RANGE  NOMINAL    OPAL  LG7:2005 APPROX.    SIZE (mm)  LED  VERSION  VERSION  kg  CIRCUIT   16W  RAD 16400D  RAD 16721D 7.0      28W  RAD 16401D  RAD 16722D 7.0      600 x 600  38W  RAD 16402D  RAD 16723D 7.0      51W  RAD 16403D  RAD 16724D 7.0    16W  RAD 16713D   7.0      28W  RAD 16714D   7.0      1200 x 300  38W  RAD 16715D   7.0      51W  RAD 16716D   7.0    16W  RAD 16404  RAD 16725 6.9  L/A    28W  RAD 16405  RAD 16726 6.9  L/A    600 x 600  38W  RAD 16406  RAD 16727 6.9  L/A    51W  RAD 16407  RAD 16728 6.9  L/A   16W  RAD 16717   6.9  L/A    28W  RAD 16718   6.9  L/A    1200 x 300  38W  RAD 16719   6.9  L/A    51W  RAD 16720   6.9  L/A CIRCUIT TYPE - suffix catalogue number with: L - non-dimming (LED)  /  A - dimming (DALI)     e.g. RAD 16404L etc.  Smart versions use digital dimming gear and are always suffixed D EMERGENCY VERSION - prefix catalogue number with: ERD - Emergency  /  TRD - AutoTest  /  DRD - Scanlight AT     e.g. ERD 16404L etc.  Emergency, AutoTest and Scanlight AT versions add 0.3kg to weights listed SM AR T ST AND ARD RADIANCE SPECIFICATION •  Zinc coated steel body•  Extruded aluminium frame•  Polycarbonate flat panel diffuser•  Edge lit panel eliminating visible LEDs•  Suitable for most ceiling types     (lay-in only) •  Integral gear enclosure •  Fitted with 4000K LEDs LED EDGELIT LAY-IN RECESSED  PANEL LUMINAIRES IP20 IP40 ABOVE CEILING BELOW CEILING LED TP(a) Ra   80+ P/U   P R/Rx   Rx °K   4000 %   85 PF   0.9 L70/B10   60K   LED CHARACTERISTICS Smart version For LED characteristics explanation see   www.thorlux.com/led-characteristics Web link:     Smart System LL/CW  OPAL   106.3 LG7:2005   92.6 141 www.thorlux.com /recessed Nov. 14

RADIANCE RADIANCE 142 www.thorlux.com /recessed Nov. 14

RADIANCE DIMENSIONS 596 596 18 56 81 6-way ‘T’ piece (Smart and LCM versions only) All dimensions in millimetres 56 81 18 596 296 6-way ‘T’ piece (Smart and LCM versions only) 622 18 56 81 6-way ‘T’ piece (Smart and LCM versions only) 622 600 x 600 1200 x 300 625 x 625 PHOTOMETRIC GUIDE 600 x 600 - OPAL Luminaire Lumen Output 16W = 1875lm  28W = 3125lm  38W = 4105lm  51W = 5230lm 1200 x 300 - OPAL Luminaire Lumen Output 16W = 2020lm  28W = 3360lm  38W = 4415lm  51W = 5640lm 600 x 600 - LG7: 2005 Luminaire Lumen Output 16W = 1760lm  28W = 2930lm  38W = 3850lm  51W = 4905lm CANDELAS PER 1000 LUMENS 100 200 300 400 TRANSVERSE AXIAL 600x600 opal CANDELAS PER 1000 LUMENS 100 200 300 TRANSVERSE AXIAL 400 600x600 LG7 CANDELAS PER 1000 LUMENS 100 200 300 400 TRANSVERSE AXIAL 1200x300 opal METALLIC GEAR   ENCLOSURE -  RIGID, SAFE   CONSTRUCTION 143 www.thorlux.com /recessed Nov. 14
