Slave device high-bay storages 360° SM white IP54 30m 1Channel

Slave device high-bay storages 360° SM white IP54 30m 1Channel

Slave device for high-bay applications, For extending the detection area of a Master device, Trigger pulse to master device upon detected movement independent of the ambient light level, Compatible with 230 V devices. Concerning exceptions please see the respective master device., There are markings to ensure correct alignment during installation, When used in high-bay warehouses, care should be taken that, in the cross-aisles of the warehouse, detectors are installed that can detect movement only in the desired aisle locations, by using blinds or other technical arrangements.

Product identifiers

SKU: 92265
EAN: 4007529922659
GTIN: 4007529922659
MPN: PD4-S-GH-SM

Specifications

Depth -
Model Movement sensor
Width -
Colour White
Height 76.0
Diameter 101.0
Material Plastic
Frequency 50 - 60
Diameter 2 -
Animal zone no
Sensor type Passive infrared
Transparent no
Halogen free yes
Built-in depth -
Surface height 38.0
Built-in length -
Control current 1
Max. duty cycle -
Nominal voltage 110.0 - 240.0
Material quality Other
Remote operation no
Switch-off delay 0
Built-in diameter -
Surface finishing Matt
Switching-on delay 0
Max. reach sideways 15
Suitable for C-load no
With alarm function no
Max. reach frontally 30
RAL-number (similar) 9010
Background monitoring no
Min. starting current -
Constant light control -
Connection cable length 0
IFTTT support available no
Anti-bacterial treatment no
Degree of protection (IP) IP54
Response value luminosity
Staircase light controller yes
Compatible with Amazon Alexa no
Suitable for ceiling mounting yes
Compatible with Google Assistant no
Suitable for wireless transmission no
Response value sensitivity adjustable -
Min. depth of built-in installation box -
