Decca Catalogue

DECCA RANGE

22  DOWnLIgHT  / ACCEnT  & WALL WASHERS 112mm Ø90mm Cut out 85mm DeccA pin hole Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 10w 800lm   ¨ 25°  ‘pin hole’ beam distribution   ¨ Extremely low glare   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1816834  • • • 1816834D  • • • • order code 10W  800lm  3000k  Dimming White  Trim DeccA Decca   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º 3000 Offset Illuminance Cone Width h (m) Emax (lx) 3344 836 372 209 134 93 0.21m 0.41m 0.62m 0.83m 1.04m 1.24m 0.5 1.0 1.5 2.0 2.5 3.0

23  DOWnLIgHT  / ACCEnT & WALL WASHERS 30° Decca DeccA ADJUSTABle Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 10w 800lm   ¨ 38° adjustable  ‘pin hole’ beam distribution   ¨ Extremely Low glare   ¨ 30° tilt   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1816934  • • • 1816934D  • • • • order code 10W  800lm 3000k Dimming White  Trim DeccA Ø90mm 112mm Tilt 30° Cut out 85mm   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º 2400 Offset Illuminance Cone Width h (m) Emax (lx) 2947 737 327 184 118 82 0.33m 0.65m 0.98m 1.31m 1.63m 1.96m 0.5 1.0 1.5 2.0 2.5 3.0

24  DOWnLIgHT  / ACCEnT  & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1474 0.39m 0.78m 1.18m 1.57m 1.96m 2.35m 368 164 92 59 41 Offset Illuminance Cone Width DeccA cloSeD cone 90 Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 13w 850lm   ¨ 43° beam distribution   ¨ Low glare spill ring   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1816734  • • • 1816734D • • • • order code 13W  850lm 3000k Dimming White  Trim DeccA Decca 133mm Ø90mm Cut out 85mm  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1200   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM

25  DOWnLIgHT  / ACCEnT & WALL WASHERS ip44 DeccA cloSeD cone 135 Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.    Features   ¨ Available LED colour temperature 3000k & 4000k   ¨ 3000k 24w 1360lm   ¨ 4000k 24w 1610lm   ¨ 51° beam distribution   ¨ Low glare spill ring   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1816534 • • • 1816544  • • • 1816534D  • • • • 1816544D  • • • • order code 24W  1360lm 24W  1610lm 3000k 4000k Dimming White  Trim DeccA 155mm Ø135mm Cut out124mm Decca  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1400   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1728 0.48m 1.96m 1.44m 1.93m 2.41m 2.89m 432 192 108 69 48 Offset Illuminance Cone Width DiM

26  DOWnLIgHT  / ACCEnT  & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1060 0.47m 0.95m 1.42m 1.89m 2.36m 2.84m 265 118 66 42 29 Offset Illuminance Cone Width DeccA ip54 111 Decca combines all that is required for a simple yet effective architectural  lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity in the overall  design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 13w 850lm   ¨ 50° beam distribution   ¨ Front glass gasket IP54   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1817334  • • • 1817334D  • • • • order code 13W  850lm 3000k Dimming White  Trim DeccA 133mm Ø111mm Cut out 95mm Decca  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1000   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip54 DiM

27  DOWnLIgHT  / ACCEnT & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1539 0.51m 1.03m 1.54m 2.06m 2.57m 3.08m 385 171 96 62 43 Offset Illuminance Cone Width  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1000 DeccA ip54 138 Decca combines all that is required for a simple yet effective architectural  lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity in the overall  design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k & 4000k   ¨ 3000k 24w 1360lm   ¨ 4000k 24w 1610lm   ¨ 55° beam distribution   ¨ Front glass gasket IP54   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life DeccA 1817234  • • • 1817244  • • • 1817234D  • • • • 1817244D  • • • • order code 24W  1360lm 24W  1610lm 3000k 4000k Dimming White  Trim Decca 140mm 138mm Cut out 124mm   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip54 DiM

28  DOWnLIgHT  / ACCEnT  & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1597 0.40m 0.79m 1.19m 1.58m 1.98m 2.38m 399 177 100 64 44 Offset Illuminance Cone Width Decca DeccA open cone 90 Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.    Features   ¨ Available LED colour temperature 3000k   ¨ 3000k 13w 850lm   ¨ 43° beam distribution   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1816634  • • • 1816634D • • • • order code 13W  850lm  3000k  Dimming White  Trim DeccA 133mm Ø90mm Cut out 85mm  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 900   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM

29  DOWnLIgHT  / ACCEnT & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 1738 0.37m 0.74m 1.12m 1.49m 1.86m 2.23m 434 193 109 70 48 Offset Illuminance Cone Width DeccA open cone 108 Decca combines all that is required for a simple yet effective architectural  lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity in the overall  design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 13w 850lm   ¨ 41° beam distribution   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1817134  • • • 1817134D  • • • • order code 13W  850lm 3000k Dimming White  Trim DeccA Decca 130mm Ø108mm Cut out 95mm  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1400   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM

30  DOWnLIgHT  / ACCEnT  & WALL WASHERS h (m) 0.5 1.0 1.5 2.0 2.5 3.0 Emax (lx) 2468 0.42m 0.84m 1.26m 1.68m 2.10m 2.52m 617 274 154 99 69 Offset Illuminance Cone Width DeccA open cone 135 Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity  in the overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k & 4000k   ¨ 3000k 24w 1360lm   ¨ 4000k 24w 1610lm   ¨ 46° beam distribution   ¨ Enclosed LED IP44   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life DeccA 1817034  • • • 1817044  • • • 1817034D  • • • • 1817044D  • • • • order code 24W  1360lm 24W  1610lm 3000k 4000k Dimming White  Trim Decca 152mm Ø135mm Cut out 124mm  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 800   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM

31  DOWnLIgHT  / ACCEnT & WALL WASHERS 30° 355° DeccA ADJUSTABle WAll WASher  108 Decca combines all that is required for a simple yet effective architectural  lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity in the overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k    ¨ 3000k 13w 850lm   ¨ Wall washer    ¨ Tilt 30° and rotate 355°   ¨ Symmetrical glass IP44. Optional Elongation lens accessory available   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life 1817534  • • • 1817534D  • • • • order code 13W  850lm 3000k Dimming White  Trim DeccA 122mm Tilt 30° Ø108mm Cut out 95mm Decca  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1000 h (m) 0.5 1.0 1.5 2.0 2.5 3.0 2.01 .0 01 .0 2.0 diameter (m) Emax (lx) 1933 483 215 121 77 54 cone 43.4º   606 lm   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 DiM

32  DOWnLIgHT  / ACCEnT  & WALL WASHERS 30° DeccA ADJUSTABle WAll WASher  135 Decca combines all that is required for a simple yet effective  architectural lighting design solution with freedom from compromise.It encompasses most lighting fundamentals to allow continuity in the  overall design process without impacting on performance or appearance.   Features   ¨ Available LED colour temperature 3000k & 4000k   ¨ 3000k 24w 1360lm   ¨ 4000k 24w 1610lm   ¨ Wall washer    ¨ Tilt 30° and rotate 355°   ¨ Symmetrical glass IP44. Optional Elongation lens accessory available   ¨ One of a family of 3 trim sizes including IP54 and wall wash versions   ¨ Die cast aluminium trim stoved powder coated white finish   ¨ Available with Non dim & Dimmable – Dimmable DALi 1-10v & push to dim (PTD)   ¨ Tool less plug and play format. Driver – mains side, is fitted with a flex and plug. Secondary side is fitted with a quick connect socket. Fixture is fitted with a long tail and quick connect plug   ¨ Suitable for ceiling thickness up to 30mm   ¨ 50,000hr rated life DeccA order code 24W  1360lm 24W  1610lm 3000k 4000k Dimming White  Trim 1817434  • • • 1817444  • • • 1817434D  • • • • 1817444D  • • • • Decca Ø135mm 165mm Cut out 124mm 355°  180º 120º 90º 60º 30º  0º 30º 60º 90º 120º cd/klm 1200   ¨ APPLICATIOnS RETAIL / OFFICES / HOTEL & LEISuRE / EDuCATIOnAL / PubLIC buILDIngS / RESIDEnTIAL / HEALTHCARE ip44 Tilt 30° DiM
