VIDEO DOOR ENTRY SYSTEM OFFER

Kits are a simplification of the VIDEO DOOR ENTRY SYSTEM OFFER offer. They represent the most competitive solution for creating ONE-FAMILY audio and video door entry systems.

VIDEO DOOR ENTRY SYSTEM OFFER CA

3 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Index Different solutions for different applications 4 Expandable kit – catalogue 14 System – overview 22 Entrance panel – overview 24 Internal unit – overview 25 Transition to the NEW SFERA – catalogue 28 SFERA entrance – overview 32 SFERA entrance panel – catalogue 36 SFERA NEW - SFERA ROBUR composition examples 41 Entrance panel – catalogue 54 Internal unit – catalogue 58 System accessories – catalogue 61 Examples of wiring diagrams 64 Interface – overview 78 You Diagram software 79 Offer overview Expandable kits 2 wire system D45 system System to system interfaces Pre-sale software System – overview 68 Entrance panel – overview 70 Internal unit – overview 71 Entrance panel – catalogue 72 Internal unit – catalogue 73 System accessories – catalogue 74 Examples of wiring diagrams 76 Basic kit – catalogue 8 4 wire kits – overview 10 Basic kits

4 From single-storey houses to large multi-storey buildings Different types of construction means different types of offers FOR DIFFERENT DIFFERENT SOLUTIONS APPLICATIONS Villas Small buildings Building complex

5 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE ONE-FAMILY HOMES READY MADE SOLUTIONS BASIC FUNCTIONS PLUG-IN POWER CONNECTIONS ONE OR TWO-FAMILY HOMES READY MADE SOLUTIONS FULLY EXPANDABLE ENHANCED FUNCTIONS BASIC KITS for standard level homes EXPANDABLE KITS for high level homes Closed solution that provides BASIC FUNCTIONS, normally for simple systems: Initial basic solution that CAN DEVELOP into a MORE COMPLEX and CUSTOMISED system: SMALL BUILDINGS/HOMES EASY AND QUICK TO INSTALL MAXIMUM VERSATILITY PERFECT FOR REFURBISHMENTS LARGER BUILDINGS AND COMPLEXES HIGH PERFORMANCE LONG DISTANCES AND LARGE NUMBER OF APARTMENTS INTEGRATED SECURITY FUNCTIONS 2 WIRE SYSTEM 2 WIRE SYSTEM for small buildings D45 SYSTEM for big constructions The best technology when TIME SAVING and EASE of INSTALLATION are required: System developed mainly to increase competitiveness in large projects, buildings and complexes. D45 BASIC KITS EXPANDABLE KITS

7 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Basic kit overview 8 Basic 4 wire kit range 10 Basic kits Index BASIC KITS

8 Kits are a simplification of the VDE offer. They represent the most competitive solution for creating ONE-FAMILY audio and video door entry systems. With one single reference code, the kit includes all the items required for the installation: entrance panel and internal units. All audio and video kits can be installed very easily: each internal unit has an easy PLUG IN power connector. Includes a door lock release key and INTERCOM function (expansion for up to a maximum of 3 internal units). All in one easy package Basic kits PLUG-IN POWER SUPPLY ADDITIONAL INTERNAL UNITS (max. 2 additional audio or video internal units) INTERCOM DIRECT CONNECTION BETWEEN ENTRANCE PANEL AND INTERNAL UNIT WITH ONE CABLE

9 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Australian SUITABLE FOR AUSTRALIA EXAMPLE OF ONE-FAMILY VIDEO SYSTEM 2 WIRE SOLUTION Entrance panel 2 Door lock PLUG-INPower supply BASIC KITS 2 Uw p PLPowsup Entrance panel INTERCOM

10 PLUG-IN STANDARD TYPE COLOUR VIDEO KITS Australian standard 316513 (handsfree 7” kit) 331853 (additional video unit) COLOUR VIDEO KITS 7” Colour handsfree video kit ONE-FAMILY analogue colour video handsfree kit with wall mounted dedicated entrance panel and video monitor. Metal entrance panel with colour camera and LED for the illumination of the ﬁeld of view. Video Internal Unit with 7” colour monitor and PLUG IN system power supply included. It can be expanded with up to 3 dedicated internal units. NOTE: for the control of electric door lock release we recommend the use of DIN transformer 336842 (230V a.c. - 12V a.c.). Basic 4 wire kit range D TYPE COLOUR VI WIREBASIC KITS

11 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE

13 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Expandable kit overview 14 Expandable kits Index EXPANDABLE KITS Handsfree colour video kits 16 Colour video kits 17 Audio kits 18 Audio kits 19 Catalogue 2 WIRE expandable kit range: ANALOGUE expandable kit range:

14 To simplify the purchase process, BTicino has created expandable kits. With one single reference code it is possible to have a BASIC SYSTEM that can be customised and expanded with other system devices like: additional entrance panels and internal units, additional cameras to control, for example, car access, home automation devices for the management of home automation systems. The kit includes a manual with all the technical information required about installation, connection, features and expansion possibilities. The starting basis system in one package Expandable kits INTERCOM DIN POWER SUPPLY AUDIO/VIDEO CALL MEMORY STAIRCASE LIGHT ACTIVATION INTERC DIN P AU

15 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE TWO WIRE TECHNOLOGY Suitable for expandable ONE and TWO-family home systems. NOTE: some analogue (4+n) audio kits are also available, see page 19. Maximum flexibility and customised composition. 2 2 2 2 2 Video entrance panel Door lock Handsfree Handset Power supply Video adapter HOME 1 HOME 2 EXAMPLE OF TWO-FAMILY VIDEO KIT DIFFERENT COMBINATIONS TO SATISFY ALL NEEDS FULL EXPANDABILITY Audio kits Video kits H H Handsfree Memory One-family One- family Two- family Robust Two-family Flush mounted Robust Two family EXPANDABLE KITS Flush B/Whandset Colourhandset Handsfree

16 Item POLYX MEMORY DISPLAY HANDSFREE KIT WITH MEMORY - LINEA 2000 METAL WALL MOUNTED INSTALLATION 369411 One-family handsfree kit with call memory and colour video display consisting of POLYX MEMORY DISPLAY 3.5” video internalunit and LINEA 2000 METAL push button panel. The video handset has an icon menu for the control of videodoor entry functions and MyHOME automation functions. 2 WIRE technology. Devices suitable for wall mounted installation. The push button panel has an IK10 protection index againstmechanical impact 2 WIRE EXPANDABLE KIT RANGE Handsfree colour video kits with memory Handsfree colour video kits Item POLYX VIDEO HANDSFREE KIT - LINEA 2000 METAL WALL MOUNTED INSTALLATION 368911 One-family handsfree video (colour) kit with POLYX VIDEO 3.5” internal unit and LINEA 2000 push button panel. 2 WIRE technology.Devices suitable for wall mounted installation. The push button panel has an IK10 protection index against mechanical impact EXPANDABLE KITS

17 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Colour video kits Item SWING VIDEO KIT - LINEA 2000 METAL 367511 One-family video (colour) kit with SWING 4” video handset and LINEA 2000 push button panel. 2 WIRE technology. Devices suitable for wall mounted installation. The push button panel has an IK10 protection index against mechanical impact EXPANDABLE KITS

18 2 WIRE EXPANDABLE KIT RANGE Audio kits Item SWING AUDIO KIT - LINEA 2000 METAL 368111 One-family kit with SWING handset and LINEA 2000 METAL push button panel. 2 WIRE technology. Devices suitable forwall mounted installation. The push button panel has an IK10protection index against mechanical impact EXPANDABLE KITS Item POLYX AUDIO KIT - LINEA 2000 METAL 369211 One-family expandable audio kit with POLYX handsfree internal unit and LINEA 2000 METAL push button panel. Both devices are suitable for wall mounted installation. Push button panel protection index against mechanical impact : IK10

19 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE ANALOGUE EXPANDABLE KIT RANGE Audio kits Analogue kits (4+n) represent the most economic solution for the installation of one and two-family door entry systems. Kit 363811 , only available in the one-family version, is installed using the analogue technology, but the system wiring is based on the 2 wire solution. This kit is ideal for refurbishments, particularly when replacing simple door bell systems with a new door entry system, without the need for replacing the existing wiring. Possible to connect up to 4 handsets, item 331550, in parallel with the handset of the Basic kit Item SPRINT - LINEA 2000 ONE-FAMILY AUDIO KIT 363811 One-family kit with SPRINT handset and LINEA 2000 push button panel. Analogue technology with 2 wire connection. Devices suitable for wall mounted installation. Expansion possibility using the specific additional handset, item 331550 Composition Item Quantity LINEA 2000 push button panel – 1 SPRINT audio handset – 1 Transformer 336842 1 ACCESSORIES 331550 Specific additional handset EXPANDABLE KITS

21 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE System overview 22 Entrance panel overview 24 Internal unit overview 25 Special accessories 26 Transition to the NEW SFERA 28 2 WIREsystem Index 2 WIRE SYSTEM Entrance panels 32 SFERA NEW - SFERA ROBUR composition examples 41 Internal units 56 Switchboard 60 System accessories 61 Examples of wiring diagrams 64 Catalogue

22 SMALL AND MEDIUM SIZE SYSTEMS SMALL AND MEDIUM SIZE SYSTEMS RENOVATIONS RENOVATIONS The possibility of using existing cables makes it the ideal solution when refurbishing systems. 2 wire system The 2 WIRE SYSTEM is the best technology for when TIME SAVING and EASE of INSTALLATION are crucial. Thanks to the non-polarised 2 wire system it is possible to install all kinds of systems, from single storey houses to apartment complexes. The easiest system offer THE HOUSE THE APARTMENT This technology is particularly suitable, for example, for: Remove the old entrancepanel being replaced. Use the two cables already present to connect the new entrance panel.

23 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 2 non-polarised wires for all the system In addition to the extreme simplicity, the system offers EXCELLENT PERFORMANCE SYSTEM MAIN FEATURES 3900 3900 39 5 600 m Apartments Apartment video entrance panels Risers with independent sound mode Handsets per apartment Distance between entrance panel and farthest internal unit THE 2 WIRE SYSTEM CAN BE INTEGRATED AND COMBINED WITH MyHOME AUTOMATION SYSTEM APPLICATIONS OR CAN BE AESTHETICALLY INTEGRATED WITH THE BTICINO RESIDENTIAL SERIES 2 2 2 2 2 WIRE SYSTEM

24 ROBURﬁnish VERSATILITY NEW SFERA entrance panels STRENGTH LINEA 300 monobloc solutions ENTRY LEVEL SOLUTIONS LINEA 100 audio VILLA SOLUTIONS LINEA 2000 METAL LINEA 2000 The solution for every installation need: from the single-storey house to the large residential complex. Two versions (SFERA New and SFERA Robur) available in different colours Modular composition: 13 electronic modules for unlimited combinations of functions (traditional, specialistic and door lock release functions) Minimalist strong design Aluminium and stainless steel versions From 4 to 32 push buttons Competitive entrance panels for price sensitive markets Digital or push button call (max 8 apartments) Door lock release using the keypad Wall or ﬂush mounted installation Elegant and strong solution, ideal for a house Audio and video solutions One or two call push buttons Wall or ﬂush mounted installation The basic solution for the smaller size, from one to four-family homes Audio and B/W video solutions One to four call push buttons Wall mounted installation ALLMETALﬁnish Wall-mountedAUDIO EP Wall-mountedVIDEO EP AUDIO EP VIDEO EP Push button entrance panels Single rowpush buttons Double rowspush buttons ENTRANCE PANEL OVERVIEW 2 WIRE SYSTEM Digital callversion VID V V V VID EO E EP EP E EP EP E

25 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE CLASSE 100 INTERNAL UNIT OVERVIEW AUDIO OFFER VIDEO OFFER MyHOME OFFER Handset and handsfree solutions Wall mounted installation Colour or black and white screen Handset and handsfree solutions Wall or ﬂush mounted installation Basic or with additional functions MyHOME automation and intercom management POLYX AUDIO CLASSE 100 A12B SWING SPRINT L2 SWING(colour or b/w) POLYX(basic or with memory functions) CLASSE 100 V12B My HOME SCREEN 10 AXOLUTENIGHTER and WHICE 2 WIRE SYSTEM CLASSE 300 V13E CLASSE 300 V13E

26 In addition to the entrance panels of the 2 WIRE range, it is also possible to install push button panels for other brands: The universal speaker module (346991) can manage up to 8 call keys. For systems with more than 8 call keys it is possible to use the key expansion module, item 346992 (up to 6 expansion modules), to manage up to 56 call keys. SUITABLE FOR USE WITH CUSTOM MADE ENTRANCE PANELS 2 WIRE SYSTEM Custom made push button panels Pattern design brass Compact sheet metal panel using a speciﬁc accessory(346991 - universal speaker module) Universal speaker module To other keyexpansion modules Keyexpansion module Up to 8key call push buttons connections Kem

27 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Using the 2 WIRE solution, it is possible to install small home CCTV systems, connecting several entrance panels and cameras to the system. A/V NODE (BUS IU) 2 WIRE SYSTEM HIGHER SECURITY THANKS TO THE CCTV SYSTEM Driveway camera Entrance panel Porch camera Video internal unit Entrance panels cameras connection POWER SUPPLY This is made possible by the use of the audio/video node (F441) instead of the video adapter (346830).

28 SFERA CLASSIC SFERA NEWSFERA ROBUR SWITCHING TO THE NEW SFERA SWITCHING TO THE NEW SFERA 2 WIRE SYSTEM

29 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE UNDERSTANDING THE CODE Description Detailed description 1 st and 2 nd digit 35 New SFERA 3 rd and 4 th digit M ACRO T YPE (M ECHANICS , E LECTRONIC MODULES , FRONT COVERS , ...) 00 Flush-mounted box 01 Flush-mounted box in steel (tamper-proof) 02 SFERA New support 03 SFERA Robur frame support 04 SFERA Robur surround plate 05 Rainshield 06 Wall mounted box 10 Basic audio speaker module+ Basic speaker module front cover 11 Audio speaker module + audio speaker module front cover 12 A/V module + A/V front covers 13 A/V wide angle module + A/V wide angle front covers 20 Module with 4 push buttons arranged on single column + front covers 21 Module with 8 push buttons arranged on double column + front covers 22 Nameplate module + front covers 23 Blanking module 24 N&D and wide angle camera module + front covers 25 Display module + front covers 27 Inductive loop and control speech synthesis module + front covers 30 Keypad module + front covers 32 BADGE reader module + front covers 33 Fingerprint module + front covers 34 Vigik front covers 40 Accessories 5 th digit N O . OF MODULES 0 - 1 1 module 2 2 modules 3 3 modules 4 4 modules (Wall mounted box) 6 6 modules (Wall mounted box) 8 8 modules (Wall mounted box) 9 9 modules (Wall mounted box) N O . OF PUSH BUTTONS 0 No. of push buttons 1 No. of push buttons 2 No. of push buttons 3 No. of push buttons 4 No. of push buttons 6 No. of push buttons (on double column) 8 No. of push buttons (on double column) 6 th digit F INISHES 0 No finish (e.g. boxes) 1 All metal 2 All white 3 All street 5 Robur New SFERA No. of push buttons 1 push button Finish All metal Macro Type Wide angle A/V module Front Cover BT - 35 13 1 1 2 WIRE SYSTEM

30 The SFERA New and SFERA Robur push button panels represent the evolution of the SFERA CLASSIC offer. SFERA Classic Photo Item MECHANICS 331110331120331130331211331221331231 ASSEMBLY ACCESSORIES (OPTIONAL) 331411331421331431331441331461331491331311331321331331331341331361331391 BASIC SPEAKER MODULE 342150 SPEAKER MODULE 342170 342350 AUDIO/VIDEO MODULE 342560 DISPLAY MODULE 342630 CAMERA MODULE 342510 342550 PUSH BUTTON MODULE 342240 342480 KEYPAD MODULE 342640 342600 342610 332650 NAMEPLATE MODULE 342200 BLANKING MODULE 332911 Total installation compatibility with the SFERA CLASSIC range.Same box, same sizes, ideal in case of refurbishments. The table shown on the side has been produced to help the installer during the initial stages when switching from SFERA CLASSIC to the new series. SFERA CLAS SIC SFERA ROBUR SFERA NEW It provides for the comparative product in the new series. SWITCHING TO THE NEW SFERA 2 WIRE SYSTEM

31 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE SFERA New and Robur Description Photo Item Description Flush-mounted box + frame 1 module 350010 Flush-mounted box - 1 module Flush-mounted box + frame 2 modules 350020 Flush-mounted box - 2 modules Flush-mounted box + frame 2 modules 350030 Flush-mounted box - 3 modules Surround plate -1 module 350211 SFERA New 1 module support frame Surround plate - 2 modules 350221 SFERA New 2 module support frame Surround plate - 3 modules 350231 SFERA New 3 module support frame Rainshield - 1 module 350511 Rainshield -1 module Rainshield - 2 modules 350521 Rainshield - 2 modules Rainshield - 3 modules 350531 Rainshield - 3 modules Rainshield - 4 modules 350541 Rainshield - 4 modules Rainshield - 6 modules 350561 Rainshield - 6 modules Rainshield - 9 modules 350591 Rainshield - 9 modules Wall mounted box - 1 module 350611 Wall mounted box - 1 module Wall mounted box - 2 modules 350621 Wall mounted box - 2 modules Wall mounted box - 3 modules 350631 Wall mounted box - 3 modules Wall mounted box - 4 modules 350641 Wall mounted box - 4 modules Wall mounted box - 6 modules 350661 Wall mounted box - 6 modules Wall mounted box - 9 modules 350691 Wall mounted box - 9 modules Speaker module with 2 call push buttons for audio systems (max. 26 handsets) 351000 Basic speaker module with 4 call push buttons for audio systems Speaker module with 2 call push buttons for audio/video systems 351100 Speaker module with 4 call push buttons for audio/video systems Speaker module with 4 call push buttons for audio/video systems Audio/video module 351200 Audio/video module 351300 Audio/video module with wide angle camera Speaker module with graphic display 351100 + 352500 Speaker module + Display module Black and white camera module 352400 Night & Day and wide angle camera module Colour camera module Module with 4 call push buttons 352000 4-push button modules arranged on single column Module with 8 call push buttons on double column 352100 8-push button modules arranged on double column Additional keypad module for speaker module with graphic display 353000 Keypad module Alphanumeric call module 352500 + 353000 Display module + Keypad module Direct numerical call module 352500 + 353000 Display module + Keypad module Code lock module 353000 Keypad module Nameplate module 352200 Nameplate module Blanking module 352301 Blanking module + + + All metal finish transcoding example 2 WIRE SYSTEM

32 2 WIRE SYSTEM 32 New outdoor audio and video push button panelsfeaturing a modern design and improved aestheticimpact: perfect alignment of the modules, minimumprotrusion from the wall, reinforced plastic components.Available in two versions: SFERA NEW and SFERA ROBUR. A L L M E TA L F IN IS H Extra strong front section and frame for increased safety, ﬂush mounted box in steel to prevent the device being pulled off.

33 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Basic speaker module 4 push buttons module A/V module with wide angle camera Keypad module Night & Day and wide angle camera module Badge reader module Inductive loop and control speech synthesis module Speaker module 8 push buttons module Audio/video module Nameplate module Display module I d l d l N h & D d d A/V d l ith id FUNCTIONS TRADITIONAL FUNCTIONS DOOR LOCK RELEASE FUNCTIONS BASIC AUDIO AUDIO AUDIO/VIDEO 4 PUSH BUTTONS 8 PUSH BUTTONS NAMEPLATE DISPLAY Wide angle AUDIO/VIDEO Wide angle Night and Day CAMERA Inductive loop with control speechsynthesis Keypad Badge reader TWO SOLUTIONS, ONE SINGLE “ELECTRONIC HEART” WITH ONLY 13 ELECTRONIC MODULES A WIDE RANGE OF AUDIO AND VIDEO FUNCTIONS 2 WIRE SYSTEM

34 ﬂush mounted box rainshield(optional) support frame function modules front covers - FLUSH MOUNTED INSTALLATION wall mounted box with in-built rainshield support frame function modules front covers surround plate - FLUSH MOUNTED INSTALLATION ﬂush mounted box with tearing protection support frame function modules front covers Note: compatibility with SFERA CLASSIC ﬂush mounted boxes wall mounted box with in-built rainshield support frame function modules front covers surround plate Note: compatibility with SFERA CLASSIC ﬂush mounted boxes ENTRANCE PANELS Installation 2 WIRE SYSTEM - WALL MOUNTED INSTALLATION - WALL MOUNTED INSTALLATION

35 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE SFERA New - mechanics and function modules FLUSH MOUNTED BOX ELECTRONIC MODULES RAINSHIELD (optional) WALL MOUNTED BOX (optional) FRAME + SUPPORT SURROUND PLATE 3500101 module 351000basic speaker module 3505111 module 3505414 modules 3506111 module 3506414 modules 3502111 module 3500202 modules 3521008 push buttons on double row 3505212 modules 3505616 modules 3506212 modules 3506616 modules 3502212 modules 3500303 modules 353000keypad 3505313 modules 3505919 modules 3506313 modules 3506919 modules 3502313 modules 350521 350561 350621 350641 350661 350221 352100 351300audio/video with wide angle camera 352500display 351300 352500 3520004 push buttons on single row 352700Inductive loop and control speech synthesis 352000 352700 353000 351100speaker module 352200nameplate 353200badge reader 351100 352200 353200 351200audio/video 352400wide angle N/D camera 351200 352400 351000 2 WIRE SYSTEM

36 AUDIO FRONT COVERS - PUSH BUTTON CALL 351001basic speaker module 351101speaker module 3520313 push buttons 351000 351100 352000 351000 351100 352000 351000 351100 352100 351000 351100 352100 351000 351100 351011basic speaker module 1 push button 351111speaker module 1 push button 3520414 push buttons 351021basic speaker module2 push buttons 351121speaker module 2 push buttons 3521616 push buttons on 2 rows 351041basic speaker module2 push buttons on 2 rows 351141speaker module 2 push buttons on 2 rows 3521818 push buttons on 2 rows 351081basic speaker module4 push buttons on 2 rows 351181speaker module 4 push buttons on 2 rows 351100 351100 351100 351100 351100 351000 351000 351000 351000 351000 352000 352000 352100 352100 351001 351011 351021 351041 351081 351101 351101 351111 351111 351121 351121 351141 351181 351181 352161 352181 352031 352041 ENTRANCE PANEL CATALOGUE SFERA New - front cover 2 WIRE SYSTEM

37 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE VIDEO FRONT COVERS - NAMEPLATE - BLANKING MODULE DISPLAY FRONT COVERS - INDUCTIVE LOOP AND ACCESS CONTROL 351201A/V 352501display 352401wide angle N/D camera 351200 352500 352400 351200 352700 351200 353200 352200 351300 353000 351300 351300 351211A/V 1 push button 352701Inductive loop - speech synthesis 352301blanking module 351221A/V 2 push buttons on 2 rows 353201badge reader 352201nameplate 351301A/V wide angle 353001keypad 351311A/V wide angle 1 push button 351321A/V wide angle2 push buttons on 2 rows 351200 351200 351200 351300 351300 351300 352200 352400 352500 352700 353000 353200 351201 351211 351221 351301 351311 351321 352201 352401 352301 352501 352701 353001 353001 353201 2 WIRE SYSTEM

38 ENTRANCE PANEL CATALOGUE SFERA Robur - Mechanics and function modules 2 WIRE SYSTEM ELECTRONIC MODULES 351000basic speaker module 3521008 push buttons on double row 353000keypad 352100 351300audio/video with wide angle camera 352500display 351300 352500 3520004 push buttons on single row 352700Inductive loop and control speech synthesis 352000 352700 353000 353000 351100speaker module 352200nameplate 353200badge reader 351100 352200 353200 351200audio/video 352400wide angle N/D camera 351200 352400 351000 3501101 module 3501202 modules 3501303 modules 350130 350110 350120 3503151 module 3503252 modules 3503353 modules 350315 350325 350335 3504151 module 3504252 modules 3504353 modules 350415 350425 350435 FLUSH MOUNTED BOX SUPPORT FRAME SURROUND PLATE Note:- compatibility with SFERA CLASSIC ﬂush mounted boxes- compatibility with SFERA NEW ﬂush mounted boxes 3506111 module 3506414 modules 3506212 modules 3506616 modules 3506313 modules 3506919 modules 350631 350691 350661 350621 350641 3 0 WALL MOUNTED BOX (optional) O X X X ASSIC W

39 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE SFERA Robur - Mechanics and function modules AUDIO FRONT COVERS - PUSH BUTTON CALL VIDEO FRONT COVERS - NAMEPLATE - BLANKING MODULE DISPLAY FRONT COVERS - INDUCTIVE LOOP - ACCESS CONTROL 351005basic speaker module 351105speaker module 3520353 push buttons 351000 351100 352000 351205A/V 352505display 352405wide angle N/D camera 351200 352500 352400 351000 351100 352000 351015basic speaker module 1 push button 351115speaker module 1 push button 3520454 push buttons 351200 352700 351215A/V 1 push button 352705Inductive loop - control speech synthesis 351000 351100 352100 351025basic speaker module 2 push buttons 351125speaker module 2 push buttons 3521656 push buttons on 2 rows 351200 353200 352200 351225A/V 2 push buttonson 2 rows 353205badge reader 352205nameplate 351000 351100 352100 351045basic speaker module 2 push buttons on 2 rows 351145speaker module 2 push buttons on 2 rows 3521858 push buttons on 2 rows 351300 353000 352305blanking module 351305A/V wide angle 353005keypad 351300 351315A/V wide angle 1 push button 351300 351325A/V wide angle 2 push buttons on 2 rows 351000 351100 351085basic speaker module 4 push buttons on 2 rows 351185speaker module 4 push buttons on 2 rows 351100 351100 351100 351100 351100 351000 351000 351000 351000 351000 352000 352000 352100 352100 351200 351200 351200 351300 351300 351300 352200 352400 352500 352700 p y 353000 353200 351005 351005 351015 351015 351025 351025 351045 351045 351085 351085 351105 3 0 351115 351115 351125 351125 351145 351145 351185 351185 352035 352045 352165 352185 352185 351205 351215 351225 351305 351305 351315 351325 352205 352305 352305 352405 352405 352505 352505 352705 353005 353205 CTIVE LOO 2 WIRE SYSTEM

41 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE SFERA New audio EP with speaker module, item 351100 42 SFERA Robur audio EP with speaker module, item 351100 44 SFERA New video EP with A/V wide angle module, item 351300 46 SFERA Robur video EP with A/V wide angle module, item 351300 48 SFERA New video EP with N&D wide angle camera module, item 352400 50 SFERA Robur video EP with N&D wide angle camera module, item 352400 52 SFERA NEW SFERA ROBUR Index 2 WIRE SYSTEM Examples of compositions of audio and video entrance panels

42 No. of calls 350010 350020 350030 350211 350221 350231 351100 352000 1 1 1 1 2 1 1 1 3 1 1 1 1 4 1 1 1 1 5 1 1 1 1 6 1 1 1 1 7 1 1 1 2 8 1 1 1 2 9 1 1 1 2 10 1 1 1 2 11 1 1 1 12 1 1 1 13 1 1 1 14 1 1 1 15 1 1 1 16 1 1 1 17 1 1 1 18 1 1 1 19 1 1 1 20 1 1 1 350020 350030 350221 350231 351100 352500 353000 without keypad 1 1 1 1 with keypad 1 1 1 1 1 ( ) - the speaker module is also available in the basic version (351000), with appropriate front covers.NOTE: the double push button row solution makes it possible to install systems with up to 20 call push buttons using only one flush mounted box. NOTE: the display module item 352500 provides storage for up to 4000 residents names. 2 WIRE ENTRANCE PANELS - AUDIO SFERA NEW Examples of compositions with speaker module, item 351100 Digital call audio composition with display module 352500 and keypad 353000 PUSH BUTT ONS ON SINGLE RO W PUSH BUTT ONS ON DOUBLE RO W FLUSH MOUNTED BOXES FLUSH MOUNTED BOXES FRAME + SURROUND PLATE ELECTRONIC MODULES FRAME + SURROUND PLATE ELECTRONIC MODULES Speaker module   4 push buttons Speaker module Display Keypad 2 WIRE SYSTEM

43 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 352100 351101 351111 351121 352031 352041 351141 351181 352161 352181 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 2 1 2 1 1 1 1 1 1 2 1 1 1 2 1 1 1 2 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 1 2 351101 352501 353001 1 1 1 1 1 WARNING Add to the system composition any configurators needed. As an alternative to using the flush mounted boxes indicated, installation is also possible using wall mounted boxes with rainshield, available in different modularities (see catalogue). 1 to 9 module rainshields are available on request (see catalogue). The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. FRONT COVERS AUDIO + PUSH BUTTON CALL FRONT COVERS 8 push buttons 2 WIRE SYSTEM

44 No. of calls 350110 350120 350130 350315 350325 350335 351100 352000 352100 351105 1 1 1 1 2 1 1 1 3 1 1 1 1 1 4 1 1 1 1 1 5 1 1 1 1 6 1 1 1 1 7 1 1 1 2 1 8 1 1 1 2 1 9 1 1 1 2 10 1 1 1 2 11 1 1 1 1 12 1 1 1 1 13 1 1 1 2 1 14 1 1 1 2 1 15 1 1 1 2 1 16 1 1 1 2 1 17 1 1 1 2 18 1 1 1 2 19 1 1 1 2 20 1 1 1 2 2 WIRE ENTRANCE PANELS - AUDIO SFERA ROBUR Examples of compositions with speaker module, item 351100 FLUSH MOUNTED BOXES TAMPERPROOF SUPPORT FRAME ELECTRONIC MODULES Speaker module   4 push buttons 8 push buttons ( ) - the speaker module is also available in the basic version (351000), with appropriate front covers.NOTE: the double push button row solution makes it possible to install systems with up to 20 call push buttons using only one flush mounted box. p 350120 350130 350325 350335 351100 352500 353000 without keypad 1 1 1 1 with keypad 1 1 1 1 1 NOTE: the display module item 352500 provides storage for up to 4000 residents names. Digital call audio composition with display module 352500 and keypad 353000 FLUSH MOUNTED BOX TAMPERPROOF FRAME ELECTRONIC MODULES Speaker module Display Keypad PUSH BUTT ONS ON SINGLE RO W PUSH BUTT ONS ON DOUBLE RO W 2 WIRE SYSTEM

45 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 351115 351125 352035 352045 351145 351185 352165 352185 350415 350425 350435 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 AUDIO + PUSH BUTTON CALL FRONT COVERS SURROUND PLATE 351105 352505 353005 350425 350435 1 1 1 1 1 1 1 FRONT COVERS SURROUND PLATE WARNING Add to the system composition any configurators needed. In alternative to flush mounted steel boxes (tamper-proof), it is also possible to use plastic flush mounted boxes, items 350010, 350020, and 350030. SFERA ROBUR can be wall mounted using the specific boxes with built-in rainshield, available in several modularities (see catalogue). 1 to 9 module rainshields are available on request (see catalogue). The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. 2 WIRE SYSTEM

46 No. of calls 350010 350020 350030 350211 350221 350231 351300 1 1 1 1 2 1 1 1 3 1 1 1 4 1 1 1 5 1 1 1 6 1 1 1 7 1 1 1 8 1 1 1 9 1 1 1 10 1 1 1 11 1 1 1 12 1 1 1 13 1 1 1 14 1 1 1 15 1 1 1 16 1 1 1 17 1 1 1 18 1 1 1 2 WIRE ENTRANCE PANELS - VIDEO SFERA NEW Examples of composition with wide angle audio/video module, item 351300 ( ) - the A/V module is also available in the standard camera version (351200), with appropriate front covers.( ) - for 2 calls only use the composition with one module with 2 push buttons on double row.NOTE: the double push button row solution makes it possible to install systems with up to 18 call push buttons using only one flush mounted box. 350020 350030 350221 350231 351300 352500 353000 without keypad 1 1 1 1 with keypad 1 1 1 1 1 NOTE: the display module item 352500 provides storage for up to 4000 residents names. Digital call audio/video composition with display module 352500 and keypad 353000 FLUSH MOUNTED BOX FRAME + SURROUND PLATE ELECTRONIC MODULES A/V Display Keypad A/V   FLUSH MOUNTED BOXES FRAME + SURROUND PLATE PUSH BUTT ONS ON SINGLE RO W P U S H B U T T O N S O N D O U B L E R O W ( ) 2 WIRE SYSTEM

47 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 352000 352100 351301 351311 352031 352041 351321 352161 352181 1 1 1 1 1 1 1 1 1 1 1 2 1 2 2 1 1 1 2 1 2 2 1 2 1 1 1 2 1 2 2 1 2 2 1 1 1 2 1 1 1 2 1 2 2 1 2 2 1 2 2 1 2 351301 352501 353001 1 1 1 1 1 FRONT COVERS WARNING Add to the system composition any configurators needed As an alternative to using the flush mounted boxes indicated, installation is also possible using wall mounted boxes with rainshield, available in different modularities (see catalogue). 4 push buttons 8 push buttons A/V + PUSH BUTTON CALL FRONT COVERS ELECTRONIC MODULES 1 to 9 module rainshields are available on request (see catalogue). The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. 2 WIRE SYSTEM

48 No. of calls 350110 350120 350130 350315 350325 350335 351300 352000 352100 1 1 1 1 2 1 1 1 3 1 1 1 1 4 1 1 1 1 5 1 1 1 1 6 1 1 1 2 7 1 1 1 2 8 1 1 1 2 9 1 1 1 2 10 1 1 1 1 11 1 1 1 2 12 1 1 1 2 13 1 1 1 2 14 1 1 1 2 15 1 1 1 2 16 1 1 1 2 17 1 1 1 2 18 1 1 1 2 2 WIRE ENTRANCE PANELS - VIDEO SFERA ROBUR Examples of composition with wide angle audio/video module, item 351300 FLUSH MOUNTED BOXES TAMPERPROOF SUPPORT FRAME ELECTRONIC MODULES ( ) - the A/V module is also available in the standard camera version (351200), with appropriate front covers.( ) - for 2 calls only use the composition with one module with 2 push buttons on double row.NOTE: the double push button row solution makes it possible to install systems with up to 18 call push buttons using only one flush mounted box. 350120 350130 350325 350335 351300 352500 353000 without keypad 1 1 1 1 with keypad 1 1 1 1 1 NOTE: the display module item 352500 provides storage for up to 4000 residents names. Digital call audio/video composition with display module 352500 and keypad 353000 FLUSH MOUNTED BOXES TAMPERPROOF SUPPORT FRAME ELECTRONIC MODULES A/V Display Keypad 4 push buttons A/V   8 push buttons PUSH BUTT ONS ON SINGLE RO W P U S H B U T T O N S O N D O U B L E R O W ( ) 2 WIRE SYSTEM

49 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 351305 351315 352035 352045 351325 352165 352185 350415 350425 350435 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 2 1 1 2 1 1 1 1 1 2 1 1 2 1 1 1 1 1 1 1 1 1 1 2 1 1 2 1 1 2 1 1 2 1 A/V + PUSH BUTTON CALL FRONT COVERS SURROUND PLATE 351305 352505 353005 350425 350435 1 1 1 1 1 1 1 WARNING Add to the system composition any configurators needed In alternative to flush mounted steel boxes (tamper-proof), it is also possible to use plastic flush mounted boxes, items 350010, 350020, and 350030. SFERA ROBUR can be wall mounted using the specific boxes with built-in rainshield, available in several modularities (see catalogue). 1 to 9 module rainshields are available on request (see catalogue). FRONT COVERS SURROUND PLATE The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. 2 WIRE SYSTEM

50 2 WIRE ENTRANCE PANELS - VIDEO SFERA NEW VIDEO Examples of composition with wide angle Night and Day camera module, item 352400 No. of calls 350020 350030 350221 350231 352400 351100 352000 352100 1 1 1 1 1 2 1 1 1 1 3 1 1 1 1 1 4 1 1 1 1 1 5 1 1 1 1 1 6 1 1 1 1 1 7 1 1 1 1 1 8 1 1 1 1 1 9 1 1 1 1 1 10 1 1 1 1 1 11 1 1 1 1 1 12 1 1 1 1 1 13 2 2 1 1 2 14 2 2 1 1 2 15 2 2 1 1 2 16 2 2 1 1 2 17 2 2 1 1 2 18 2 2 1 1 2 19 2 2 1 1 2 20 2 2 1 1 2 For the connection of modules installed side by side, cable item 354000 (L=620 mm) must be used FLUSH MOUNTED BOXES FRAME + SURROUND PLATE ELECTRONIC MODULES 4 push buttons Speaker module N/D camera 8 push buttons 350030 350010 350231 350211 352400 351100 352500 353000 without keypad 1 1 1 1 1 with keypad 1 1 1 1 1 1 1 1 NOTE: the display module item 352500 provides storage for up to 4000 residents names. Digital call video composition with display module 352500 and keypad 353000 FLUSH MOUNTED BOXES FRAME + SURROUND PLATE ELECTRONIC MODULES Display Speaker module N/D camera Keypad PUSH BUTT ONS ON SINGLE RO W PUSH BUTT ONS ON DOUBLE RO W 2 WIRE SYSTEM

51 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 352401 351101 351111 351121 352031 352041 351141 351181 352161 352181 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 CAMERA + AUDIO PUSH BUTTON FRONT COVERS WARNING Add to the system composition any configurators needed(software configuration using TiSferaDesign recommended). As an alternative to using the flush mounted boxes indicated, installation is also possible using wall mounted boxes with rainshield, available in different modularities (see catalogue). 1 to 9 module rainshields are available on request (see catalogue). 352401 351101 352501 353001 1 1 1 1 1 1 1 FRONT COVERS The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. 2 WIRE SYSTEM

52 2 WIRE ENTRANCE PANEL - VIDEO SFERA ROBUR Examples of composition with wide angle Night and Day camera module, item 352400 No. of calls 350120 350130 350325 350335 352400 351100 352000 352100 352405 351105 1 1 1 1 1 1 2 1 1 1 1 1 3 1 1 1 1 1 1 1 4 1 1 1 1 1 1 1 5 1 1 1 1 1 1 6 1 1 1 1 1 1 7 1 1 1 1 1 1 1 8 1 1 1 1 1 1 1 9 1 1 1 1 1 1 10 1 1 1 1 1 1 11 1 1 1 1 1 1 12 1 1 1 1 1 1 13 2 2 1 1 2 1 1 14 2 2 1 1 2 1 1 15 2 2 1 1 2 1 1 16 2 2 1 1 2 1 1 17 2 2 1 1 2 1 18 2 2 1 1 2 1 19 2 2 1 1 2 1 20 2 2 1 1 2 1 FLUSH MOUNTED BOXES TAMPERPROOF SUPPORT FRAME ELECTRONIC MODULES 350130 350110 330335 330315 352400 351100 352500 353000 without keypad 1 1 1 1 1 with keypad 1 1 1 1 1 1 1 1 NOTE: the display module item 352500 provides storage for up to 4000 residents names. Digital call video composition with display module 352500 and keypad 353000 FLUSH MOUNTED BOX FRAME ELECTRONIC MODULES 4 push buttons Speaker module N/D camera 8 push buttons For the connection of modules installed side by side, cable item 354000 (L=620 mm) must be used Display Speaker module N/D camera Keypad PUSH BUTT ONS ON SINGLE RO W PUSH BUTT ONS ON DOUBLE RO W 2 WIRE SYSTEM

53 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 351115 351125 352035 352045 351145 351185 352165 352185 350425 350435 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 2 2 2 2 2 1 2 2 1 2 2 1 2 2 1 2 2 CAMERA + AUDIO PUSH BUTTON FRONT COVERS SURROUND PLATE 352405 351105 352505 353005 350435 350415 1 1 1 1 1 1 1 1 1 1 SURROUND PLATE FRONT COVERS WARNING Add to the system composition any configurators needed(software configuration using TiSferaDesign recommended). In alternative to flush mounted steel boxes (tamper-proof), it is also possible to use plastic flush mounted boxes, items 350020 - 350030. 1 to 9 module rainshields are available on request (see catalogue). SFERA ROBUR can be wall mounted using the specific boxes with built-in rainshield, available in several modularities (see catalogue). The shown compositions are examples. However, it is possible to install compositions with push buttons on single or double rows depending on needs. 2 WIRE SYSTEM

54 ENTRANCE PANEL CATALOGUE 2 WIRE SYSTEM 2 WIRE SYSTEM LINEA 100 343101 343102 343100 Item PUSH BUTTON ENTRANCE PANELS 343101 2 WIRE audio push button panel with 4 call push buttons for wall mounted installation. Fitted with internal contact (C - NO - NC) for the connection of an electrical door lock or an external actuator (for the power supply to the electrical door lock allow for the installation of auxiliary transformer item 336482). Connections (PL) for a local door lock release push button 343102 2 WIRE audio push button panel with 8 call push buttons for wall mounted installation. Fitted with internal contact (C - NO - NC) for the connection of an electrical door lock or an external actuator (for the power supply to the electrical door lock allow for the installation of auxiliary transformer item 336482). Connections (PL) for a local door lock release push button Item DIGITAL CALL ENTRANCE PANELS 343100 2 WIRE AUDIO digital call push button panel for wall mounted installation. The device consists of a push button panel with 16 keys and a digital display showing the operating status. Using previously saved numerical (SCS addresses) or alphanumerical (logical addresses) codes, it is possible to call the internal units, and for the residents to release the door lock using a dedicated numerical code. The push button panel manages up to 4000 internal unit addresses (from 0 to 3999), as well as the direct call to the 2 WIRE switchboard. Fitted with internal contact (C - NO - NC) for the connection of an electrical door lock or an external actuator (for the power supply to the electrical door lock allow for the installation of auxiliary transformer item 336482). Connections (PL) for a local door lock release push button Minimum protrusion from the wall STRONG AND DURABLE, THANKS TO THE METAL CASE ACCESS CONTROL FUNCTION (ONLY AVAILABLE WITH THE DIGITAL CALL VERSION)

55 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 2 WIRE SYSTEM LINEA 2000 entrance panels 342911 Audio and video entrance panels for wall mounted or gate post installation. 342951 Audio and video entrance panels for one-family and two-family systems for wall mounted, gate post, or flush mounted installation.Protection index against mechanical impact: IK10 (audio EP) – IK07 (video EP) 342971 342981342991 ENTRANCE PANEL CATALOGUE LINEA 2000 METAL entrance panels Item WALL MOUNTED AUDIO ENTRANCE PANELS 342971 2 WIRE audio push button panel with one call push button for wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK10 342972 As item 342971, but with 2 call push buttons Item LINEA 2000 AUDIO ENTRANCE PANELS 342911 2 WIRE audio push button panel with one call push button for wall mounted installation. Aluminium front cover. Nameplate lit by green LED 342921 As item 342911, but with 2 call push buttons LINEA 2000 VIDEO ENTRANCE PANELS 342951 2 WIRE video push button panel with black and white camera and one call push button. Wall mounted installation. Aluminium front cover. Nameplate lit by green LED WALL MOUNTED VIDEO ENTRANCE PANELS 342981 2 WIRE video push button panel with black and white camera and one call push button. With white LEDs for illumination of the viewing field in low light conditions. Communication status audible - light signals for: call active, system busy, door lock release. Wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK07 342982 As item 342981, but with 2 call push buttons 342991 2 WIRE video push button panel with colour camera and one call push button. With white LEDs for illumination of the viewing field in low light conditions. Communication status audible - light signals for: call active, system busy, door lock release. Wall mounted installation. Zamak front cover. Nameplate lit by blue LED. Protection index against mechanical impact: IK07 342992 As item 342991, but with 2 call push buttons LINEA 300 Video push button entrance panels for flush mounted or wall mounted installation, available in ALUMINIUM and STAINLESS STEEL finish. Protection index: IP44. Protection index against mechanical impact: IK07. Item ALUMINIUM FINISH PUSH BUTTON PANEL 308001 Monobloc vandal-resistant 2 WIRE video push button panel for 2 and 4 calls with aluminium finish. The item code includes: flush mounted box, frame, colour video and audio electronic module, prewired push button module/s. Presetting for the mounting of transponder reader or key switch. Backlit call keys. Visual and sound notifications of the communication status for: call active, system busy, door lock status 308002 As item 308001 but for up to 8 calls 308003 As item 308001 but for up to 12 calls 308004 As item 308001 but for up to 20 calls 308005 As item 308001 but for up to 32 calls STAINLESS STEEL FINISH PUSH BUTTON PANEL 308011 Monobloc vandal-resistant 2 WIRE video push button panel for 2 and 4 calls with stainless steel finish. The item code includes: flush mounted box, frame, colour video and audio electronic module, prewired push button module/s. Presetting for the mounting of transponder reader or key switch. Backlit call keys. Visual and sound notifications of the communication status for: call active, system busy, door lock status 308012 As item 308011 but for up to 8 calls 308013 As item 308011 but for up to 12 calls 308014 As item 308011 but for up to 20 calls 308015 As item 308011 but for up to 32 calls WALL MOUNTED BOXES 308021 Wall mounted box for push button panels, items 308001-308011 308022 Wall mounted box for push button panels,items 308002-308012 308023 Wall mounted box for push button panels, items 308003-308013 308024 Wall mounted box for push button panels, items 308004-308014 308025 Wall mounted box for push button panels, items 308005-308015 308001308011 308002308012 308003308013 308004308014

56 067219 INTERNAL UNIT CATALOGUE MyHOME Screen 10 AXOLUTEVIDEO STATION Item AXOLUTE VIDEO STATION NIGHTER AND WHICE 349320 2 WIRE handsfree video internal unit for wall mounted installation in Nighter finish. With 8” colour LCD display, backlit capacitive keypad with soft touch controls and PC customisable OSD navigation icon menu for the management of the following MyHOME applications: video door entry system, temperature control, sound system, automation (scenarios) and anti-intrusion and multimediality. In systems integrated with the sound system, the VIDEO STATION behaves as an amplifier, enabling playback of all audio/video sources connected to the system. Keys available: navigation, auto-switch on, door lock release, staircase lights, mute, handsfree/pager connection, and call exclusion. LED signalling for: call exclusion, door status, and connection. Firmware update/programming USB port. Can be integrated with MyHOME, also in combination with the Multimedia interface, item 3465 - (in this case, allow for a local video door entry system power supply). Suitable for wall mounted installation using the special bracket (supplied as standard). Can be configured using physical configurators or the TiNighterandWhiceStation programming and configuration software (supplied as standard) 349321 As item 349320, white 349320 349321 2 WIRE SYSTEM Item MyHOME SCREEN 10 067228 Touchscreen control terminal with LCD 16/9 10” display and new graphic interface for wall mounted installation.Black finish. In addition to the video door entry and the CCTV functions, when integrated with MyHOME home automation systems it becomes an actual control terminal for the home. Thanks to the advanced graphic interface, it is possible to control and monitor all the home automation functions, as well as offering navigation by room. It manages multimedia contents (Ethernet, USB, SD Card), and the WEB Browser. Possibility of customising the backgrounds. Wall installation with flush mounted box 506E. NO finishing surround plate required. 067219 As item 067228, white 067228 344613 344613 Item CLASSE 300 344612 2 WIRE handsfree video internal units with inductive loop and 7” colour TOUCHSCREEN LCD display.Main functions are activated by touch sensitive buttons. Curved slimline metal profile. Wall and table mounted. White 344613 As item 344612, black 344612 CLASSE 300

57 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 2 WIRE SYSTEM POLYX 344082 344163 344192 344163 344192 Item POLYX AUDIO 344082 Wall mounted 2 WIRE handsfree audio internal unit. Performs all the traditional door entry system functions. Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and 4 programmable keys, which operation is defined during the configuration procedure. Configuration through physical connection of the configurators. Wall fixing bracket supplied. Specific audible and visual signals mean that it is also suitable for use by disabled people. Fixing bracket supplied POLYX VIDEO BASE 344192 Wall mounted 2 WIRE handsfree video internal unit with 3.5” colour LCD display. Performs all the traditional video door entry system functions. Keys available: entrance panel/cycling activation, door lock release, staircase light switching on, and 4 programmable keys, which operation is defined during the configuration procedure. Configuration through physical connection of the configurators. Wall fixing bracket supplied. Specific audible and visual signals mean that it is also suitable for use by disabled people. Fixing bracket supplied POLYX MEMORY DISPLAY AND INDUCTIVE LOOP MODULE 344163 Wall mounted installation 2 WIRE handsfree video internal unit with audio and video memory. With 3.5” colour LCD display with PC customisable OSD navigation icon menu for the management of the following MyHOME applications: video door entry system, temperature control, sound system, scenarios and anti-intrusion. With video door entry system answering machine with call memory function. LED signalling for: call exclusion, door status, connection with entrance panel, and answering machine status. Suitable for wall mounted installation using the special bracket (supplied as standard). Configuration using the physical configurators or the TiPolyxMemoryDisplay software supplied as standard with the product 2 WIRE SYSTEM

58 344582 344502344512 HANDSET ACCESSORY FOR CLASSE 100 344582 Accessory device for the wall mounted or table-top installation with handset at the side (support to be purchased separately) for CLASSE 100V12E (344522), and CLASSE 100X12B (344602) video internal units. With this type of installation, the device can be used to communicate in both ways: using the handset or in handsfree mode.The accessory includes the basic support for the housing and the wall mounting of the video internal unit and the integrated audio handset. No. 2 supports 344552 are required for table-top installation(to be purchased separately). Item CLASSE 100 VIDEO INTERNAL UNIT 344502 2 WIRE handsfree colour video internal unit for wall mounted or table top installation (support required, to be purchased separately). 4 push buttons door lock release, handsfree connection, staircase lights, and entrance panel activation and cycling. Independent adjustment of ringtone volume, speaker volume, display colour and brightness. 344512 As above but with INDUCTIVE LOOP 344552 Table top support for 344502 - 344512 344582 Item CLASSE 100 VIDEO INTERNAL UNIT 344522 2 WIRE handsfree colour video internal unit with inductive loop, preset for different types of installations, depending on the accessories: wall mounted, flush mounted, table mounted, with side-by-side handset, and tilted, when wall and flush mounted. 4.3” (16:9) colour LCD display. Keys available: entrance panel/ scrolling activation, door lock release, staircase light control, handsfree connection and 4 configurable keys. Depending on the configurators connected to (M), the 4 configurable keys perform different functions (e.g. Intercom, additional door lock activation, generic activations). LEDs used for: call exclusion, door status, connection with the entrance panel. Adjustable audio and ringtone volume (with call exclusion), as well as display colour, brightness, and contrast, using the appropriate rocker keys, after accessing the menu using the dedicated keys. 16 different ringtones available. Wall mounted bracket supplied. For all other types of installation, use appropriate accessories purchased separately. The device must be configured. 344602 2 WIRE handsfree colour video internal unit with inductive loop, preset for different types of installations, depending on the accessories: wall mounted, flush mounted, table mounted, with side-by-side handset, and tilted, when wall and flush mounted. The device, appropriately integrated with an Energy Management system, provides graphic display of consumption. Function for storing messages from a 2 WIRE switchboard. LEDs used for: call exclusion, door status, connection with the entrance panel, and new message notification. Adjustable audio and ringtone volume (with call exclusion), as well as display colour, brightness, and contrast, using the appropriate rocker keys, after accessing the menu using the dedicated keys. 16 different ringtones available Wall mounted bracket supplied. For all other types of installation, appropriate accessories purchased separately. The device must be configured. 344522 344602 2 WIRE SYSTEM INTERNAL UNIT CATALOGUE CLASSE 100

59 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE 344552 344252 Item CLASSE 100 AUDIO INTERNAL UNIT 344252 2 WIRE handsfree audio internal unit for wall mounted or table topinstallation (support required, to be purchased separately). 4 push buttons door lock release, handsfree connection, staircase lights, and entrance panel activation and cycling. Independent adjustment of ringtone volume and speaker volume 344552 Table top support 344252 344824 344704 SWING Item SWING AUDIO AND VIDEO HANDSETS 344704 2 WIRE audio handset for wall mounted installation. Fitted with keys for: door lock release and 4 programmable keys (0-1-2-3), operating mode is set through theconfiguration. Adjustable or disabled ringtone volume. Conversation secrecy function, office function, and door lock release (signalling through appropriate LED). White. Wall mounted bracket supplied as standard 344824 2 WIRE video handset with colour 4” TFT monitor. Wall mounted installation. With door lock release key and 4 programmable keys (0-1-2-3), which operating mode is setthrough appropriate configuration procedure. The ringtone volume can be adjusted, or the ringtone volume may be disabled. Conversation secrecy function, office function, and door lock release (signalling through appropriate LED). White. Wall mounted bracket supplied as standard Item CLASSE 100 AUDIO INTERNAL UNIT 344262 2 WIRE internal unit with handset for wall mounted or table-top installation (with specific support to be purchased separately). Keys available: entrance panel/scrolling activation, door lock release and staircase lights control. LEDs used for: call exclusion, door status, connection with the entrance panel. Bell volume adjustment (with call exclusion) using the appropriate selector. 16 different ringtones available. For wall mounted installation, the bracket supplied must be used. The device must be configured. 344272 2 WIRE internal unit with handset for wall mounted or table-top installation (with specific support to be purchased separately). Keys available: auto-switching on / cycling, door lock release, staircase lights control and 4 configurable keys. Depending on the configurators connected to (M), the 4 configurable keys will perform different functions (e.g. Intercom, additional door lock activation, generic activations). LEDs used for: call exclusion, door status, connection with the entrance panel. Bell volume adjustment (with call exclusion) using the appropriate selector. 16 different ringtones available. For wall mounted installation, the bracket supplied must be used. The device must be configured Item 100 AUD D IO INTERNA 344262 344272 2 WIRE SYSTEM INTERNAL UNIT CATALOGUE CLASSE 100 SPRINT L2 Item SPRINT L2 AUDIO HANDSET 344242 2 WIRE audio handset (without the possibility of fitting withaccessories) for audio systems and mixed audio /video systems.Wall mounted installation without the need of accessories.With door lock release key and auxiliary functions key (thatcan be configured). Ringtone volume adjustable on 3 levels. White 344242

60 INTERNAL UNIT CATALOGUE 2 WIRE Switchboard Software Switchboard 346310 Item SWITCHBOARD AND ACCESSORIES 346310 Switchboard for 2 WIRE audio and video systems. Provides access to various services (video door entry system functions, door lock and/or stair light management, and monitoring of apartment alarms) directly from the keyboard, or using the intuitive menu icons. Supplied with built-in table-top support and has a 7” colour LCD display, receiver and handsfree, dedicated keys for the main functions, and configurable keys. Programming can be performed directly from the device, orusing a PC with the software (supplied as standard) 336982 8-way socket, white LIVINGLIGHT, for table-top installation of switchboard item 346310 346300 Item SOFTSWITCHBOARD SOFTWARE 346300 Switchboard software for the management of audio and videodoor entry system calls. The software (Windows operatingsystem compatible) can be installed on any desktop or laptopPC, and gives the possibility of receiving, managing andtransferring the calls from the entrance panel and the handset.Implements home video monitoring, with cyclical displayof the cameras, night and day functions, and the possibilityof displaying the alarms in the various apartments.- Supported operating systems: Microsoft Windows XP Service Pack 2 and Windows Vista.- Software required: NET Framework 2.0 or higher CL AK Camera enabling Entrance panel call reception Door lock release Staircase light switching on Intercomcalls Alarm reception and management 2 WIRE SYSTEM

61 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE SYSTEM ACCESSORIES CATALOGUE DIN accessories 346850 346891 346000 346030 F441 VIDEO MIXER 346830 Video adapter with 2 DIN modular housing. For connecting 3 BUS to the system. Therefore, it is possible to install systems with 2 video entrance panels and 1 riser, as well as systems with one video entrance panel and 2 risers. The device must be used with system power supply, item 346000 F441 Audio/video node with 2 DIN modular housing preset with 4 input clamps and 4 output clamps. Can be used for connecting up to 4 source device posts (entrance panels or cameras) on the input and up to 4 2 WIRE video risers on the output. The device must be used with system power supply item 346000. Must be used in alternative to the audio/video adapter, item 346830 F441M Multichannel matrix with 10 DIN modular housing.Preset for the connection of video door entry system entrance panels, cameras and sound system sources on the input, and entrance panels and amplifiers on the output. Four inputs are for entrance panels/cameras, and 4 for sound system sources. Enables to create multichannel sound system. The device must be used with system power supply item 346000. Within the systems, it replaces the video adapter, item 346830, and the audio/video node, item F441 Item POWER SUPPLIES 346000 2 WIRE audio and video system power supply with 8 DIN modular housing. Power supply 230V a.c. @ 50-60 Hz. On the output it supplies 27V d.c. continuous low voltage, with a maximum current of 1.2A. Electronically protected (without fuses) against short circuit and overload. SELV double insulation safety device 346040 2 WIRE audio system power supply with 6 DIN modular housing. Power supply 110 – 240V a.c. @ 50 – 60 Hz. On the output it supplies 27V d.c. rated low voltage, and a maximum rated current of 600mA. Protected on the PRI side (with fuses) against short circuit and overload. SELV double insulation safety device 346030 Mini power supply with integrated video adapter for small 2 WIRE video systems (intercom). 2 DIN modular housing. Power supply 230V a.c. @ 50-60 Hz. On the output it supplies 27V d.c. continuous low voltage, with a maximum current of 600mA. Protected on the PRI side (with fuses) against short circuit and overload. SELV double insulation safety device 346020 Additional power supply used for the local power supply of preset handsets and entrance panels. 2 DIN modular housing. Power supply 230V a.c. @ 50-60 Hz. On the output it supplies 27V d.c. continuous low voltage, with a maximum current of 600mA. Protected on the PRI side (with fuses) against short circuit and overload. SELV double insulation safety device Item SYSTEM INTERFACE 346850 Apartment interface in 4 DIN modular housing. Can be used to interface to a 2 WIRE riser a dedicated apartment video door entry system with local video monitoring system, sound system, and MyHOME applications control. The device must be configured using physical configurators 346851 System expansion interface with modular 4 DIN housing. Enables doubling of the length of the entrance panel - handset line, to create independent audio risers, and to expand the range or functions of the apartment system. The device must be configured using physical configurators DIN ACTUATORS 346200 Relay actuator with 4 DIN modular housing. Can be used for switching the lights on, opening the gates, repeating calls on bells (MOD=SLA), or for controlling other devices using the video handsets. The device must be configured using physical configurators 346230 Door lock relay actuator with 2 DIN modular housing. For the power supply and activation of an electrical door lock. The device must be configured using physical configurators 346260 Timed door lock relay actuator with 4 DIN modular housing. Can be used for switching the lights on, opening gates, or manage electromagnetic door locks, timed door opening, and door lock status (with NC contact). The device must be configured using physical configurators 346210 Relay actuator for 2 wire systems. Enables switching on lights, the release of door locks, the control of other devices from the video handsets and provides call repetition using bells. This device REQUIRES configuration. INTERFACES WITH OTHER BTICINO SYSTEMS 346891 2 WIRE - IP interface with 10 DIN modular housing. Thanks to the creation of an IP backbone with 2 WIRE risers, gives the possibility of installing very large mixed 2 WIRE/IP systems with a high number of devices. The device must be configured using physical configurators, or the software supplied 346810 2 WIRE - PABX interface with 3 DIN modular housing.For interfacing the 2 WIRE audio system with PABX 335818 and 335828 telephone switchboards 346200 346000 346030 F441 346850 346891 2 WIRE SYSTEM

62 SYSTEM ACCESSORIES CATALOGUE Item BASIC HOUSING DEVICES 346841 4 outputs floor shunt. For installing 2 WIRE video doorentry systems with star wiring distribution. The deviceautomatically adapts the video signal. Thanks to its compactsizes, it can also be fitted inside a flush mounted box 346833 Call to the floor interface. By connecting a traditionalpush button, the following functions will be possible: generalcall to the floor, addressed call to the floor, staircase lightson, and door lock release (specific actuator needed) andassociation of the video image to the call to the floor. The device must be configured using physical configurators 347400 Interface for the conversion of the coaxial signal into a 2 WIRE BUSsignal. Can be used to connect to the BUS of the 2 WIRE videodoor entry system a camera with coaxial video output powered at12V d.c., with maximum absorption 150 mA and 1 Vpp video output (75 Ω). The device must be configured using physical configurators UNIVERSAL SPEAKER UNIT AND EXPANSION MODULE 346991 The universal speaker unit can be used to install the 2 WIRE audio system in new or refurbished systems, where push button panels of other manufacturers are present orrequired (mail boxes, patterned brass, compact sheet metalunits, etc.), preset for a traditional speaker module (e.g. 2659N). The universal speaker unit has a contact base for the connection of 8 call keys; for systems with a higher numberof keys up to 56 one or more key expansion modules must be used (1 every 8 keys) 346992 Expansion module for connecting more than 8 call keys to item346991 - max. 6 modules (56 calls max.) with power supply346000. Max 2 modules (24 calls max.) with power supply 346010 Item WIRING ACCESSORIES 346870 2 WIRE video amplifier. In video systems wired usingnon-twisted wires, where the distance between theentrance panels and the handset exceeds 50 metres, itenables increasing such distance to up to 100 metres 346250 Gate opening relay module to be used with LINEA 2000, LINEA 2000 METAL, MINISFERA AND SFERA push button panels (only audio/video module 342560). Can be used to release door locks (NOT managed through the BUS) from the entrance panel 3499 Line terminator. To be used to terminate the riseror apartment line, when the last installed deviceis not fitted with line closing micro switch 354000 Cable for the connection of more SFERA NEW and SFERA ROBUR push button modules. Length 620mm 346841 347400 346870 3499 347400 346841 346870 3499 346991 346991 346250 2 WIRE SYSTEM

63 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Transponder keys and programmer Item SYSTEM CABLE 336904 Specific cable for 2 wire video door system applications with 2twisted conductors. Can be installed in underground piping, in accordance with CEI 20-13 e CEI 20-14 standards. Ensures thebest performance in video systems (higher distance betweenEP and Handset when compared with other cables). 200 m coil System cable Conﬁgurators 348205 348202 348201 Item TRANSPONDER KEYS AND PROGRAMMER 348200 Black transponder key 348201 Red transponder key 348202 Green transponder key 348203 Blue transponder key 348204 Orange transponder key 348205 Grey transponder key 348206 Yellow transponder key 348402 Table-top transponder key programmer CONFIGURATOR KIT 3501K Configurator kit consisting of:- 10 pieces for each type of configurator from 0 to 9- 2 blue removable 8-clamp connectors- 2 green removable 2-clamp connectors- 1 configurator connection tool- 1 plastic screwdriver Item CONFIGURATORS (10 PIECE 5 PACK) 3501/0 Configurator 0 3501/1 Configurator 1 3501/2 Configurator 2 3501/3 Configurator 3 3501/4 Configurator 4 3501/5 Configurator 5 3501/6 Configurator 6 3501/7 Configurator 7 3501/8 Configurator 8 3501/9 Configurator 9 3501/JMP Configurator JMP 3501K 3501K 2 WIRE SYSTEM 336904 2 WIRE SYSTEM

64 WIRING DIAGRAM Example of multi-family audio system BUS BUS BUS BUS BUS BUS BUS BUS 230V a.c. BUS BUS C NO NC P L 344242 344242 344242 344242 344242 344242 344242 344242 346040 343102 N = - = 7 P = - N = - = 8 P = - N = - = 5 P = - N = - = 6 P = - N = - = 3 P = - N = - = 4 P = - N = - = 1 P = - N = - = 2 P = - P = - = - N = - = - T = - S = - APARTMENT 1 APARTMENT 3 APARTMENT 5 APARTMENT 7 APARTMENT 2 APARTMENT 4 APARTMENT 6 APARTMENT 8 3 3 3 3 2 2 2 2 2 2 2 2 BUS BU Entrance panel S 2 WIRE SYSTEM

65 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Example of multi-family video system BUS 2 1 BUS BUS BUS BUS 230V a.c. ON ON ON P = – = – N = – = 1 S = – T = – M = – J1 = – JMP P = – = – N = 1 = 6 MOD = – = – P = – = – N = 1 = 8 MOD = – = – P = – = – N = – = 2 M = – = – P = – = – N = – = 1 M = – = – ON 346841 344832 346841 346841 344192 344082 351200 352100 346830 346000 352100 APARTMENT 1 APARTMENT 2 APARTMENT 16 APARTMENT 18 344832 P N M 344192 P N M 344082 3468 BUS 2 1 346000 346 346 346 P N M 344832 S Entrance panel 2 WIRE SYSTEM

67 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE System overview 68 Entrance panel overview 72 Internal unit overview 73 D45 system Index D45 Entrance panels 72 Internal units 73 System accessories 74 Examples of wiring diagrams 76 System to system interfaces 78 Software 79 Catalogue

68 The high performance system offer Complexes with large numbers of apartments D45 SYSTEM simpliﬁes installation in residential complexes with large numbers of apartments. The use of UTP cables and RJ45 connections for all the devices provides quick, easy installation for both backbone and riser devices. The system is suitable for the varied requirements of systems of different sizes on risers or TCP/IP networks, ensuring maximum cost saving. ANTI-TAMPER FUNCTION ON ALL INDOOR HANDSETS INTERCOM BETWEEN ALL THE APARTMENT OF THE RISER SOS PUSH BUTTON ON ALL INDOOR HANDSETS POSSIBILITY TO CONNECT AN ADDITIONAL CAMERA TO THE SWITCHBOARD ETS R ETS OARD D45 SYSTEM

69 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE D45 INSTALLATION OF UP TO: Apartments Handsets per riser Entrance panels per riser Switchboards Riser shunts Distance for colour video installation Distance for B/W video installation HIGH PERFORMANCE AUDIO INTERCOMBETWEEN APARTMENTS Switchboard operation as a comprehensive alarm management device: alarm receipt, recording and storage functions. 4000 800 80 16 100 1 km 2 km VIDEO DOOR ENTRY SYSTEM CATALO

70 ENTRANCE PANEL OVERVIEW Three different entrance panels to meet different needs: DIGITAL CALL ENTRANCE PANEL PUSH BUTTON CALL ENTRANCE PANEL SINGLE CALL ENTRANCE PANEL Digital call keypad for large buildings numeric or alphanumeric code access control function - open the door with a code number - one conﬁgurable code per family direct call to switchboard Zamak ﬁnish guarantees high resistance IP54 protection index ﬂush mounted (box sold with entrance panel) possibility of use in conjunction with name plate module software conﬁguration call list addresses Call push button calls for large buildings same design as the digital call version 10 and 20 push button models 16 and 32 push button extension panel models easy name label replacement IP54 protection index ﬂush mounted installation Single push button call suitable for: ONE-FAMILY system private entrance panel in multi-family system aluminium alloy panel IP54 protection degree wall mounted installation D45 SYSTEM

71 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE INTERNAL UNIT OVERVIEW Different models of internal units to cover all the market segments, from audio to colour video solutions, from basic to innovative functions : AUDIO OFFER AUDIO HANDSET VIDEO OFFER B/W AND COLOUR VIDEO INTERNAL UNITS wall mounted installation door lock push button direct call to the switchboard external SOS push button option wall mounting installation SOS push button INTERCOMdirect call to the switchboarddoor lock push button direct integration with alarm sensors Entry level 3.5" colour handsfree Top level 7" wide screen colour handsfree Touchscreen 7" wide screen colour handsfree Touchscreen 10" wide screen colour handsfree B/W handset B/W handsfree D45

72 Item DIGITAL CALL COLOUR ENTRANCE PANEL 322011 Zamak digital call entrance panel with keyboard, LCD display andcolour camera. Address list feature. Equipped with door lock release and burglar alarm notification. Configuration screen menu and software upgrade without the need to dismantle the device.Flush mounted installation (flush mounted box sold with the entrance panel). Protection index : IP54 NAMEPLATE MODULE 322012 Zamak nameplate module to install at the side of the digital call entrance panel 322010 to insert the list of residents or customised messages. Easy insertion / replacement of nameplates.Flush mounted installation (flush mounted box sold with the module). Protection index : IP54 PUSH BUTTON CALL COLOUR ENTRANCE PANELS 322030 Zamak push button entrance panel with 10 call push buttons and colour camera. Flush mounted installation (flush mounted box sold with the entrance panel). Protection index : IP54 322031 Zamak push button entrance panel with 20 call push buttons and colour camera. Flush mounted installation (flush mounted box sold with the entrance panel). Protection index : IP54 Item ADDITIONAL PUSH BUTTON MODULE 322032 Additional Zamak push button panel with 16 call push buttons on single column. Easy insertion / replacement of nameplates. Flush mounted installation (flush mounted box sold with the module). Protection index: IP54 322033 Additional Zamak push button panel with 32 call push buttons on double column. Easy insertion / replacement of nameplates. Flush mounted installation (flush mounted box sold with the module). Protection index: IP54 SINGLE CALL SMALL ENTRANCE PANEL 322020 Aluminium alloy single call small entrance panel to be installed in one-family systems or as private entrance panel in multi-family systems. Touch-sensitive push button forcalling indoor handsets and direct conversation.Double verified intercom calls. Surface mounted device.Protection index : IP54 ENTRANCE PANEL CATALOGUE 322030 322031 322032 322033 322011 322020 322020 322030 322031 322032 322033 D45 SYSTEM

73 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE INTERNAL UNIT CATALOGUE 322050 321070 321071 321060 Item HANDSFREE COLOUR INTERNAL UNITS 322050 Handsfree slim colour internal unit with alarm function, with 7 “ TFT LED backlit screen (16/9 format). Equipped for standard VDE functions plus INTERCOM with other internal units,direct call to the switchboard, SOS push button and possibility of direct connection with alarm sensors. 12 different ringtones (available).Wall mounted device. 321060 Handsfree colour internal unit with 3.5 “ TFT LED backlit screen . Equipped for standard VDE functions plus direct call to the switchboard and entrance panel camera activation. 12 different ringtones (available).Wall mounted device. 321070 D45 System 7” touchscreen video internal unit. Complete door entry functions with alarm managements. International standard SOS push button, intercom function, programming device touchscreen functions. Digital photo frame and camera functions.Direct call to switchboard function. 6 different default selectable ringtones (can be changed with your favourite music). Slot for SD CARD. Surge protection. Wall mount installation. 321071 D45 System 10” touchscreen video internal unit. Complete door entry functions with alarm managements. International standard SOS push button, intercom function, programming device touchscreen functions. Digital photo frame and camera functions.Direct call to switchboard function. 6 different default selectable ringtones (can be changed with your favourite music). Slot for SD CARD. Surge protection. Wall mount installation. Item BLACK & WHITE INTERNAL UNIT 321020 Handsfree B/W internal unit with alarm function, with 3.5 “ CRT screen . Equipped for standard VDE functions plus INTERCOM with other internal units, direct call to the switchboard, SOS push button and possibility of direct connection with alarm sensors. 12 different ringtones (available).Wall mounted device. AUDIO HANDSET INTERNAL UNIT 322040 Handset audio internal unit ,equipped for standard DES functions plus INTERCOM with other internal unit and direct call to the switchboard. Possibility to connect an external SOS call switch. Wall mounted device. SWITCHBOARD 323001 Table-top switchboard unit with high resolution 7” LCD display with graphic icons.Able to communicate with internal units, entrance panels and other devices. Manages incoming calls and alarms. Possibility to save up to 1000 calls and alarms and to directly connect an external COAX camera. Equipped with 12 shortcut push buttons for direct access of calls and services. 321060 321020 322040 40 32204 321020 322050 321070 D45

74 SYSTEM ACCESSORIES CATALOGUE 323002 323003 323005 Item SYSTEM ACCESSORIES 323002 Floor shunt Used to convert video signals on the BUS to transfer mode and then distribute them to the connected internal units. To be installed between floors. Each floor shunt can be connected to 4 internal units. DIN rail installation 323003 Riser shunt Used to connect the riser BUS and system BUS in order to obtain BUS separation, transfer signals and switch between video and audio channels. The video transferdistance can be increased by setting the gain adjustment dip switch. DIN rail installation. 323004 Entrance panel video mixer Can mix signals coming from 5 entrance panels. The video transfer distance can be adjusted by setting the gain adjustment dip switch. DIN rail installation. 323005 Power supply System power supply unit able to supply power on the data communication cable and simultaneously provide impedance matching for the audio channel. Protected against short circuits: in case of DC output short circuit, the device will switch to protected mode. Once the problem has been resolved, it will return to normal status automatically. Can also be set up to operate as an auxiliary power supply. Wall mounted installation. 323007 2-way video splitter Splits the BUS signal into two channels where the video signal can only be transferred from input to output. Provides compensation to the two channels separately and adapts the video signal output from the entrance panel for different distances via settings. Mainly used in riser systems to divide the riser BUS into several channels to adapt the cabling. DIN rail installation. 323008 Basic apartment interface Must be used in apartments with 2 or 3 internal units. To be installed between the floor shun (323002) and the internal units. DIN rail installation. Item SYSTEM ACCESSORIES 323009 Apartment interface Used to expand the number of internal units andadd a small entrance panel. Each device can connect 5 internal units and 1 entrance panel, providing the intercom function and call or monitor function of the entrance panel. DIN rail installation. 323010 Auxiliary power supply Auxiliary power supply protected against short circuits: in case of DC output short circuit, the device will switch to protected mode. Once the problem has been resolved, it will return to normal status automatically. Wall mount installation. 323011 D45/IP interface IP interface which can be connected to the D45 SYSTEM and BTicino 2 wire/IP System in order to create mixed installations. DIN rail installation. 323012 IP management switchboard software The integrated IP management software can provide the communication for calls between internal units and the switchboard. 323013 District generator District hub which can be connected to 4 riser shunts (323003), one entrance panel, one switchboard and one system power supply. Enables a large network to be created. Controls and changes video channels and provides amplifying compensation for video signals. DIN rail installation. 323015 Door lock accessory Used to operate electric door locks, particularly the commonly used 12 V cathode locks. When the opening current of an anode lock is over 1 A, this device is also required to operate anode locks. Generally connected to the EP to obtain the door lock release control signal. Can open door locks by means of external manual switches. The user can select the type of electric door lock release via the jumper configuration line. DIN rail installation. 323016 House shunt Can distribute video, audio and data signals from the BUS to the floor shunt (323002) connected to it, so that the signals from the BUS unit can reach the maximum distance of 200 metres, to meet specific domestic requirements. Should be installed in the low voltage subscriber unit in the house. DIN rail installation. 323009 D45 SYSTEM

75 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Item SYSTEM ACCESSORIES 323017 Lift control interface Integrate the D45 system with the elevator system. Possibility to manage the elevator directly from the internal unit 323018 EP/Switchboard shunt Used to connect the entrance panel and the switchboard to the system. The device automatically switches over the video channels. DIN rail installation. 323019 System expansion interface Extend the riser system when the number of internal units installed on the riser exceeds the limit of 400. The interface can increase this limit to 800 handsets. Also used to adjust the video gains and improve video transmission quality. DIN rail installation. 323020 Configuration tool Configuration kit consisting of:- SF2 configuration software- Tool interface- Serial extension cable- Flat cable 323023 Small entrance panel video mixer Interface for the installation of several small entrance panels for each internal unit or for each apartment. The accessory permits to install 4 small entrance panels. By using more than one accessory in series, it’s possible to install more than 4 entrance panels. 346858 D45 to BTicino 2 wire interface Switch-over interface that makes it possible to install theBTicino 2 wire door entry system inside the apartment. DIN rail installation. Item SYSTEM ACCESSORIES 3501K Configurator kit consisting of: - 10 of each type of configurator (from 0 to 9)- 2 green removable clamp connectors- 1 configurator insertion clamp- 1 plastic screwdriver 3501/0 Configurator 0 (pack of 10) 3501/1 Configurator 1 (pack of 10) 3501/2 Configurator 2 (pack of 10) 3501/3 Configurator 3 (pack of 10) 3501/4 Configurator 4 (pack of 10) 3501/5 Configurator 5 (pack of 10) 3501/6 Configurator 6 (pack of 10) 3501/7 Configurator 7 (pack of 10) 3501/8 Configurator 8 (pack of 10) 3501/9 Configurator 9 (pack of 10) 346858 346858 323012 323016 323013 323023 D45

76 CAT5 connection Apartment 4 Apartment 4 Apartment 3 Apartment 3 Apartment 2 Apartment 2 Apartment 1 Apartment 1 FLOOR 1 FLOOR 2 TO FLOOR N FLOOR N SHUNT 1ST FLOOR SHUNT Building entrance panel WIRING DIAGRAM Example of basic solution for multi-storey buildings SystemPowersupply D45 SYSTEM

77 WWW.BTICINO.COM VIDEO DOOR ENTRY SYSTEM CATALOGUE Switchboard Additional camera Entrance panel switchboard shunt CAT5 connection Building complex entrance panel Riser shunt 1 Riser shunt 2 Riser shunt n... Building 1entrance panel Building 2entrance panel Building n...entrancepanel BACKBONE RISER XX FLOOR 1 FLOOR 1 FLOOR 2 FLOOR 2 RISER 2 RISER 1 COAX Powersupply Powersupply Powersupply Powersupply Example of a building complex solution with 1 switchboard D45

78 SYSTEM TO SYSTEM INTERFACES The 2 WIRE/2 WIRE IP and D45 systems can be integrated together, for the creation of speciﬁc systems, where the potentials of Suitable for D45 SYSTEM installations where MyHOME home automation system applications are required. It allows to install the 2 wire VDE system inside the apartment. IP and 2 WIRE technologies can be integrated for the realisation of large projects with an high number of devices. Thanks to the dedicated LAN network, IP technology D45 and IP technologies can be integrated for the realisation of very large protects with very long distances and a high number of CAT5 INSTALLATION INSTALLATION FROM FROM D45 D45 D45 TO 2 WIRE SYSTEM INTERFACE (346858) 2 WIRE TO IP SYSTEM INTERFACE (346890) D45 TO IP SYSTEM INTERFACE (323011) 2 WIRE SYSTEM INSIDE THE APARTMENT My HOME AUTOMATION APPLICATIONS INSIDE THE APARTMENT 2 the individual systems within the main installation must be available. System integration is ensured by the use of speciﬁc interfaces as listed below: INSTALLATION FROM IP BACKBONE IP BACKBONE HUB SWITCH R IS E R R IS E R I 2 2 2 offers high system performances: long distances, multichannel operation,switchboard software and centralised alarm notiﬁcation. It allows creation of an IP backbone with several 2 WIRE risers. This integration provides higher system performance. devices. This allows the creation of one or more HUBS in order to simplify installation management. CAT5 NOTE: no distance limits NOTE: no distance limits

79 WWW.BTICINO.COM CATALOGUE WWW.BTICINO.COM software Pre-sale YouDiagram is the Legrand group pre-sale software for the design and configuration of 2 WIRE and D45 VIDEO DOOR ENTRY systems. Intended for professionals to use at the design and costing stages for the installation, design and selection of the devices, as well as for configuration and validation of the system current absorption. The YouDiagram software can be free downloaded from the website www.bticino.com YouDiagram Software EXAMPLES OF YOUDIAGRAM SOFTWARE SCREENSHOTS VIDEO DOOR ENTRY SYSTEM
