Prysmian Mining Catalogue

Published: 23 May 2013 · Category: Product Catalogues

From this document

Mining Cables Contents Introduction _________________________________ 3 Cable Components __________________________ 4 Cable Handling ______________________________ 8 Health, Safety and Environment__________ 9 Quick Reference Guide ____________________ 10 Underground Mining - Coal ________________12 Type 241 and 241SF ____________________________ 14 Type 245SF _____________________________________16 Type 275 ______________________________________ 18 Metalliferous Mining ______________________ 20 Type 241 and 241SF ____________________________ 22 Type 245SF ____________________________________ 24 Type 275 ______________________________________ 26 Feeder Cables ______________________________ 28 11/11kV Paper Insulated ________________________ 30 6.35/11kV Copper ______________________________ 32 12.7/22kV Copper ______________________________ 34 Whilst every care has been taken in the preparation of this publication, the Prysmian Group take no responsibility for any errors and or omissions. This booklet is intended as a guide only and reference must be made by any person using this booklet to the appropriate Australian/New Zealand Standard and or to local electricity supply authority rulings. The company reserves the right to make changes in product without notice. All rights reserved. Subject to change without notice. Introduction ONE LEADER, TWO BRANDS The worlds largest cable company, the Prysmian Group, consists of Prysmian and Draka which are two of the worlds most...
