.84 0.86 4 0.63 0.70 0.77 0.80 0.84 19/33kV 2 0.80 0.83 0.87 0.89 0.91 3 0.70 0.73 0.78 0.82 0.85 4 0.64 0.68 0.74 0.78 0.82 These spacings may not be possible for some of the larger diameter cables. 2. Cables in singleway ducts, buried direct in the ground:  Variation in ground temperature Ground temperature °C 10 15 20 25 30 35 40 Rating factor 1.11 1.07 1.03 1.00 0.97 0.93 0.89 136 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

Variation in depth of laying Rating factors Depth of Laying m Single core Multicore 0.8 1 1 1 0.98 0.99 1.25 0.95 0.97 1.5 0.93 0.96 1.75 0.92 0.95 2 0.90 0.94 2.5 0.89 0.93 3.0 or more 0.88 0.92 Measured to centre of cable or trefoil group of cables. Group rating factors for single core cables in single way ducts, laid in trefoil touching, horizontal formation Circuit spacing – metres spacing Voltage range of cables No. of circuits Touching 0.45 0.60 From 1.9/3.3kV   to 12.7/22kV 2 0.85 0.88 0.90 3 0.75 0.80 0.83 4 0.70 0.76 0.80 19/33kV 2 0.85 0.88 0.90 3 0.76 0.80 0.83 4 0.71 0.76 0.80 Group rating factors for three core cables in   singleway ducts, in horizontal formation Circuit spacing – metres spacing Voltage range of cables No. of ducts in group Touching 0.30 0.45 0.60 From 1.9/3.3kV   to 12.7/22kV 2 0.88 0.91 0.93 0.94 3 0.80 0.84 0.87 0.89 4 0.75 0.81 0.84 0.87 19/33kV 2 0.87 0.89 0.92 0.93 3 0.78 0.82 0.85 0.87 4 0.73 0.78 0.82 0.85 137 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au

AS 1018   Partial discharge measurements AS/NZS 1026   Electric cables – Impregnated paper insulated for working voltages up to and including 19/33 (36)kV AS/NZS 1125   Conductors in insulated electric cables and flexible cords AS/NZS 1429.1   Electric cables – Polymeric insulated Part 1: electric cables for working voltages 1.9/3.3 (3.6)kV     up to and including 19/33 (36)kV AS/NZS 1660   Test methods for electric cables, cords and conductors AS 1931   High-voltage testing techniques AS/NZS 2857   Timber drums for insulated electric cables and bare conductors AS/NZS 2893   Electric cables – lead and lead alloy sheaths – composition AS/NZS 3008   Electrical installations – selection of cables AS/NZS 3808   Insulating and sheathing materials for electric cables AS/NZS 3863   Galvanized mild steel wire for armouring cables AS 3983   Metal drums for insulated electric cables and bare conductors AS/NZS 4026   Electric cables – for underground residential distribution systems IEC 754-2  Test on gases evolved during combustion of electric cables, Part 2: Determination of degree of acidity     of gases evolved during the combustion of materials taken from electric cables by measuring pH     and conductivity IEC 60287  Electric cables – calculation of the current rating IEC 60332-1  Tests on electric and optical fibre cables under fire conditions, Part 1: Test for vertical flame     propagation for a single insulated wire or cable IEC 60332-3  Tests on electric cables under fire conditions, Part 3: Test for vertical flame spread of vertically-mounted     bunched wires or cables  IEC 60502-2  Power cables with extruded insulation and their accessories for rated voltages from 1kV (Um = 1.2kV)     up to 30kV (Um = 36kV) - Part 2: Cables for rated voltages from 6kV (Um = 7.2kV) up to 30kV (Um = 36kV) IEC 60949  Calculation of thermally permissible short-circuit currents, taking into account non-adiabatic     heating effects IEC 60986  Short-circuit temperature limits of electric cables with a rated voltages from 6kV (Um = 7.2kV)     up to 30kV (Um = 36kV) IEC 61034  Measurement of smoke density of cables burning under defined conditions General information Variation in ambient air temperature Ambient air temperature °C 15 20 25 30 35 40 45 50 Rating factor 1.26 1.20 1.15 1.10 1.05 1.00 0.94 0.88 3. Cables installed in free air:  Grouping of cables in air: Derating is not necessary if the following minimum clearance between adjacent circuits can be maintained 1  The horizontal clearance is not less than twice the diameter of an individual cable. 2  The vertical clearance is not less than four times the diameter of an individual cable. 3  Where the number of circuits is more than three, they are installed in a horizontal plane. 138 MEDIUM VOLTAGE CABLES www.prysmiancable.com.au
